Hans Grohe MySport M 71110 7 Series Manual

ZH 用户手册/组装说明 2
EN Instructions for use / Assembly instructions 3
Lesezeichen
中文 2
English 3
MySport L
711110 07
MySport M
71110XX7
Ecos
14080007
Ecos L
14081007
Logis E 100
711610 07
Logis E 70
71160007

2
中文
安装 (参见第页4)
安全技巧
装配时为避免挤压和切割受伤,必须戴上手套.
本产品只允许作为洗浴,卫生和洁身之用.
冷热水管间过大的压力差必须予以平衡.
安装提示
• 安装前必须检查产品是否受到运输损害.安装后
将不认可运输损害或表面损伤.
• 管道和阀门必须根据通用标准进行安装,冲洗和
检查.
• 请遵守当地国家现行的安装规定.
• 只能按规定使用溢流阀.禁止将半露柱及其他部
件固定到溢流阀上.
技术参数
工作压强: 最大1MPa
推荐工作压强:0,1-0,5MPa
测试压强:1,6MPa
(1MPa=10bar=147PSI)
热水温度: 最大60°C
热力消毒:70°C/4分钟
该产品专为饮用水设计!
符号说明
请勿使用含有乙酸的硅胶!
调节 (参见第页7)
热水温度调节.如果使用即热式喷头,则不建议安
装热水阀门.
大小 (参见第页8)
流量示意图 (参见第页9)
备用零件 (参见第页10)
XX=颜色代码
00=镀铬
67=MattBlack
70=MattWhite
选装附件 (不在供货范围内)
• 专用工具#58085000(参见第页5)
• 水管胶泥(参见第页5)
• 垫圈#98996000(参见第页4)
清洗 (参见第页14)
操作 (参见第页13)
汉斯格雅建议,清晨或在水流长时间停滞后,前半
升水不作饮用水使用.

3
English
Assembly (see page 4)
Safety Notes
Gloves should be worn during installation to prevent
crushing and cutting injuries.
The product may only be used for bathing, hygienic
and body cleaning purposes.
The hot and cold supplies must be of equal pressures.
Installation Instructions
• Prior to installation, inspect the product for transport
damages. After it has been installed, no transport or
surface damage will be honoured.
• The pipes and the fixture must be installed, flushed
and tested as per the applicable standards.
• The plumbing codes applicable in the respective
countries must be observed.
• The drain valve must only be used as intended. It is
not allowed to attach other objects to the drain valve,
for example a semi-pedestal.
Technical Data
Operating pressure: max. 1 MPa
Recommended operating pressure: 0,1 - 0,5 MPa
Test pressure: 1,6 MPa
(1 MPa = 10 bar = 147 PSI)
Hot water temperature: max. 60°C
Thermal disinfection: 70°C / 4 min
The product is exclusively designed for drinking water!
Symbol description
Do not use silicone containing acetic acid!
Adjustment (see page 7)
To adjust the hot water limiter. Using a hot water limiter in
combination with a continuous flow water heater is not
recommended.
Dimensions (see page 8)
Flow diagram (see page 9)
Spare parts (see page 10)
XX = Colors
00 = Chrome Plated
67 = Matt Black
70 = Matt White
Special accessories (order as an extra)
• special tool #58085000 (see page 5)
• Installation putty (see page 5)
• seal #98996000 (see page 4)
Cleaning (see page 14)
Operation (see page 13)
Hansgrohe recommends not to use as drinking water the
first half liter of water drawn in the morning or after a
prolonged period of non-use.

4
4
3
2
(7 Nm)
SW 11 mm
> 4 mm
< 4 mm
1
1. 2.
98996000
MySport M 71110XX7 / MySport L 7 11110 07
Montage

5
SW 9 mm SW 23 mm
(4 Nm)
558085000
(max.
7 Nm)
Armaturenfett
Grease
䀵䅠㽈
6
58085000
(max.
7 Nm)
Armaturenfett
Grease
䀵䅠㽈
9
11 9
7 8
10
11
Putty

6
11 12
14
15
13
SW 22 mm > 2 min
SW 22 mm
(2 Nm)
(50 Ncm)
Montage

60 °C 10 °C 0,3 MPa
7
Justierung
+
+
21 3
4 5
6 7
4.
3.
1.
2.
3.
1.
2.
6 x
36°C
38°C
43°C
50°C
55°C
60°C
17 x
SW 4 mm
SW 4 mm
(5 Nm)
SW 4 mm
SW 4 mm

8
MySport L
711110 0 7
MySport M
71110XX7
107
67
47
3 9
°
137
158
max. 30
398
G1/2
Ø34
93
108
3 3
°
47
153
182
max. 30
383
G1/2
Ø34
min. 38
55 max. 54
61Ø
193
Ø G 1 ¼
min. 38
55 max. 54
61Ø
193
Ø G 1 ¼
92168007
92168007
148
133
max. 30
Ø34
390
G 1
/
2
max. 30
Ø34
370
G 1/2
Ecos
14080007
Ecos L
14081007
94139007
Logis E 70
71160007
Logis E 100
711610 07
184
145
20°
Ø32
max. 30
390
G 1/2
164
203
Ø32
max. 30
380
G1/2
Maße

9
MySport M 71110XX7
MySport L 711110 07
Ecos 14080007
Ecos L 14081007
Logis E 70 71160007
Logis E 100 711610 07
bar
4,5
0,0
0,5
1,0
1,5
2,0
2,5
3,0
3,5
4,0
5,0
0,45
0,00
0,05
0,10
0,15
0,20
0,25
0,30
0,35
0,40
0,50
5,50,55
6,00,60
036912 15 18 21 24 27 30
MPa
00,1 0,2 0,3 0,4 0,5
Q = l/min
Q = l/sec
Durchflussdiagramm

10
MySport M 71110XX7
MySport L 711110 07
96338000
(71110007
711107 0 7
711110 07 )
96338610
(71110677)
97406XX0
95008000
92730000
98193000
(32x2)
98186000
(30x2)
92604000
(35x2)
98750000
96657XX0
97736000
98722000
97443000
(450 mm)
96016000
SW 11 mm
97209000
(M37x1,5)
SW 30 mm
13185000
(M24x1 - 5 l/min)
SW 22 mm
95140000
(M4x20)
SW 4 mm
92374XX0
94139XX7
Serviceteile

11
92168007
97443000
(450 mm)
96016000
97209000
95140000
96657000
92604000
(35x2)
92372000
(M24x1 - 5 l/min)
SW 22 mm
98193000
(32x2)
97736000
98069000
(34x3)
98186000
(30x2)
98750000
Ecos 14080007
Ecos L 14081007
97406000
95518000
96338000
95008000
92730000
Serviceteile

12
97406000
92730000
96016000
93024000
96338000
97209000
96657000
92604000
(35x2)
95140000
95008000
98193000
(32x2)
98750000
98186000
(30x2)
97736000
98069000
(34x3)
Logis E 70 71160007
Logis E 100 711610 07
97443000
(450 mm)
92168007
92372000
(M24x1 - 5 l/min)
SW 22 mm
Serviceteile

13
关 / close开 / open
热 / hot 冷 / cold
Bedienung

14
, , , , ,
,
.
,
.
, :
•
.
• , ,
,
.
• .
• .
• ,
, .
• .
• ,
.
• .
• ,
. ,
.
• ,
( ).
• , .
, , , , , ,
.
: .
,
.
.

.
Hansgrohe , .
, Hansgrohe
.
www.hansgrohe-int.com/guarantee.
.
QuickClean
QuickClean, ,
, .
Reinigung
QUICK
CLEAN

15
English
Cleaning Recommendation for Hans-
grohe Products
T
oday, modern sanitary and kitchen tapware, showers,
accessories, washstands, tubs and radiators consist of
ve
ry different materials to comply with the needs of the
mark
et with regard to design and functionality.
To
avoid damage and reclamations, it is necessary to
consider ce
rtain criteria when cleaning.
Wi
th regard to caring for the Hans-
gro
he products, the following must in
principle be heeded
:
• Only use cleaning material which is explicitly
provided for this type of application.
• Never use cleaning materials, which contain
hydrochloric acid, formic acid, chlorine pale lye or
acetic acid, as they cause considerable damage.
• Phosphorus acidic cleaners are only conditionally
applicable.
• Mixing cleaning agents is not permitted, generally.
• Never use cleaning materials or appliances with an
abrasive effect, such as unsuitable cleaning powders,
sponge pads or micro fibre cloths.
• The instructions of the cleaning agent manufacturers
have to be followed absolutely.
• Cleaning has to be carried out with a specified
cleaner dosage, contact time, object-related and
adapted to the needs.
• The building up of calcifications has to be removed by
cleaning regulary.
• When using spray cleaners, spray the cleaning
solution onto a soft cloth or sponge, never directly
onto the Hansgrohe products, as the atomised spray
could enter openings and gaps in the Hansgrohe
products and cause damage.
• After cleaning rinse thoroughly with clean water to
remove any cleaner residue.
• The use of steam cleaners is not permitted. The high
temperatures can damage the products.
Important
R
esidues of toiletries such as liquid soaps, shampoos and
shower gels, hair dyes, perfumes, aftershave and nail
varnish can also cause damage.
Here too: Carefully rinse with water after use to remove
residues.
Likewise, do not store any cleaning agents or chemicals
under the products, for example in a vanity unit, as the
vapours may damage the products.
The damage of already damaged surfaces will
deteriorate under the effect of the cleansers.
Components with damaged surfaces
must be exchanged, otherwise t
here
could be an injury danger.
Damage caused by improper treatment will not be
covered by our guarantee.
Warranty
Hansgrohe guarantees to the consumer that this product
is free of production faults. If evertheless any defect is
detected within 5 years from date of purchase, Hans-
grohe will remedy this defect free of charge. Y
ou will find
the conditions and details of this guarantee at
www.hansgrohe-int.com/guarantee. Please contact your
contracting party to claim your rights under this
guar
antee. This guarantee does not affect the customer‘s
rights under the respective national legislation.
QuickClean
The QuickClean cleaning function only needs a small
manual rub over to remove the lime scale from the spray
channels.
Reinigung
QUICK
CLEAN

Hansgrohe · Auestraße 5 - 9 · D-77761 Schiltach · Telefon [phone] · Telefax +49 (0) 7836/511440
E-Mail: [email protected] · Internet: www.hansgrohe.com
09/2022 9.04580.06
