Happy Beds Soho 4 Drawer 5FT Fabric Bed User manual

Title of Product
Assembly Instructions
www.happybeds.co.uk
Important before assembly:
.
Health & Safety:
.
Read these instructions carefully before assembling or using the product.
Please check the contents of the boxes before attempting to assemble this product. The instructions will
have a checklist of parts and fittings.
It would be sensible to lay a rug or a carpet on the floor where you intend to assemble the product, to avoid
scratches and damaging the product or the floor.
Assemble the product as close to its intended final location/room as possible.
Do NOT use any power tools as this may damage the frame.
This product or some parts of this product will be heavy. Please use an assistant when lifting.
Please keep small parts out of reach of children.
Always use on a level, even surface.
DO NOT jump on the product or any of its parts.
DO NOT use this product if any parts are missing, damaged or worn.
DO NOT use this product unless all fixings are secured.
Please keep these instructions for future reference.
Soho 4 Drawer 5FT Fabric Bed

@
This product or some parts of this product will be heavy. Please use an assistant
when lifting.
Never drag or push the pieces across a hard or stone floor as this will cause
damage to the joints. Use a carpet or a rug for extra care.
If you have problems assembling or have damaged or missing pieces, please
contact us by visiting:
https://www.happybeds.co.uk/customer-service
(Not metal)
These tools are not
necessary, but may
help to assemble
certain parts of the
product.
Do NOT use any power
tools as this may
damage the frame.

Important Information
Please be aware that there may be a light smell emitting from the product once you have opened the
boxes and begun to assemble the bed. This smell will subside within 6-8 weeks. We recommend
keeping windows open and fresh air circulating wherever possible.
Please take the time to carefully read through all of these instructions before you commence building
this bed.
Keep these instructions for future reference.
Make sure to unpack, inspect and check all contents to ensure you have received every component.
WARNING - Small components or parts could choke a child if swallowed.
We strongly recommend that you keep children away from the work area.
We recommend laying a sheet or blanket on the floor where you intend to work to avoid scratching
this product and protect your floor.
This product is heavy. Take extreme care when lifting and use two people to avoid personal injury or
damage to the product.
Assemble the product close to its intended final position in your room, so you do not need to move it
too much.
Keep any sharp objects away from the bed frame.
Please dispose of all packing safely.
HANDY HINT: If you keep the hardware in a bowl during assembly, you will be less likely to lose them
HEALTH AND SAFETY
DO NOT: jump on this bed frame.
DO NOT: use this bed frame if any part is missing, damaged or worn.
DO NOT: use this bed frame unless all fixings are secured.
DO NOT: push this bed frame as this will damage the legs.
WARNING: If placing this bed on a non-carpeted floor, you must place some protection under all legs
to stop the bed frame from moving. If you do not adhere to this, then there is no guarantee if the bed
frames collapse.
CAUTION
DO NOT: stand inside the draw area.
DO NOT: overload the internal storage draw.
Page 2 of 9

Page 1 of 7
4FT6
SOHO 4 DRAWER BED
Page 1 of 7
SOHO 4 DRAWER BED
1680mm
2310mm
370mm
1830mm
2410mm
370mm
1180mm
1180mm
1.Headboard(x1)
2.Footboard(x1)
3.Siderail(x2)4.Centre Rail(x1)5.Legs(4)
6.Slats(x32)7.Support Legs(x2) 8.Drawer Front Panel(x4)
PARTS
Carton 1
Carton 2
Carton 3
Page 3 of 9

Page 1 of 7
4FT6
SOHO 4 DRAWER BED
Page 1 of 7
SOHO 4 DRAWER BED
1680mm
2310mm
370mm
1830mm
2410mm
370mm
1180mm
1180mm
1.Headboard(x1)
Box 1
Box 1
Box 2
2.Footboard(x1)
3.Siderail(x2)4.Centre Rail(x1)5.Legs(4)
6.Slats(x32)7.Support Legs(x2) 8.Drawer Front Panel(x4)
Box 3
Page 3 of 7
PARTS
Page 2 of 7
1.Headboard(x1)
Box 1
Box 1
Box 2
2.Footboard(x1)
3.Siderail(x2)4.Centre Rail(x1)5.Legs(4)
6.Slats(x28)7.Support Legs(x2) 8.Drawer Front Panel(x4)
Box 3
Page 3 of 7
All fitting are stored within Box 3
A.M 6x30mm JCBC
(x20)
B.M8x30mm JCBC
(x8)
C.M8 Flat Washer
(x8)
D.M4*30mm CSK
(x100)
E.Allen Key 65mm
（x1) F.End Slat Cap (x32)
G.Middle Slat Cap (x16) H.White Nail Leg(x20)
9.Drawer Back Panel
(x4)
11.Drawer Side Panel
(x4)
10.Drawer Side Panel
(x4)
12.Drawer Botton Panel
(x4) 13.Drawer Support
(x8) 14.Drawer Holder Side
Panel (x2)
15.Drawer Divider 1（X2） 16.Drawer Divider 1（X2） 17.Drawer Frame
Cross Bar (x2)
PARTS
HARDWARE
All fitting are stored within Box 3
A.M 6x30mm JCBC
(x20)
B.M8x30mm JCBC
(x8)
C.M8 Flat Washer
(x8)
D.M4*30mm CSK
(x100)
E.Allen Key 65mm
（x1) F.End Slat Cap (x28)
G.Middle Slat Cap (x14) H.White Nail Leg(x20)
9.Drawer Back Panel
(x4)
11.Drawer Side Panel
(x4)
10.Drawer Side Panel
(x4)
12.Drawer Botton Panel
(x4) 13.Drawer Support
(x8) 14.Drawer Holder Side
Panel (x2)
15.Drawer Divider 1（X2） 16.Drawer Divider 1（X2） 17.Drawer Frame
Cross Bar (x2)
Box 4
Hardware
Page 4 of 7
PARTS
HARDWARE
Carton 4
Page 4 of 9

Page 1 of 7
4FT6
SOHO 4 DRAWER BED
Page 1 of 7
SOHO 4 DRAWER BED
1680mm
2310mm
370mm
1830mm
2410mm
370mm
1180mm
1180mm
1.Headboard(x1)
Box 1
Box 1
Box 2
2.Footboard(x1)
3.Siderail(x2)4.Centre Rail(x1)5.Legs(4)
6.Slats(x32)7.Support Legs(x2) 8.Drawer Front Panel(x4)
Box 3
Page 3 of 7
PARTS
Page 2 of 7
1.Headboard(x1)
Box 1
Box 1
Box 2
2.Footboard(x1)
3.Siderail(x2)4.Centre Rail(x1)5.Legs(4)
6.Slats(x28)7.Support Legs(x2) 8.Drawer Front Panel(x4)
Box 3
Page 3 of 7
All fitting are stored within Box 3
A.M 6x30mm JCBC
(x20)
B.M8x30mm JCBC
(x8)
C.M8 Flat Washer
(x8)
D.M4*30mm CSK
(x100)
E.Allen Key 65mm
（x1) F.End Slat Cap (x32)
G.Middle Slat Cap (x16) H.White Nail Leg(x20)
9.Drawer Back Panel
(x4)
11.Drawer Side Panel
(x4)
10.Drawer Side Panel
(x4)
12.Drawer Botton Panel
(x4) 13.Drawer Support
(x8) 14.Drawer Holder Side
Panel (x2)
15.Drawer Divider 1（X2） 16.Drawer Divider 1（X2） 17.Drawer Frame
Cross Bar (x2)
Box 4
Hardware
Page 4 of 7
PARTS
HARDWARE
All fitting are stored within Box 3
A.M 6x30mm JCBC
(x20)
B.M8x30mm JCBC
(x8)
C.M8 Flat Washer
(x8)
D.M4*30mm CSK
(x100)
E.Allen Key 65mm
（x1) F.End Slat Cap (x28)
G.Middle Slat Cap (x14) H.White Nail Leg(x20)
9.Drawer Back Panel
(x4)
11.Drawer Side Panel
(x4)
10.Drawer Side Panel
(x4)
12.Drawer Botton Panel
(x4) 13.Drawer Support
(x8)
14.Drawer Holder Side
Panel (x2)
15.Drawer Divider 1（X2） 16.Drawer Divider 1（X2） 17.Drawer Frame
Cross Bar (x2)
Box 4
Hardware
Page 4 of 7
PARTS
HARDWARE
Step 1 Step 2
Step 4
Step 3
12
11
10
9
13
13 14
14
17
17
D
D
D8
Step 1 Step 2
Step 4
Step 3
Step 5 Step 6
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
ATTENTION:
Please keep the adjuster around 5 to 8
mm distant away from the floor.
7
7
12
11
10
9
13
13 14
14
17
17
15
16
15
16
D
D
D8
D
17
17
14
H
15 16
Page 5 of 7
x4
Bottom View
Bottom View
x4
Side View
Bottom View
x4
Assembing Draws
x4
x4
Bottom View
x4
Side View
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
D
Page 5 of 9

Step 5
Step 6
ATTENTION:
Please keep the adjuster around 5 to 8
mm distant away from the floor.
7
7
15
16
15
16
D
17
17
14
H
15 16
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
17
X 2 X 2
X 2 X 2
Page 6 of 9

Step 7
Step 8
B
C
3
1
2
3
1
3
A
A
D
D
D
D
2
1
5
5
5
5
4
1
1
2
15
Step 7
Step 8
Step 9
B
C
3
1
2
3
1
3
A
A
D
D
D
D
2
1
5
5
5
5
4
1
1
2
15
Page 6 of 7
F
G
6
Yo u r So h o 4 D ra w e r Be d n ow i s r e ad y t o u se
Step 10
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
Page 7 of 9

F
G
6
Step 9
Step 10
Page 8 of 9
Your Soho 4 Drawer Bed now is ready to use

www.happybeds.co.uk
General Care & Maintenance
Please dispose of all packaging safely.
Wipe clean with a slightly damp cloth.
Avoid the use of all household cleaners and abrasives.
Periodically check all screw & fixings to ensure they are secure.
When moving your product, carefully lift into place. Never drag or push the product across the
floor as this will cause damage to the joints. If the product is used on hard flooring, such as
wood or laminated floor, you must place some protection under the legs to stop the product
from moving. If this is not adhered to, it could result in failure to the product that will invalidate
the warranty.
For more information on cleaning and product care visit:
https://www.happybeds.co.uk/help-and-advice
We’ve tried to make this product as easy to assemble as possible. In the unlikely event that
you have problems putting it together or have damaged or missing pieces, please contact
us by visiting:
https://www.happybeds.co.uk/customer-service
Notes
