HappyJapan HCH(Puls) User manual

FCRC20-4
HCH(Puls) ,HCS2,
HCD2,HCD3
Shoe Clamp Frame
INSTRUCTION MANUAL
Program Ver. *1.60 ~
IMPORTANT SAFETY INSTRUCTIONS
Use this Manual together with Instruction Manual of embroidery machine for mounting this appliance and for
operating.
Use this appliance only for its intended use as described in this manual. Use only attachments recommended
by the manufacturer as contained in this manual.
 Keepngersawayfromallmovingparts.Specialcareisrequiredaroundthesewingmachineneedle.
Do not pull or push fabric while stitching. It causes damage.
Do not modify this appliance.
SAVE THESE INSTRUCTIONS
0

-FC -2
INDEX
BASICINFORMATIONOFSHOESCLAMPFRAME .... 1-1
ACCESSORIES.............................................................. 1-2
ADJUSTMENTOFEMBROIDERYAREA...................... 2-1
ADJUSTMENTOFUPPERARM ................................... 2-2
INSTALLINGTHEFRAME ............................................. 3-1
HOOPINGSHOES
Sideofshoes.................................................................. 4-1
Tongue............................................................................ 4-3
STARTINGTOEMBROIDER ......................................... 5-1
ETC.
EXCHANGESPONGEANDSHEET........................... 6-1
PARTSLIST ................................................................... 7-1
0_1 PB19
0-1

-FC -3
1-1
BASIC INFORMATION OF SHOE CLAMP FRAME
FRA21D0
Shoesclampframeass’y(forHCH,HCS2)
FRA21D1
Shoesclampframeass’y(forHCD2, HCD3)
Thetypesofshoeclampframearedescribedbelow.
Use correct type of shoe frame for your embroidery machine.
CAUTION: To avoid problems.
Touseshoeclampframe,select“Specialframe”fromframeselectionmenu.
Pleasenotethatthefollowingfunctionswillbecanceledat“SpecialFrame”mode.
*Frameconrmation(embroideryareaofframe)
*Autostopfunctionwhenframemovementexceedsthecarriagelimit.
1-2
ACCESSORIES
FRA21161Sponge(2pcs)
FRA21171Sheet(2pcs)
(packedwithframe)
1_1 PB19

-FC -4
2-1
ADJUSTMENT OF EMBROIDERY AREA
Pleasenotethatbasicallytheupperarmandthelowerarmshouldbeparallelatlockingposi-
tion.
Incasethethicknessofthematerialisuneven,useadjustingsetscrewandeccentricpinto
changeangleoftheupperarmtogiveholdingpressureevenly.
Lowerarm
Setscrew
Eccentricpin
Upper arm
Parallel
2-2
ADJUSTMENT OF UPPER ARM
Adjustwidthoftheupperarmtomeetsizeoftongueandembroiderydesign.
Widthofthearmshouldhaveenoughmarginsforembroideryarea.
Loosenbothsideknobnutsforadjustmentofarm.
Tightenallknobnutsafteradjustment.
0 ~ 100mm
60mm
Knob nut Knob nut
Arm Arm
2_1 PA13
Open
Close
Open
Close
RightLeft
Lever
5mm ~ 5mm ~

-FC -5
3-1
INSTALLING THE FRAME
WhenyouuseShoeclampframeorSideclampframe,pleasemakemachinesettingaccordingtoframetypese-
lected.
CAUTION: To avoid problems.
Themachineand/orframemaybedamagediftheincorrectframesettingsareused.
ON
OFF Selectedframe
1. Turnonthepowerswitch.
Indicates the selected frame.
2. Incaserequired “Specialframe”isalready
selected,pressthe andjumptooperation
no.4.
Incaseselectedframetypeisnot“Specialframe”,
press .
3. Select “Specialframe”.
4. Press .
3_1 PA13

-FC -6
3-2
INSTALLING THE FRAME
5. Press .
Iindication of frame type disappears.
Itmeansthat“Specialframe”isselected.
 WhenyouneedtochangefromSpecialframetooth-
ertypeofframe,pleasepowormachineoffandstart
again.
Withoutre-startingmachine,machinewillmovein-
correctly.
6. Press andmovethecarriagetotheposition
shown by press .
Frame Iindication disappears
HCD2, HCD3
HCH, HCS2
3_2 PA13
Machine
Machine
Carriage
Carriage

-FC -7
3-3
INSTALLING THE FRAME
7. Insertshoeclampframetobelowthexing
base of carriage by sliding on bed.
Fixknobscrewsashittingthebearing
against the carriage while pressing the shoe
clamp frame to the carriage.
HCD2, HCD3
HCH, HCS2
Carriage
Knob screw
Fixingbase
Shoes
clamp frame
Carriage
Knob screw
Fixingbase
Shoesclampframe
3_3 PA13
Pushing
against
Positioning bolt
Pushing
against
Bearing
Carriage

-FC -8
4-1
HOOPING SHOES
Side of shoes
Thefollowingisanexampletomakeembroideryonsideofsportsshoe.
Lever
1. Adjustwidthofthearmtomeetsizeofma-
terial and embroidery design.
Widthofthearmshouldhaveenoughmar-
gins for embroidery area.
Loosenbothsideknobnutsforadjustment
of arm.
Tightenallknobnutsafteradjustment.
2. Turnrightandleftlevertoopentheupper
arm.
3. Removeshoestring.
Pull tongue toward outside.
Tongue
Upper arm
Knob nut Knob nut
Arm Arm
4_1 PA13
Open
Close
Open
Close
RightLeft
5mm~ 5mm~

-FC -9
4-2
HOOPING SHOES
4. Turnrightandleftlever,thentheshoewill
belocked.
Pleasemakesurethatthematerialinsideof
embroideryareaissetat.
Pleasealsocheckthatnohardmateriallike
eyelet is located in the embroidery area.
Shoessupportshouldbeinsertedinthe
shoe.
Shoessupport
Embroideryarea
Lever
4_2 PA13

-FC -10
4-3
HOOPING SHOES
Tongue
Thefollowingisanexampletomakeembroideryontongueofsportsshoe.
Lever
Tongue
Upper arm
1. Adjustwidthoftheupperarmtomeetsize
of tongue and embroidery design.
Widthofthearmshouldhaveenoughmar-
gins for embroidery area.
Loosenbothsideknobnutsforadjustment
of arm.
Tightenallknobnutsafteradjustment.
2. Turnrightandleftlevertoopentheupper
arm.
3. Removeshoestring.
Pull tongue toward outside.
Knob nut Knob nut
Arm Arm
4_3 PA13
Open
Close
Open
Close
RightLeft
5mm~ 5mm~

-FC -11
4-4
HOOPING SHOES
4. Turnrightandleftlever,thentheshoewill
belocked.
Pleasemakesurethatthematerialinsideof
embroideryareaissetat.
Pleasealsocheckthatnohardmateriallike
eyelet is located in the embroidery area.
Shoessupportshouldbeinsertedinthe
shoe.
In case you cannot install shoes support due to
shapeoftheshoe,holdthebodyoftheshoeby
handwhilemakingembroiderytopreventthe
tongue from coming off.
Shoessupport
Embroideryarea
Lever
4_4 PA13

-FC -12
5-1
STARTING TO EMBROIDER
:Originalpoint
(Startpoint)
Embroideryarea
1. Press andmovetheframetotheoriginal
point with the .
2. Press .
Press ,andtheembroideringframemoves
for the design trace.
Youcanconrmoutlinetraceandthepositionof
the design.
Press ,andtraceisstopped.
Goontostep4ifyouwanttostartembroidering
without tracing.
3. Press after the trace is completed.
Theembroideringframehasmovedtotherst
stitch point of the pattern.
4. Press .
Theembroiderywillstart.
5. Afterembroideringyourdesigniscomplete,show
“>>End”andthemachinewillstop.
Theembroideryframereturnstotheoriginal
pointautomaticallyifthe“Autoorigin”function
hasbeenactivated.
:Originalpoint(Startpoint)
Forward only when pressing
Backwardonlywhenpressing
Youcanconrmtheoutline
and position of design.
>>End
Side of shoes Tongue
5_1 PA13
Pause button

-FC -136_1 PB19
6-1
ETC.
EXCHANGE SPONGE AND SHEET
Spongeandsheetarelocatedundertheupperarmandonthelowerarmtoholdfabricrmly.
Whenspongeorsheetarewornordamaged,pleaseexchangespongeorsheet.
1. Removethesetscrewanddisassemblethe
eccentric pin.
2. Removetheupperarm.
3. Removethespongeorsheetfromthe
upper arm or the lower arm.
4. Attachthespongetotwiththeedgeof
the upper arm as shown.
5. Attachthesheettotwiththeedgesofthe
lower arm as shown.
Cuttotaroundthecorner.
4. Inthereverseorderofdisassembling,x
theupperarm,byscrew.
Afterxtheupperframe,adjusttheupper
frameinaccordancewith“ADJUSTMENT
OFUPPERARM2-2”.
Rightside
Eccentricpin
Setscrew
Upper armSponge
Sheet Lowerarm
Sheet
Upper arm
Sponge
Lowerarm

HCH, HCS2 HCD2, HCD3
SHOES FRAME 7-1
FCPA13
16
16
10
15
13
12
7
10
4 5
26
C
11
B
6
15
14
12
3
A
25
E
ED
F
27
1
I
I
17
19
22
20
23
K
21
K
23
20 I
2
18
24
J
24
J
7
9
8

SHOES FRAME 靴枠 7-2
指図 部品番号 部品名 FCPA15 備考
Ass'y El't Parts No. Parts Names Note
1FRA21D0 Shoes frame ass'y (for HCH, HCS2) 靴枠組（HCH, HCS2用）
2FRA21D1 Shoes frame ass'y (for HCD2) 靴枠組（HCD2, HCD3用）
3FRA21F00 Lower arm (right) ass'y 下アーム（Ｒ）組
4FRA21F10 Lower arm (left) ass'y 下アーム（Ｌ）組
5FRA21171 Sheet 滑り止めシート
6FRA21F40 Fulcrum block (right) ass'y 支点ブロック（Ｒ）組
7FRA21F50 Fulcrum block (left) ass'y 支点ブロック（Ｌ）組
8FRA21F70 Upper arm (right) ass'y 上アーム（Ｒ）組
9FRA21F80 Upper arm (left) ass'y 上アーム（Ｌ）組
10 FRA21161 Sponge 滑り止めスポンジ
11 FRA21F60 Eccentric pin ass'y 偏心ピン組
12 MPZ04730 Washer 金属ワッシャ
13 FRA21F20 Cam (right) ass'y 溝カム（Ｒ）組
14 FRA21F30 Cam (left) ass'y 溝カム（Ｌ）組
15 FRA21340 Shaft シャフト
16 FRA21102 Knob nut ノブナット
17 FRA21152 Connecting plate 靴枠連結板
18 FRA21B51 Connecting plate ass'y 靴枠連結板組
19 FRA21200 Scale sticker A (250mm) メモリテープA
20 HCB40041 Screw ベアリング止めネジ
21 HCB40121 Arm 連結アーム
22 HCB40132 Bracket 取付け板
23 MPB00250 Bearing (L1680ZZ) ミニチュアベアリング
24 HCD37092 Knob screw ノブネジA
25 FRA21082 Shoes support (right) 靴受け（R)
26 FRA21092
Shoes support (left)
靴受け（L)
27 MPZ04260 U-nut Ｕナット M4
ASGAK04010 Flat head screw (phillips, M4x10) 十字穴付き皿小ねじ （Ｍ４×１０）
BSSAA03005 Hex socket screw (M3x5) 六角穴付き止めねじ （Ｍ３×５）
CSCAD04010 Hex socket head cap screw (M4x10) 六角穴付きボルト （Ｍ４×１０）
DNHAD04000 Hex nut (M4) 六角ナット （Ｍ４）
EWPAD04000 Plain washer (M4) 平座金 （Ｍ４）
FWSAD04000 Spring lock washer (M4) ばね座金 （Ｍ４）
ISBAK04008 Bind head screw (phillips, M4x8) 十穴付きバインド小ねじ （Ｍ４×８）
JSCAD04006 Hex socket head cap screw (M4x6) 六角穴付きボルト （Ｍ４×６）
KWPAD05000 Plain washer (M5)
平座金 （Ｍ５）
