ASSEMBLY INSTRUCTIONS
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web site at http://www.harborfreight.com
Copyright © 2003 by Harbor Freight Tools®. All rights reserved. No portion of this manual
or any artwork contained herein may be reproduced in any shape or form without the
express written consent of Harbor Freight Tools.
For technical questions please call 1-800-444-3353
GREENHOUSE
PORTABLE DOME
®
Model 04325
Brought to You by Augusta Flint

SKU 04325 PAGE 2
SPECIFICATIONS
SAVE THIS MANUAL
You will need the manual for the safety warnings and precautions, assembly
instructions, operating and maintenance procedures, parts list and diagram. Keep
your invoice with this manual. Write the invoice number on the inside of the front
cover. Keep the manual and invoice in a safe and dry place for future reference.
SAFETY WARNINGS AND PRECAUTIONS
1. AVOID SHARP EDGES WHEN ASSEMBLING.
2. KEEP PRODUCT USAGE AREA CLEAN. Greenhouse can be hosed off when
cleaning.
3. ALWAYS CHECK HARDWARE AND ASSEMBLED PARTS AFTER ASSEMBLING.
Place in an area that is flat and leveled. All connections should be tight and hardware
tightened.
4. CHECK FOR DAMAGED PARTS. Before using this product, carefully check that it
will operate properly and perform its intended function. Check for damaged parts and
any other conditions that may affect its operation. Replace or repair damaged or worn
parts immediately.
5. REPLACEMENT PARTS AND ACCESSORIES. When servicing, use only identical
replacement parts.
6. USE EXTREME CAUTION when moving assembled Greenhouse. Do not lift the
Greenhouse Dome without assistance. Caution against pinching of fingers. Could also
cause damage to plants if dragged. You may wish to disassemble and reassemble in the
new location.
7. DO NOT ALLOW CHILDREN TO PLAY IN, STAND UPON OR CLIMB UPON
THE GREENHOUSE. Do not place anything on top of Greenhouse Dome. This is a
delicate assembly.
8. AVOID HARSH WEATHER CONDITIONS. Could topple in strong winds. Creatively anchor
with rocks or sandbags along “Skirt Flap”. Disassemble if weather conditions could damage
Greenhouse Dome.
DESCRIPTION
64-3/4"L X 47-1/4"W X 77-1/4"H
23/32" Tubular Steel, Polypropylene Cover (Green)
63"L X 12-5/8"W X 23/32"H
75 Lbs.
ITEM
Overall Dimensions
Construction
Shelf Dimensions
Net Weight
Brought to You by Augusta Flint

SKU 04325 PAGE 3
ASSEMBLY INSTRUCTIONS
1. The Greenhouse Dome allows you to make the most of a year round growing season. The
Greenhouse provides six shelves, a zippered doorway for entering and closing and
convenience for watering and plant maintenance. Each of the Tubular Steel parts
(#1 thorough #7) have numbered stickers applied to help you assemble the Greenhouse
Dome. See Figure A.
2. Construct on a flat, level surface. Start with two Leg Parts ( #1) and Roof Pipes (#3 & #4)
forming an arch. Repeat for the second arch. Construct the two smaller arches with two Leg
Pipes (#2) and Side Pipe (#7).
3. Attach the bottom Shelves (#6) to the Leg Pipes (#1 & #2), both right and left, using the
Support Pipes (#5). Lock into position with Bolts (#8). Finger tighten the Bolts. With an
assistant, attach the center and upper Shelves and stand constructed frame upright.
Tighten all hardware. See Figure B.
4. Unfold the transparent Polypropylene Cover. Fit over the frame with the “Zippered Door” at one
end of the Dome. See Figure C & D.
Numbers on
Stickers
Figure A
Figure B
Figure D
Figure C
5. Inside the Greenhouse Dome, secure the Poly transparent Cover in place by tying interior
Cords to the Tubes. See Figure E & F.
Figure E Figure F
6. The Greenhouse Door can be rolled-up and snapped out of the
way for easy access to the interior of the Greenhouse Dome.
Unroll the “door” and zipper it closed when not using to enter
and exit. This will insure an even temperature inside the
Greenhouse and help keep the humidity inside for better plant
growth. See Figure G. Figure G
Cord
Brought to You by Augusta Flint

SKU 04325 Page 4
MAINTENANCE
1. For better and safer performance, keep all parts of this product clean and dry.
2. Periodically check to see that all hardware is in place.
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS DIAGRAM IN THIS MANUAL AS A REFERENCE
TOOL ONLY. NEITHER THE MANUFACTURER NOR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY
KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT OR THAT HE OR SHE IS
QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EX-
PRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND LI-
CENSED TECHNICIANS AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS
OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER
INSTALLATION OF REPLACEMENT PARTS THERETO.
PARTS LIST
PART # DESCRIPTION DRAWING QTY
1 Leg Pipe 4
2 Leg Pipe 4
3 Roof Pipe 2
4 Roof Pipe 2
5 Support Pipe 14
6 Shelf 6
7 Side Pipe 2
8 Bolt 28
