INSTALLATION INSTRUCTIONS
Billet Footpegs for 18-20 STACYC® eDRIVE.
Made for Enthusiasts by Enthusiasts!
Part No. NSP-HL-18-20
Fits STACYC® 18-20 eDRIVE.

,
Page 1
Danger
When Using Billet Footpegs...
DO NOT ride without adult supervision.
DO NOT ride bare-footed.
DO NOT ride without proper safety equipment. (Always wear helmet,
pants, shirt, gloves, and boots.)
DO NOT hit or run into objects with Billet Footpegs, this may cause
damage or injury to the rider and the bike.
DO NOT ride more than one person at a time.
DO NOT modify the Billet Footpegs.
Use soft soap and water to clean footpegs. Rinse thourghly.
.
.
.
FAILURE TO USE THIS APPARATUS CORRECTLY CAN
RESULT IN SERIOUS INJURY OR DEATH. ONLY USE
BILLET FOOTPEGS FOR ITS INTENDED PURPOSE.
DISCONTINUE USE IF ANY PART IS BENT, BROKEN OR MISSING
INSPECT BEFORE AND AFTER EVERY USE.
KEEP FEET ON FOOTPEGS AT ALL TIMES TO AVOID RUNNING OVER
YOUR FEET.
DO NOT INSTALL IF YOU ARE UNSURE ABOUT INTSTALLATION
STEPSOR THE REQUIRED TOOLS OUTLINED IN THESE
INSTRUCTIONS. HAVE AN AUTHORIZED DEALER INSTALL BILLET
FOOTPEGS FOR YOU. READ ALL OF INSTRUCTIONS BEFORE
STARTING INSTALL.

Page 2
.
Bike without side covers.
.
Qty.1 Left & 1 Right Billet Peg with wedges.
Tools required: No. 2 Phillips Screwdriver, 5mm. Allen Wrench,
Hacksaw or Jig Saw, Blue Loctite®
Installing Foot Pegs Stacyc® model 18-20 edrive
Parts Included.
x2 pcs.
6x1mm Allen Bolts.
No. 2 Phillips
Screwdriver.
5mm. Allen Wrench.
Hacksaw.
Step 2. Remove side covers with #2 Phillips Screwdriver
from both sides of bike. Keep these screws you will need
them later.
Step 1. Remove battery from bike.
Side Cover

Step 3. Remove both screws from floorboard.
You will not reuse these screws.
Step 4. Lift floorboard from the rear and slide forward to remove.
Bike without floorboard and wedge plate.
Page 3
.
Step 5. Lay bike on it’s side and remove wedge plate,
pry it out with your fingers or flatblade screwdriver.
Wedge Plate.

Step 6. Place your New! Billet foot peg on the top of the floorboard flange.
Install 6mm bolt through the top hole in the footpeg. Bolt threads into
wedge on bottom side. Tapered side of the wedge goes to the outside of
the bike. Tighten with 5mm Allenwrench.
Page 4
.
Step 6 cont. This is what the bottom side should look like after assembly
with tapered wedge to the outside.

Page 5
Step 7. With diagram provided below trim floorboard with hacksaw. Save center-
piece for re-installing on bike.
Finished trimmed center piece from flooboard. Use sandpaper on sides
where cuts were made if desired to smooth finish.
Trimmed Center Piece from Floorboard

Page 6
Step 8. Put side covers back on bike. Insert all screws but do not tighten.
Leave covers loose so you can insert center piece and battery receptacle.
Warning: Be careful not to pinch wires from battery receptacle to speed controller
when installing, make sure wires are not in the way of your screws and get pinched.
Step 9. Flip bike over and rest on seat and handlebars. Insert trimmed centerpiece
and battery prong between side covers. Tighten screws on side panels.
.

If you are unhappy with this product or have suggestions
please contact us directly using the contact information below,
so we can make it right.
We want you 100% satisfied!
If you are pleased with the product, and the transaction please
review us on Amazon or our web page hardlineproducts.com
If you have a new product idea, but don’t know how to
bring it to market, Hardline Products® can help
and pay you for your idea. Call or write us!
HARDLINE PRODUCTS®, INC.
8172 SW Jack James Drive.
Stuart, FL 34997
www.hardlineproducts.com
email: [email protected]
toll free 888-413-8315
SAVE THESE INSTRUCTIONS
STACYC® and Nihilo® brands is property of their respective owner(s)
All company, product and service names used in this install guide
Use of these names, logos and brands does not imply endorsement
Step 10. Install battery and Ride. Check to make sure foot-pegs are tight before
every ride.
Scan for video of installation of Foot Pegs.
Scan for video of how to trim FloorBoard.
