Harman Kardon AVR 155 Installation and operation manual

Home Solutions
The AVR 155 is all about getting connected. It features three HDMI inputs, two wide-
bandwidth HDTV-ready component video inputs, four S-video inputs, a front-panel input
for video games, an auxiliary input for portable media players, and a portfolio of advanced
surround processing technologies, including Dolby Digital, DTS and Logic 7 processing.
But the AVR 155 is also about ease of use, with EzSet/EQ equalization for quick system
setup and color-coded inputs.
Key Specifications
• Audio Section – Continuous Average Power (FTC), (stereo mode): 50 watts per channel
into 8 ohms @ 20Hz – 20kHz, <0.07% THD, both channels driven; (fi ve-channel sur-
round mode): 40 watts per channel into 8 ohms @ 20Hz – 20kHz, <0.07% THD,
all channels driven; High Instantaneous Current capability (HCC): ±25 amps
• Tuner – Usable Sensitivity: IHF 1.3μV/13.2dBf; THD at 1kHz with 100% modulation,
(mono): 0.2%; (stereo): 0.3%; FM Adjacent Channel Selectivity: ±400kHz, 70dB;
Ultimate (maximum) S/N Ratio (measured at 1mV RF input level), (mono): 70dB;
(stereo): 68dB
• Dimensions (H x W x D) and weight: 165mm x 440mm x 382mm, 11.1kg
Depth measurement includes knobs, buttons and terminal connections, unless stated otherwise;
height measurement includes feet and chassis, unless stated otherwise.
Highlights
• Dolby Pro Logic®II processing
• Logic 7® (5.1) processing
• DTS®5.1 processing
• HDMITM switching
• EzSet/EQTM equalization
• HDTV-ready
• Component video inputs
• Triple-crossover bass manager
• High-current capability
• 192kHz/24-Bit DACs
/ AVR 155
5 x 40W 5.1-Channel A/V receiver with HDMITM switching

Harman Consumer Group, Inc.
8500 Balboa Boulevard, Northridge, CA 91329, USA
www.harmankardon.com
© 2008 Harman International Industries, Incorporated. All rights reserved. Harman Kardon and Logic 7 are trademarks of Harman International Industries, Incorporated, registered in the
United States and/or other countries. Designed to Entertain and EzSet/EQ are trademarks of Harman International Industries, Incorporated. HDMI is a trademark or registered trademark of
HDMI Licensing LLC. Dolby and Pro Logic are registered trademarks of Dolby Laboratories. DTS is a registered trademark of DTS, Inc. Cirrus Logic is a registered trademark of Cirrus Logic, Inc.
Features, specifications and appearance are subject to change without notice.
Features
Power
• 40W x 5 into 8 ohms, 20Hz – 20kHz, at <0.07% THD, with all channels driven simultaneously
• High-current (±25 amps), ultrawide-bandwidth (10Hz – 100kHz) amplifi er design
Surround Processing
• Dolby Digital surround decoding using an advanced Cirrus Logic® CS 49510 32-bit DSP processor
• Full suite of DTS modes
• DTS 5.1 (Movie, Music and Game modes) surround sound
• Harman-exclusive Logic 7 Cinema and Music surround sound processing in 5.1 channels
• Dolby Headphone and Dolby Virtual Speaker surround modes
• Five-channel Stereo, Hall and Theater surround modes
• 192kHz/24-Bit DACs
Connectivity
• Three HDMI 1.3a inputs and one HDMI output
• Two assignable, wide-bandwidth (100MHz), HDTV-ready component video inputs and one output
• Subwoofer output for direct connection to a powered subwoofer
• Four A/V inputs with S-video, plus two audio-only inputs
• Six-channel-direct inputs for use with external surround decoders
• Convenient front-panel audio/video input with S-video for use with video games or portable players
• Six digital inputs (two optical and two coaxial on rear panel, and one optical and one coaxial on front panel)
• One coaxial digital output on rear panel
• RS-232 port for fi rmware upgrades
• Auxiliary input for connecting portable media players
Ease of Use
• HDMI 1.3a switching
• A/V Sync Delay adjustable for each input
• EzSet/EQ equalization for quick and accurate system setup
• FM stereo/AM tuner with 30 presets and direct-access tuning
• Triple-crossover bass manager
• Wide range of low-frequency crossover points (40Hz, 60Hz, 80Hz, 100Hz, 120Hz and 200Hz) available
• Improved, text-based on-screen display, on Component and S-Video output
• Programmable power-up volume
• Six-device, preprogrammed system remote control
EAN Code AVR 155/230: 0282925061926
/ AVR 155
5 x 40W 5.1-Channel A/V receiver with HDMI™ switching
