Harman JBL AE Series User manual

PURPOSEFUL DESIGN DRIVECORE POWERED PREMIUM DSP
QUICK START GUIDE
ASB6118p ASB6125p
1. Open the top of the box.
2. Lay box on its side.
3. Turn box upside down, then
lift box up to reveal speaker.
OPTIONAL SETUPS
UNBOX IT

Please visit jblpro.com/AE Powered for complete documentation.
JBL Professional 8500 Balboa Blvd. Northridge, CA 91329 USA ©2017 Harman International Industries, Incorporated
PART NUMBER: 5089389-00
BACK PANEL
POWER IT ON
1. Connect the supplied power cord to the PowerCon
inlet on the rear of the speaker.
2. Connect the power cord to an available power out-
let. Once the power cord is plugged into the power
source, the Green Power LED will illuminate.
3. Once the Green Power LED illuminates, press the
Power Button. After several seconds, you will notice
the LCD Screen boot an you will now be on the main
screen.
PLUG IN THE INPUTS
1. The CH1 and CH2 Input levels and Master Level
default to 0dB. It’s a good idea to turn the inputs
down all the way before plugging in your audio source.
Turn CH1 and/or CH2 Encoders to the left until
the level reads “-80.0” on the LCD.
2. Connect XLR cable from audio sources to CH1
and/or CH2 Inputs.
3. Select LINE, CONSUMER or MIC gain setting by
pushing the correct CHANNEL ENCODER twice.
You will see a rectangle highlighting the sensitivity
setting. Simply roll the encoder left or right to
select the correct setting. Once the correct set-
ting is shown, push the encoder one more time to
make your selection.
SET THE OUTPUT LEVEL
1. Set the gain level for each input using the CH1 and/
or CH2 ENCODER. The input level meter on the
LCD will allow you to monitor your input level.
2. Once the input level is set, use the MASTER
ENCODER to turn up (Right) or turn down (Left)
the overall level until the desired volume is reached.
LCD Screen
Power LED
Power Button
CH1 Direct Out
CH1 Input
CH1 Encoder
CH2 Encoder
CH2 Input
CH2 Direct Out
Master Encoder
Back Button
Ethercon
Link LED
Data LED
Connector
PowerCon
Connectors
