Harman JBL SoundPoint SP8 Series User manual

ACOUSTIC & ELECTRICAL SPECIFICATIONS:
•Nominal Impedance 8 Ohms
•Max Amp Power 100 Watts*
•Frequency Response 30Hz – 20kHz (–10dB)
•Sensitivity 89dB (2.83V @ 1 meter)
•Crossover Frequency 2,400Hz
SYSTEM COMPONENTS:
•Grille, Gray 590-0104
•Low-Frequency Transducer 8" (203mm) Titanium-laminate
cone w/rubber surround
330-0207
DC Resistance 5.4 Ohms ±10%
•High-Frequency Transducer 1" (25mm) Titanium-laminate
dome, w/swivel mount
300-0136
•DC Resistance 7.4 Ohms ±10%
•Crossover Network 340-0230
AURAL SWEEP TEST SPECIFICATIONS:
•System Aural Sweep Test 6.0V Input 30Hz to 20kHz
•L.F. Aural Sweep Test 5.0V Input 30Hz to 3kHz
•H.F. Aural Sweep Test 2.83V Input 1kHz to 20kHz
PHYSICAL SPECIFICATIONS:
•Plate Size (W x H) 10-1/8" x 13-1/8" (257mm x 333mm)
•Mounting Cutout Size 8-7/8" x 11-13/16"
(W x H) (225mm x 300mm)
•Mounting Depth 4" (102mm)
•Weight 12 lb/5.4kg (sold in pairs)
WARRANTY:
•Refer to Warranty Statement packed with each product.
*The maximum recommended amplifier power rating will ensure
proper system headroom to allow for occasional peaks. We do not
recommend sustained operation at these maximum power levels.
Technical Manual
SP8 SoundPoint®Series
SP8 SoundPoint®Series
Harman Consumer Group, Inc., 250 Crossways Park Drive, Woodbury, New York 11797
Rev 4 6/07
Legend on Page 2
11
19
12
14
13
15
PACKAGING
YEL
BLK
GRN
BLK
+
+
+
+
LOW-FREQUENCY
TRANSDUCER
330-0207
CROSSOVER NETWORK
340-0230
HIGH-FREQUENCY
TRANSDUCER
330-0136
4uF
250V
C1
L1
0.5mH
C2
20uF
100V
L2
0.6mH
R2
7.5 ohms
10 watts
6.0 ohms
5 watts
R1
GRN .250
BLK
.205
YEL
.110
BLK
.110
L3
0.6mH
C3
25uF
100V
SP8 SCHEMATIC

GRILLE CLOTH
BACK VIEW FRONT VIEW
TWEETER
BAFFLE
DOG
CROSSOVER
WOOFER
26
16
16
1
REF
20.0mm
GREEN WIRE
CONNECTS TO
+ TERMINAL
BLACK WIRE
CONNECTS TO
– TERMINAL
2
8
3
4
5
(4)
(4)
(4)(4)
(4)
(4)
10
18
17 9
7
ITEM PART NO. DESCRIPTION QTY.
1 020-0095 BAFFLE SP8 1
2 590-0104 GRILLE HTi8/SP8 1
3 330-0207 WOOFER JBL SP8 1
4 340-0230 CROSSOVER JBL SP8 1
5 300-0136 TWEETER JBL SP8 1
6 GRILLE CLOTH not sold alone – see 590-0104 1
7 210-0205 DOG SOUNDPOINT 4
8 130-0124 SCREW #6-AB x 0.5" PHL PAN STL ZNC 4
9 130-0010 SCREW #8-AB x 0.38" PHL PAN SST 4
10 130-0111 SCREW #8-AB x 2.25" PHL FLT STL ZNC 4
ITEM PART NO. DESCRIPTION QTY.
11 220-0564 CARTON BEAUTY JBL SP8 1
12 220-0438 CARTON TEMPLATE HTi8/SP8 1
13 170-0035 OWNER’S MANUAL JBL SP8 1
14 170-0022 WARRANTY CARD JBL 1
15 170-0023 CUSTOMER SURVEY CARD JBL 1
16 180-0008 LOGO JBL 1
17 130-4003 WASHER #8 FLAT NARROW STL ZNC 4
18 130-0110 SCREW #6-AB x 0.38" PHL PAN STL ZNC 4
19 SP8 SP8 SOUNDPOINT SERIES IN-WALL SPEAKER 1
SP8 SoundPoint®Series
Technical Manual
SP8 SoundPoint®Series
EXPLODED VIEW
SP8 ROUGH-IN FRAME part no. RIF8
Harman Consumer Group, Inc., 250 Crossways Park Drive, Woodbury, New York 11797
Rev 4 6/07
