Harmony Folding Adjustable Base Installation and operating instructions

PART#532K0460 REV: 2020-12-21
Assembly and Operation
Manual
Folding
Adjustable Base

Specifications
Weight Capacity
880
lb
Wall Hugger
X
Incline Degree
Backrest
:
0°
~
65°
Legrest
:
0°
~
35°
Power Transformer Output
DC 29V 1.8A
Power Input
AC 100
–
240 50/60 HZ
Massage Vibrator
USB Charger
X
Bluetooth Control
Floor Light
Flash Light on Remote
Preset Position: ZG
and QUIET SLEEP
Memory Position
X
X
X
X
X
X

Table of Contents
Safety Precaution and Usage Guide.............................................................................................2
To decrease the risk of electronic shock...............................................................................2
Adjustable base performance. ..................................................................................................2
Restrictions of your adjustable base ......................................................................................3
Electronic system information.................................................................................................3
Parts List...............................................................................................................................................4
Electronics Overview........................................................................................................................5
Assembly Guide ..................................................................................................................................6
Operating Your Adjustable Base ..................................................................................................9
Wireless pairing operation.....................................................................................................10
.............................................................................11
Synchronization of Two Bases (Option)
Power outage or failure of remote
control........................................................................ 12
Troubleshooting
............................................................................................................................13
20
YEAR LIMITED WARRANTY
1

2
Safety Precaution and Usage Guide
Your new adjustable base has been strictly tested and inspected prior to dispatch. It is highly recommended
to read these instructions thoroughly before you try your new adjustable base, in order to keep your high-
quality adjustable base performing well in its lifetime but also to reduce the risk of fire, electric shock, burns
or any injury to users.
To decrease the risk of electronic shock, burns, or injury to users, children or
pets, please follow these instructions.
1. After unpacking your adjustable, be aware of your small children and pets. Its packing material may put
your small children or pets in smothering dangers.
2. Unplug the power cord from the power outlet before installing parts or cleaning your adjustable base.
3. Keep the power cord away from water and heated areas. If your adjustable base is wet or has a frayed
power cord, please do not operate it.
4. Do not operate your adjustable base near explosive gases or aerosol spray products are being used.
5. Before you disconnect the power cable, please return your adjustable base to the flat position and stop all
operations.
6. Unplug your electronic gadgets from the USB port (option) of your adjustable base if they are fully charged.
7. Do not use your adjustable base in outdoors. Your adjustable base is only designed for in-home use.
8. Use your adjustable base in compliance with the restrictions.
To keep your high-quality adjustable base performing well in its lifetime, please
follow these instructions.
1. Do not unscrew or open the control box, lift motors, massage vibrators (option), SMPS, wired handset or
remote control (option), and other electronic components on your adjustable base, except for opening the
battery compartment on your remote control or SMPS. The warranty will be void if there is any component
damaged by users. Only authorized service personnel are allowed to repair or replace parts.
2. Do not mix different types of batteries or old batteries with a fresh one for your handset or SMPS.
3. Remove the batteries from your remote control (option) and SMPS if your adjustable base will not be used
for a long time period to prevent damage caused by battery leakage.
4. Do not sit on the head or leg section while in the raised position. It can damage your adjustable base and lead
to shorter life expectancy.
5. Do not lift or move the base during operation. It might cause damage to your system.
6. Do not lift or move your adjustable base by grabbing its mattress platform or its wood lower frame
(option) furnished with fabric. If it is necessary to lift or move your adjustable base, please do it by
grabbing the cross bars of its metal frame.
7. Your adjustable base must be on flat ground to avoid damage to your product.
8. Use a compatible mattress for your adjustable base. A memory foam mattress or latex mattress is
recommended. Some spring mattresses or pocket spring mattresses, for example, may not suit your
adjustable base. Consult your mattress specialist to verify your mattress is compatible.
Attention: SAVE THESE PRECAUTIONS AND USAGE GUIDES

3
Restrictions of your adjustable base
1. Do not operate lift motors above the 10% duty cycle. For example, after continuous 2-minute operation 18-
minute rest is required.
2. Do not continuously or intensively operate the massage vibrators (option) above maximum 2 hours within 6
hours.
3. Weight Restrictions: the maximum weight limits on your adjustable base for Twin, Twin XL, Full and Queen
are at a maximum of 400kg/880lbs (evenly allocated across the mattress platform). This capacity includes
the mattress and occupants. The warranty of your adjustable base will be void if excessive weight of
400kg/880lbs is loaded on your adjustable base.
Electronic system information
Radio Frequency Compliance:
Radio Frequency: 2.4 MHZ.
FCC ID:
Your Device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired
operation.
Attention:
In compliance with FCC RF exposure requirements, there must be no change to the antenna or the device without
permission. Users may be deprived of his/her right to the device if the device exceeds the RF exposure
requirements caused by any change the antenna.
Power Ratings:
Input: AC100-240V 50/60Hz 1.5A
Output: DC29V 1.8A
Protection Class: Class II
O3YRF075A

Parts List
4
IMPORTANT NOTE:
Check and confirm the following items are included in the carton,
BEFORE disposing of any packing materials.
A.
B.
Remote Control * 1
AC Main Cable
* 1
E.
D.
Support Leg * 6 sets
AAA Battery
* 2
F.
H.
Mattress Retainer * 1
Cotter Pin *2
G.
I. (Option)
Clevis Pin *2
Headboard Brackets * 2
K. (Option)
J. (Option)
Hex Key * 1
Wrench * 1
L. (Option)
M. (Option)
Bolt for Headboard * 8
Nut for Headboard * 8
N. (Option)
Washer for Headboard
Sync Box* 1 (TXL only)
* 16
(Option)
I-1
I-2
C.
SMPS
* 1
(Switched
-
M
ode Power
Supply
)
O.
Side Retainer * 2

Electronics Overview
HEAD MOTOR
FOOT MOTOR
SMPS
CONTROL BOX
5

Assembly Guide
STEP 1
Leave the carton in the flat position. After opening this carton, carefully take your Adjustable Base
to the desired location and leave it topside down.
STEP 2
Firstly open your folded base.
Cut off white nylon plastic ties only to take out the accessories.
IMPORTANT NOTE:
Two people are required to set up your adjustable base.
STEP 3
Insert Clevis Pin (G)
through the Cross bars and
insert Cotter Pin (H) through the hole of Clevis Pin,
as shown in the picture. Make sure it is securely locked. Repeat it on the other side.
6

STEP 4
STEP 5
Insert two AAA Batteries (D) into the compartment of the Remote Control (A).
STEP 6
7
STEP 7
Carefully flip over your topside-down Adjustable Base. Lift up the Base to desired location.
Find Extension Cable from the Head Section of your Adjustable Base and plug it into SMPS (B).
Take out AC Main Cable (C) from accessories box and plug it into SMPS (B).
IMPORTANT NOTE:
Be Careful when flipping your Base:
The installed legs could get damaged or bent by excessive pressure, if you lean your
Adjustable Base on the legs.
1. Do not recline the Base against the installed legs to fl
ip it over.
2. Do not drag the Base across the floor.
Take out Support Legs(E) *6 and securely tighten onto your Adjustable Base and leave no gap between
them.
**If you have two or three-sectional legs, you may allow to choose the suitable height for your base.
STEP 8
Plug the AC Main Cable (C) in an electrical outlet with 100-240V, 50/60 Hz. A surge protector (not
included) is recommended for longer life of your Adjustable Base.

8
STEP 10
(Installing Headboard-Option)
STEP 9
Raise the Backrest by using Remote Control (A).
Take out the Hex Key (K),Wrench (J), 8x Bolts (L), 8x Nuts (N) and 16x Washers (M) from the accessories box.
Refer to the following picture, place the Headboard Bracket (I-1) on the tube of the right hand side of your
Adjustable Base.
Insert the Bolt (L) with the Washer (M) through the pre-drilled holes on the Bracket (I-1) and the vertical
tube
on your Adjustable Base.
Fasten the Bolt (L) with the Washer (M) and the Nut (N) by using the Wrench (J) and Hex Key (K).
The Bracket (I-2) allows adjustment to meet the dimension of user's Headboard.
After choosing desired pre-drilled holes on the Bracket (I-2), pass the Bolt (L) with the Washer (M) through
the holes on H-1 and H-2 Brackets.
Fasten these Bolts (L), Washers (M) and Nuts (N) by using the Wrench (J) and Hex Key (K).
Redo these steps on the other side of your Adjustable Base.
L
MN
M
I-1
I-2
Step 11
Now place your mattress on your Adjustable Base. All the installation procedures have been completed.
8
Take out Retainer*1 (F) and Side Retainers*2 (O). Insert the retainers into the corresponding holes on the
Retainer Bar Fixation at the bedside and the foot of your adjustable base.

9
Operating Your Adjustable Base

10
Wireless pairing operation
Step1:
Make sure the RF receiver is properly connected to the Motor.
Step2:
Press the pairing button on the RF receiver until the green LED turns on. Now you have
10 seconds for pairing process.
Step3:
Press and hold simultaneously Heads-Up and Heads-Down buttons on the Remote (A)
until the LED on the RF receiver starts blinking. The blinking confirms successful pairing.
Please repeat all the above steps if the pairing operation failed.
Important Notes:
For pairing the distance between the Remote (A) and the RF receiver
should be less than 2 meters.

11
Synchronization (OPTION)
Synchronization may be required for setting up two TXL Adjustable Bases.
Insert one cable of the Sync Box into the female end of the Head Motor and insert the RF
Receiver into the Sync Box as shown in the picture.Repeat the same action to your second
base.
Now, you can operate both of your Adjustable Bases simultaneously with either one of the
Remotes.
NOTE : Your bases will freeze in place if both Remotes are used at the same time until one
of the Remotes are released.

Power outage or failure of remote control
In the case of failure of the Remote Control, press and hold the Emergency Button on the RF receiver to
flatten your Adjustable Base. When releasing the Emergency Button, allthe movements will stop
immediately.
In the case of the power outage, insert two 9V Batteries (not provided) to the Battery Compartment
on the backside of SMPS. It can be used as the backup power.
NOTE : It's only for flatting the Base without load. Do not use the Massage Vibrator when using the
backup power.
12

13
Troubleshooting
TROUBLE
SOLUTION
There is no feature of the base that can be
activated.
Remote control illuminates
Reset the electronic components by
unplugging your base for 30 seconds. Re-
plug it into the power outlet.
Ensure the surge protection or the power
outlet is working. Test it by plugging in
another working electronic appliance.
The unworked power outlet may be led by
the tripped electrical circuit breaker.
Check the box of electrical service breaker.
Re-pair the remote control (see Wireless
pairing operation).
Remote control does not illuminate
Replace batteries in the remote control.
Install 3 AAA batteries correctly.
The base cannot return to the flat position.
Ensure the base is not obstructed. Remove
the obstruction.
Ensure there is a sufficient space between
the wall or headboard and the edge of the
mattress. The insufficient space may
obstruct the movement of the base.
Excessive noise of massage function.
Place carpet pieces or soft material
beneath each leg of the base.
If headboard is equipped ensure the
hardware of the headboard brackets are
tightened firmly.
Ensure the base stands clear of walls,
nightstands or other objects.
Minor interference with lifts functions.
Replace batteries in remote control if
necessary.
Ensure you’re operating within 10% duty
cycle (see Restrictions of your adjustable
base).
Press the adjust buttons squarely and
accurately.
Control box may be subject to the common
radio frequency from other devices.
Reprogram the remote control and the
control box on a different radio frequency
if necessary (see Wireless pairing
operation).
USB ports do not charge electronic
gadgets.
Try another well-working USB cable.
Unplug all USB cables for 10 minutes to
reset and try it again.

20 YEAR LIMITED WARRANTY
Your New Adjustable Base has a 20 Year Limited Warranty, subject to the terms and
conditions set fourth herein.
The Purchaser must show original proof of purchase for Warranty to be valid.
The decision for repair or replacement of defective parts under this limited warranty is the
option and sole discretion of the manufacturer.
Year-1: Full Coverage of Parts and Labor
This adjustable base is warranted by the manufacturer against defects and workmanship
for a period of one year from the date of purchase.
During this time, the manufacturer will repair or replace, at no cost to the original
purchaser, any warranted parts found to be defective by the manufacturer.
Year 2 –3: Full Coverage of Parts Only
During 2 through 3 years from the original purchase date, the manufacturer will offer
replacement parts for any defective adjustable base parts determined by the manufacturer
to be defective.
The manufacturer’s liability is limited to the replacement of the defective electrical and
mechanical parts only.
The purchaser shall bear all transportation costs for parts and installation labor related to
the delivery and replacement of the defective parts.
Year 4 –20: Full Coverage of Mechanical Parts Replacement
During 4 through 20 years, the manufacturer will offer mechanical replacement parts for
any mechanical base part to be found defective at 1/16 of the current replacement parts
multiplied by the number of years from the original purchase date.
The manufacturer’s liability is limited to the replacement of the defective mechanical parts
only. This does not apply to the fabrics, electrical components, lift motors, massage motors
or wood components.
The purchaser shall bear all transportation costs for parts and installation labor related to
the delivery and replacement of the defective part.
Additional Terms and Conditions:
This warranty is void and does not apply:
To any damaged caused by user
If damaged occurred during transit or mishandled
Subjected to physical or electrical abuse or misuse
Exceeded the Load Capacity recommended by the manufacturer in your Owner’s
Manual
Repair or replacement of adjustable base parts will be the sole remedy of the purchaser.
There shall be no liability on the part of the manufacturer and their respective parents,
subsidiaries, divisions or affiliates for any special, indirect, incidental or consequential
damages or other damages, claim or loss not expressly covered by terms of this Limited
Warranty.
For further assistance, please contact the dealer you purchased your Adjustable Base from.

Pliage
Base réglable
Manuel d’assemblage et
d’opération
PARTIE#532K0460
REV: 2020-12-21

Spécifications
Capacité de
poids
880 lb
Hugger mur
X
Degré
d’inclinaison
Backrest: 0°~65°
Legrest
:
0°~35°
Sortie de transformateur de
puissance
DC 29V 1,8A
Entrée de
puissance
AC 100-240 50/60 HZ
Vibromasseur de massage
X
Chargeur USB
X Contrôle Bluetooth X
Lumière de
plancher
X
Lumière flash sur la
télécommande
X
Position prédéfinise:
ZG
et SOMMEIL TRAN
X
Position de mémoire
X

Tableau des matières
Guide de précaution et ............................................................................. ....................2
de la sécurité .............................................................. ...... .......................................... 2
Pour réduire le risque de choc électronique .......................................................2
Une
performance de base djustable .........................................................................2
Restrictions de votre base réglable .........................................................................
3
Informations sur le système électronique ................................................................ 3
Liste
des pièces .................................................................................................................... 4
A pièces perçu électronique ........... ... ............................................................................. 5
Guide d’assemblage ..................................................................................................... 6
Exploitation de votre base réglable . ............................................................................ 9
Opération d’appariement ......................................................................................10
Synchronisation de deux bases (option) ......................................... ....... .............
11
Panne de
c ourantou
défaillance
de l atélécommande
... .................................... ... 12
Dépannage.............................................................................................................13
GARANTIE LIMITÉE DE 20 ANS
1

2
Guide de précaution et d’utilisation de la sécurité
Votre nouvelle base réglable a été rigoureusement testée et inspectée avant l’expédition. Il est
fortement recommandé de lire attentivement ces instructions avant d’essayer votre
nouvelle base réglable, afin de maintenir votre base réglable de haute qualité performante au cours de
sa
vie, mais aussi de réduire le risque d’incendie, de choc électrique, de brûlures ou de blessures
pour les utilisateurs.
Pour réduire le risque de
choc
électronique, de brûlures ou de blessures pour les
utilisateurs,
les enfants ou les animaux de compagnie, veuillez suivre
ces
instructions.
1. Après avoir déballé votre réglable, soyez conscient de vos petits enfants et animaux de
compagnie. . Son matériel d’emballage peut mettre vos petits enfants ou animaux de compagnie
dans des dangers étouffants. .
2. Débranchez le cordon d’alimentation de la prise de courant avant d’installer des pièces ou de
nettoyer votre base réglable.
3. Gardez le cordon d’alimentation loin de l’eau et des zones chauffées. . Si votre base réglable
est
mouillée ou a un cordon d’alimentation effiloché, s’il vous plaît ne pas l’utiliser.
4. N’actionnez pas votre base réglable près des gaz explosifs ou des produits de pulvérisation
d’aérosol sont utilisés.
5. Avant de débrancher le câble d’alimentation, veuillez remettre votre base réglable à la position
plane et arrêter toutes les opérations.
6. Débranchez vos gadgets électroniques à partir du port USB (option) de votre base réglable s’ils
sont entièrement chargés. .
7. N’utilisez pas votre base réglable à l’extérieur. . Votre base réglable n’est conçue que pour une
utilisation à domicile. .
8. Utilisez votre base réglable en conformité avec les restrictions .
Pour que votre
base
réglable de haute
qualité
fonctionne bien au cours de
sa
vie,
veuillez
suivre ces
instructions.
ATTENTION: ENREGISTRER CES PRÉCAUTIONS ET GUIDES
1.
remote
Ne
dévissez pas ou
n’ouvrez
pas
la
boîte
de
commande,
les moteurs de
levage, les
vibrateurs
de massage (option), le SMPS, , le combiné câblé ou la télécommande (option), et d’autres
composants
électroniques sur votre base
,
réglable, excepté l’ouverture du compartiment de batterie
sur
votre télécommande ou SMPS.
La
garantie sera nulle s’il
y
a
un composant endommagé par
les
utilisateurs.
Seul
le personnel de service autorisé
est
autorisé
à
réparer ou
à
remplacer les
pièces.
2.
Ne
mélangez pas différents types de piles ou de vieilles batteries avec une batterie neuve pour
votre combiné
ou SMPS.
3. Retirez
les piles de votre télécommande (option) et de votre SMPS si votre base réglable ne
sera
pas
utilisée pendant une longue période pour éviter les dommages causés par
les
fuites de batterie.
4.
Ne vous asseyez
pas
sur la tête ou la section de la jambe lorsque vous êtes en position surélevée. Il
peut endommager
votre
base
réglable et conduire
à
une espérance de vie plus
courte.
