HartSport Pro-79 Guide

ASSEMBLY
STEP ONE
Attach the front [18] and rear feet [14] to the frame using the nuts [8], washer [9] and
bolts [10].
STEP TWO
Attach the handlebar post [22] inserting into the head tube on the frame. Use the release
lever to adjust and tighten the height in proper position. Then attach handlebar slider [23]
on the handlebar post [22], use release lever [17] to adjust and tighten the handlebar in
the proper position.
STEP THREE
Insert the seat post [43] into the frame’s seat tube. Attach the saddle [1] into seat slider
[42]. Insert the seat slider into the seat post and fix. Using release lever [6], adjust and
tighten the height in proper position.
STEP FOUR
Attach the pedals [11] into the crank arms [20 + 21], each pedal is marked with the L (left)
or R (right) to denote the side of the spinning bike they are on. Note: the right hand crank
is on the same side as the chain guard [19]. Be careful to align the threads correctly to
avoid any damage. A little grease on the threads should help the pedals to screw in easily
and correctly, tighten using a 15mm spanner; both pedal’s threads should tighten towards
the front of the spinning bike.
STEP FIVE
To adjust the exercising resistance on the complete spinning bike, use the brake knob [24]
of brake system, and then simply loosen (-) or tighten (+).
The flywheel should rotate freely without resistance when you loosen (-) the brake system
totally.

PART LIST
No.
Part Name Unit
No.
Part Name Unit
1 Saddle PC
28 Spring plate PC
2 Alloy bind clamp ( L ) PC 29 Brake pad holder PC
3 Spring for release lever PC 30 Brake pad PC
4 Alloy bind clamp ( R ) PR
31 Nut & Screw PC
5 Washer for release lever PC 32 Axle cover with bolt
PC
6 Release lever PC
33 BB bearing PC
7 Crank bolt PC
34 BB Axle with plate
PC
8 Foot tube nut PC 35 Flywheel axle
SET
9 Foot tube washer PC 36 Flywheel security nut
10 Foot fixing bolt PC 37 Flywheel bearing
11 Pedal PR
38 Axle bolt for moving wheel PC
12 Foot tube end cap PC
39 Moving wheel PC
13 Foot tube adjuster pad PC 40 Plastic washer for release lever PC
14 Rear foot tube PC 41 Fixed bolt for release lever PC
15 Flywheel security washer PC
42 Seat slider SET
16 Flywheel adjuster bolt PC
43 Seat post SET
17 Handle bar release lever w/washer
PC
44 Belt PC
18 Front foot tube PC 45 Fender PC
19 Outer chain guard PC 46 Stainless screw for fender PC
20 Left crank arm PR
47 Stainless washer for fender PC
21 Right crank arm
48 Stainless nut for fender PC
22 Handle bar post PC
49 Stainless hexagon bolt PC
23 Handle bar w/slider PC 50 Holding bracket for fender PC
24 Brake system SET
51 Side fender PR
25 Bolt for bottle cage PC
52 Bolt for side fender PC
26 Bottle cage PC
53 Rubber fixed plug PC
27 Bolt for spring plate PC
54 Stainless washer PC

INSTRUCTIONS FOR USE
The model HART PRO-79 is designed to be used as a “spin” cycle in fitness studios and health clubs. It has
a fixed wheel driven flywheel and should only be used under professional supervision.
Installation – it is important that the HART PRO-79 is correctly assembled and we recommend that suitably
qualified personnel carry out installation and assembly
HANDLEBAR AND SEAT ADJUSTMENT
It is important that the handlebar and seat are set at the correct height for your body. Ask your instructor
for assistance.
Adjusting the handlebar height
1. Undo the release lever that is located where the H-bar post fits into the frame.
2. Slide the handlebar post up or down to the required height and tighten the release lever.
3. Make sure it is securely tightened and that there is no lateral or vertical movement of the handlebar.
4. The handlebar position can also be adjusted forwards or backwards.
5. Undo the Release lever located below the H-bar slider.
6. Slide the handlebar assembly forwards or backwards until you reach the desired position.
7. Then securely tighten the Release lever.
Adjusting the seat height
1. Undo the release lever located where the seat post fits into the frame.
2. Adjust the seat to the required height then tighten the release lever.
3. Make sure it is tight enough to prevent the seat from twisting side to side.
4. The seat position can be adjusted forwards and backwards.
5. Undo the release lever located directly to the side of the seat slider.
6. Loosen the release lever, slide the seat to the required position, then tighten the release lever.
PEDALS AND TOE STRAPS
Your feet should be securely positioned in the toe clips during the exercise. Put your foot as far forwards as
you can into the toe-clip and then pull the strap tight.
LEVEL SURFACE
The HART PRO-79 should operate on a level surface with no lateral movement. There is a height adjuster
pad located on either side underneath the foot tube. Turn these pads clockwise or anti-clockwise until the
bike is totally stable on the ground
EMERGENCY BRAKE
Press down brake system (24) for stop.
MAINTENANCE
It may be unsafe when bolts loosen on the parts of the flywheel or the flywheel becomes noisy, please
contact your supplier if this occurs. Like any other mechanical cycling device, the HART PRO-79 should be
regularly maintained. Please follow the enclosed maintenance chart.

MAINTENANCE CHART
No DESCRIPTION Daily Weekly Monthly Quarterly Annually
1 Wipe machine down X
2 Spray with WD40 or similar X
3 Visual check X
4 Check security of handle bar post & seat post X
5 Check security of saddle X
6 Remove handlebar post and clean tube X
7 Remove seat and clean tube X
8 Check brake pads for wear-align X
9 Check brake adjustment X
10 Check security of all knobs & release lever X
11 Check toe straps for signs of wear X
12 Check crank bolts and re-tighten X
13 Make sure pedals are screwed in X
14 Check belt tension X
15 Wipe anti-rust oil on the flywheel X
16
Check bottom bracket X
17
Check flywheel bearings X
18
Full service-frame inspection X

EXTENDED WARRANTY
1. This product is covered by a Frame warranty for 2 years and a Component warranty for 1
year. (Consumables including but not limited to Brake Pads, Pedals, Pedal Straps, seat and
water bottle holders are not covered by this warranty). This warranty is only applicable for
the original purchaser (or gift recipient) and is not transferable.
2. The warranty commences from the invoice date for the product.
3. The warranty covers defective paint or application, defective materials and workmanship.
4. The warranty does not cover normal wear and tear, abrasion, neglect, abuse, accidents,
improper assembly or maintenance, oxidisation or solvents damage, failure to clean or
maintain the product on a regular basis, improper installation or lack of reasonable care
during use of the product and it specifically ceases to apply if:
a. the product is misused,
b. the product is used contrary to the Company’s recommendations,
c. the product is altered or modified without prior written consent from the Company,
d. parts of the product have been replaced or substituted without the prior written
consent of the Company, or
e. inadequate maintenance procedures have been carried out on the product.
5. A warranty claim must be reported immediately to the Company after a defect is believed
to have been detected but no later than 7 days after detection or the claim will be void.
6. The Company’s liability (if any) will be determined by the Company after an examination of
the product by the Company and will be in proportion to the degree of usage completed by
the product. The customer would be responsible for returning the product to the premises
of the Company and:-
a. all costs associated with traveling to and from or transporting the product to and
from the premises of the Company will be met by the customer,
b. if there is a defect in the material or workmanship covered by this warranty it will
either be repaired or replaced by the Company at the absolute discretion of the
Company.
7. The total liability of the Company will be limited to the repair or replacement of the
defective product. The Company will not be in any way liable for any damage caused by
the product being defective nor any consequential costs, damages or losses incurred by the
customer resulting from the defect.
8. The benefit of this warranty is in addition to all rights, remedies in respect of the product
that the customer has under the Trade Practices Act.
