NordicTrack NTC89021 User manual

USER'S MANUAL
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
Serial Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, we will guarantee
satisfaction through direct assis-
tance from our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The trained technicians on our
customer hot line will provide
immediate assistance, free of
charge to you.
CUSTOMER HOT LINE:
1-888-825-2588
Mon.–Fri., 6 a.m.–6 p.m. MST
Model No. NTC89021
Serial No.
Patent Pending
Visit our website at
www.nordictrack.com
new products, prizes,
fitness tips, and much more!

2
TABLE OF CONTENTS
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
HOW TO USE THE CHEST PULSE SENSOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
HOW TO OPERATE THE EXERCISE CYCLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
MAINTENANCE AND TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
EXERCISE GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
EXPLODED DRAWING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
HOW TO ORDER REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
NordicTrack is a registered trademark of ICON IP, Inc.

3
IMPORTANT PRECAUTIONS
WARNING: To reduce the risk of serious injury, read the following important precau-
tions before using the exercise cycle.
1. Read all instructions in this manual before
using the exercise cycle. Use the exercise
cycle only as described.
2. It is the responsibility of the owner to
ensure that all users of the exercise cycle
are adequately informed of all precautions.
3. Use the exercise cycle indoors on a level
surface. Keep the exercise cycle away from
moisture and dust. Place a mat under the
exercise cycle to protect the floor or carpet.
4. Inspect and properly tighten all parts regu-
larly. Replace any worn parts immediately.
5. Keep children under the age of 12 and pets
away from the exercise cycle at all times.
6. The exercise cycle should not be used by
persons weighing more than 250 pounds.
7. Wear suitable clothing when using the
exercise cycle; do not wear loose clothing
that could become caught on the exercise
cycle. Always wear athletic shoes.
8. Always keep your back straight when using
the exercise cycle. Do not arch your back.
9. If you feel pain or dizziness while exercis-
ing, stop immediately and cool down.
10. The pulse sensors are not medical devices.
Various factors, including the user's move-
ment, may affect the accuracy of heart rate
readings. The pulse sensors are intended
only as exercise aids in determining heart
rate trends in general.
11. The exercise cycle is intended for in-home
use only. Do not use the exercise cycle in a
commercial, rental, or institutional setting.
WARNING: Before beginning this or any exercise program, consult your physician. This
is especially important for persons over the age of 35 or persons with pre-existing health problems.
Read all instructions before using. ICON assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.

4
Congratulations for selecting the new NordicTrack®
SL 760 exercise cycle. Cycling is one of the most
effective exercises for increasing cardiovascular fit-
ness, building endurance, and toning the entire body.
The NordicTrack®SL 760 offers an impressive array
of features designed to let you enjoy this healthful
exercise in the comfort and privacy of your home.
For your benefit, read this manual carefully before
you use the exercise cycle. If you have questions
after reading this manual, call our Customer Service
Department toll-free at 1-888-825-2588, Monday
through Friday, 6 a.m. until 6 p.m. Mountain Time
(excluding holidays). To help us assist you, mention
the product model number and serial number when
calling. The model number is NTC89021. The serial
number can be found on a decal attached to the exer-
cise cycle (see the front cover of this manual for the
location of the decal).
Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.
BEFORE YOU BEGIN
Seat Handle
Fan
Water Bottle Holder*
*No water bottle is included
FRONT
REAR
Backrest
Seat
Wheel
Pedal/Strap
Console
Bookrack
Pulse Sensor
Handlebar
Seat Knob
Leveling Foot
RIGHT SIDE

5
ASSEMBLY
Assembly requires two persons. Place all parts of the exercise cycle in a cleared area and remove the packing
materials. Do not dispose of the packing materials until assembly is completed.
Assembly requires the included tools and your own adjustable wrench .
Use the drawings below to identify the small parts used in assembly. The number in parenthesis below each
drawing refers to the key number of the part, from the PART LIST on page 29. The second number refers to the
quantity needed for assembly. Note: Some small parts may have been pre-attached for shipping. If a part is
not in the parts bag, check to see if it has been pre-assembled.
M10 Nylon
Locknut (63)–2
M8 Split
Washer (55)–14 M10 Split
Washer (38)–2
M8 Washer
(60)–4
M10 x 52mm Button Bolt (48)–2
M8 Nylon
Locknut (69)–4
M8 x 40mm Button
Bolt (68)–4
M10 x 118mm Button Screw (64)–2
M8 x 25mm Button
Screw (61)–4
M4 x 16mm
Screw (57)–5 1/4” x 16mm Button
Screw (59)–8 M8 x 40mm Button
Screw (54)–8
1. Identify the Front Stabilizer (15). While another person
lifts the front of the Frame (1), attach the Front
Stabilizer to the Frame with four M8 x 40mm Button
Screws (54) and four M8 Split Washers (55).
15
1
55
55 54
54
1

6
2. While another person lifts the rear of the Frame (1),
attach the Rear Stabilizer (16) to the Frame with four
M8 x 40mm Button Screws (54) and four M8 Split
Washers (55).
3
2
1
64
64
38
38
43
71
71
3. Have another person hold the Upright (2) in the posi-
tion shown. See the inset drawing. Locate the wire
extending from the bottom of the Upright. Tie the wire
around the end of the Wire Harness (43) as shown.
Carefully pull the wire up through the Upright until the
Wire Harness is extending from the top of the Upright.
Then, untie the wire and discard it.
Carefully pull the end of the Wire Harness (43) to
remove any slack. Insert the Upright (2) into the
Frame (1); be careful to avoid pinching the Wire
Harness. Attach the Upright with two M10 x 118mm
Button Screws (64), two M10 Split Washers (38), and
two Upright Spacers (71). Make sure the concave
end of each Upright Spacer is turned toward the
Upright.
Do not pinch
the Wire
Harness (43)
during this
step.
16
1
55
55 54
54
2
43
Wire
4. Identify the Left Handlebar (32), which is marked with a
sticker. While another person holds the Left Handlebar
near the Upright (2), connect the left Pulse Sensor Wire
(6) to the Pulse Wire (3). Carefully pull the upper end
of the Pulse Wire to remove any slack, and slide the
Left Handlebar onto the left tube on the Upright; be
careful to avoid pinching the Wires. Next, insert two
M8 x 40mm Button Bolts (68) into the Left Handlebar
and the tube on the Upright; be careful not to damage
the Wires with the Button Bolts. Finger tighten two
M8 Nylon Locknuts (69) onto the Button Bolts. Then,
slide the Handlebar Collar (49) onto the upper end of
the Left Handlebar.
Attach the Right Handlebar (44) as described above.
Note: As you slide the Right Handlebar onto the right
post on the Upright (2), insert the upper end of the
Right Handlebar into the Left Handlebar (32).
Connect the Handlebars (32, 44) with the Handlebar
Collar (49) and an M4 x 16mm Screw (57). Then, tight-
en the four M8 x 40mm Button Bolts (68); make sure
the M8 Nylon Locknuts (69) are seated in the
hexagonal holes in the Handlebars.
Tube
3
3
2
6
32
44
Make sure the wires
do not get damaged
during this step.
68
69
4
49
57

7
7. Attach the Seat Frame (7) to the Seat Carriage (11)
with two M10 x 52mm Button Bolts (48) and two M10
Nylon Locknuts (63). 63
7
11
6. Attach the Seat (9) to the Seat Frame (7) with four 1/4”
x 16mm Button Screws (59) and four M8 Washers (60).
7
59
60
60
9
6
7
48
5. Have another person hold the Console (4) near the
Upright (2).
Connect the Wire Harness (43) to the wire harness on
the Console (4). Connect the Pulse Wire (3) to the
pulse wire on the Console. Next, locate the ground
wire that is connected with a screw to the Upright (2).
Connect the ground wire to the smallest wire on the
Console.
Carefully insert all excess wiring down into the Upright
(2). Attach the Console (4) to the Upright with four M4
x 16mm Screws (57). Be careful to avoid pinching
the wires. Next, press the bookrack onto the Console
in the indicated location.
4
Ground Wire
2
57
43
3
5
Do not pinch
the wires
during this step.
Bookrack

8
10. Make sure that all parts are properly tightened before you use the exercise cycle. Note: After assembly is
completed, some extra parts may be left over. Place a mat beneath the exercise cycle to protect the floor.
9. Identify the Left Pedal (22), which is marked with an
“L.” Using an adjustable wrench, firmly tighten the
Left Pedal counterclockwise into the Left Crank Arm
(24). Tighten the Right Pedal (not shown) clockwise
into the Right Crank Arm. Important: Tighten both
Pedals as firmly as possible. After using the
exercise cycle for one week, retighten the
Pedals. For best performance, the Pedals must
be kept tightened.
Identify the Left Pedal Strap (25), which is marked
with an “L.” Attach the Left Pedal Strap to the Left
Pedal (22), and adjust it to the desired position.
Attach and adjust the Right Pedal Strap (not shown)
in the same way.
9
22 24
25
8. Attach the Backrest (62) to the Backrest Frame (42)
with four 1/4” x 16mm Button Screws (59).
Slide the Backrest Frame (42) onto the Seat Frame
(7). Attach the Backrest Frame with four M8 x 25mm
Button Screws (61) and four M8 Split Washers (55).
62
7
59
61
55
55 61
42
8

9
To get the best performance from the chest pulse sen-
sor, please read the instructions below.
HOW TO PUT ON THE CHEST PULSE SENSOR
The chest pulse sensor consists of two components:
the chest strap and the sensor unit. Follow the steps
below to put on the chest pulse sensor.
See the inset drawing above. Insert the tab on
one end of the chest strap through one end of the
sensor unit as shown. Then, press the end of the
sensor unit under the buckle on the chest strap.
Wrap the
chest pulse
sensor
around
your chest.
Attach the
free end of
the chest
strap to the sensor unit as described above.
Adjust the length of the chest strap, if necessary.
The chest pulse sensor should be under your
clothing, against your skin, and as high under the
pectoral muscles or breasts as is comfortable.
Make sure that the logo is facing forward and is
right-side-up.
Pull the
sensor unit
away from
your body
a few inch-
es and
locate the
two elec-
trode areas on the inner side. Using a saline
solution such as saliva or contact lens solution,
wet both electrode areas. Return the sensor unit
to a position against your chest.
CHEST PULSE SENSOR TROUBLESHOOTING
If the chest pulse sensor does not function proper-
ly, or if the displayed heart rate is excessively high
or low, try the steps below.
• Make sure that the chest pulse sensor is worn
exactly as described in step 2 at the left. If the chest
pulse sensor does not function when positioned as
described, move it slightly lower or higher on your
chest.
• Each time you use the chest pulse sensor, use
saline solution such as saliva or contact lens solu-
tion to wet the two electrode areas on the sensor
unit (see the drawing in step 3 at the left). If heart
rate readings do not appear until you begin perspir-
ing, re-wet the electrode areas.
• Make sure that you are within arm’s length of the
console. For the console to display heart rate
readings, the user must be within arm’s length of
the console.
• The chest pulse sensor is designed to work with
people who have normal heart rhythms. Heart rate
reading problems may be caused by medical condi-
tions such as premature ventricular contractions
(pvcs), tachycardia bursts, and arrhythmia.
•The operation of the chest pulse sensor can be
affected by magnetic interference caused by high
power lines or other sources. If it is suspected that
magnetic interference may be causing a problem,
try relocating your exercise equipment.
• If the chest pulse sensor still does not function prop-
erly, test the chest pulse sensor in the following way:
Hold the chest
pulse sensor
and place your
thumbs over
the electrode
areas as
shown.
3
2
1
Chest Strap
Sensor Unit
Tab
Buckle
Electrode Areas
Sensor
Unit
Electrode Areas
HOW TO USE THE CHEST PULSE SENSOR
Logo

10
Next, hold the chest pulse sensor near the console.
While holding one thumb stationary, begin tapping
the other thumb against the electrode area at a rate
of about one tap per second. Check the heart rate
reading on the console.
•If the chest pulse sensor does not function properly
after you have followed all of the above instructions,
the battery should be replaced in the following way:
Locate the battery
cover on the back of
the sensor unit. Insert
a coin into the slot in
the cover, turn the
cover counterclock-
wise, and remove the
cover.
Remove the old bat-
tery and insert a
new CR 2032 bat-
tery. Make sure that
the battery is
turned so the writ-
ing is on top.
Replace the battery
cover and turn it
clockwise to close it.
CHEST PULSE SENSOR CARE
•Thoroughly dry the chest pulse sensor after each
use. The chest pulse sensor is activated when the
electrode areas are wetted and the chest pulse sen-
sor is put on; the chest pulse sensor shuts off when
it is removed and the electrode areas are dried. If
the chest pulse sensor is not dried after each use, it
may remain activated longer than necessary, drain-
ing the battery prematurely.
• Store the chest pulse sensor in a warm, dry place.
Do not store the chest pulse sensor in a plastic bag
or other container that may trap moisture.
• Do not expose the chest pulse sensor to direct
sunlight for extended periods of time. Do not expose
the chest pulse sensor to temperatures above 122°
Fahrenheit (50° Celsius) or below 14° Fahrenheit
(-10° Celsius).
• Do not excessively bend or stretch the sensor unit
when using or storing the chest pulse sensor.
• Clean the sensor unit using a damp cloth—never
use alcohol, abrasives, or chemicals. The chest
strap may be hand washed and air dried.
CR 2032
Battery

11
HOW TO OPERATE THE EXERCISE CYCLE
HOW TO MOVE AND LEVEL THE EXERCISE
CYCLE
Stand in back of the exercise cycle, and lift the exer-
cise cycle until it can be moved on the front wheels.
Move the exercise cycle to the desired location and
carefully lower it. Due to the weight of the exercise
cycle, use extreme caution while moving it.
If the exercise cycle
rocks slightly during
use, turn the level-
ing feet under the
rear stabilizer until
the rocking motion
is eliminated.
HOW TO ADJUST THE SEAT
The seat can be
adjusted to the posi-
tion that is the most
comfortable for you.
To adjust the seat,
pull the seat knob,
slide the seat for-
ward or backward,
and then release
the seat knob. Move
the seat forward or
backward slightly
until the pin on the
seat knob snaps into one of the holes in the seat rail.
HOW TO ADJUST THE PEDAL STRAPS
The pedal straps
can be adjusted to
the position that is
the most comfort-
able for you. Press
the tabs on the ped-
als, adjust the
straps to the
desired position,
and then release
the tabs.
Leveling
Foot
Wheel
Seat Seat
Knob
Pedal
Strap
Tab

12
FEATURES OF THE CONSOLE
The state-of-the-art console offers an impressive array
of features. When the manual mode of the console is
selected, the resistance of the pedals can be changed
with a touch of a button. As you exercise, the console
will provide continuous exercise feedback. You can
even measure your heart rate using the handgrip
pulse sensor or the chest pulse sensor.
The console also offers 15 certified personal trainer
programs. Each program automatically changes the
resistance of the pedals and prompts you to increase
or decrease your pace as it guides you through an
effective workout.
In addition, the console features four heart rate control
programs that automatically change the resistance of
the pedals and prompt you to vary your pace to keep
your heart rate near a target level as you exercise.
The console even measures your body fat percentage,
provides custom programs based on personal data
that you enter, and displays your fat burning or weight
loss progress.
The console also features iFIT.com interactive technol-
ogy. Having iFIT.com technology is like having a per-
sonal trainer in your home. Using the included audio
cable, you can connect the exercise cycle to your
home stereo, portable stereo, or computer and play
special iFIT.com CD programs (CDs are available sep-
arately). IFIT.com CD programs automatically control
the resistance of the pedals and prompt you to vary
your pace as a personal trainer coaches you through
every step of your workout. High-energy music pro-
vides added motivation. Each CD features two pro-
grams designed by certified personal trainers.
In addition, you can connect the exercise cycle to your
VCR and TV and play iFIT.com video programs (video-
cassettes are available separately). Video programs
offer the same benefits as iFIT.com CD programs, and
allow you to enjoy breathtaking scenery while you
exercise. To purchase iFIT.com CDs and videocas-
settes, call toll-free 1-888-825-2588.
With the exercise cycle connected to your computer,
you can also go to www.iFIT.com and use programs
directly from our Web site. Explore www.iFIT.com for
details.
To use the manual mode of the console, see page
13. To use a personal trainer program, see page
15. To use a heart rate program, see page 16. To
use an iFIT.com CD or videocassette, see page 21.
To use a program from our Web site, see page 22.
To measure your body fat percentage, see page 23.
To use a custom program based on personal date
that you enter, see page 24. To review your fat
burning or weight loss progress, see page 25.
CONSOLE DIAGRAM
Note: If there is a sheet of clear plastic on the face of the console, remove it before using the console.

13
HOW TO USE THE MANUAL MODE
Begin pedaling to activate the console.
The exercise cycle requires no batteries or
external power source. Power is supplied by
a generator while you are pedaling. To activate
the console, begin pedaling at a speed of about
3 miles per hour or faster. After a few seconds,
the console displays will light. A tone will then
sound and the console will be ready for use.
Note: While the console is activated, messages
such as “PUSH ‘MEASURE’ TO DETERMINE
YOUR BODY FAT PERCENTAGE” will scroll
across the main display. If you wish to use these
features, see pages 23 to 25.
Select the manual mode.
When the power is turned on, the manual mode
will be selected. If you have already selected a
program or a different mode, select the manual
mode again by repeatedly pressing the Program
Select button until the words “MANUAL MODE”
appear in the main display. Another way to select
the manual mode is to press the iFIT.com button
twice.
Change the resistance of the pedals as
desired.
To change the resis-
tance of the pedals,
press the Resis-
tance buttons.
Resistance level 10
is the highest resis-
tance level.
Monitor your progress with the matrix, the
Training Zone bar, and the main display.
The matrix—When
the manual mode or
the iFIT.com mode
is selected, the
matrix will display a
1/4-mile track. As
you pedal, the indi-
cators around the track will light, one at a time,
until the entire track is lit. The track will light once
each time you pedal 1/4 mile.
The Training Zone
bar—The Training
Zone bar will indicate
the approximate
intensity level of your
exercise. For exam-
ple, if three or four indicators in the bar are lit, the
bar shows that your pace is ideal for fat burning.
Note: During programs, the Training Zone bar will
also prompt you to increase or decrease your
pace.
The main display—The main display will show
the following information:
The left side of the
main display will
show the distance
you have pedaled,
your pedaling speed,
and the resistance
level of the pedals.
The display will change from one number to the
next every few seconds, as shown by the indica-
tors around the display. Note: Each time the
resistance of the pedals changes, the display will
show the resistance level.
The center of the
main display will
show your pedaling
pace (in minutes per
mile) and the elapsed
time. The display will
change from one
number to the next every few seconds, as shown
by the indicators around the display. Note: When
a program is selected, the display will show the
time remaining in the program and the time
remaining in the current segment of the program
instead of the elapsed time.
The right side of the
main display will
show the approxi-
mate numbers of
calories and fat calo-
ries you have burned
(see FAT BURNING
on page 27). The display will change from one
number to the next every few seconds, as shown
by the indicators around the display. Note: When
you use the handgrip pulse sensor or the chest
pulse sensor, the display will also show your
heart rate.
4
3
2
1

14
Note: The console
can display speed
and distance in
either miles or kilo-
meters. To find
which unit of mea-
surement is select-
ed, you must select the console’s user mode.
Hold down the Program Select button for about
three seconds. The letter “E” for English miles or
the letter “M” for metric kilometers will appear on
the right side of the main display. To change the
unit of measurement, press the Resistance 10
button.
While the user mode is selected, press the
iFIT.com button. The main display will then show
the total number of hours that the exercise cycle
has been used. Press the iFIT.com button again.
The main display will then show the total number
of miles pedaled. To exit the user mode, press the
Program Select button again.
Measure your heart rate if desired.
To use the chest pulse sensor, see page 9. To
use the handgrip pulse sensor, follow the instruc-
tions below. Note: If you wear the chest pulse
sensor and hold the handgrip pulse sensor at
the same time, the console may not display
your heart rate accurately.
If there are
thin sheets
of plastic on
the metal
contacts on
the handgrip
pulse sensor,
peel off the
plastic. To
measure your
heart rate,
hold the con-
tacts; your palms must be resting on the contacts
closest to you, and your fingers must be touching
the contacts on the opposite side of the handle-
bar. Avoid moving your hands.
When your pulse is
detected, the Heart
Rate indicator above
the right side of the
main display will light,
two dashes (– –)
will appear in the
main display, and then your heart rate will be
shown. For the most accurate heart rate reading,
hold the contacts for at least 15 seconds.
Note: If you continue to hold the contacts, the
main display will show your heart rate for up to
30 seconds. The main display will then show
your heart rate along with the other modes.
If your heart rate is not shown, make sure that
your hands are positioned as described. Be care-
ful not to move your hands excessively or to
squeeze the contacts too tightly. For optimal per-
formance, clean the contacts using a soft cloth;
never use alcohol, abrasives, or chemicals.
Turn on the fan if desired.
To turn on the fan, press the Fan button. Pivot
the fan to the desired angle. To turn on the fan at
high speed, press the Fan button a second time.
To turn off the fan, press the Fan button a third
time.
When you are finished exercising, the
console will automatically turn off.
If the pedals are not moved for several seconds,
a tone will sound, the console will pause, and the
time will begin to flash in the main display.
If the pedals are not moved for about one minute,
the console will turn off; however, the main dis-
play will not be reset. If the pedals are not moved
for about five minutes, the main display will be
reset.
7
6
5
Contacts

15
HOW TO USE PERSONAL TRAINER
PROGRAMS
Begin pedaling to activate the console.
See step 1 on page 13.
Select one of the 15 personal trainer
programs.
When the power is turned on, the manual mode
will be selected. To select a personal trainer pro-
gram, repeatedly press the Program Select but-
ton until the name of the desired program appears
in the main display.
The matrix will show
the first seven resis-
tance settings of the
program you have
selected.
Begin pedaling to start the program.
Each program is divided into several time seg-
ments of different lengths. (The main display will
show both the time remaining in the program and
the time remaining in the current segment of the
program.) One resistance setting and one pace
setting are programmed for each segment. (The
same resistance setting and/or pace setting may
be programmed for two or more consecutive seg-
ments.)
The resistance set-
ting for the first seg-
ment will be shown
in the flashing
Current Segment
column of the
matrix. (The pace
settings are not shown in the matrix.) The resis-
tance settings for the next several segments will
be shown in the columns to the right.
When only three seconds remain in the first seg-
ment of the program, both the Current Segment
column and the column to the right will flash, a
series of tones will sound, and all resistance set-
tings will move one column to the left. The resis-
tance setting for the second segment will then be
shown in the flashing Current Segment column,
and the resistance of the pedals will automatically
change if a different resistance setting is pro-
grammed for the second segment.
As you exercise, the Training Zone bar will help
you to keep your pedaling pace near the pace
setting for the current segment. The lit indicators
in the bar will show
your actual pace. If
an indicator to the
right of the lit indica-
tors is flashing (see
drawing a), increase
your pace. If an indi-
cator to the left of
any lit indicator is
flashing (see drawing
b), decrease your
pace. When no indi-
cator is flashing, your
pace matches the
pace setting for the current segment. Important:
The pace settings are intended only to pro-
vide motivation. Your actual pace may be
slower than the current pace setting. Make
sure to exercise at a pace that is comfortable
for you.
The program will continue in this way until the
main display shows that no time remains in the
program.
Note: During the program, you can override the
resistance setting for the current segment, if
desired, by pressing the Resistance buttons.
However,when the next segment begins, the
resistance will automatically change if a different
resistance setting is programmed for the next
segment. If you stop pedaling for several sec-
onds, a tone will sound and the program will
pause. To restart the program, simply resume
pedaling.
3
2
1
a
b
Current Segment

16
Monitor your progress with the main display.
See step 4 on page 13.
Measure your heart rate if desired.
See step 5 on page 14.
Turn on the fan if desired.
See step 6 on page 14.
When the program is finished, the console
will automatically turn off.
See step 7 on page 14.
HOW TO USE HEART RATE PROGRAMS
Each heart rate program helps you to keep your heart
rate near a certain percentage of your maximum heart
rate during your workout. Note: Your maximum heart
rate is estimated by subtracting your age from 220.
For example, if you are 30 years old, your maximum
heart rate is 190 (220 – 30 = 190).
Heart rate program 1 will keep your heart rate
between 50% and 80% of your maximum heart rate;
heart rate program 2 will keep your heart rate
between 55% and 85%; heart rate program 3 will
keep your heart rate between 60% and 85%; heart
rate program 4 will keep your heart rate between 50%
and 85%.
Follow the steps below to use a heart rate program.
Begin pedaling to activate the console.
See step 1 on page 13.
Select one of the four heart rate programs.
When the power is turned on, the manual mode
will be selected. To select a heart rate program,
press the Program Select button repeatedly until
the words “HEARTRATE 1,” “HEARTRATE 2,”
“HEARTRATE 3,” or “HEARTRATE 4” appear in
the main display.
Three seconds after a program is selected, the
name of the selected program and the total pro-
gram time will scroll across the main display.
The current age setting will then begin to flash in
the main display.
During heart rate pro-
grams, the matrix will
show a graphic that
represents your heart
rate. Each time a
heartbeat is detect-
ed, an additional
peak will appear.
2
1
7
6
5
4

17
Enter your age.
You must enter your age to use a heart rate pro-
gram. If you have already entered your age,
press the Enter button and go to step 4. If you
have not entered your age, press the Up Arrow
or Down Arrow button repeatedly to enter your
age, and then press the Enter button. Once you
have entered your age, it will be saved in memory.
Wear the chest pulse sensor or hold the
handgrip pulse sensor.
To use the chest pulse sensor, see page 9.
To use the handgrip pulse sensor, it is not neces-
sary to hold the handgrips continuously during
the program. However, you should hold the
handgrips frequently for the program to operate
properly. Each time you hold the handgrips,
keep your hands on the metal contacts for at
least 30 seconds. Note: When you are not hold-
ing the handgrips, the letters “PLS” will appear in
the right side of the display instead of your heart
rate.
Begin pedaling to start the program.
Each heart rate program consists of 20 one-
minute segments. (The main display will show
both the time remaining in the program and the
time remaining in the current segment of the pro-
gram.) One resistance setting is programmed for
each segment. (The same resistance setting may
be programmed for two or more consecutive
segments.)
At the end of each segment, a series of tones will
sound. The resistance of the pedals will then
change if a different resistance setting is pro-
grammed for the next segment. Note: If the resis-
tance is too high or too low, you can adjust the
resistance by pressing the Resistance buttons.
However, when the next segment begins, the
resistance will automatically change if a different
resistance setting is programmed for the next seg-
ment.
As you exercise, the Training Zone bar will help
you to keep your heart rate near the current tar-
get heart rate for the program. The lit indicators
in the bar will show your actual pace. When you
wear the chest pulse sensor or hold the handgrip
pulse sensor, the console will periodically com-
pare your heart rate to the current target heart
rate; if necessary,
an indicator in the
bar will then flash
to prompt you to
increase or
decrease your
pace to bring your
heart rate closer to
the current target
heart rate. If an
indicator to the
right of the lit indi-
cators is flashing
(see drawing a),
increase your
pace. If an indicator to the left of any lit indicator
is flashing (see drawing b), decrease your pace.
When no indicator is flashing, your heart rate is
near the current target heart rate. Important:
The target heart rates are intended only to
provide motivation. Your actual heart rate
may be slower than the current target heart
rate. Make sure to exercise at a pace that is
comfortable for you.
The program will continue in this way until the
main display shows that no time remains in the
program.
Note: If you stop pedaling for several seconds, a
tone will sound and the program will end. Heart
rate programs cannot be stopped temporarily and
then restarted.
Monitor your progress with the main display.
See step 4 on page 13.
Turn on the fan if desired.
See step 6 on page 14.
When the program is finished, the console
will automatically turn off.
See step 7 on page 14.
8
7
6
5
4
3
a
b

18
HOW TO CONNECT YOUR CD PLAYER, VCR,
OR COMPUTER
To use iFIT.com CDs, the exercise cycle must be con-
nected to your portable CD player, portable stereo,
home stereo, or computer with CD player. See pages
18 and 19 for connecting instructions. To use iFIT.com
videocassettes, the exercise cycle must be connected
to your VCR. See page 20 for connecting instructions.
To use iFIT.com programs directly from our Web
site, the exercise cycle must be connected to your
home computer. See page 19 for connecting instruc-
tions.
HOW TO CONNECT YOUR PORTABLE CD PLAYER
Note: If your CD player has separate LINE OUT and
PHONES jacks, see instruction A below. If your CD
player has only one jack, see instruction B.
A. Plug one end of the audio cable into the jack
beneath the console. Plug the other end of the
cable into the LINE OUT jack on your CD player.
Plug your headphones into the PHONES jack.
B. Plug one end of the audio cable into the jack
beneath the console. Plug the other end of the
cable into a 1/8” Y-adapter (available at electronics
stores). Plug the Y-adapter into the PHONES jack
on your CD player. Plug your headphones into the
other side of the Y-adapter.
HOW TO CONNECT YOUR PORTABLE STEREO
Note: If your stereo has an RCA-type AUDIO OUT
jack, see instruction A below. If your stereo has a
1/8” LINE OUT jack, see instruction B. If your
stereo has only a PHONES jack, see instruction C.
A. Plug one end of the audio cable into the jack
beneath the console. Plug the other end of the
cable into the adapter. Plug the adapter into an
AUDIO OUT jack on your stereo.
B. Plug one end of the audio cable into the jack
beneath the console. Plug the other end of the
cable into the LINE OUT jack on your stereo. Do
not use the adapter.
C. Plug one end of the audio cable into the jack
beneath the console. Plug the other end of the
cable into a 1/8” Y-adapter (available at electronics
stores). Plug the Y-adapter into the PHONES jack
on your stereo. Plug your headphones into the
other side of the Y-adapter.
LINE OUT
PHONES LINE OUT
PHONES
Audio
Cable
Head-
phones
A
PHONES
PHONES
Audio
Cable
1/8”
Y-adapter
Headphones
B
AUDIO OUT
RIGHT
LEFT
PHONES
Audio
Cable
C
1/8”
Y-adapter
Headphones
Audio Cable
Adapter
A, B

19
HOW TO CONNECT YOUR HOME STEREO
Note: If your stereo has an unused LINE OUT jack,
see instruction A below. If the LINE OUT jack is
being used, see instruction B.
A. Plug one end of the audio cable into the jack
beneath the console. Plug the other end of the
cable into the adapter. Plug the adapter into the
LINE OUT jack on your stereo.
B. Plug one end of the audio cable into the jack
beneath the console. Plug the other end of the
cable into the adapter. Plug the adapter into an
RCA Y-adapter (available at electronics stores).
Next, remove the wire that is currently plugged into
the LINE OUT jack on your stereo and plug the
wire into the unused side of the Y-adapter. Plug the
Y-adapter into the LINE OUT jack on your stereo.
HOW TO CONNECT YOUR COMPUTER
Note: If your computer has a 1/8” LINE OUT jack,
see instruction A. If your computer has only a
PHONES jack, see instruction B.
A. Plug one end of the audio cable into the jack
beneath the console. Plug the other end of the
cable into the LINE OUT jack on your computer.
B. Plug one end of the audio cable into the jack
beneath the console. Plug the other end of the
cable into a 1/8” Y-adapter (available at electronics
stores). Plug the Y-adapter into the PHONES jack
on your computer. Plug your headphones or speak-
ers into the other side of the Y-adapter.
CD
VCR
Amp
LINE OUT
LINE OUT
Audio Cable
Adapter
A
CD
VCR
Amp
LINE OUT
Audio
Cable
RCA
Y-adapter
Wire removed from
LINE OUT jack
B
Adapter
LINE OUT
Audio
Cable
A
PHONES
Audio Cable
B
1/8”
Y-adapter
Headphones/Speakers

20
HOW TO CONNECT YOUR VCR
Note: If your VCR has an unused AUDIO OUT jack,
see instruction A below. If the AUDIO OUT jack is
being used, see instruction B. If you have a TV
with a built-in VCR, see instruction B. If your VCR
is connected to your home stereo, see HOW TO
CONNECT YOUR HOME STEREO on page 19.
A. Plug one end of the audio cable into the jack
beneath the console. Plug the other end of the
cable into the adapter. Plug the adapter into the
AUDIO OUT jack on your VCR.
B. Plug one end of the audio cable into the jack
beneath the console. Plug the other end of the
cable into the adapter. Plug the adapter into an
RCA Y-adapter (available at electronics stores).
Next, remove the wire that is currently plugged into
the AUDIO OUT jack on your VCR and plug the
wire into the unused side of the Y-adapter. Plug the
Y-adapter into the AUDIO OUT jack on your VCR.
AUDIO OUT
RIGHT
LEFT
VIDEO AUDIO
ANT.IN
RF OUT
IN
OUT
CH
34
Audio Cable
Adapter
A
VIDEO AUDIO
ANT.IN
RF OUT
IN
OUT
CH
34
A
Audio Cable Adapter
B
Wire removed from
AUDIO OUT jack
RCA Y-adapter
