Hatari HE-S18M1 User manual

PRODUCT SPECIFICATIONS
Model
Size
Voltage
Electric Power
Electric Current
Service Value
HE-S18M1
450 mm
220-240V 50/60Hz
64W
0.28A
1.25 m3/min/W
Item code: 1002356 REV.02
User Manual
Slide Fan
Model: HE-S18M1

1 2
DIRECTION OF USE
Plug power supply cord into a 220-240V, 50/60Hz power socket.
Fan speed adjustment
Oscillation adjustment
Fan angle adjustment
1.
2.
3.
3 adjustable fan speed settings 0: off, 1: low speed, 2: medium speed, 3: high speed
Push the oscillation knob down to activate left-right movements. Pull the oscillation knob up to cease
movement.
Tilt the grille upwards or downwards according to the desired wind direction.
CARE AND CLEANING INSTRUCTIONS
1.
2.
3.
Use a damp cloth to wipe stains, and then dry the area by wiping.
When cleaning the fan, be careful not to let the wire, switch, motor and other electrical components get wet.
Do not use chemical products, thinner solvents, alcohol, kerosene or petrol to clean the fan.
ASSEMBLY INSTRUCTIONS
1String the power supply cord through the
hole in the fan base. Place the stand into
the corresponding base slot and press on
all sides. (Be careful not to let the power
supply cord be squeezed between the fan
and the base)
5
Place the blade onto the motor shaft,
ensuring that grooves of the blade fit with
the motor shaft pin. Place the blade cap
over the blade and tighten it by twisting in
the direction as shown by the arrow
(TIGHTEN).
2
Loosen the blade cap by twisting it in the
direction as shown by the arrow (LOOSEN).
6
Assemble the front grille with the catch on
the grille ring interlocking with the back
grille clip lock. Press the grille ring in all
directions then push the grille clip up.
3
Loosen the back grille lock by twisting it in
the direction as shown by the arrow
(LOOSEN).
7
Adjust the height by pressing the height
adjustment button and moving the height
adjustment post.
4
Assemble the back grille as shown in the
diagram. Place the back grille lock over the
grille and tighten it by twisting in the
direction as shown by the arrow
(TIGHTEN).
Plug in the fan and press the fan speed button 1, 2, 3
respectively. If the fan makes a loud noise, check if the blade cap
is screwed on tightly and whether the grooves of the blade fit
the corresponding motor shaft pin.
Unplug the power supply cord before cleaning or changing the components, and when not in use for a long period of time.
Do not use the fan if components are not assembled fully or properly, or if a component such as blade, grille, or blade cap is
damaged.
The appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or instruction.
Do not press the height adjustment button if the fan is not assembled properly.
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
CAUTION
1.
2.
3.
4.
5.
6.
7.
1.
2.
3.
4.
5.
6.
7.
FAN COMPONENTS
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
DECO
FRONT GRILLE
GRILLE RING
GRILLE CLIP
BLADE CAP
FAN BLADE
BACK GRILLE LOCK
BACK GRILLE CLIP LOCK
BACK GRILLE
FRONT MOTOR COVER
OSCILLATION KNOB
BACK MOTOR COVER
NECK JOINT SET
HEIGHT ADJUSTMENT POST
HEIGHT ADJUSTMENT BUTTON
STAND COVER
STAND
FAN SPEED BUTTONS
FAN BASE
POWER SUPPLY CORD & PLUG
51 2 3 6 7 98
4
10 11
12
13
14
17
20
15
16
18
19
USAGE RECOMMENDATIONS
The fan components should be assembled correctly according to the manual to prevent possible harm that may occur while in
use.
The fan should not be placed or installed in areas that are of extreme temperatures or near stoves, or in areas that are wet with
high humidity, or has hydrocarbon vapors such as petroleum.
The fan should not be operated near curtains or mosquito nets because the fan may suck in the light material and entangle them
with the blades, possibly causing harm.
Do not spray all types of spray into the fan; for example, hairspray or cleaning spray.
Do not insert fingers, pencils or other objects into the grille while the blades are spinning as it may result in possible injury or
physical damage.
If a component such as blade, grille, blade cap, or the back grille lock is damaged, replacement can be made using a new
component. Please refer to the assembly instructions.
If an electrical component such as supply cord, motor, or switch is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard. It is not advisable to fix the fan at home.
