Hunter T User manual

For Your Records and Warranty
Assistance
Model Name: _____________________
Catalog/Model No.: ________________
Serial No.: ________________________
Date Purchased: ___________________
Where Purchased: _________________
For reference also attach your receipt or a
copy of your receipt to the manual. TYPE T Models
installation and
operation manual
for Hunter
Ceiling Fans
 42765-01•10/05/07

2
42765-01•10/05/07•HunterFanCompany
© 2007 Hunter Fan Company
YournewHunter®ceiling fan is an addition to your home or office that
will provide comfort and performance for many years. is installation
and operation manual gives you complete instructions for installing
and operating your fan.
We are proud of our work. We appreciate the opportunity to supply
you with the best ceiling fan available anywhere in the world.
Before installing your fan, for your records and warranty assistance,
recordinformationfromthecartonandHunternameplatelabel
(located on the top of the fan motor housing).
Cautions and Warnings
•READ THIS ENTIRE MANUAL CAREFULLY BEFORE BEGINNING
INSTALLATION. SAVE THESE INSTRUCTIONS.
•UseonlyHunterreplacementparts.
•Toreducetheriskofpersonalinjury,attachthefandirectlytothe
support structure of the building according to these instructions,
and use only the hardware supplied.
•Toavoidpossibleelectricalshock,beforeinstallingyourfan,
disconnect the power by turning off the circuit breakers to the
outlet box and associated wall switch location. If you cannot lock
the circuit breakers in the off position, securely fasten a prominent
warning device, such as a tag, to the service panel.
•Allwiringmustbeinaccordancewithnationalandlocalelectrical
codesandANSI/NFPA70.Ifyouareunfamiliarwithwiring,usea
qualified electrician.
•Toreducetheriskofpersonalinjury,donotbendtheblade
attachment system when installing, balancing, or cleaning the fan.
Neverinsertforeignobjectsbetweenrotatingfanblades.
•Toreducetheriskofre,electricalshock,ormotordamage,donot
useasolid-statespeedcontrolwiththisfan.UseonlyHunterspeed
controls.
Welcome
Table Of Contents

3
42765-01•10/05/07•HunterFanCompany
Installer’s Choice and Optional Accessories
Understanding Mounting and Installer’s Choice®
Hunter’spatented3-positionmountingsystemprovidesyoumaximum
installationexibilityandease.YoucaninstallyourHunterfaninone
of three ways, depending on ceiling height and your preference: Low
Prole,Standard,orAngledmounting.estepsinthismanualinclude
instructionsforallthreeInstaller’sChoicemountingmethods.
Considering Optional Accessories
ConsiderusingHunter’soptionalaccessories,includingawall-mounted
or remote speed control. To install and use the accessories, follow
the instructions included with each product. For quiet and optimum
performanceofyourHunterfan,useonlyHunterspeedcontrols.
For ceilings higher than 8 feet, you can purchase
Hunterextensiondownrods.AllHunterfansuse
sturdy3/4”diameterpipetoassurestabilityand
wobble-free performance.
Standard Mounting hangs from the
ceiling by a downrod (included).
Angled Mounting recommended for a
vaulted or angled ceiling
Support Brace
Standard
Mounting
Style
Ceiling
Outlet Box
Support Brace
Ceiling
Outlet Box
Angled
Mounting
Style
Low Profile Mounting fits close to the
ceiling, recommended for ceilings less
than 8 feet high
Support Brace
Low Profile
Mounting
Style
Ceiling
Outlet Box
8
12
CAUTION: To
reduce the risk of
personalinjury,attach
the fan directly to the
support structure of
the building according
to these instructions,
and use only the
hardware supplied.

4
42765-01•10/05/07•HunterFanCompany
To install a ceiling fan, be sure you can do the following:
•Locatetheceilingjoistorothersuitablesupportinceiling.
•Drillholesforandinstallwoodscrews.
•Identifyandconnectelectricalwires.
•Lift40pounds.
Ifyouneedhelpinstallingthefan,yourHunterfandealercandirect
you to a licensed installer or electrician.
Gathering the Tools
You will need the following tools for installing the fan:
•Electricdrillwith9/64”bit
•Standardscrewdriver(magnetictiprecommended)
•Phillips-headscrewdriver(magnetictiprecommended)
•Wrenchorpliers
•Ladder(heightdependentuponinstallationsite)
Checking Your Fan Parts
Carefully unpack your fan to avoid damage to the fan parts. Refer to
the included Parts Guide. Check for any shipping damage to the motor
orfanblades.Ifanypartsaremissingordamaged,contactyourHunter
dealerorcallHunterTechnicalSupportDepartmentat866-268-1936.
Preparing the Fan Site
Before you begin installing the fan, follow all the instructions in
thepulloutsheetcalled“PreparingtheFanSite.”Properceilingfan
location and attachment to the building structure are essential for
safety, reliable operation, maximum efficiency, and energy savings.
Installing Multiple Fans?
If you are installing more than
one fan, keep the fan blades and
blade irons (if applicable) in sets,
as they were shipped.
1 • Getting Ready

5
42765-01•10/05/07•HunterFanCompany
CAUTION: To avoid possible electrical shock, before installing your fan,
disconnect the power by turning off the circuit breakers to the outlet box
and associated wall switch location. If you cannot lock the circuit breakers
in the off position, securely fasten a prominent warning device, such as a
tag, to the service panel.
2-1. Drill two pilot holes into the wood support structure through the
outermostholesintheoutletbox.epilotholesshouldbe9/64”
in diameter.
2-2.Yourfancomeswithfourneoprenenoiseisolators(“Isolators”).
Position the isolators between the ceiling plate and ceiling by
inserting the raised areas on each isolator into the holes in the
ceiling plate.
2-3. readtheleadwiresfromtheoutletboxdownthroughthehole
in the middle of the ceiling plate.
2-4. Aligntheslottedholesintheceilingplatewiththepilotholesyou
drilled in the wood support structure. For proper alignment use
slotted holes directly across from each other.
Note: e isolators should be flush against the ceiling.
2-5. Placeaatwasheroneachofthetwo3”woodscrewsandpass
the screws through the slotted holes in the ceiling plate into the
pilot holes you drilled.
  Tightenthescrewsintothe9/64”pilotholes;donotuselubricants
on the screws. Do not over tighten.
Step 2-2
Flat Washer
3”WoodScrew
Steps 2-3 – 2-5
For Angled Ceilings: Be sure to
orient the ceiling plate so that the
arrows printed on the ceiling plate are
pointing toward the ceiling peak.
Ceiling
Plate
Isolator
2 • Installing the Ceiling Plate

6
42765-01•10/05/07•HunterFanCompany
Steps 3-5 – 3-6
Low Profile Screw
Low Profile Washer
Steps 3-2 – 3-3
Downrod
Canopy
Canopy
Trim Ring
Set Screw
WARNING: Fan may fall if not assembled as directed in these
installation instructions.
3-1.Unbundlethewiresfromthefan.
For Standard or Angled mounting:
3-2.Toassemblefantohangdownfromaatorangledceiling,insert
the downrod through the canopy and canopy trim ring. Feed the
wires from the fan through the downrod.
3-3.Loosenthesquareheadsetscrewontheadaptertoinstallthe
pipe and ball assembly. Note: When the pipe and ball assembly
isfullyinstalled,2-3threadsonthepipewillstillbevisible;thisis
normal. Securely retighten the set screw with a wrench or pliers.
SkiptoStep3-7.
CAUTION: e adapter has a special coating on the threads. Do
notremovethiscoating;thecoatingpreventsthedownrodfrom
unscrewing. Once assembled, do not remove the downrod.
For Low Profile mounting:
Note: For low profile mounting, the downrod is replaced with the low
profile washer.
3-4. Removethesetscrewfromtheadapter.
3-5.Placethelowprolewasher(lipup)intothecanopy.Besurethe
green ground wire is pointing up toward the ceiling.
3-6.Aligntheholesinthewasherwiththeholesintheadapter.
Assemblesecurelywiththreelowprolescrews.
3-7.Raisethefanandplacethehookontheceilingplatethroughthe
U-shapedholeintherim.
Step 3-7
U-shaped
Hole
3 • Assembling and Hanging the Fan

7
42765-01•10/05/07•HunterFanCompany
4 • Securing Fan to Secondary Support System
4-1. Find the looped end of the braided cable and insert it through the
ceiling plate and one of the holes in the outlet box into the ceiling.
4-2.Accessthesupportbraceintheceiling.Youmaynotbeabletodo
this from below the ceiling depending on your installation site.
4-3.Drivea#10x38mm(1-1/2”)woodscrewandwasherintotheside
ofthebracethatholdstheoutletbox.Leave3mm(1/8”)ofspace
between the support brace and the washer.
4-4. Wrap the braided cable around the support brace once creating a
complete circle.
4-5.Hooktheloopedendofthecableoverthewoodscrewsothatthe
braided cable lies between the washer and the support brace.
4-6. Tighten the loop and secure the screw and washer all the way
down to the support brace.
4-7. Coil up the excess cable.
4-8. Return to the fan so you can complete the fan wiring.
Step 4-1
3mm (1/8")
Steps 4-2 – 4-3 Steps 4-4 – 4-5 Steps 4-6 – 4-7
Support
Brace
Ceiling
Outlet Box Braided
Cable

8
42765-01•10/05/07•HunterFanCompany
fsdfsdf
5 • Wiring the Fan
All wiring must be in accordance with national and local electrical
codes and ANSI/NFPA 70-1999. If you are unfamiliar with wiring,
use a qualified electrician.
Wall switches are not included. Select an acceptable general-use switch
in accordance with national and local electrical codes.
5-1. Before attempting installation, make sure the power is still off.
5-2. To connect the wires, hold the bare metal leads together and place
a wire connector over them, then twist clockwise until tight. For
all these connections use the wire connectors provided.
5-3. Connectthebareorgreengroundwire(grounded)fromthe
ceiling to the green ground wire (grounded) from the ceiling plate
and the green ground wire from the fan.
5-4. Connect the white wire (ungrounded) from the ceiling to the
white wire (ungrounded) from the fan.
5-5. Connect the remaining wires as follows:
Dual Switch Wiring:
•eblackwire(ungrounded)fromtheceilingtotheblackwire
(ungrounded) from the fan
•eblack/whitewire(ungrounded)fromthefantothewire
(ungrounded) for the wall switch
Single Switch Wiring:
•eblackwire(ungrounded)fromtheceilingtotheblack
(ungrounded) and the black/white wire (ungrounded) from
the fan
CAUTION: Be sure no bare wire or wire strands are visible after
making connections.
5-6. Turn the splices upward and push them carefully back through the
ceiling plate into the outlet box.
5-7. Spread the wires apart, with the grounded wires on one side of
the outlet box and the ungrounded wires on the other side of the
outlet box.
Single Switch Wiring
Dual Switch Wiring
Wire
Connector

9
42765-01•10/05/07•HunterFanCompany
6-1.Holdingthecanopy,raisethefanothehook.
6-2.Aligntheslotsinthecanopywiththetabsontheceilingplate.
6-3.Raisethecanopyovertheceilingplate.Rotatethecanopy
clockwise until the tabs on the ceiling plate totally engage with
the slots in the canopy.
6-4. Partially install the three canopy screws into the canopy one at a
time. Once all three screws are in, tighten them.
6-5. Usingbothhands,pushthecanopytrimringuptothetopofthe
canopy. e canopy trim ring will snap and lock into place.
Should you need to remove the canopy
trim ring, follow these steps:
1. Locate the tab indicators, small
bumps on top of tabs.
2. Press firmly on opposite sides of the
ring toward the canopy. e tabs will
flex out releasing the trim ring from
the canopy.
Step 6-2
Canopy Trim
Ring
Canopy
Ceiling Plate
Step 6-3
Steps 6-4 – 6-5
Canopy
Screw
6 • Installing the Canopy and Canopy Trim Ring

10
42765-01•10/05/07•HunterFanCompany
7 • Assembling the Blades
Hunterfansuseseveralstylesoffanbladeirons(bracketsthatholdthe
blade to the fan).
7-1. Your fan may include blade grommets. If your fan has grommets,
insert them by hand into the holes on the blades.
7-2. Attacheachbladetoabladeironusingthreebladeassembly
screws. If you used grommets, the blades may appear slightly loose
after screws are tightened. is is normal.
7-3. Removetheblademountingscrewsandrubbershippingbumpers
from the motor. Note: Some blade mounting screws are installed
in the motor to secure shipping blocks.
7-4. For each blade, insert one blade mounting screw through the
blade iron, and attach lightly to the fan. Insert the second blade
mounting screw, then securely tighten both mounting screws.
Step 7-1 (Detail)
BladeAssembly
Screws
Usewithgrommet
Usewithoutgrommet
Grommet
Blade
Mounting
Screw
Steps 7-1 – 7-2
Step 7-4

11
42765-01•10/05/07•HunterFanCompany
8 • Installing the Switch Housing
8-1. To attach the upper switch housing, partially install two housing
assembly screws into the switch housing mounting plate.
8-2. Feed the upper plug connector through the center opening of the
housing.
8-3. Alignthekeyholeslotsinthehousingwiththehousingassembly
screws.
8-4. Turn the housing counterclockwise until the housing assembly
screws are firmly situated in the narrow end of the keyhole slots.
Install the remaining screw into the housing. Tighten all three
screws firmly.
CAUTION: Make sure the upper switch housing is securely attached
to the switch housing mounting plate. Failure to properly attach and
tighten all three assembly screws could result in the switch housing
fixture falling.
8-5. To attach the lower switch housing, connect the upper plug
connector from the motor to the lower plug connector in the
lower switch housing assembly.
Note: Both plug connectors are polarized and will only fit together
one way. Make sure the connectors are properly aligned before
connecting them. Incorrect connection could cause improper
operation and damage to the product.
8-6. Place the lower switch housing assembly over the upper switch
housing.Alignthesidescrewholesintheupperandlowerswitch
housings.Attachthelowerswitchhousingtotheupperswitch
housing with three housing assembly screws.
Note:YoucancustomizeyourHunterfanwithanumberofaccessory
light kits.
Steps 8-1 – 8-4
Housing
Assembly
Screw
Upper
Switch
Housing
Housing
Assembly
Screw
Lower
Switch
Housing
Steps 8-5 – 8-6
Plug
Connector
Detail

12
42765-01•10/05/07•HunterFanCompany
9 • Operating and Cleaning Your Ceiling Fan
In warm weather, use
downward air flow pattern
In cold weather, use upward
air flow pattern
9-1. Turnonelectricalpowertothefan.
9-2. efanpullchaincontrolspowertothefan.epullchainhas
foursettingsinsequence:High,Medium,LowandO.
• Pullthechainslowlytochangesettings.
• Releaseslowlytopreventthechainfromrecoilingintothe
blades.
• echainusesabreakawayconnectorthatseparatesifthe
chainisjerked.Ifthishappens,simplyreinsertthechaininto
the connector.
9-3. Ceilingfansworkbestbyblowingairdownward(counterclockwise
blade rotation) in warm weather to cool the room with a direct
breeze. In winter, having the fan draw air upward (clockwise blade
rotation) will distribute the warmer air trapped at the ceiling
around the room without causing a draft.
9-4. Forcleaningnishes,useasoftbrushorlint-freeclothtoprevent
scratching.Avacuumcleanerbrushnozzlecanremoveheavier
dust. Remove surface smudges or accumulated dirt and dust using
a mild detergent and a slightly dampened cloth. You may use
an artistic agent, but never abrasive cleaning agents as they will
damage the finish.
9-5. Cleanwoodnishbladeswithafurniturepolishingcloth.
Occasionally, apply a light coat of furniture polish for added
protection and beauty. Clean painted and high-gloss blades in the
same manner as the fan finish.
To Change Airflow Direction
Turn the fan off and let it come to a complete
stop. Slide the reversing switch on the fan to the
opposite position. Restart fan.
Reversing
Switch

13
42765-01•10/05/07•HunterFanCompany
Hunterfanshavethepowertocutyourcoolingcostsupto40%.
Beat the High Cost of Cooling
eairmovementcreatedbyaHunterceilingfanletsyousetyour
thermostat higher and still stay comfortable. Every degree you
raisethethermostatsavesupto7%onenergycosts.So,youcan
cutbackonexpensiveairconditioning...andsaveupto40%*on
cooling.Inwinter,yourHunterfanrecirculateswarmairandsaves
upto10%*onheatingbills.
*Onaverageatlowspeedsettings.Yoursavingsmayvarybased
on climate, building type and thermostat setting.
Save Energy and Money While Protecting the Environment
Congratulations!You’resavingenergyandmoneywhileprotecting
theenvironmentbypurchasingthisENERGYSTARqualied
Hunterceilingfan!Withthispurchase,youaredoingyourpartto
protecttheenvironment.In2010,ENERGYSTARqualiedceiling
fansareprojectedtocutairpollutionbymorethan500million
pounds!
YournewceilingfanhasearnedtheENERGYSTARlabel
because it meets high energy efficiency specifications set by
theEnvironmentalProtectionAgency(EPA).ENERGYSTAR
labeled ceiling fans save energy because they have more efficient
fan motors and air delivery due to more aerodynamic blade
congurations.CeilingfanmodelsbearingtheENERGYSTARlabel
moveair14-20%moreecientlythantypicalceilingfanmodels.
FormoreinformationonENERGYSTARvisitwww.energystar.gov.

14
42765-01•10/05/07•HunterFanCompany
Problem: Nothing happens; fan does not move.
1. Turn power on, replace fuse, or reset breaker.
2. Loosen canopy, check all connections according to the wiring the
fan section.
3.Checktheplugconnectionintheswitchhousing.
4. Push motor reversing switch firmly left or right to ensure that the
switch is engaged.
5. Pull the pull chain to ensure it is on.
6. Remove the shipping bumpers.
Problem: Noisy operation.
1. Tighten the blade bracket screws until snug.
2. Check to see if the blade is cracked. If so, replace all the blades.
Problem: Excessive wobbling.
1. If your fan wobbles when operating, use the enclosed balancing kit
and instructions to balance the fan.
2. Tighten all blade iron screws.
3.Turnpowero,supportfanverycarefully,andcheckthatthe
hanger ball is properly seated.
If you need parts or service assistance, please call
866-268-1936 or visit us at our Web site at
http://www.hunterfan.com.
HunterFanCompany
2500FriscoAvenue
Memphis,Tennessee38114
10 • Troubleshooting
