Hatco GLO-RAY GRS Series Installation instructions

G O-RAY®®
Heated Shelf
GRS, GRSB & GRSBF Series
Installation &
Operating Manual
&W #07.05.047.00
ANAQUELES CALENTADOS NSERTABLES
Manual de nstalación y Operación
P AN R SCALDAT
Manuale di nstallazione e Funzionamento
WARMHALTERPLATEN
nstallations- und Bedienungshandbuch
PLAQUES CHAUFFANTES
nstallation et Fonctionnement
WARMHOUDPLATEN
Handleiding voor nstallatie en Gebruik
Modelli: Glo-Ray®
Modelo: Glo-Ray®
Modell: Glo-Ray®
Modèle: Glo-Ray®
Model: Glo-Ray®

Form No. GRSCEM-0108 i
I USTRATIONS
21 A
B
C
D
E
A NEMA 5-15P A NEMA 5-15P
B NEMA 5-20P B NEMA 5-20P
C NEMA 6-15P C NEMA 6-15P
D CEE 7/7 Schuko D CEE 7/7 Schuko
E BS-1363 E BS-1363
A NEMA 5-15P A NEMA 5-15P
B NEMA 5-20P B NEMA 5-20P
C NEMA 6-15P C NEMA 6-15P
D CEE 7/7 Schuko D CEE 7/7 Schuko
E BS-1363 E BS-1363
A NEMA 5-15P A NEMA 5-15P
B NEMA 5-20P B NEMA 5-20P
C NEMA 6-15P C NEMA 6-15P
D CEE 7/7 Schuko D CEE 7/7 Schuko
E BS-1363 E BS-1363
Plug Configurations Configurations de Prise
Steckerkonfigurationen Configurazione delle Spine
Configuraciones del Enchufe Stekkerconfiguraties
A
B
C
Note: All models listed are based on 495 mm (19-1/2")
depth. Additional depths available:
152 mm (6"), 197 mm (7-3/4"), 248 mm (9-3/4"),
305 mm (12"), 349 mm (13-3/4"), 394 mm (15-1/2"),
400 mm (15-3/4"), 445 mm (17-1/2"),
546 mm (21-1/2"), 597 mm (23-1/2")
and 648 mm (25-1/2").
Anmerkung:
Alle aufgelisteten Modelle basieren auf einer Tiefe
von 495 mm (19-1/2"). Folgende weitere
Tiefenmaße sind erhältlich:
152 mm (6"), 197 mm (7-3/4"), 248 mm (9-3/4"),
305 mm (12"), 349 mm (13-3/4"), 394 mm (15-1/2"),
400 mm (15-3/4"), 445 mm (17-1/2"),
546 mm (21-1/2"), 597 mm (23-1/2")
und 648 mm (25-1/2").
Nota: Todos los modelos de la lista están basados en una
profundidad de 495 mm (19-1/2 pulg). Se pueden
obtener otras profundidades:
152 mm (6"), 197 mm (7-3/4"), 248 mm (9-3/4 "),
305 mm (12"), 349 mm (13-3/4"), 394 mm (15-1/2"),
400 mm (15-3/4"), 445 mm (17-1/2"), 546 mm
(21-1/2"), 597 mm (23-1/2") y 648 mm (25-1/2 ").
Remarque: Tous les modèles listés sont basés sur une
profondeur de 495 mm (19-1/2"). Autres
profondeurs disponibles:
152 mm (6"), 197 mm (7-3/4"), 248 mm (9-3/4"),
305 mm (12"), 349 mm (13-3/4"), 394 mm (15-1/2"),
400 mm (15-3/4"), 445 mm (17-1/2"),
546 mm (21-1/2"), 597 mm (23-1/2")
et 648 mm (25-1/2").
Nota: Tutti i modelli indicati si basano su una profondità
di 495 mm (19-1/2"). Altre profondità disponibili:
152 mm (6"), 197 mm (7-3/4"), 248 mm (9-3/4"),
305 mm (12"), 349 mm (13-3/4"), 394 mm (15-1/2"),
400 mm (15-3/4"), 445 mm (17-1/2"),
546 mm (21-1/2"), 597 mm (23-1/2")
e 648 mm (25-1/2").
Opmerking:
Alle vermelde modellen zijn gebaseerd op een
diepte van 495 mm (19-1/2"). Overige verkrijgbare
dieptematen:
152 mm (6"), 197 mm (7-3/4"), 248 mm (9-3/4"),
305 mm (12"), 349 mm (13-3/4"), 394 mm (15-1/2"),
400 mm (15-3/4"), 445 mm (17-1/2"),
546 mm (21-1/2"), 597 mm (23-1/2")
en 648 mm (25-1/2").
Dimensions - Modèles GRS
Dimensioni - Modelli GRS
Afmetingen - GRS -
Modellen
Dimensions - GRS Models
Abmessungen - GRS-Modelle
Dimensiones - Modelos GRS
The instructions in English begin on page....................................................................5
Deutsche Anweisungen beginnen auf Seite...............................................................19
Las instrucciones en Espanol comienzan en la pagina..............................................33
Les instructions en Francais commencent a la page .................................................47
Le istruzioni in Italiano iniziano dalla pagina ..............................................................61
Nederlandse instructies beginnen op bladzijde..........................................................75

Form No. GRSCEM-0108
1
I USTRATIONS
5
6
Glo-Ray Model GRS Glo-Ray Modèles GRS
Glo-Ray-Modell GRS Glo-Ray Modello GRS
Glo-Ray Modelo GRS Glo-Ray Model GRS
Glo-Ray Model GRSB & GRSBF
(GRSB Shown)
Glo-Ray-Modelle GRSB
und GRSBF (Modell GRSB
Gezeigt)
Glo-Ray Modelo GRSB y GRSBF
(GRSB Mostrado)
Glo-Ray Modèles GRSB &
GRSBF (GRSB Montré)
Glo-Ray Modelli GRSB e
GRSBF (GRSB llustrato)
Glo-Ray model GRSB &
GRSBF (GRSB Getoond)
Models GRSB & GRSBF Underside
Unterseite der GRSB- und GRSBF-Modelle
Parte nferior de Modelos GRSB y GRSBF
Dessous des Modèles GRSB et GRSBF
Fondo Modelli GRSB & GRSBF
Modellen GRSB & GRSBF Onderkant
Remove and save these screws.
Entfernen Sie diese Schrauben, und heben Sie sie auf.
Retire y guarde estos tornillos.
Enlever et conserver ces vis.
Estrarre e conservare queste viti.
Verwijder en bewaar deze schroeven.
3
Dimensions - GRSB Models
Abmessungen - GRSB-Modelle
Dimensiones - Modelos GRSB
Dimensions - GRSBF Models
Abmessungen - GRSBF-
Modelle
Dimensiones - Modelos
GRSBF
Dimensions - Modèles
GRSBF
Dimensioni - Modelli GRSBF
Afmetingen - GRSBF-
Modellen
B
CG
D
F
A
7
Dimensions - Modèles GRSB
Dimensioni - Modelli GRSB
Afmetingen - GRSB-Modellen
E
4
B
CG
D
F
A
E

Form No. GRSCEM-0108 2
I USTRATIONS
BB
C
D
A
A
A Countertop A Comptoir
B Z-Bracket B Attache Z
C Four screws from underside C Quatre vis du
of unit dessous de l’appareil
D Apply a bead of NSF (National Sanitation Foundation) D Appliquez un cordon d'agent d'étanchéité
approved sealant between the countertop and approuvé par la NSF (National Sanitation
mounting flange. Foundation) entre le matériau du comptoir et le
rebord de fixation.
A Arbeitsplatte A Piano di Lavoro
B Z-Klammer B Staffa a Z
C Vier Schrauben von der C Quattro viti dal fondo
Unterseite des Geräts dell’unità
D Tragen Sie einen Streifen eines von der NSF D Applicare una goccia di sigillante approvato dalla
(National Sanitation Foundation) zugelassenen NSF (National Sanitation Foundation) tra il materiale
Dichtmittels zwischen dem Arbeitsplattenmaterial del banco e la flangia di montaggio.
und dem Befestigungsflansch auf.
A Mostrador A Toonbank
B Ménsula en Z B Z-steun
C Cuatro tornillos de la parte C Vier schroeven van de
inferior de la unidad onderkant van apparaat
D Aplique una perla de sellador aprobado por NSF D Breng een door de NSF (National Sanitation
(National Sanitation Foundation) entre el material del Foundation) goedgekeurd afdichtmiddel
mostrador y la brida de montaje. aan tussen de toonbank en de montageflens.
GRSB & GRSBF Countertop nstallation nstallation Comptoir des Modèles GRSB et GRSBF
nstallation der GRSB- und GRSBF-Modelle in der Arbeitsplatte nstallazione del Piano da Lavoro GRSB & GRSBF
nstalación del mostrador GRSB y GRSBF GRSB & GRSBF Toonbankinstallatie
8

Form No. GRSCEM-0108
3
I USTRATIONS
A
B
C
D
E
F
G
F
A Panel A Panneau
B Recessed B Encastré
C Surface C Surface
D Under Counter D Sous le comptoir
E Top View E Vue de dessus
F Optional F Optionnel
G Standard G Standard
A Senkrecht auf einer Platte A Pannello
B n einer Platte B ncassato
C Auf einer Platte C Superficie
D Unterhalb der Theke D Sotto al banco
E Aufsicht E Vista top
F Optional F Optional
G Standard G Standard
A Panel A Paneel
B Rebajada B ngebouwd
C Superficie C Oppervlak
D Debajo del mostrador D Onder de toonbank
E Vista superior E Bovenaanzicht
F Opcional F Optioneel
G Estándar G Standaard
9Use this arc to determine
approximate mounting
distances for semi-remote
controls.
Verwenden Sie diesen
Bogen, um die maximale
Entfernung, in der das
Steuerpult montiert werden
kann, zu bestimmen.
Utilice este arco para
determinar las distancias de
montaje aproximadas para
los controles semi remotos.
Utiliser cet arc pour
déterminer les distances de
montage approximatives
pour les contrôles semi-
distants.
Utilizzare questo arco per
stabilire la distanza di
montaggio approssimativa
per i comandi semi-remoti.
Gebruik deze boog om de
geschatte montageafstanden
te bepalen voor semi-
afstandbedieningen.
Maximum Remote Mounting Distance for Control Box
Maximale Entfernung, in der das Steuerpult Montiert werden
Kann
Distancia Máxima de Montaje del Control Remoto para la caja
de Control
Distance Maximum pour Montage Distant du Boîtier de
Contrôle
Distanza Massima di Montaggio della Scatola di Comando
Maximale Montageafstand voor de Regeldoos

Form No. GRSCEM-0108 4
I USTRATIONS
Operating Controls - GRSB & GRSBF (GRSB Shown)
Bedienungselemente - GRSB- und GRSBF-Modelle
(Modell GRSB Gezeigt)
Controles de Operación - GRSB y GRSBF (GRSB Mostrado)
Contrôles de Fonctionnement - GRSB et GRSBF
(GRSB montré)
Comandi - GRSB & GRSBF (GRSB llustrato)
Bedieningsapparatuur - GRSB & GRSBF (GRSB Getoond)
A
B
AB
A Power On/Off Switch
B Shelf Thermostat
A Netzschalter ein/aus
B Thermostat
der Warmhalteplatte
A nterruptor de
Encendido/Apagado
B Termostato del Anaquel
A nterrupteur Marche-Arrêt
B Thermostat du Rayonnage
A nterruttore di
Alimentazione
B Termostato piano
A Stroomschakelaar Aan/Uit
B Plaatthermostaat
A Power On/Off Switch
B Shelf Thermostat
A Netzschalter ein/aus
B Thermostat der
Warmhalteplatte
A nterruptor
de Encendido/Apagado
B Termostato del anaquel
A nterrupteur Marche-Arrêt
B Thermostat du Rayonnage
A nterruttore di
Alimentazione On/Off
B Termostato Piano
A Stroomschakelaar Aan/Uit
B Plaatthermostaat
Operating Controls - GRS
Bedienungselemente - GRS-
Modell
Controles de Operación - GRS
10
11
Contrôles de Fonctionnement -
GRS
Comandi - GRS
Bedieningsapparatuur -
GRS
12
Adjustable Legs Verstellbare Füße
Patas Ajustables Pieds Réglables
Piedini Regolabili Verstelbare Poten
B Leg nstallation B Einbau der Füße
B nstalación de la Pata B nstallation des Pieds
B nstallazione del Piedino B nstallatie van Poten
C SHORTEN C VERKÜRZEN
C ACORTAR C RACCOURC R
C PER ACCORC ARE C KORTER
D LENGTHEN D VERLÄNGERN
D ALARGAR D RALLONGER
D PER ALLUNGARE D LANGER
A Adjust leg using a 14 mm (9/16") open-end wrench
and turning bottom of leg accordingly.
A Die Fußhöhe mit einem 14-mm-(9/16") Maulschlüssel
durch Drehen des unteren Teils des Fußes verstellen.
A Ajuste la pata usando una llave de boca de 14 mm
(9/16") y girando la parte inferior de la pata en el
sentido correspondiente.
A Réglez les pieds avec une clé à fourche de 14 mm
(9/16"), en tournant à la base du pied dans le sens
désiré.
A Regolare la lunghezza del piedino girandone la parte
inferiore mediante una chiave fissa da 14 mm (9/16").
A De poot bijstellen met behulp van een steeksleutel van
14 mm (9/16") en de onderkant van de poot
dienovereenkomstig draaien.
A
B
C
D

Form No. GRSCEM-0108
5
CONTENTS
CAUTIONS
To avoid any injury or damage locate the unit at the
proper counter height, in an area that is convenient for
use. The location should be level to prevent the shelf
or its contents from accidentally falling, and strong
enough to support the weight of the unit and food.
Some exterior surfaces on the unit will get hot. Use
caution when touching these areas to avoid injury.
Unit is not weatherproof. For safe and proper operation
locate the unit indoors where the ambient air
temperature is a minimum of 21°C (70°F).
WARNINGS
To avoid any injury, turn the power switch off, unplug
the unit from the power source and allow to cool before
performing any maintenance or cleaning.
The Glo-Ray Heated Shelf is not waterproof. To avoid
any injury or damage to the unit DO NOT submerge or
saturate with water. Do not operate if it has been
submerged or saturated with water.
Plug unit into a grounded electrical outlet of the correct
voltage, size and plug configuration. If the plug and
receptacle do not match, contact a qualified electrician
to determine the proper voltage and size, and install the
proper electrical outlet.
INTRODUCTION
The Hatco Glo-Ray Heated Shelf is designed to keep prepared
foods hot at kitchen work areas, waitress pick-up stations or
customer serving points.
The Glo-Ray Heated Shelf keeps all foods at optimum serving
temperatures without affecting quality. This warmer has a
thermostat controlled heated base to extend the holding times
of most foods.
This manual provides the installation, safety and operating
instructions for the Glo-Ray Heated Shelf. We recommend all
installation, operating and safety instructions appearing in this
manual be read prior to installation or operation of your
Glo-Ray Heated Shelf. Safety instructions that appear in this
manual after a warning symbol and the words WARNING
or CAUTION printed in bold face are very important.
WARNING means there is the possibility of serious injury or
death to yourself or others. CAUTION means there is the
possibility of minor or moderate injury. The word NOTICE
without the symbol signifies the possibility of equipment or
property damage only.
Glo-Ray Heated Shelves are a product of extensive research
and field testing. The materials used were selected for
maximum durability, attractive appearance and optimum
performance. Every unit is thoroughly inspected and tested
prior to shipment.
IMPORTANT SAFETY INFORMATION
Illustrations.............................................................................i
Introduction ...........................................................................5
Important Safety Information...............................................5
Specifications........................................................................6
Plug Configurations........................................................6
Dimensions GRS Models ...............................................6
Dimensions GRSB Models.............................................7
Dimensions GRSBF Models ..........................................8
Electrical Rating Chart - GRS Models............................9
Electrical Rating Chart - GRSB Models .......................10
Electrical Rating Chart - GRSBF Models.....................12
Model Descriptions.............................................................13
GRS Model...................................................................13
GRSB & GRSBF Models..............................................13
Installation ...........................................................................14
GRS Models.................................................................14
GRSB & GRSBF Models..............................................14
Operation .............................................................................17
Maintenance ........................................................................17
Cleaning .......................................................................17
Accessories.........................................................................17
Hatco imited Warranty......................................................18
Important Owner Information..............................Back Cover
IMPORTANT! Read the following important safety information to avoid personal injury or death, and to avoid
damage to the equipment or property.

Form No. GRSCEM-0108 6
CAUTIONS
The National Sanitation Foundation (NSF) requires that
GRS Series units over 914 mm (36") in length or
weighing more than 36 kg (80 lbs.) to be either sealed
or raised on the installation surface. If this unit cannot
be sealed at the point of use, 102 mm (4") legs are
included to allow for proper cleaning access below
unit. See Hatco ACCESSORIES for installation
instructions.
NOTICES
Damage to non-metallic countertop material caused by
heat generated from Hatco equipment is not covered
under the Hatco warranty. Recommended for use in
metallic counters. For other surfaces, verify that the
material is suitable for temperature up to 82°C (180°F).
Use of excessive force when tightening mounting
screws may damage unit or countertop (GRSB &
GRSBF units).
Use only non-abrasive cleaners. Abrasive cleaners
could scratch the finish of your unit marring its
appearance and making it susceptible to soil
accumulation.
WARNINGS
For safe and proper operation, the unit must be located
a reasonable distance from combustible walls and
materials. If safe distances are not maintained,
discoloration or combustion could occur.
To avoid any injury or damage to the unit do not pull
unit by power cord.
To prevent any injury, discontinue use if power cord is
frayed or worn.
Do not lay unit on the side with the control panel or
damage to the unit could occur.
If service is required on this unit, contact your
Authorized Hatco Service Agent, or contact the Hatco
Service Department at 414-671-6350; International fax
414-671-3976.
This product has no “user” serviceable parts. To avoid
damage to the unit or injury to personnel, use only
Authorized Hatco Service Agents and Genuine Hatco
Replacement Parts when service is required.
Genuine Hatco Replacement Parts are specified to
operate safely in the environments in which they are
used. Some aftermarket or generic replacement parts
do not have the characteristics that will allow them to
operate safelyin Hatco equipment. It is essential to use
Hatco Replacement Parts when repairing Hatco
equipment. Failure to use Hatco Replacement Parts
may subject operators of the equipment to hazardous
electrical voltage, resulting in electrical
shock or burn.
IMPORTANT SAFETY INFORMATION
SPECIFICATIONS
P UG CONFIGURATIONS
Units are supplied from the factory with an electrical cord and
plug installed. Plugs are supplied according to the applications
as shown in 1 .
WARNING
Plug unit into a grounded electrical outlet of the correct
voltage, size and plug configuration. If the plug and
receptacle do not match, contact a qualified electrician to
determine the proper voltage and size, and install the
proper electrical outlet.
DIMENSIONS - GRS MODE S SEE 2
Model Width (A) Depth (B) Height (C)
GRS-18- 457 mm (18") 495 mm (19-1/2") 57 mm (2-1/4")†
GRS-24- 610 mm (24") 495 mm (19-1/2") 57 mm (2-1/4")†
GRS-30- 762 mm (30") 495 mm (19-1/2") 57 mm (2-1/4")†
GRS-36- 914 mm (36") 495 mm (19-1/2") 57 mm (2-1/4")†
GRS-42- 1067 mm (42") 495 mm (19-1/2") 133 mm (5-1/4")*
GRS-48- 1219 mm (48") 495 mm (19-1/2") 133 mm (5-1/4")*
GRS-54- 1372 mm (54") 495 mm (19-1/2") 133 mm (5-1/4")*
GRS-60- 1524 mm (60") 495 mm (19-1/2") 133 mm (5-1/4")*
GRS-66- 1676 mm (66") 495 mm (19-1/2") 133 mm (5-1/4")*
GRS-72- 1829 mm (72") 495 mm (19-1/2") 133 mm (5-1/4")*
† Height includes 25 mm (1") legs.
* Height includes 102 mm (4") legs.

Form No. GRSCEM-0108
7
SPECIFICATIONS
Model Width (A) Width (B) Width (C) Depth (D) Depth (E) Height (F) Height (G)
GRSB-24-F 648 mm (25-1/2") 610 mm (24") 179 mm (7-1/16") 394 mm (15-1/2") 432 mm (17") 73 mm (2-7/8") 52 mm (2-1/32")
GRSB-24- 648 mm (25-1/2") 610 mm (24") 179 mm (7-1/16") 495 mm (19-1/2") 533 mm (21") 73 mm (2-7/8") 52 mm (2-1/32")
GRSB-24-O 648 mm (25-1/2") 610 mm (24") 179 mm (7-1/16") 762 mm (30") 800 mm (31-1/2") 73 mm (2-7/8") 52 mm (2-1/32")
GRSB-30-F 800 mm (31-1/2") 762 mm (30") 179 mm (7-1/16") 394 mm (15-1/2") 432 mm (17") 73 mm (2-7/8") 52 mm (2-1/32")
GRSB-30- 800 mm (31-1/2") 762 mm (30") 179 mm (7-1/16") 495 mm (19-1/2") 533 mm (21") 73 mm (2-7/8") 52 mm (2-1/32")
GRSB-30-O 800 mm (31-1/2") 762 mm (30") 179 mm (7-1/16") 762 mm (30") 800 mm (31-1/2") 73 mm (2-7/8") 52 mm (2-1/32")
GRSB-36-F 953 mm (37-1/2") 914 mm (36") 179 mm (7-1/16") 394 mm (15-1/2") 432 mm (17") 73 mm (2-7/8") 52 mm (2-1/32")
GRSB-36- 953 mm (37-1/2") 914 mm (36") 179 mm (7-1/16") 495 mm (19-1/2") 533 mm (21") 73 mm (2-7/8") 52 mm (2-1/32")
GRSB-36-O 953 mm (37-1/2") 914 mm (36") 179 mm (7-1/16") 762 mm (30") 800 mm (31-1/2") 73 mm (2-7/8") 52 mm (2-1/32")
GRSB-42-F 1105 mm (43-1/2") 1067 mm (42") 179 mm (7-1/16") 394 mm (15-1/2") 432 mm (17") 73 mm (2-7/8") 52 mm (2-1/32")
GRSB-42- 1105 mm (43-1/2") 1067 mm (42") 179 mm (7-1/16") 495 mm (19-1/2") 533 mm (21") 73 mm (2-7/8") 52 mm (2-1/32")
GRSB-42-O 1105 mm (43-1/2") 1067 mm (42") 179 mm (7-1/16") 762 mm (30") 800 mm (31-1/2") 73 mm (2-7/8") 52 mm (2-1/32")
GRSB-48-F 1257 mm (49-1/2") 1219 mm (48") 179 mm (7-1/16") 394 mm (15-1/2") 432 mm (17") 73 mm (2-7/8") 52 mm (2-1/32")
GRSB-48- 1257 mm (49-1/2") 1219 mm (48") 179 mm (7-1/16") 495 mm (19-1/2") 533 mm (21") 73 mm (2-7/8") 52 mm (2-1/32")
GRSB-48-O 1257 mm (49-1/2") 1219 mm (48") 179 mm (7-1/16") 762 mm (30") 800 mm (31-1/2") 73 mm (2-7/8") 52 mm (2-1/32")
GRSB-54- 1410 mm (55-1/2") 1372 mm (54") 179 mm (7-1/16") 495 mm (19-1/2") 533 mm (21") 73 mm (2-7/8") 52 mm (2-1/32")
GRSB-60-F 1562 mm (61-1/2") 1524 mm (60") 179 mm (7-1/16") 394 mm (15-1/2") 432 mm (17") 73 mm (2-7/8") 52 mm (2-1/32")
GRSB-60- 1562 mm (61-1/2") 1524 mm (60") 179 mm (7-1/16") 495 mm (19-1/2") 533 mm (21") 73 mm (2-7/8") 52 mm (2-1/32")
GRSB-60-O 1562 mm (61-1/2") 1524 mm (60") 179 mm (7-1/16") 762 mm (30") 800 mm (31-1/2") 73 mm (2-7/8") 52 mm (2-1/32")
GRSB-66- 1715 mm (67-1/2") 1676 mm (66") 179 mm (7-1/16") 495 mm (19-1/2") 432 mm (17") 73 mm (2-7/8") 52 mm (2-1/32")
GRSB-72-F 1867 mm (73-1/2") 1829 mm (72") 179 mm (7-1/16") 394 mm (15-1/2") 432 mm (17") 73 mm (2-7/8") 52 mm (2-1/32")
GRSB-72- 1867 mm (73-1/2") 1829 mm (72") 179 mm (7-1/16") 495 mm (19-1/2") 533 mm (21") 73 mm (2-7/8") 52 mm (2-1/32")
GRSB-72-O 1867 mm (73-1/2") 1829 mm (72") 179 mm (7-1/16") 762 mm (30") 800 mm (31-1/2") 73 mm (2-7/8") 52 mm (2-1/32")
DIMENSIONS - GRSB MODE S SEE 3

Form No. GRSCEM-0108 8
SPECIFICATIONS
Model Width (A) Width (B) Width (C) Depth (D) Depth (E) Height (F) Height (G)
GRSBF-18-F 495 mm (19-1/2") 460 mm (18-3/32") 179 mm (7-1/16") 394 mm (15-1/2") 432 mm (17") 57 mm (2-1/4") 52 mm (2-1/32")
GRSBF-24-F 648 mm (25-1/2") 612 mm (24-3/32") 179 mm (7-1/16") 394 mm (15-1/2") 432 mm (17") 57 mm (2-1/4") 52 mm (2-1/32")
GRSBF-24- 648 mm (25-1/2") 612 mm (24-3/32") 179 mm (7-1/16") 495 mm (19-1/2") 533 mm (21") 57 mm (2-1/4") 52 mm (2-1/32")
GRSBF-24-S 648 mm (25-1/2") 612 mm (24-3/32") 179 mm (7-1/16") 610 mm (24") 648 mm (25-1/2") 57 mm (2-1/4") 52 mm (2-1/32")
GRSBF-24-O 648 mm (25-1/2") 612 mm (24-3/32") 179 mm (7-1/16") 762 mm (30") 800 mm (31-1/2") 57 mm (2-1/4") 52 mm (2-1/32")
GRSBF-30-F 800 mm (31-1/2") 764 mm (30-3/32") 179 mm (7-1/16") 394 mm (15-1/2") 432 mm (17") 57 mm (2-1/4") 52 mm (2-1/32")
GRSBF-30- 800 mm (31-1/2") 764 mm (30-3/32") 179 mm (7-1/16") 495 mm (19-1/2") 533 mm (21") 57 mm (2-1/4") 52 mm (2-1/32")
GRSBF-30-O 800 mm (31-1/2") 764 mm (30-3/32") 179 mm (7-1/16") 762 mm (30") 800 mm (31-1/2") 57 mm (2-1/4") 52 mm (2-1/32")
GRSBF-36-F 953 mm (37-1/2") 917 mm (36-3/32") 179 mm (7-1/16") 394 mm (15-1/2") 432 mm (17") 57 mm (2-1/4") 52 mm (2-1/32")
GRSBF-36- 953 mm (37-1/2") 917 mm (36-3/32") 179 mm (7-1/16") 495 mm (19-1/2") 533 mm (21") 57 mm (2-1/4") 52 mm (2-1/32")
GRSBF-36-S 953 mm (37-1/2") 917 mm (36-3/32") 179 mm (7-1/16") 610 mm (24") 648 mm (25-1/2") 57 mm (2-1/4") 52 mm (2-1/32")
GRSBF-36-O 953 mm (37-1/2") 917 mm (36-3/32") 179 mm (7-1/16") 762 mm (30") 800 mm (31-1/2") 57 mm (2-1/4") 52 mm (2-1/32")
GRSBF-42-F 1105 mm (43-1/2") 1069 mm (42-3/32") 179 mm (7-1/16") 394 mm (15-1/2") 432 mm (17") 57 mm (2-1/4") 52 mm (2-1/32")
GRSBF-42- 1105 mm (43-1/2") 1069 mm (42-3/32") 179 mm (7-1/16") 495 mm (19-1/2") 533 mm (21") 57 mm (2-1/4") 52 mm (2-1/32")
GRSBF-42-S 1105 mm (43-1/2") 1069 mm (42-3/32") 179 mm (7-1/16") 610 mm (24") 648 mm (25-1/2") 57 mm (2-1/4") 52 mm (2-1/32")
GRSBF-42-O 1105 mm (43-1/2") 1069 mm (42-3/32") 179 mm (7-1/16") 762 mm (30") 800 mm (31-1/2") 57 mm (2-1/4") 52 mm (2-1/32")
GRSBF-48-F 1257 mm (49-1/2") 1222 mm (48-3/32") 179 mm (7-1/16") 394 mm (15-1/2") 432 mm (17") 57 mm (2-1/4") 52 mm (2-1/32")
GRSBF-48- 1257 mm (49-1/2") 1222 mm (48-3/32") 179 mm (7-1/16") 495 mm (19-1/2") 533 mm (21") 57 mm (2-1/4") 52 mm (2-1/32")
GRSBF-48-S 1257 mm (49-1/2") 1222 mm (48-3/32") 179 mm (7-1/16") 610 mm (24") 648 mm (25-1/2") 57 mm (2-1/4") 52 mm (2-1/32")
GRSBF-48-O 1257 mm (49-1/2") 1222 mm (48-3/32") 179 mm (7-1/16") 762 mm (30") 800 mm (31-1/2") 57 mm (2-1/4") 52 mm (2-1/32")
GRSBF-60-F 1562 mm (61-1/2") 1526 mm (60-3/32") 179 mm (7-1/16") 394 mm (15-1/2") 432 mm (17") 57 mm (2-1/4") 52 mm (2-1/32")
GRSBF-60- 1562 mm (61-1/2") 1526 mm (60-3/32") 179 mm (7-1/16") 495 mm (19-1/2") 533 mm (21") 57 mm (2-1/4") 52 mm (2-1/32")
GRSBF-60-S 1562 mm (61-1/2") 1526 mm (60-3/32") 179 mm (7-1/16") 610 mm (24") 648 mm (25-1/2") 57 mm (2-1/4") 52 mm (2-1/32")
GRSBF-60-O 1562 mm (61-1/2") 1526 mm (60-3/32") 179 mm (7-1/16") 762 mm (30") 800 mm (31-1/2") 57 mm (2-1/4") 52 mm (2-1/32")
GRSBF-72-F 1867 mm (73-1/2") 1831 mm (72-3/32") 179 mm (7-1/16") 394 mm (15-1/2") 432 mm (17") 57 mm (2-1/4") 52 mm (2-1/32")
GRSBF-72- 1867 mm (73-1/2") 1831 mm (72-3/32") 179 mm (7-1/16") 495 mm (19-1/2") 533 mm (21") 57 mm (2-1/4") 52 mm (2-1/32")
GRSBF-72-S 1867 mm (73-1/2") 1831 mm (72-3/32") 179 mm (7-1/16") 610 mm (24") 648 mm (25-1/2") 57 mm (2-1/4") 52 mm (2-1/32")
GRSBF-72-O 1867 mm (73-1/2") 1831 mm (72-3/32") 179 mm (7-1/16") 762 mm (30") 800 mm (31-1/2") 57 mm (2-1/4") 52 mm (2-1/32")
DIMENSIONS - GRSBF MODE S SEE FIGURE 4

Form No. GRSCEM-0108
9
SPECIFICATIONS
E ECTRICA RATING CHART - STANDARD GRS MODE S
†All GRS models listed are based on 495 mm (19-1/2") heated depth. Additional depths available.
The electrical information in the shaded areas pertains to Export models only.
Plug Shipping
Model
†
Voltage Watts Amps Configuration Weight
GRS-18- 100 250 2.5 NEMA 5-15P 7 kg (16 lbs.)
120 250 2.1 NEMA 5-15P 7 kg (16 lbs.)
220 228 1.0 CEE 7/7 Schuko 7 kg (16 lbs.)
240 272 1.1 BS-1363 7 kg (16 lbs.)
220-230 CE 228-250 1.0-1.1 CEE 7/7 Schuko 7 kg (16 lbs.)
230-240 CE 250-272 1.1 BS-1363 7 kg (16 lbs.)
GRS-24- 100 350 3.5 NEMA 5-15P 9 kg (20 lbs.)
120 350 2.9 NEMA 5-15P 9 kg (20 lbs.)
220 320 1.5 CEE 7/7 Schuko 9 kg (20 lbs.)
240 380 1.6 BS-1363 9 kg (20 lbs.)
220-230 CE 320-350 1.5-1.6 CEE 7/7 Schuko 9 kg (20 lbs.)
230-240 CE 350-380 1.5-1.6 BS-1363 9 kg (20 lbs.)
GRS-30- 100 450 4.5 NEMA 5-15P 11 kg (25 lbs.)
120 450 3.8 NEMA 5-15P 11 kg (25 lbs.)
220 412 1.9 CEE 7/7 Schuko 11 kg (25 lbs.)
240 490 2.0 BS-1363 11 kg (25 lbs.)
220-230 CE 412-450 1.9-2.0 CEE 7/7 Schuko 11 kg (25 lbs.)
230-240 CE 450-490 2.0 BS-1363 11 kg (25 lbs.)
GRS-36- 100 550 5.5 NEMA 5-15P 13 kg (28 lbs.)
120 550 4.6 NEMA 5-15P 13 kg (28 lbs.)
220 504 2.3 CEE 7/7 Schuko 13 kg (28 lbs.)
240 598 2.5 BS-1363 13 kg (28 lbs.)
220-230 CE 504-550 2.3-2.4 CEE 7/7 Schuko 13 kg (28 lbs.)
230-240 CE 550-598 2.4-2.5 BS-1363 13 kg (28 lbs.)
GRS-42- 100 600 6.0 NEMA 5-15P 15 kg (32 lbs.)
120 600 5.0 NEMA 5-15P 15 kg (32 lbs.)
220 548 2.5 CEE 7/7 Schuko 15 kg (32 lbs.)
240 652 2.7 BS-1363 15 kg (32 lbs.)
220-230 CE 548-600 2.5-2.6 CEE 7/7 Schuko 15 kg (32 lbs.)
230-240 CE 600-652 2.6-2.7 BS-1363 15 kg (32 lbs.)
GRS-48- 100 700 7.0 NEMA 5-15P 16 kg (36 lbs.)
120 700 5.8 NEMA 5-15P 16 kg (36 lbs.)
220 640 3.0 CEE 7/7 Schuko 16 kg (36 lbs.)
240 760 3.2 BS-1363 16 kg (36 lbs.)
220-230 CE 640-700 3.0-3.1 CEE 7/7 Schuko 16 kg (36 lbs.)
230-240 CE 700-760 3.0-3.2 BS-1363 16 kg (36 lbs.)
GRS-54- 100 800 8.0 NEMA 5-15P 19 kg (42 lbs.)
120 800 6.7 NEMA 5-15P 19 kg (42 lbs.)
220 732 3.3 CEE 7/7 Schuko 19 kg (42 lbs.)
240 870 3.6 BS-1363 19 kg (42 lbs.)
220-230 CE 732-800 3.3-3.5 CEE 7/7 Schuko 19 kg (42 lbs.)
230-240 CE 800-870 3.5-3.6 BS-1363 19 kg (42 lbs.)
GRS-60- 100 900 9.0 NEMA 5-15P 20 kg (44 lbs.)
120 900 7.5 NEMA 5-15P 20 kg (44 lbs.)
220 824 3.7 CEE 7/7 Schuko 20 kg (44 lbs.)
240 980 4.1 BS-1363 20 kg (44 lbs.)
220-230 CE 824-900 3.7-3.9 CEE 7/7 Schuko 20 kg (44 lbs.)
230-240 CE 900-980 3.9-4.1 BS-1363 20 kg (44 lbs.)
GRS-66- 100 1000 10.0 NEMA 5-15P 23 kg (50 lbs.)
120 1000 8.3 NEMA 5-15P 23 kg (50 lbs.)
220 916 4.2 CEE 7/7 Schuko 23 kg (50 lbs.)
240 1088 4.5 BS-1363 23 kg (50 lbs.)
220-230 CE 916-1000 4.2-4.3 CEE-Schuko 23 kg (50 lbs.)
230-240 CE 1000-1088 4.3-4.5 BS-1363 23 kg (50 lbs.)
GRS-72- 100 1100 11.0 NEMA 5-15P 25 kg (56 lbs.)
120 1100 9.2 NEMA 5-15P 25 kg (56 lbs.)
220 1008 4.6 CEE 7/7 Schuko 25 kg (56 lbs.)
240 1196 5.0 BS-1363 25 kg (56 lbs.)
220-230 CE 1008-1100 4.6-4.8 CEE 7/7 Schuko 25 kg (56 lbs.)
230-240 CE 1100-1196 4.8-5.0 BS-1363 25 kg (56 lbs.)

Form No. GRSCEM-0108 10
SPECIFICATIONS
E ECTRICA RATING CHART - STANDARD GRSB MODE S
†All GRSB-F models listed are only available in 394 mm (15-1/2") heated depth.
All GRSB- models listed are only available in 495 mm (19-1/2") heated depth.
All GRSB-O models listed are only available in 762 mm (30") heated depth.
The electrical information in the shaded areas pertains to Export models only.
Plug Shipping
Model † Voltage Watts Amps Configuration Weight
GRSB-24-F 120 420 3.5 NEMA 5-15P 9 kg (20 lbs.)
220 384 1.7 CEE 7/7 Schuko 9 kg (20 lbs.)
240 458 1.9 BS-1363 9 kg (20 lbs.)
GRSB-24- 100 550 5.5 NEMA 5-15P 10 kg (22 lbs.)
120 550 4.6 NEMA 5-15P 10 kg (22 lbs.)
220 550 2.5 CEE 7/7 Schuko 10 kg (22 lbs.)
240 550 2.3 BS-1363 10 kg (22 lbs.)
220-230 CE 550-601 2.5-2.6 CEE 7/7 Schuko 10 kg (22 lbs.)
230-240 CE 505-550 2.2-2.3 BS-1363 10 kg (22 lbs.)
GRSB-24-O 120 790 6.6 NEMA 5-15P 12 kg (26 lbs.)
220 722 3.3 CEE 7/7 Schuko 12 kg (26 lbs.)
240 860 3.4 BS-1363 12 kg (26 lbs.)
GRSB-30-F 120 505 4.2 NEMA 5-15P 10 kg (23 lbs.)
220 462 2.1 CEE 7/7 Schuko 10 kg (23 lbs.)
240 550 2.3 BS-1363 10 kg (23 lbs.)
GRSB-30- 100 665 6.7 NEMA 5-15P 11 kg (25 lbs.)
120 665 5.6 NEMA 5-15P 11 kg (25 lbs.)
220 665 3.0 CEE 7/7 Schuko 11 kg (25 lbs.)
240 665 2.8 BS-1363 11 kg (25 lbs.)
220-230 CE 665-727 3.0-3.2 CEE 7/7 Schuko 11 kg (25 lbs.)
230-240 CE 611-665 2.7-2.8 BS-1363 11 kg (25 lbs.)
GRSB-30-O 120 950 7.9 NEMA 5-15P 13 kg (28 lbs.)
220 916 4.2 CEE 7/7 Schuko 13 kg (28 lbs.)
240 985 4.1 BS-1363 13 kg (28 lbs.)
GRSB-36-F 120 590 4.9 NEMA 5-15P 12 kg (26 lbs.)
220 540 2.5 CEE 7/7 Schuko 12 kg (26 lbs.)
240 642 2.7 BS-1363 12 kg (26 lbs.)
GRSB-36- 100 780 7.8 NEMA 5-15P 13 kg (29 lbs.)
120 780 6.5 NEMA 5-15P 13 kg (29 lbs.)
220 780 3.5 CEE 7/7 Schuko 13 kg (29 lbs.)
240 780 3.3 BS-1363 13 kg (29 lbs.)
220-230 CE 780-853 3.5-3.7 CEE 7/7 Schuko 13 kg (29 lbs.)
230-240 CE 716-780 3.1-3.3 BS-1363 13 kg (29 lbs.)
GRSB-36-O 120 1110 9.3 NEMA 5-15P 15 kg (32 lbs.)
220 1110 5.0 CEE 7/7 Schuko 15 kg (32 lbs.)
240 1110 4.6 BS-1363 15 kg (32 lbs.)
GRSB-42-F 120 685 5.7 NEMA 5-15P 13 kg (29 lbs.)
220 627 2.9 CEE 7/7 Schuko 13 kg (29 lbs.)
240 746 3.1 BS-1363 13 kg (29 lbs.)
GRSB-42- 100 885 8.9 NEMA 5-15P 15 kg (32 lbs.)
120 885 7.4 NEMA 5-15P 15 kg (32 lbs.)
220 885 4.0 CEE 7/7 Schuko 15 kg (32 lbs.)
240 885 3.7 BS-1363 15 kg (32 lbs.)
220-230 CE 885-967 4.0-4.2 CEE 7/7 Schuko 15 kg (32 lbs.)
230-240 CE 813-885 3.5-3.7 BS-1363 15 kg (32 lbs.)
GRSB-42-O 120 1270 10.6 NEMA 5-15P 16 kg (35 lbs.)
220 1236 5.6 CEE 7/7 Schuko 16 kg (35 lbs.)
240 1305 5.4 BS-1363 16 kg (35 lbs.)

Form No. GRSCEM-0108
11
SPECIFICATIONS
E ECTRICA RATING CHART - STANDARD GRSB MODE S
†All GRSB-F models listed are only available in 394 mm (15-1/2") heated depth.
All GRSB- models listed are only available in 495 mm (19-1/2") heated depth.
All GRSB-O models listed are only available in 762 mm (30") heated depth.
The electrical information in the shaded areas pertains to Export models only.
Plug Shipping
Model
† Voltage Watts Amps Configuration Weight
GRSB-48-F 120 770 6.4 NEMA 5-15P 15 kg (33 lbs.)
220 705 3.2 CEE 7/7 Schuko 15 kg (33 lbs.)
240 838 3.5 BS-1363 15 kg (33 lbs.)
GRSB-48- 100 1000 10.0 NEMA 5-15P 16 kg (36 lbs.)
120 1000 8.3 NEMA 5-15P 16 kg (36 lbs.)
220 1000 4.5 CEE 7/7 Schuko 16 kg (36 lbs.)
240 1000 4.2 BS-1363 16 kg (36 lbs.)
220-230 CE 1000-1093 4.5-4.7 CEE 7/7 Schuko 16 kg (36 lbs.)
230-240 CE 918-1000 4.0-4.2 BS-1363 16 kg (36 lbs.)
GRSB-48-O 120 1430 11.9 NEMA 5-15P 18 kg (39 lbs.)
220 1430 6.5 CEE 7/7 Schuko 18 kg (39 lbs.)
240 1430 6.0 BS-1363 18 kg (39 lbs.)
GRSB-54- 100 1110 11.1 NEMA 5-15P 19 kg (42 lbs.)
120 1110 9.3 NEMA 5-15P 19 kg (42 lbs.)
220 1110 5.0 CEE 7/7 Schuko 19 kg (42 lbs.)
240 1110 4.6 BS-1363 19 kg (42 lbs.)
220-230 CE 1110-1213 5.0-5.3 CEE 7/7 Schuko 19 kg (42 lbs.)
230-240 CE 1019-1110 4.4-4.6 BS-1363 19 kg (42 lbs.)
GRSB-60-F 120 950 7.9 NEMA 5-15P 20 kg (45 lbs.)
220 870 4.0 CEE 7/7 Schuko 20 kg (45 lbs.)
240 1034 4.3 BS-1363 20 kg (45 lbs.)
GRSB-60- 100 1220 12.2 NEMA 5-15P 23 kg (50 lbs.)
120 1220 10.2 NEMA 5-15P 23 kg (50 lbs.)
220 1220 5.5 CEE 7/7 Schuko 23 kg (50 lbs.)
240 1220 5.1 BS-1363 23 kg (50 lbs.)
220-230 CE 1220-1333 5.5-5.8 CEE 7/7 Schuko 23 kg (50 lbs.)
230-240 CE 1120-1220 4.9-5.1 BS-1363 23 kg (50 lbs.)
GRSB-60-O 120 1750 14.6 NEMA 5-20P 24 kg (54 lbs.)
220 1750 8.0 CEE 7/7 Schuko 24 kg (54 lbs.)
240 1750 7.3 BS-1363 24 kg (54 lbs.)
GRSB-66- 120 1330 11.1 NEMA 5-15P 24 kg (54 lbs.)
220 1330 6.0 CEE 7/7 Schuko 24 kg (54 lbs.)
240 1330 5.5 BS-1363 24 kg (54 lbs.)
220-230 CE 1330-1454 6.0-6.3 CEE 7/7 Schuko 24 kg (54 lbs.)
230-240 CE 1221-1330 5.3-5.5 BS-1363 24 kg (54 lbs.)
GRSB-72-F 120 1130 9.4 NEMA 5-15P 24 kg (52 lbs.)
220 1034 4.7 CEE 7/7 Schuko 24 kg (52 lbs.)
240 1230 5.1 BS-1363 24 kg (52 lbs.)
GRSB-72- 120 1440 12.0 NEMA 5-15P 26 kg (58 lbs.)
220 1440 6.5 CEE 7/7 Schuko 26 kg (58 lbs.)
240 1440 6.0 BS-1363 26 kg (58 lbs.)
220-230 CE 1440-1574 6.5-6.8 CEE 7/7 Schuko 26 kg (58 lbs.)
230-240 CE 1322-1440 5.8-6.0 BS-1363 26 kg (58 lbs.)
GRSB-72-O 208 2070 10.0 NEMA 6-15P 29 kg (64 lbs.)
240 2070 8.6 NEMA 6-15P 29 kg (64 lbs.)
220 2070 9.4 CEE 7/7 Schuko 29 kg (64 lbs.)
240 2070 8.6 BS-1363 26 kg (64 lbs.)

Form No. GRSCEM-0108 12
SPECIFICATIONS
†All GRSBF-F models listed are only available in 394 mm (15-1/2") heated depth.
All GRSBF- models listed are only available in 533 mm (21") heated depth.
All GRSBF-S models listed are only available in 610 mm (24") heated depth.
All GRSBF-O models listed are only available in 762 mm (30") heated depth.
The electrical information in the shaded areas pertains to Export models only.
E ECTRICA RATING CHART - STANDARD GRSBF MODE S
Plug Shipping
Model
†
Voltage Watts Amps Configuration Weight
GRSBF-18-F 120 330 2.8 NEMA 5-15P 7 kg (15 lbs.)
GRSBF-24-F 120 420 3.5 NEMA 5-15P 9 kg (20 lbs.)
GRSBF-24- 100 550 5.5 NEMA 5-15P 10 kg (22 lbs.)
120 550 4.6 NEMA 5-15P 10 kg (22 lbs.)
GRSBF-24-S 120 700 5.8 NEMA 5-15P 11 kg (24 lbs.)
220 640 2.9 CEE 7/7 Schuko 11 kg (24 lbs.)
240 762 3.2 BS-1363 11 kg (24 lbs.)
GRSBF-24-O 120 790 6.6 NEMA 5-15P 12 kg (26 lbs.)
GRSBF-30-F 120 505 4.2 NEMA 5-15P 10 kg (23 lbs.)
GRSBF-30- 100 665 6.7 NEMA 5-15P 11 kg (25 lbs.)
120 665 5.5 NEMA 5-15P 11 kg (25 lbs.)
GRSBF-30-O 120 950 7.9 NEMA 5-15P 13 kg (28 lbs.)
GRSBF-36-F 120 590 4.9 NEMA 5-15P 11 kg (25 lbs.)
GRSBF-36- 100 780 7.8 NEMA 5-15p 12 kg (26 lbs.)
120 780 6.5 NEMA 5-15P 12 kg (26 lbs.)
GRSBF-36-S 120 950 7.9 NEMA 5-15P 15 kg (31 lbs.)
220 870 4.0 CEE 7/7 Schuko 15 kg (31 lbs.)
240 1034 4.3 BS-1363 15 kg (31 lbs.)
GRSBF-36-O 120 1110 9.3 NEMA 5-15P 15 kg (32 lbs.)
240 1110 4.6 NEMA 6-15P 15 kg (32 lbs.)
220-230 CE 1110-1213 5.0-5.3 CEE 7/7 Schuko 15 kg (32 lbs.)
230-240 CE 1020-1110 4.4-4.6 BS-1363 15 kg (32 lbs.)
GRSBF-42-F 120 685 5.7 NEMA 5-15P 13 kg (29 lbs.)
GRSBF-42- 100 885 8.9 NEMA 5-15P 15 kg (32 lbs.)
120 885 7.4 NEMA 5-15P 15 kg (32 lbs.)
GRSBF-42-S 120 1100 9.2 NEMA 5-15P 15 kg (34 lbs.)
220 1006 4.6 CEE 7/7 Schuko 15 kg (34 lbs.)
240 1198 5.0 BS-1363 15 kg (34 lbs.)
GRSBF-42-O 120 1270 10.6 NEMA 5-15P 16 kg (35 lbs.)
GRSBF-48-F 120 770 6.4 NEMA 5-15P 15 kg (33 lbs.)
GRSBF-48- 100 1000 10.0 NEMA 5-15P 16 kg (36 lbs.)
120 1000 8.3 NEMA 5-15P 16 kg (36 lbs.)
GRSBF-48-S 120 1225 10.2 NEMA 5-15P 17 kg (38 lbs.)
220 1121 5.1 CEE 7/7 Schuko 17 kg (38 lbs.)
240 1334 5.6 BS-1363 17 kg (38 lbs.)
GRSBF-48-O 120 1430 11.9 NEMA 5-15P 18 kg (39 lbs.)
240 1430 6.0 NEMA 6-15P 18 kg (39 lbs.)
220-230 CE 1430-1562 6.5-6.8 CEE 7/7 Schuko 18 kg (39 lbs.)
230-240 CE 1313-1430 5.7-6.0 BS-1363 18 kg (39 lbs.)

Form No. GRSCEM-0108
13
SPECIFICATIONS
E ECTRICA RATING CHART - STANDARD GRSBF MODE S
†All GRSBF-F models listed are only available in 394 mm (15-1/2") heated depth.
All GRSBF- models listed are only available in 533 mm (21") heated depth.
All GRSBF-S models listed are only available in 610 mm (24") heated depth.
All GRSBF-O models listed are only available in 762 mm (30") heated depth.
The electrical information in the shaded areas pertains to Export models only.
Plug Shipping
Model
†
Voltage Watts Amps Configuration Weight
GRSBF-60-F 120 950 7.9 NEMA 5-15P 20 kg (45 lbs.)
GRSBF-60- 100 1220 12.2 NEMA 5-15P 23 kg (50 lbs.)
120 1220 10.2 NEMA 5-15P 23 kg (50 lbs.)
GRSBF-60-S 120 1500 12.5 NEMA 5-20P 24 kg (53 lbs.)
220 1372 6.2 CEE 7/7 Schuko 24 kg (53 lbs.)
240 1634 6.8 BS-1363 24 kg (53 lbs.)
GRSBF-60-O 120 1750 14.6 NEMA 5-20P 25 kg (54 lbs.)
240 1750 7.3 NEMA 6-15P 25 kg (54 lbs.)
220-230 CE 1750-1912 8.0-8.3 CEE 7/7 Schuko 25 kg (54 lbs.)
230-240 CE 1607-1750 7.0-7.3 BS-1363 25 kg (54 lbs.)
GRSBF-72-F 120 1130 9.4 NEMA 5-15P 24 kg (52 lbs.)
GRSBF-72- 100 1440 14.4 NEMA 5-15P 26 kg (58 lbs.)
120 1440 12.0 NEMA 5-15P 26 kg (58 lbs.)
GRSBF-72-S 120 1750 14.6 NEMA 5-20P 28 kg (62 lbs.)
220 1602 7.3 CEE 7/7 Schuko 28 kg (62 lbs.)
240 1906 7.9 BS-1363 28 kg (62 lbs.)
GRSBF-72-O 208 2070 10.0 NEMA 6-15P 29 kg (64 lbs.)
240 2070 8.6 NEMA 6-15P 29 kg (64 lbs.)
220-230 CE 2070-2262 9.4-9.8 CEE 7/7 Schuko 29 kg (64 lbs.)
230-240 CE 1901-2070 8.3-8.6 BS-1363 29 kg (64 lbs.)
MODE DESCRIPTIONS
GRS MODE (SEE FIGURE 5 )
The GRS Heated Shelf is ideal for pass-through areas, buffet
lines or as a heated work shelf. t features an on/off rocker
switch with indicator light, 60° to 82°C (140° to 180°F)
adjustable thermostat and 1829 mm (6') cord with plug.
Surface mounted foil elements distribute heat under the entire
stainless steel surface.
All GRS models are shipped from the factory completely
assembled and ready for use.
GRSB & GRSBF MODE S (SEE FIGURE 6 )
The GRSB and GRSBF Drop- n Heated Shelves have
a hardcoat aluminum top and a blanket-type foil element
for uniform heat distribution. deal for server-to-customer pass
through areas, buffet and cafeteria lines and other self-service
areas. The GRSB model features a recessed top. The GRSBF
model incorporates a flat design top.
A 914 mm (3') flexible conduit channels the power lines from
the shelf to a remote control box. The control box comes with
a control thermostat with a range of 27° to 93°C (80° to
200°F), an illuminated on/off switch and mounting brackets.
The attached control box can be located up to 914 mm (3')
from the unit. A 1829 mm (6’) cord and plug is attached to the
control box.
The Drop- n Heated Shelf has a 19 mm (3/4") flanged edge
that allows the unit to drop into a countertop opening. The shelf
is easy to clean with a soft damp cloth or non-abrasive cleaner.
All GRSB and GRSBF models are shipped from the factory
completely assembled and ready for use.
NOTICE
Use only non-abrasive cleaners. Abrasive cleaners could
scratch the finish of your Glo-Ray Heated Shelf marring its
appearance and making it susceptible to soil
accumulation.
CAUTION
The National Sanitation Foundation (NSF) requires that
GRS Series units over 914 mm (36") in length or weighing
more than 36 kg (80 lbs.) to be either sealed or raised
on the installation surface. If this unit cannot be sealed
at the point of use 102 mm (4") legs are included to allow
for proper cleaning access below unit. See Hatco
ACCESSORIES for installation instructions.

Form No. GRSCEM-0108 14
INSTA ATION
WARNING
For safe and proper operation, the unit must be located
a reasonable distance from combustible walls and
materials. If safe distances are not maintained,
discoloration or combustion could occur.
CAUTION
To avoid any injury or damage locate the unit at the proper
counter height, in an area that is convenient for use. The
location should be level to prevent the shelf or its contents
from accidentally falling, and strong enough to support
the weight of the unit and food.
CAUTION
The National Sanitation Foundation (NSF) requires that
GRS Series units over 914 mm (36") in length or weighing
more than 36 kg (80 lbs.) to be either sealed or raised
on the installation surface. If this unit cannot be sealed
at the point of use, 102 mm (4") legs are included to allow
for proper cleaning access below unit. See Hatco
ACCESSORIES for installation instructions.
WARNING
To avoid any injury or damage to the unit do not pull unit
by power cord.
WARNING
To prevent any injury, discontinue use if power cord is
frayed or worn.
GRS MODE S
1. Remove the unit from the carton and lay it upside down
on the cardboard.
2. nstall the four feet into the corner holes on the base.
Tighten securely but do not overtighten.
NOTE: If 102 mm (4") legs are required, see ACCESSOR ES
in this manual for installation instructions.
3. Place one rubber boot over each metal foot. (For 25 mm
(1") only.)
4. Turn unit upright and position warmer in desired location.
GRSB & GRSBF MODE S
1. Remove the unit from the carton and lay it upside down
on the cardboard.
2. Remove and save the four screws (8-32) from the
underside of the unit. See 7 .
NOTE: The control box may be moved to the most convenient
location on the underside of the unit. For semi-remote
installations, we recommend you leave the control in place until
the unit is placed into the countertop. See 9 .
NOTICE
Damage to non-metallic countertop material caused by
heat generated from Hatco equipment is not covered
under the Hatco warranty. Recommended for use in
metallic ounters. For other surfaces, verify that the
material is suitable for temperature up to 82°C (180°F).
3. Prepare countertop opening. (See Figure 8 for
recommended countertop cutout dimensions.)
4. Apply a bead of NSF (National Sanitation Foundation)
approved sealant between the countertop material and
mounting flange.
5. Place the unit into the countertop opening.
6. Assemble the Z-brackets to the underside of the unit using
the four screws removed in step 2.
NOTE: Units 1219 mm (48") or longer require two additional -
brackets installed midway along the front and rear of the unit.
7. Adjust the 1/4-20 screws on the Z-brackets until the top
flange lies flat on the countertop.
8. Remove any excess sealant.
NOTICE
Use of excessive force when tightening mounting screws
may damage unit or countertop (GRSB and GRSBF units).
9. f you wish to move the control box to a semi-remote
location, remove it from the bottom of the unit. f necessary,
remove the end brackets from the control box, rotate and
reposition them. The control box will require a hole
mounting pattern of 194 mm x 32 mm (7-5/8" x 1-1/4") for
#8 screws. See Figure 9 for mounting distances.
10. Once all components are secured, the unit may be plugged
in and turned on.
NOTE: A 1829 mm (6') cord is supplied with this appliance; any
excess cord should be neatly routed so it does not hang down.

Form No. GRSCEM-0108
15
INSTA ATION
COUNTERTOP CUTOUT SEE FIGURE 8
MODE MINIMUM WIDTH MAXIMUM WIDTH MINIMUM DEPTH MAXIMUM DEPTH
GRSB-24-F 622 mm (24-1/2") 629 mm (24-3/4") 406 mm (16") 413 mm (16-1/4")
GRSB-24- 622 mm (24-1/2") 629 mm (24-3/4") 508 mm (20") 514 mm (20-1/4")
GRSB-24-O 622 mm (24-1/2") 629 mm (24-3/4") 775 mm (30-1/2") 781 mm (30-3/4")
GRSB-30-F 775 mm (30-1/2") 781 mm (30-3/4") 406 mm (16") 413 mm (16-1/4")
GRSB-30- 775 mm (30-1/2") 781 mm (30-3/4") 508 mm (20") 514 mm (20-1/4")
GRSB-30-O 775 mm (30-1/2") 781 mm (30-3/4") 775 mm (30-1/2") 781 mm (30-3/4")
GRSB-36-F 927 mm (36-1/2") 934 mm (36-3/4") 406 mm (16") 413 mm (16-1/4")
GRSB-36- 927 mm (36-1/2") 934 mm (36-3/4") 508 mm (20") 514 mm (20-1/4")
GRSB-36-O 927 mm (36-1/2") 934 mm (36-3/4") 775 mm (30-1/2") 781 mm (30-3/4")
GRSB-42-F 1080 mm (42-1/2") 1086 mm (42-3/4") 406 mm (16") 413 mm (16-1/4")
GRSB-42- 1080 mm (42-1/2") 1086 mm (42-3/4") 508 mm (20") 514 mm (20-1/4")
GRSB-42-O 1080 mm (42-1/2") 1086 mm (42-3/4") 775 mm (30-1/2") 781 mm (30-3/4")
GRSB-48-F 1232 mm (48-1/2") 1238 mm (48-3/4") 406 mm (16") 413 mm (16-1/4")
GRSB-48- 1232 mm (48-1/2") 1238 mm (48-3/4") 508 mm (20") 514 mm (20-1/4")
GRSB-48-O 1232 mm (48-1/2") 1238 mm (48-3/4") 775 mm (30-1/2") 781 mm (30-3/4")
GRSB-54- 1384 mm (54-1/2") 1391 mm (54-3/4") 508 mm (20") 514 mm (20-1/4")
GRSB-60-F 1537 mm (60-1/2") 1543 mm (60-3/4") 406 mm (16") 413 mm (16-1/4")
GRSB-60- 1537 mm (60-1/2") 1543 mm (60-3/4") 508 mm (20") 514 mm (20-1/4")
GRSB-60-O 1537 mm (60-1/2") 1543 mm (60-3/4") 775 mm (30-1/2") 781 mm (30-3/4")
GRSB-66- 1689 mm (66-1/2") 1696 mm (66-3/4") 508 mm (20") 514 mm (20-1/4")
GRSB-72-F 1842 mm (72-1/2") 1848 mm (72-3/4") 406 mm (16") 413 mm (16-1/4")
GRSB-72- 1842 mm (72-1/2") 1848 mm (72-3/4") 508 mm (20") 514 mm (20-1/4")
GRSB-72-O 1842 mm (72-1/2") 1848 mm (72-3/4") 775 mm (30-1/2") 781 mm (30-3/4")

Form No. GRSCEM-0108 16
COUNTERTOP CUTOUT SEE FIGURE 8
MODE MINIMUM WIDTH MAXIMUM WIDTH MINIMUM DEPTH MAXIMUM DEPTH
GRSBF-18-F 470 mm (18-1/2") 476 mm (18-3/4") 406 mm (16") 413 mm (16-1/4")
GRSBF-24-F 622 mm (24-1/2") 629 mm (24-3/4") 406 mm (16") 413 mm (16-1/4")
GRSBF-24- 622 mm (24-1/2") 629 mm (24-3/4") 508 mm (20") 514 mm (20-1/4")
GRSBF-24-S 622 mm (24-1/2") 629 mm (24-3/4") 622 mm (24-1/2") 629 mm (24-3/4")
GRSBF-24-O 622 mm (24-1/2") 629 mm (24-3/4") 775 mm (30-1/2") 781 mm (30-3/4")
GRSBF-30-F 775 mm (30-1/2") 781 mm (30-3/4") 406 mm (16") 413 mm (16-1/4")
GRSBF-30- 775 mm (30-1/2") 781 mm (30-3/4") 508 mm (20") 514 mm (20-1/4")
GRSBF-30-O 775 mm (30-1/2") 781 mm (30-3/4") 775 mm (30-1/2") 781 mm (30-3/4")
GRSBF-36-F 927 mm (36-1/2") 934 mm (36-3/4") 406 mm (16") 413 mm (16-1/4")
GRSBF-36- 927 mm (36-1/2") 934 mm (36-3/4") 508 mm (20") 514 mm (20-1/4")
GRSBF-36-S 927 mm (36-1/2") 934 mm (36-3/4") 622 mm (24-1/2") 629 mm (24-3/4")
GRSBF-36-O 927 mm (36-1/2") 934 mm (36-3/4") 775 mm (30-1/2") 781 mm (30-3/4")
GRSBF-42-F 1080 mm (42-1/2") 1086 mm (42-3/4") 406 mm (16") 413 mm (16-1/4")
GRSBF-42- 1080 mm (42-1/2") 1086 mm (42-3/4") 508 mm (20") 514 mm (20-1/4")
GRSBF-42-S 1080 mm (42-1/2") 1086 mm (42-3/4") 622 mm (24-1/2") 629 mm (24-3/4")
GRSBF-42-O 1080 mm (42-1/2") 1086 mm (42-3/4") 775 mm (30-1/2") 781 mm (30-3/4")
GRSBF-48-F 1232 mm (48-1/2") 1238 mm (48-3/4") 406 mm (16") 413 mm (16-1/4")
GRSBF-48- 1232 mm (48-1/2") 1238 mm (48-3/4") 508 mm (20") 514 mm (20-1/4")
GRSBF-48-S 1232 mm (48-1/2") 1238 mm (48-3/4") 622 mm (24-1/2") 629 mm (24-3/4")
GRSBF-48-O 1232 mm (48-1/2") 1238 mm (48-3/4") 775 mm (30-1/2") 781 mm (30-3/4")
GRSBF-60-F 1537 mm (60-1/2") 1543 mm (60-3/4") 406 mm (16") 413 mm (16-1/4")
GRSBF-60- 1537 mm (60-1/2") 1543 mm (60-3/4") 508 mm (20") 514 mm (20-1/4")
GRSBF-60-S 1537 mm (60-1/2") 1543 mm (60-3/4") 622 mm (24-1/2") 629 mm (24-3/4")
GRSBF-60-O 1537 mm (60-1/2") 1543 mm (60-3/4") 775 mm (30-1/2") 781 mm (30-3/4")
GRSBF-72-F 1842 mm (72-1/2") 1848 mm (72-3/4") 406 mm (16") 413 mm (16-1/4")
GRSBF-72- 1842 mm (72-1/2") 1848 mm (72-3/4") 508 mm (20") 514 mm (20-1/4")
GRSBF-72-S 1842 mm (72-1/2") 1848 mm (72-3/4") 622 mm (24-1/2") 629 mm (24-3/4")
GRSBF-72-O 1842 mm (72-1/2") 1848 mm (72-3/4") 775 mm (30-1/2") 781 mm (30-3/4")
INSTA ATION

Form No. GRSCEM-0108
17
OPERATION
MAINTENANCE
CAUTION
Some exterior surfaces on the unit will get hot. Use
caution when touching these areas to avoid injury.
CAUTION
Unit is not weatherproof. For safe and proper operation
locate the unit indoors where the ambient air temperature
is a minimum of 21°C (70°F).
1. Plug warmer into a properly grounded electrical outlet of
the correct voltage, size and plug configuration. See
SPECIFICATIONS for details.
2. Place the Power Switch in the ON position. See Figures
10 and 11 .
3. Turn the thermostat to the desired temperature settings.
4. Allow unit 30 minutes to reach operating temperature.
ACCESSORIES
102 MM (4") ADJUSTAB E EGS
(GRS MODE S)
NOTE: 102 mm (4") legs are standard on models
1067 mm (42") and wider.
Carefully lay unit on its side. nstall legs to bottom of unit as
shown in Figure 12 . Hand tighten legs until snug. Do not
overtighten. Return unit to the upright position.
C EANING
The Hatco Glo-Ray Heated Shelf units are designed for
maximum durability and performance, with minimum
maintenance.
WARNING
To avoid any injury, turn the power switch OFF, unplug the
unit from the power source and allow to cool before
performing any maintenance.
WARNING
The Glo-Ray Heated Shelf is not waterproof. To avoid any
injury or damage to the unit DO NOT submerge or saturate
with water. Do not operate if it has been submerged or
saturated with water.
To preserve the finish of the Glo-Ray Heated Shelf, it is
recommended that the surfaces be wiped daily with a damp
cloth. Stubborn stains may be removed with a good stainless
steel cleaner or a non-abrasive cleaner. Hard to reach areas
should be cleaned with a small brush and mild soap.
NOTICE
Use only non-abrasive cleaners. Abrasive cleaners could
scratch the finish of your Glo-Ray Heated Shelf marring its
appearance and making it susceptible to soil
accumulation.
WARNING
If service is required on this unit, contact your Authorized
Hatco Service Agent, or contact the Hatco Service
Department at 414-671-6350; International fax
414-671-3976.
WARNING
This product has no “user” serviceable parts. To avoid
damage to the unit or injury to personnel, use only
Authorized Hatco Service Agents and Genuine Hatco
Replacement Parts when service is required.
WARNING
Genuine Hatco Replacement Parts are specified to operate
safely in the environments in which they are used. Some
aftermarket or generic replacement parts do not have the
characteristics that will allow them to operate safely in
Hatco equipment. It is essential to use Hatco Replacement
Parts when repairing Hatco equipment. Failure to use
Hatco Replacement Parts may subject operators of the
equipment to hazardous electrical voltage, resulting in
electrical shock or burn.
WARNING
Do not lay unit on the side with the control panel or
damage to unit could occur.
NOTE: Legs are adjustable for leveling the unit. Use a 14 mm
(9/16") open-end wrench to make leveling adjustments once
the unit is placed in final position.

Form No. GRSCEM-0108 18
HATCO IMITED WARRANTY
1. PRODUCT WARRANTY
Hatco warrants the products that it manufactures (the
“Products”) to be free from defects in materials and
workmanship, under normal use and service, for a period of
one (1) year from the date of purchase when installed and
maintained in accordance with Hatco’s written instructions or
18 months from the date of shipment from Hatco. Buyer must
establish the product’s purchase date by returning Hatco’s
Warranty Registration Card or by other means satisfactory to
Hatco in its sole discretion.
Hatco warrants the following Product components to be free
from defects in materials and workmanship from the date of
purchase (subject to the foregoing conditions) for the period(s)
of time and on the conditions listed below:
a) One (1) Year Parts and abor P US One (1)
Additional Year Parts-Only Warranty:
Toaster Elements (metal sheathed)
Drawer Warmer Elements (metal sheathed)
Drawer Warmer Drawer Rollers and Slides
Food Warmer Elements (metal sheathed)
Display Warmer Elements (metal sheathed air heating)
Holding Cabinet Elements (metal sheathed air heating)
b) One (1) Year Parts and abor P US Four (4)
Additional Years Parts-Only Warranty on
pro-rated terms that Hatco will explain at
Buyer’s Request:
3CS and FR Tanks
c) One (1) Year Parts and abor P US Nine (9) Years
Parts-Only Warranty on:
Electric Booster Heater Tanks
Gas Booster Heater Tanks
THE FOREGO NG WARRANT ES ARE EXCLUS VE AND N
L EU OF ANY OTHER WARRANTY, EXPRESSED OR
MPL ED, NCLUD NG BUT NOT L M TED TO ANY MPL ED
WARRANTY OF MERCHANTAB L TY OR F TNESS FOR A
PART CULAR PURPOSE OR PATENT OR OTHER
NTELLECTUAL PROPERTY R GHT NFR NGEMENT.
Without limiting the generality of the foregoing, SUCH
WARRANT ES DO NOT COVER: Coated incandescent light
bulbs, fluorescent lights, lamp warmer heat bulbs, glass
components, Product failure in booster tank, fin tube heat
exchanger, or other water heating equipment, caused by
liming, sediment buildup, chemical attack or freezing, Product
misuse, tampering or misapplication, improper installation, or
application of improper voltage.
2. IMITATION OF REMEDIES AND DAMAGES
Hatco’s liability and Buyer’s exclusive remedy hereunder will
be limited solely, at Hatco’s option, to repair or replacement by
a Hatco-authorized service agency (other than where Buyer is
located outside of the United States, Canada, United Kingdom
or Australia in which case Hatco’s liability and Buyer’s
exclusive remedy hereunder will be limited solely to
replacement of part under warranty) with respect to any claim
made within the applicable warranty period referred to above.
Hatco reserves the right to accept or reject any such claim in
whole or in part. Hatco will not accept the return of any Product
without prior written approval from Hatco, and all such
approved returns shall be made at Buyer’s sole expense.
HATCO W LL NOT BE L ABLE, UNDER ANY
C RCUMSTANCES, FOR CONSEQUENT AL OR
NC DENTAL DAMAGES, NCLUD NG BUT NOT L M TED TO
LABOR COSTS OR LOST PROF TS RESULT NG FROM THE
USE OF OR NAB L TY TO USE THE PRODUCTS OR FROM
THE PRODUCTS BE NG NCORPORATED N OR
BECOM NG A COMPONENT OF ANY OTHER PRODUCT OR
GOODS.
