Hatco Burger King Glo-Ray GRSDS Series Installation instructions

Burger KingTM
Glo-Ray®Sandwich Display Warmer
GRSDS Series
Installation & Operating Manual &
Replacement Parts List
I&W #07.05.180.00
This manual contains important safety information
concerning the maintenance, use and operation of this
product. Failure to follow the instructions contained in this
manual may result in serious injury. If you’re unable to
understand the contents of this manual, please bring it to
the attention of your supervisor. Do not operate this
equipment unless you have read and understood the
contents of this manual.
Este manual contiene importante información sobre
seguridad concerniente al mantenimiento, uso y
operación de este producto. Cualquier falla en el
seguimiento de las instrucciones contenidas en este
manual puede resultar en un serio daño. Si usted no
puede entender el contenido de este manual por
favor pregunte a su supervisor. No opere este
equipo al menos que haya leído y comprendido el
contenido de este manual.

Form No. GRSDSDBKM-0407 i
CONTENTS
your Display Warmer. Safety instructions that appear
in this manual after a warning symbol and the
words WARNING or CAUTION printed in bold face
are very important. WARNING means there is the
possibility of serious injury or death to yourself or
others. CAUTION means there is the possibility
of minor or moderate injury. NOTICE without the
symbol signifies the possibility of equipment or
property damage only.
The Burger King Glo-Ray Sandwich Display Warmer
is a product of extensive research and field testing.
The materials used were selected for maximum
durability, attractive appearance and optimum
performance. Every unit is thoroughly inspected and
tested prior to shipment.
INTRODUCTION
The Burger King Glo-Ray Sandwich Display
Warmers, are perfect for holding wrapped
sandwiches or boxed foods on a buffet line or at
temporary serving areas. These warmers hold hot
wrapped products and keep them at optimum
serving temperatures without affecting quality.
Prefocused infrared heat from above and
thermostatically controlled heat extends the holding
times of most wrapped food. The infrared heating
elements are guaranteed against burnout and
breakage for two years. These units also feature
incandescent lights along with a cord and plug set.
This manual provides the installation, safety and
operating instructions for the Glo-Ray Sandwich
Display Warmers. We recommend all installation,
operating and safety instructions appearing in this
manual be read prior to installation or operation of
Important Owner Information...............................i
Introduction ...........................................................i
Important Safety Information..............................1
Model Description................................................2
Specifications.......................................................2
Plug Configurations.........................................2
Dimensions......................................................2
Electrical Rating Chart ....................................3
Installation ............................................................4
Unpacking .......................................................4
Location...........................................................4
Operation..............................................................5
General............................................................5
Maintenance .........................................................6
Cleaning..........................................................6
Display Light Bulb Replacement.....................6
Accessories..........................................................7
Replacement Parts List .......................................8
Hatco Limited Warranty.....................................11
Authorized Parts Distributors............Back Cover
IMPORTANT OWNER INFORMATION
Record the model number, serial number
(identification plate located on the rear of the unit),
voltage and purchase date of your Glo-Ray®
Sandwich Display Warmer in the spaces below.
Please have this information available when calling
Hatco for service assistance.
Model No. ________________________________
Serial No. ________________________________
Voltage __________________________________
Date of Purchase __________________________
Business 8:00 a.m. to 5:00 p.m.
Hours: Central Standard Time
(Summer Hours: June to September –
8:00 a.m. to 5:00 p.m. C.D.T.
Monday through Thursday
8:00 a.m. to 2:30 p.m. C.D.T. Friday)
Telephone: [phone]
Fax: [phone] (Parts & Service)
[phone] (International)
Additional information can be found by visiting our
web site at www.hatcocorp.com.
24 Hour 7 Day Parts & Service
Assistance available in the
United States and Canada
by calling [phone].

Form No. GRSDSDBKM-0407
1
IMPORTANT SAFETY INFORMATION
Genuine Hatco Replacement Parts are
specified to operate safely in the
environments in which they are used. Some
aftermarket or generic replacement parts do
not have the characteristics that will allow
them to operate safely in Hatco equipment. It
is essential to use Hatco Replacement Parts
when repairing Hatco equipment. Failure to
use Hatco Replacement Parts may subject
operators of the equipment to hazardous
electrical voltage, resulting in electrical shock
or burn.
CAUTIONS
Unit is not weatherproof. For safe and proper
operation, locate the unit indoors where the
ambient air temperature is constant and is a
minimum of 70°F (21°C).
To avoid any injury or damage, locate the unit
at the proper counter height, in an area that is
convenient for use. The location should be
level to prevent the unit or its contents from
accidentally falling, and strong enough to
support the weight of the unit and food.
Do not lay unit on the side with the control
panel or damage to unit could occur.
NOTICE
Use only non-abrasive cleaners. Abrasive
cleaners could scratch the finish of your unit,
marring its appearance and making it
susceptible to dirt accumulation.
WARNINGS
To avoid any injury, turn the power switch
OFF unplug the unit from the power source
and allow to cool completely before
performing any maintenance and cleaning.
Plug unit into a properly grounded electrical
outlet of the correct voltage, size and plug
configuration. If the plug and receptacle do
not match, contact a qualified electrician to
determine the proper voltage and size and
install the proper electrical outlet.
To avoid electrical shock or personal injury,
do not steam clean or use excessive water on
the unit.
To prevent any injury or damage to the unit
do not pull unit by power cord.
To prevent any injury, discontinue use if
power cord is frayed or worn.
Unit is not waterproof. DO NOT submerge in
water. Do not operate if unit has been
submerged in water.
Some exterior surfaces on the unit will get
hot. Use caution when touching these areas
to avoid injury.
For safe and proper operation, the unit must
be located a minimum of 1" (25 mm) from
combustible walls and materials. If safe
distances are not maintained, discoloration or
combustion could occur.
Only light bulbs which meet or exceed NSF
standards, specifically designed for food
holding areas may be used. Breakage of light
bulbs not specially coated could result in
personal injury and/or food contamination.
If service is required on this unit, contact your
Authorized Hatco Service Agent, or contact
the Hatco Service Department at 800-558-
0607 or 414-671-6350; fax [phone] or
International fax [phone].
This product has no “user” serviceable parts.
To avoid damage to the unit or injury to
personnel, use only Authorized Hatco Service
Agents and Genuine Hatco Parts when
service is required.
IMPORTANT! Read the following important safety information to avoid personal injury or
death, and to avoid damage to the equipment or property.

Form No. GRSDSDBKM-0407 2
MODEL DESCRIPTION
SPECIFICATIONS
ALL MODELS
The Burger King Glo-Ray®Sandwich Display
Warmers are constructed of aluminum and features
temperature controlled heated slanted shelves. The
slanted shelves, incandescent lights, and product
divider bars provide an ideal holding area for
wrapped foods. The infrared heating elements
provide optimum serving temperatures. All models
are equipped with legs and a cord and plug set.
These models can be ordered in various widths, 36"
(914 mm), 41" (1041 mm) and 52" (1321 mm).
Optional 4" (102 mm) adjustable legs are available. Figure 1. GRSDS-36DBK Model
PLUG CONFIGURATIONS
Units are supplied from the factory with an electrical
cord and plug installed. Plugs are supplied
according to the applications. (See Figure 2.)
WARNING
Plug unit into a properly grounded electrical
outlet of the correct voltage, size and plug
configuration. If the plug and receptacle do not
match, contact a qualified electrician to
determine the proper voltage and size and install
the proper electrical outlet.
Figure 2. Plug Configurations
NEMA 5-15P
BS 1363
NEMA 5-20P
CEE 7/7 Schuko
*Receptacle not supplied by Hatco.
**
**
DIMENSIONS
Width Depth Height
Model (A) (B) (C)
GRSDS-36DBK 36" 24" 29-3/8"
(914 mm) (610 mm) (746 mm)
GRSDS-41DBK 41" 24" 29-3/8"
(1041 mm) (610 mm) (746 mm)
GRSDS-52DBK 52" 24" 29-3/8"
(1321 mm) (610 mm) (746 mm)
Figure 3. Dimensions - GRSDS Series
B
A
C

Form No. GRSDSDBKM-0407
3
SPECIFICATIONS
ELECTRICAL RATING CHART
NOTE: Shipping weight includes packaging.
NOTE: Units listed with two circuits, Circuit 1 & Circuit 2, have two power cords attached and require two separate
receptacles.
Model Voltage Watts Amps Plug Configuration Shipping Weight
GRSDS-36DBK 120 1980 16.5 NEMA 5-20P 216 lbs. (98 kg)
220 1920 8.7 CEE 7/7 Schuko 216 lbs. (98 kg)
240 1980 8.3 BS 1363 216 lbs. (98 kg)
GRSDS-41DBK 120 1100 9.2 NEMA 5-15P 240 lbs. (109 kg)
(Circuit 1)
1160 9.7 NEMA 5-15P
(Circuit 2)
220 1070 4.9 CEE 7/7 Schuko 240 lbs. (109 kg)
(Circuit 1)
1130 5.1 CEE 7/7 Schuko
(Circuit 2)
240 1100 4.6 BS 1363 240 lbs. (109 kg)
(Circuit 1)
1160 4.8 BS 1363
(Circuit 2)
GRSDS-52DBK 120 1405 11.7 NEMA 5-15P 275 lbs. (125 kg)
(Circuit 1)
1480 12.3 NEMA 5-15P
(Circuit 2)
220 1365 6.2 CEE 7/7 Schuko 275 lbs. (125 kg)
(Circuit 1)
1440 6.5 CEE 7/7 Schuko
(Circuit 2)
240 1405 5.9 BS 1363 275 lbs. (125 kg)
(Circuit 1)
1480 6.2 BS 1363
(Circuit 2)
The electrical information in the shaded areas pertains to Export models only.

Form No. GRSDSDBKM-0407 4
INSTALLATION
UNPACKING
The Burger King Glo-Ray®Sandwich Display
Warmer is shipped with all components pre-
assembled. Care should be taken when unpacking
shipping carton to avoid damage to unit and
components enclosed.
WARNING
To prevent any injury or damage to the unit do
not pull unit by power cord.
WARNING
To prevent any injury, discontinue use if power
cord is frayed or worn.
1. Remove the unit from the carton.
2. Remove information packet. To prevent delay
in obtaining warranty coverage, fill out and
mail in the warranty card.
3. Remove tape and protective packaging from all
surfaces of unit.
CAUTION
Do not lay unit on the side with the control panel
or damage to the unit could occur.
4. Carefully lay unit on a side without the controls
(requires two people). Install rubber feet to each
leg, then install one leg in each corner of the
cabinet bottom. Return unit to the upright
position. (See Figure 4.)
5. This unit is supplied with product divider bars. To
install them, simply place the bars in the
channels provided. The bars can be readily
adjusted to separate the holding areas as
needed. (See Figure 5.)
Figure 5. Installing Product Divider Bars
Figure 4. Leg Installation
Product Divider Bar
LOCATION
For proper operation and maximum performance,
locate the unit in an area where the ambient air
temperature is constant and is a minimum of 70°F
(21°C). Areas which are susceptible to active air
movements or currents should be avoided, i.e., near
exhaust fans or hoods and air conditioning ducts.
WARNING
For safe and proper operation, the unit must be
located a minimum of 1" (25 mm) from
combustible walls and materials. If safe
distances are not maintained, discoloration or
combustion could occur.
CAUTION
Unit is not weatherproof. For safe and proper
operation, locate the unit indoors where the
ambient air temperature is constant and is a
minimum of 70°F (21°C).
CAUTION
To avoid any injury or damage, locate the unit at
the proper counter height, in an area that is
convenient for use. The location should be level
to prevent the unit or its contents from
accidentally falling, and strong enough to
support the weight of the unit and food
displayed.

Form No. GRSDSDBKM-0407
5
OPERATION
Figure 6. Control Panel
ON ON
OFF OFF
°F
SP1
TEMP
SP1
°F
SP1
TEMP
SP1
On/Off Toggle Switch
Setpoint Screw
Mode Switch
GENERAL WARNING
Unit is not waterproof. DO NOT submerge in
water. Do not operate if it has been submerged
in water.
WARNING
Some exterior surfaces on the unit will get hot.
Use caution when touching these areas to avoid
injury.
1. Plug unit into a properly grounded electrical
outlet of the correct voltage, size and plug
configuration. See SPECIFICATIONS for details.
2. Turn the two toggle switches on the control panel
to the ON position. (See Figure 6.)
3. Adjust the Temperature Controllers as follows:
To set temperature, turn the red Mode Switch
counterclockwise to the SP-1 position indicated
on the controller.
Adjust the Setpoint Screw to the desired
temperature and turn the red Mode Switch to the
TEMP position. The surface temperature range
is room temperature to 200°F (93.3°C). See
BURGER KING OPERATIONS MANUAL for
recommended setpoint.
4. Allow 15-20 minutes for unit to reach operating
temperature.

MAINTENANCE
Form No. GRSDSDBKM-0407 6
CLEANING
The Sandwich Display Warmer is designed for
maximum durability and performance, with minimum
maintenance.
WARNING
To avoid any injury, turn the power switch OFF
unplug the unit from the power source and allow
to cool completely before performing any
maintenance and cleaning.
WARNING
Units are not waterproof. DO NOT submerge in
water. Do not operate if unit has been
submerged in water.
To preserve the bright finish of the Display Warmer,
it is recommended that the exterior and interior
surfaces be wiped daily with a damp cloth. Stubborn
stains may be removed with a good stainless steel
cleaner or a non-abrasive cleaner. Hard-to-reach
areas should be cleaned with a small brush and mild
soap.
WARNING
To avoid electrical shock or personal injury, do
not steam clean or use excessive water on the
unit.
NOTICE
Use only non-abrasive cleaners. Abrasive
cleaners could scratch the finish of your unit
cabinet marring its appearance and making it
susceptible to soil accumulation.
DISPLAY LIGHT BULB REPLACEMENT
The display light is an incandescent light bulb which
illuminates the warming area. The bulb has a
special coating to guard against injury and food
contamination in the event of breakage.
1. To replace a light bulb, disconnect the power
supply and wait until the unit has cooled.
2. Light bulbs have a threaded base. Unscrew the
light bulb from the unit and replace it with a new
specially-coated incandescent light bulb.
Note: Hatco shatter-resistant light bulbs meet NSF
standards for food holding and display areas. For
120, 120/208 and 120/240 volt applications, use
Hatco part number 02.30.043.00. For 220 or 240
volt applications, use Hatco part number
02.30.058.00.
WARNING
Only light bulbs which meet or exceed NSF
standards, specifically designed for food
holding areas may be used. Breakage of light
bulbs not specially coated could result in
personal injury and/or food contamination.
WARNING
If service is required on this unit, contact your
Authorized Hatco Service Agent, or contact the
Hatco Service Department at 800-558-0607 or
414-671-6350; fax [phone] or International
fax [phone].
WARNING
This product has no “user” serviceable parts. To
avoid damage to the unit or injury to personnel,
use only Authorized Hatco Service Agents and
Genuine Hatco Parts when service is required.
WARNING
Genuine Hatco Replacement Parts are specified
to operate safely in the environments in which
they are used. Some aftermarket or generic
replacement parts do not have the
characteristics that will allow them to operate
safely in Hatco equipment. It is essential to use
Hatco Replacement Parts when repairing Hatco
equipment. Failure to use Hatco Replacement
Parts may subject operators of the equipment to
hazardous electrical voltage, resulting in
electrical shock or burn.

Form No. GRSDSDBKM-0407
7
ACCESSORIES
Figure 7. Adjustable Legs
4" (102 MM) ADJUSTABLE LEGS
CAUTION
Do not lay unit on the side with the control panel
or damage to unit could occur.
Carefully lay unit on its side. Install legs to bottom of
unit. (See Figure 7.) Hand tighten legs until snug. Do
not overtighten. Return unit to the upright position.
NOTE: Legs are adjustable for leveling the unit. Use
a 5/8" (16 mm) open-end wrench to make leveling
adjustments once the unit is placed in final position.
Leg Adjustment
Adjust leg using a
5/8" (16 mm) open-
end wrench and
turning bottom of leg
accordingly.
Leg Installation

Form No. GRSDSDBKM-0407 8
REPLACEMENT PARTS LIST
ON
OFF
ON
OFF
1
5
413
15 16
14
18
12
10
19
9
3
11
20
21
17
2
Burger King Glo-Ray®Sandwich
Display Warmer GRSDS Series
CAUTION - Use of replacement parts other
than those supplied by Hatco Corporation
may result in damage to the unit or injury
to personnel.
Model Designation
GRSDS-XXDBK G=Glo
R =Ray
S =Sandwich
D =Display
S =Slanted Shelf
X =Width in Inches
D =Dual Shelf
B =Burger
K =King
6
7
8

Form No. GRSDSDBKM-0407
9
REPLACEMENT PARTS LIST
1 Relay, 10 Amp, SPDT, 24VDC 02.01.061.00 4
2 On/Off Toggle Switch R02.19.016.00 2
3 Light Socket, Dual with Leads 02.30.045.00 2-4
4 Diode Assembly R02.40.047.00 2
5 Divider Rod 04.15.873.00 14-20
6 Leg 05.04.087.00 4
7 Rubber Foot Cover 05.06.038.00 4
8 Appliance Leg, 4" (102 mm) 05.30.007.00 4
9 Indicator, Toggle Switch 07.01.058.00 2
10 Strain Relief for Cord 02.20.206.00 1-2
11 Wire Guard for Heating Element 04.37.100.00 8-16
PARTS COMMON TO ALL GRSDS MODELS
ITEM DESCRIPTION PART NO. QTY.
12 Electronic Temperature Controller
13 Temperature Probe - Bottom Shelf
14 Temperature Probe - Top Shelf
15 Blanket Heating Element - Bottom Shelf
16 Blanket Heating Element - Center Shelf
17 Heating Element, Upper, Metal Sheath
(Qty. 4)
18 Transformer
19 Power Cord & Plug Assembly
20 Light Socket - Single with Leads (Qty. 2)
21 Light Bulb, Shatter Resistant Coating (Qty. 6)
Electrical Drawing
R02.01.062.00
02.01.078.00
02.01.079.00
02.05.363.00
02.05.364.00
R02.08.281.00
02.17.023.00
02.18.068.00
02.30.044.00
02.30.058.00
HS2-4229
PARTS SPECIFIC TO ALL GRSDS-36DBK MODELS
240V220V120V
ITEM DESCRIPTION
R02.01.062.00
02.01.078.00
02.01.079.00
02.05.357.00
02.05.358.00
R02.08.278.00
02.17.023.00
02.18.077.00
02.30.044.00
02.30.058.00
HS2-4228
02.01.049.00
02.01.056.00
02.01.057.00
02.05.335.00
02.05.336.00
R02.08.268.00
02.17.022.00
02.18.089.00
02.30.044.00
02.30.043.00
HS2-3959
Shaded area reflects export models only.
12 Electronic Temperature Controller
13 Temperature Probe - Bottom Shelf
14 Temperature Probe - Top Shelf
15 Blanket Heating Element - Bottom Shelf
16 Blanket Heating Element - Center Shelf
17 Heating Element, Upper, Metal Sheath
(Qty. 4)
18 Transformer
19 Power Cord & Plug Assembly (Qty. 2)
20 Light Socket - Single with Leads (Qty. 2)
21 Light Bulb, Shatter Resistant Coating (Qty. 6)
Electrical Drawing
R02.01.062.00
02.01.078.00
02.01.079.00
02.05.365.00
02.05.366.00
R02.08.280.00
02.17.023.00
02.18.066.00
02.30.044.00
02.30.058.00
HS2-4231
PARTS SPECIFIC TO ALL GRSDS-41DBK MODELS
240V220V120V
ITEM DESCRIPTION
R02.01.062.00
02.01.078.00
02.01.079.00
02.05.359.00
02.05.360.00
R02.08.277.00
02.17.023.00
02.18.077.00
02.30.044.00
02.30.058.00
HS2-4230
02.01.049.00
02.01.056.00
02.01.057.00
02.05.337.00
02.05.338.00
R02.08.267.00
02.17.022.00
R02.18.030.00
02.30.044.00
02.30.043.00
HS2-3960
Shaded area reflects export models only.

Form No. GRSDSDBKM-0407 10
REPLACEMENT PARTS LIST
12 Electronic Temperature Controller
13 Temperature Probe - Bottom Shelf
14 Temperature Probe - Top Shelf
15 Blanket Heating Element - Bottom Shelf
16 Blanket Heating Element - Center Shelf
17 Heating Element, Upper, Metal Sheath
(Qty. 4)
18 Transformer
19 Power Cord & Plug Assembly (Qty. 2)
20 Light Socket - Single with Leads
21 Light Bulb, Shatter Resistant Coating (Qty. 8)
Electrical Drawing
R02.01.062.00
02.01.078.00
02.01.079.00
02.05.367.00
02.05.368.00
R02.08.279.00
02.17.023.00
02.18.104.00
---
02.30.058.00
HS2-4233
PARTS SPECIFIC TO ALL GRSDS-52DBK MODELS
240V220V120V
ITEM DESCRIPTION
R02.01.062.00
02.01.078.00
02.01.079.00
02.05.361.00
02.05.362.00
R02.08.276.00
02.17.023.00
02.18.077.00
---
02.30.058.00
HS2-4232
02.01.049.00
02.01.056.00
02.01.057.00
02.05.339.00
02.05.340.00
R02.08.266.00
02.17.022.00
R02.18.030.00
---
02.30.043.00
HS2-3961
Shaded area reflects export models only.

Form No. GRSDSDBKM-0407
11
HATCO LIMITED WARRANTY
1. PRODUCT WARRANTY
Hatco warrants the products that it manufactures
(the “Products”) to be free from defects in
materials and workmanship, under normal
use and service, for a period of one (1) year from
the date of purchase when installed and
maintained in accordance with Hatco’s written
instructions or 18 months from the date of
shipment from Hatco. Buyer must establish the
product’s purchase date by returning Hatco’s
Warranty Registration Card or by other means
satisfactory to Hatco in its sole discretion.
Hatco warrants the following Product components
to be free from defects in materials and
workmanship from the date of purchase (subject
to the foregoing conditions) for the period(s) of
time and on the conditions listed below:
a) One (1) Year Parts and Labor PLUS One
(1) Additional Year Parts-Only Warranty:
Toaster Elements (TQ, TRH,TK metal
sheathed)
Drawer Warmer Elements (metal sheathed)
Drawer Warmer Drawer Rollers and Slides
Food Warmer Elements (metal sheathed)
Display Warmer Elements (metal sheathed
air heating)
Holding Cabinet Elements (metal sheathed
air heating)
b) One (1) Year Parts and Labor PLUS Four
(4) Years Parts-Only Warranty on
pro-rated terms that Hatco will explain
at Buyer’s request:
3CS and FR Tanks
c) One (1) Year Parts and Labor PLUS Nine
(9) Years Parts-Only Warranty on:
Electric Booster Heater Tanks
Gas Booster Heater Tanks
THE FOREGOING WARRANTIES ARE
EXCLUSIVE AND IN LIEU OF ANY OTHER
WARRANTY, EXPRESSED OR IMPLIED,
INCLUDING BUT NOT LIMITED TO ANY
IMPLIED WARRANTY OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE
OR PATENT OR OTHER INTELLECTUAL
PROPERTY RIGHT INFRINGEMENT. Without
limiting the generality of the foregoing, SUCH
WARRANTIES DO NOT COVER: Coated
incandescent light bulbs, fluorescent lights, lamp
warmer heat bulbs, glass components, Product
failure in booster tank, fin tube heat exchanger, or
other water heating equipment, caused
by liming, sediment buildup, chemical attack or
freezing, Product misuse, tampering or
misapplication, improper installation or application of
improper voltage.
2. LIMITATION OF REMEDIES AND
DAMAGES
Hatco’s liability and Buyer’s exclusive remedy
hereunder will be limited solely, at Hatco’s option,
to repair or replacement by a Hatco-authorized
service agency (other than where Buyer is
located outside of the United States, Canada,
United Kingdom or Australia in which case
Hatco’s liability and Buyer’s exclusive remedy
hereunder will be limited solely to replacement of
part under warranty) with respect to any claim
made within the applicable warranty period
referred to above. Hatco reserves the right to
accept or reject any such claim in whole or in part.
Hatco will not accept the return of any Product
without prior written approval from Hatco, and all
such approved returns shall be made at Buyer’s
sole expense. HATCO WILL NOT BE LIABLE,
UNDER ANY CIRCUMSTANCES, FOR
CONSEQUENTIAL OR INCIDENTAL
DAMAGES, INCLUDING BUT NOT LIMITED TO
LABOR COSTS OR LOST PROFITS
RESULTING FROM THE USE OF OR INABILITY
TO USE THE PRODUCTS OR FROM THE
PRODUCTS BEING INCORPORATED IN OR
BECOMING A COMPONENT OF ANY OTHER
PRODUCT OR GOODS.

Form No. GRSDSDBKM-0407 12
NOTES

Form No. GRSDSDBKM-0407
13
NOTES

HATCO CORPORATION
P.O. Box 340500, Milwaukee, WI 53234-0500 U.S.A.
[phone] [phone]
Parts & Service Fax [phone] Int’l. Fax [phone]
www.hatcocorp.com
HATCO AUTHORIZED PARTS DISTRIBUTORS
Printed in U.S.A. April 2007
ALABAMA
Jones McLeod Appl. Svc.
Birmingham 205-251-0159
ARIZONA
Auth. Comm. Food Equip.
Phoenix 602-234-2443
Byassee Equipment Co.
Phoenix 602-252-0402
CALIFORNIA
Industrial Electric
Commercial Parts & Service, Inc.
Huntington Beach 714-379-7100
Chapman Appl. Service
San Diego 619-298-7106
P & D Appliance
Commercial Parts & Service, Inc.
S. San Francisco 650-635-1900
COLORADO
Hawkins Commercial Appliance
Englewood 303-781-5548
FLORIDA
Whaley Foodservice Repair
Jacksonville 904-725-7800
Nass Service Co., Inc.
Orlando 407-425-2681
B.G.S.I.
Pompano Beach 954-971-0456
Comm. Appliance Service
Tampa 813-663-0313
GEORGIA
TWC Services
Smyrna 770-438-9797
Heritage Service Group
Norcross 866-388-9837
Southeastern Rest. Svc.
Norcross 770-446-6177
HAWAII
Burney’s Comm. Service, Inc.
Honolulu 808-848-1466
Food Equip Parts & Service
Honolulu 808-847-4871
ILLINOIS
Parts Town
Lombard 708-865-7278
Eichenauer Elec. Service
Decatur 217-429-4229
Midwest Elec. Appl. Service
Elmhurst 630-279-8000
Cone’s Repair Service
Moline 309-797-5323
INDIANA
GCS Service
Indianapolis 317-545-9655
IOWA
Electric Motor Service Co.
Davenport 319-323-1823
Goodwin Tucker Group
Des Moines 515-262-9308
KENTUCKY
Certified Service Center
Lexington 859-254-8854
Certified Service Center
Louisville 502-964-7007
LOUISIANA
Chandlers Parts & Service
Baton Rouge 225-272-6620
MARYLAND
Electric Motor Service
Baltimore 410-467-8080
GCS Service
Silver Spring 301-585-7550
MASSACHUSETTS
Ace Service Co., Inc.
Needham 781-449-4220
MICHIGAN
Commercial Kitchen Service
Bay City 517-893-4561
Bildons Appliance Service
Detroit 248-478-3320
Midwest Food Equip. Service
Grandville 616-261-2000
MINNESOTA
GCS Service
Minneapolis 612-546-4221
MISSOURI
General Parts
Kansas City 816-421-5400
Commercial Kitchen Services
St. Louis 314-890-0700
Kaemmerlen Parts & Service
St. Louis 314-535-2222
NEBRASKA
Anderson Electric
Omaha 402-341-1414
NEVADA
Burney’s Commercial
Las Vegas 702-736-0006
Hi. Tech Commercial Service
N. Las Vegas 702-649-4616
NEW JERSEY
Jay Hill Repair
Fairfield 973-575-9145
Service Plus
Flanders 973-691-6300
NEW YORK
Acme American Repairs, Inc.
Brooklyn 718-456-6544
Alpro Service Co.
Brooklyn 718-386-2515
Appliance Installation
Buffalo 716-884-7425
Northern Parts Dist.
Plattsburgh 518-563-3200
J.B. Brady, Inc.
Syracuse 315-422-9271
NORTH CAROLINA
Authorized Appliance
Charlotte 704-377-4501
OHIO
Akron/Canton Comm. Svc. Inc.
Akron 330-753-6635
Certified Service Center
Cincinnati 513-772-6600
Commercial Parts and Service
Columbus 614-221-0057
Electrical Appl. Repair Service
Independence 216-459-8700
E. A. Wichman Co.
Toledo 419-385-9121
OKLAHOMA
Hagar Rest. Service, Inc.
Oklahoma City 405-235-2184
Krueger, Inc.
Oklahoma City 405-528-8883
OREGON
Ron’s Service, Inc.
Portland 503-624-0890
PENNSYLVANIA
Elmer Schultz Services
Philadelphia 215-627-5401
FAST Comm. Appl. Service
Philadelphia 215-288-4800
Appliance Installation & Service
Pittsburgh 412-809-0244
K & D Service Co.
Harrisburg 717-236-9039
Electric Repair Co.
Reading 610-376-5444
RHODE ISLAND
Marshall Electric Co.
Providence 401-331-1163
SOUTH CAROLINA
Whaley Foodservice Repair
W. Columbia 803-791-4420
TENNESSEE
Camp Electric
Memphis 901-527-7543
TEXAS
GCS Service
Fort Worth 817-831-0381
Armstrong Repair Service
Houston 713-666-7100
Commercial Kitchen Repair Co.
San Antonio 210-735-2811
UTAH
La Monica’s Rest. Equip. Service
Murray 801-263-3221
VIRGINIA
Daubers
Norfolk 757-855-4097
Daubers
Springfield 703-866-3600
WASHINGTON
Restaurant Appl. Service
Seattle 206-524-8200
WISCONSIN
A.S.C., Inc.
Madison 608-246-3160
A.S.C., Inc.
Milwaukee 414-543-6460
CANADA
ALBERTA
Key Food Equipment Service
Edmonton 780-438-1690
BRITISH COLUMBIA
Key Food Equipment Service
Vancouver 604-433-4484
MANITOBA
Air Rite, Inc.
Winnepeg 204-895-2300
NEW BRUNSWICK
EMR Services, Ltd.
Moncton 506-855-4228
ONTARIO
R.G. Henderson Ltd.
Toronto 416-422-5580
Choquette CKS
Ottawa 613-739-8458
QUÉBEC
Choquette CKS
Montreal 514-722-2000
Choquette CKS
Québec City 418-681-3944
Part No. 07.04.410.00 Form No.GRSDSDBKM-0407
