Patented heated glass technology
offers double the holding capacity
with Glo-Ray®Model GRHW-1SGD
Mini-Merchandiser with Designer
color, breath protector, and accessory
sign holder (sign not included)
Glo-Ray Model GRSDH-36
Horizontal Single Shelf Merchandiser
Glo-Ray Model GRSBF-72-I
Built-in Flush Heated Shelf
High Marks in Self-Service!
Hatco has a complete range of
hot food merchandisers that enable
students to serve themselves a choice of
quality and nutritious cuisine.
Hatco Merchandising Warmers hold food
safely at peak serving temperatures
longer while minimizing the risk of food-
borne illness. And where personnel
shortage is a concern, the self-serve
concept can improve the bottom line.
Choose from an array of shapes, sizes,
and options to fit all serving locations
from buffet lines, to mobile food carts,
and snack bars to concession stands.
Hatco Display Warmers are available in
Designer colors to compliment any décor.
With equipment built for high performance,
long-lasting durability, and safety, Hatco
offers A+solutions.
Designer Glo-Ray Model GR2S-30
Heated Shelf with Designer color
inset panels and accessory pizza pans
Designer Glo-Ray Model GR2SDS-30D Slanted Shelf
Merchandiser with Designer color inset panels
Designer Glo-Ray Model GR2SDH-30
Merchandiser with Designer color inset panels
Glo-Ray Model GRSDS/H-36DHW
Merchandiser with high wattage on the
horizontal top shelf for fries and onion
rings and standard wattage on the slanted
bottom shelf for wrapped or boxed food
2

Designer Glo-Ray Model GR2BW-30
Buffet Warmer in optional Designer
Black with accessory food pans
Glo-Ray®Model GRBW-30
Warmer with accessory front and
side enclosures and sign holder
(sign not included)
Glo-Ray Model GRAHL-36
Foodwarmer with optional breath
protectors and accessory tubular stands
above Glo-Ray Model GRSB-30-I Built-in
Heated Shelf
3

Flav-R-Fresh Model FDW-1-MN
Macho Nacho™Chip Warmer
It’s Purely Academic.
Students will want to eat
nutritiously when food looks appealing.
Nothing keeps fare hot, fresh, and
enticing like Hatco Holding and Display
Cabinets and Cases. Items can be
prepared ahead of time and kept fresh
for hours using a combination of heat
and humidity, which is uniformly
distributed throughout the cabinets.
Scholastic foodservice responds to
popular and social trends as well as
nutritional demands. And the basic
principle when adding food safety to
the “show and sell”equation is Hatco
Display Cases.
When it comes to placing the focus
on your product, Hatco has done the
homework.
Flav-R-Savor Model FSDT-1X
Humidified Display Cabinet with 4-tier
pan rack and optional Designer colors,
accessory decals, and food pans
Flav-R-Savor Model FSDT-1
Humidified Holding Cabinet with
4-tier circle rack, accessory
decals, and food pans
Flav-R-Savor®
Model WFST-2X Large
Capacity Merchandising
Cabinet with optional
Designer color, self-
closing sliding doors, and
accessory sheet pans
Flav-R-Fresh®Model FDW-1X
Display Cabinet with stationary
4-shelf multi-purpose rack
4

Glo-Ray Model GRHD-3PD Heated Display
Case with optional mirrored glass doors
and accessory food pans
Glo-Ray Model GRCDH-3PD Humidified
Heated Display Case with pan skirt, optional
Designer color, and accessory food pans
Glo-Ray®Model GRCD-2P Heated Display
Case with optional Designer color, backlit
base (graphics not included), and accessory
food pans
5

Designer Glo-Ray®Model
GR2AH-24D Foodwarmer with
optional breath protectors
Ultra-Glo™Model UGAHL-60D
Ceramic Dual Foodwarmer
with optional Gleaming Gold
finish and lights (Remote
Control Box required)
Glo-Ray Model GRAH-30 Foodwarmer
with optional Designer color, infinite
switch, and accessory C-Leg stand
over Glo-Ray Model GRS-24-I Heated
Shelf in optional Designer color with
accessory food pans
6

Imperial Booster Heater
Model S-54 for sanitizing
hot water
Glo-Ray®Model GRFHS-21
Fry Holding Station with accessory
7 pleat hardcoated fry bag ribbon
Atmospheric Hot Water Dispenser
Model AWD-12 offers pre-measured
hot water on demand for beverages,
sauces, soups, gravy, cereals, rice,
pasta, potatoes, gelatin, and more
Hydro-Heater Food Rethermalizer
Model FR2-6 for reconstituting
frozen foods
7
The Equation for Success.
There’s a reason why smart
scholastic facilities use Hatco.
Combined front- and back-of-the-
house solutions guarantee customer
satisfaction, optimum food safety, and
quality. Product is displayed and held
at proper serving temperatures with
Glo-Ray Foodwarmers. Even the most
delicate foods retain an appetizing
appearance without drying or
discoloring. From prep areas to serving
points and buffet lines, Glo-Ray
foodwarmers are adaptable to any
location and configuration.
Behind the scenes Hatco offers gas
and electric Booster Water Heaters for
180ºF (82ºC) sanitizing hot water and
long life dependability. The Atmospheric
Water Dispenser delivers pre-measured
amounts of hot water at the simple
push of a button. And Hydro-Heater
Food Rethermalizers and Sanitizing
Sink Heaters offer additional capabilities
in the kitchen.
For maximum flavor, safety, and
convenience, it all adds up to Hatco.

At the Head of the Class.
For morning rush, lunchtime crunch,
or evening classes and activities,
Hatco Drawer Warmers, Holding Cabinets,
and Toasters keep up with any size crowd.
From freestanding models to built-in,
standard or narrow widths, Hatco Drawer
Warmers are perfect for kitchens, buffet
lines, and stadiums. Ideal for catering
or peak serving periods, the Hatco
Flav-R-Savor®Holding Cabinets provide
additional storage with thermostatically-
controlled heat and humidity. Also, a range
of Conveyor Toasters can handle from 300
slices up to 1500 slices an hour, toasting
bread, buns, bagels, English muffins…
even frozen waffles.
All Hatco products are built for outstanding
dependability and functionality, delivering
the highest quality and tastiest results.
Designed to minimize energy consumption
and maximize ease of use, Hatco offers
the widest range of options and
accessories to ensure the ideal solution
for your facility.
When it comes to overachieving, Hatco
maintains a high degree of dedication.
Drawer Warmer Model HDW-3
with optional casters
Drawer Warmer Model HDW-1R2
Split Drawer Warmer
8

Toast King®Model TK-135B
Conveyor Toaster
Toast-Qwik®Model TQ-800
Conveyor Toaster with patent
pending colorguard sensing
system, electronic controls,
and power save mode
Flav-R-Savor Model FSHC-1
Portable Holding Cabinet with
accessory food pans
Flav-R-Savor®Model FSHC-6W1
Portable Holding Cabinet built to
fit under lower work counters
9

STANDARD PLUG CONFIGURATIONS
Model 120 Volt 60 Hz
GR2SDS-30D NEMA 5-15P
GR2SDH-30 NEMA 5-15P
GRSDS/H-36DHW NEMA 14-20P
GRSDH-36 NEMA 5-15P
GRHW-1SGD NEMA 5-15P
GR2S-30 NEMA 5-15P
GRSBF-72-I NEMA 5-15P
GR2BW-30 NEMA 5-15P
GRBW-30 NEMA 5-15P
GRAHL-36 —
GRSB-30-I NEMA 5-15P
WFST-2X NEMA 5-15P•
293/4" (76 cm)
361/8" (92 cm)
18"
(46 cm)
8"
(20 cm) 22" (56 cm)
27" (69 cm)
FRONT VIEW SIDE VIEW
Model Volts Watts Amps Ship. Wt.
GR2SDH-30 120 845 7.0 102 lbs. (46 kg)
GR2SDH-30
Model Volts Watts Amps Ship. Wt.
GR2SDS-30D 120 1640 13.7 174 lbs. (79 kg)
361⁄8" (92 cm)
293/4" (76 cm)
293/4" (76 cm) 333/8"
(85 cm)
22" (56 cm)
22" (56 cm)
265/8" (68 cm)
FRONT VIEW SIDE VIEW
8"
(20 cm)
GR2SDS-30D
Model Volts Watts Amps Ship. Wt.
GRSDS/H-36DHW 120/208 2910 16.4 158 lbs. (72 kg)
36" (91 cm)
FRONT VIEW
321⁄2"
(83 cm)
12"
(30 cm)
103⁄8"
(26 cm)
24" (61 cm)
SIDE VIEW
GRSDS/H-36DHW
FRONT VIEW SIDE VIEW
30"
(76 cm)
147⁄8" (38 cm)
21" (53 cm)
227⁄8" (58 cm)
Model Volts Watts Amps Ship. Wt.
GRHW-1SGD 120 1690 14.1 48 lbs. (22 kg)
GRHW-1SGD
Model Volts Watts Amps Ship. Wt.
GRSDH-36 120 1170 9.8 66 lbs. (30 kg)
36" (91 cm)
FRONT VIEW
121⁄16"
(31 cm) 71⁄8"
(18 cm)
191⁄2" (50 cm)
SIDE VIEW
GRSDH-36
Model Volts Watts Amps Ship. Wt.
GR2S-30 120 450 3.8 39 lbs. (18 kg)
361⁄8" (92 cm)
293⁄4" (76 cm) 213⁄4" (55 cm)
4" (10 cm)
27" (69 cm)
FRONT VIEW SIDE VIEW
GR2S-30
331/2" (85 cm)
361⁄8" (92 cm)
293⁄4" (76 cm)
19"
(48 cm)
213/4" (55 cm)
1115/16"
(30 cm)
27" (69 cm)
FRONT VIEW SIDE VIEW
Model Volts* Watts Amps Ship. Wt.
GR2BW-30 120 1230 10.3 85 lbs. (39 kg)
GR2BW-30
Model Volts Watts Amps Ship. Wt.
GRSBF-72-I 120 1440 12.0 58 lbs. (26 kg)
2
1⁄4
"
(6 cm)
2
1⁄32
" (5 cm)
7
1⁄16
" (18 cm)
73
1⁄2
" (187 cm)
21" (53 cm)
FRONT VIEW
SIDE VIEW
GRSBF-72-I
Model Volts* Watts Amps Ship. Wt.
GRBW-30 120 1230 10.3 52 lbs. (24 kg)
173⁄4"
(45 cm)
323⁄16" (82 cm)
FRONT VIEW
201⁄8"
(51 cm)
Cord
Location
SIDE VIEW
30" (76 cm)
GRBW-30 with Enclosures
2
3⁄4
"
(7 cm)
1/2"
(1 cm) 2
1⁄32
"
(5 cm)
7
1⁄16
"
(18 cm)
0 to 1
1⁄4
"
(0 to 3 cm)
30" (76 cm)
31
1⁄2
" (80 cm)
19
1⁄2
" ( 50 c m)
21" (53 cm)
FRONT VIEW
SIDE VIEW
Model Volts Watts Amps Ship. Wt.
GRSB-30-I 120 665 5.5 25 lbs. (11 kg)
GRSB-30-I
Model Volts* Watts Amps Ship. Wt.
GRAHL-36 120 800 6.7 9 lbs. (4 kg)
36" (91 cm)
2
1⁄2
"
(6 cm)
9"
(23 cm)
END VIEWFRONT VIEW
GRAHL-36
Model Volts Watts Amps Ship. Wt.
WFST-2X 120 1790 14.9 188 lbs. (85 kg)
321⁄16" (81 cm)
FRONT VIEW SIDE VIEW
271⁄8" (69 cm)
323⁄4"
(83 cm)
WFST-2X
* Other voltages available, consult factory. See product specification sheets for additional models.
•NEMA 5-20P for Canada
10
NEMA 5-15P
NEMA 5-20P
NEMA 14-20P

227⁄16"
(57 cm) 2315⁄16"
(61 cm)
321⁄2"
(83 cm)
SIDE VIEW
FRONT VIEW
Model Volts Watts Amps Ship. Wt.
FSDT-1 120 1470 12.3 120 lbs. (54kg)
FSDT-1
Model Volts Watts Amps Ship. Wt.
FSDT-1X 120 1470 12.3 118 lbs. (54 kg)
227⁄16"
(57 cm) 2315⁄16"
(61 cm)
321⁄2"
(83 cm)
SIDE VIEW
FRONT VIEW
FSDT-1X
Model Volts Watts Amps Ship. Wt.
FDW-1X 120 1470 12.3 82 lbs. (37kg)
191⁄2" (50 cm)
SIDE VIEW
271⁄2"
(70 cm)
FRONT VIEW
18" (46 cm)
FDW-1X
451/2" (116 cm)
FRONT VIEW
313⁄4"
(81 cm)
SIDE VIEW
26" (66 cm)
25"
(64 cm)
151/4"
(39 cm)
Model Volts Watts Amps Ship. Wt.
GRCDH-3PD 120 1960 16.3 222 lbs. (101 kg)
GRCDH-3PD
Model Volts Watts Amps Ship. Wt.
FDW-1-MN 120 1128 9.4 80 lbs. (36 kg)
18"
(46 cm)
18"
(46 cm) 229/16"
(57 cm)
271/2"
(70 cm)
FRONT VIEW SIDE VIEW
FDW-1-MN
Model Volts Watts Amps Ship. Wt.
GRCD-2P 120 780 6.5 104 lbs. (47 kg)
321⁄2" (83 cm)
FRONT VIEW
24"
(61 cm)
RIGHT SIDE
26" (66 cm)
25"
(64 cm)
GRCD-2P
60" (152 cm)
2
1⁄2
"
(6 cm)
18" (46 cm)
FRONT VIEW END VIEW
Model Volts* Watts Amps Ship. Wt.
UGAHL-60D 120 5400 45.0 37 lbs. (17 kg)
UGAHL-60D
Model Volts Watts Amps Ship. Wt.
GRHD-3PD 120 1755 14.6 200 lbs. (91 kg)
FRONT VIEW SIDE VIEW
451⁄2" (116 cm)
30"
(76 cm)
83⁄4"
(22 cm)
83⁄4"
(22 cm)
26" (66 cm)
21" (53 cm)
161⁄2"
(42 cm)
GRHD-3PD
Model Volts* Watts Amps Ship. Wt.
GR2AH-24D 120 1000 8.3 48 lbs. (22 kg)
18" (46 cm)
SIDE VIEW
28" (71 cm)
24" (61 cm)
171⁄2"
(45 cm)
31⁄2"
(9 cm)
FRONT VIEW
GR2AH-24D
24" (61 cm) 191⁄2
" (61 cm)
FRONT VIEW
2
1⁄4
"
(6 cm)
SIDE VIEW
Model Volts Watts Amps Ship. Wt.
GRS-24-I 120 350 2.9 20 lbs. (9 kg)
GRS-24-I
Model Volts* Watts Amps Ship. Wt.
GRAH-30 120 660 5.5 8 lbs. (4 kg)
30" (76 cm)
2
1⁄2
"
(6 cm)
6"
(15 cm)
END VIEWFRONT VIEW
GRAH-30
Model Volts Watts Amps Ship. Wt.
GRFHS-21 120 1200 10.0 86 lbs. (39 kg)
6
1⁄4
"
(16 cm)
21
3⁄4
"
(55 cm)
21
3⁄8
" (54 cm)
27
5⁄8
" (70 cm)
FRONT VIEW SIDE VIEW
GRFHS-21
STANDARD PLUG CONFIGURATIONS
Model 120 Volt 60 Hz
FSDT-1X NEMA 5-15P•
FSDT-1 NEMA 5-15P•
FDW-1X NEMA 5-15P•
FDW-1-MN NEMA 5-15P
GRCDH-3PD NEMA 5-20P
GRCD-2P NEMA 5-15P
GRHD-3PD NEMA 5-20P
UGAHL-60D —
GR2AH-24D —
GRAH-30 NEMA 5-15P
GRS-24-I NEMA 5-15P
GRFHS-21 NEMA 5-15P
* Other voltages available, consult factory. See product specification sheets for additional models.
NEMA 5-15P
NEMA 5-20P
•NEMA 5-20P for Canada 11

P.O. Box 340500
Milwaukee, WI 53234-0500 U.S.A.
[phone] • [phone]
Fax: [phone] • [phone]
www.hatcocorp.com
E-mail: [email protected]
Printed in U.S.A.
Form No. HSB-1002-1
Revised March 2004
STANDARD PLUG CONFIGURATIONS
Model 120 Volt 60 Hz 208 Volt 60 Hz
ADW-12 — NEMA 6-30P
S-54 — —
FR2-6 — —
HDW-1R2 NEMA 5-15P —
HDW-3 NEMA 5-15P —
FSHC-6W1 NEMA 5-15P•—
FSHC-1 NEMA 5-15P•—
TQ-800 — NEMA 6-20P
TK-135B — NEMA 6-30P
231⁄2 " (60 cm)
3⁄4
" NPT TEE FOR
140ºF (60ºC) WATER INLET,
INSTALL DRAIN VALVE OTHER END.
3⁄4
" NPT NIPPLE
180ºF (82ºC) OUTLET
25
3⁄8
"
(65 cm)
2"
(5 cm) 6" (15 cm)
4" (10 cm)
ELECTRICAL CONNECTION
FROM SIDE OR BELOW
SIDE VIEW
REAR VIEW
31
3⁄8
"
(80 cm)
3⁄4
" NPT
Coupling for
Temperature/
Pressure Relief Valve
22
1⁄16
"
(56 cm) 2" (5 cm)
23 " (58 cm)
911⁄16 "
(25 cm)
93⁄4 "
(25 cm)
Model Volts* kW Amps Ship. Wt.
S-54 208 54 150 224 lbs. (102 kg)
S-54
Model Volts* Watts Amps Ship. Wt.
ADW-12 208 5000 24.0 80 lbs. (36 kg)
117/8 "
(30 cm)
24
1⁄8
"
(61 cm)
4"
(10 cm)
SIDE VIEW
FRONT VIEW
30
1⁄16
"
(76 cm)
235⁄8 " (60 cm)
281⁄8 " (71 cm)
WATER INLET
(1/4" MALE FLARE
CONNECTION)
ADW-12
Model Volts* kW Amps Ship. Wt.
FR2-6 208 6 28.8 27 lbs. (12 kg)
SIDE VIEW REAR VIEW
9
9⁄16
"
(24 cm)
1⁄2
" &
3⁄4
"
(1 & 2 cm)
Conduit K.O.
1⁄2
" &
3⁄4
" (1 & 2 cm)
Conduit K.O.
3⁄4
" (2 cm) hose
connection
to drain
1"
(3 cm)
12
5⁄16
"
(31 cm)
5
1⁄2
"
(14 cm) 8
1⁄2
"
(22 cm)
3
3⁄8
"
(9 cm)
6
3⁄4
"
(17 cm)
3
1⁄16
"
(8 cm)
17
1⁄16
" (43 cm)
2
3⁄4
"
(7 cm)
FR2-6
291⁄2" (75 cm)
311⁄4"
(79 cm)
FRONT VIEW
225⁄8"
(58 cm)
SIDE VIEW
Location
of Cord
Model Volts* Watts Amps Ship. Wt.
HDW-3 120 1350 11.3 232 lbs. (105 kg)
HDW-3
Model Volts Watts Amps Ship. Wt.
HDW-1R2 120 525 4.4 97 lbs. (44 kg)
SIDE VIEW
FRONT VIEW
165⁄8" (42 cm) 293⁄8" (75 cm)
4" (10 cm)
107⁄8"
(28 cm)
HDW-1R2
Model Volts Watts Amps Ship. Wt.
FSHC-6W1 120 1697 14.1 125 lbs. (57 kg)
SIDE VIEW
FRONT VIEW
253⁄8" (64 cm) 303⁄4" (78 cm)
31" (79 cm)
with 3" (8 cm)
diamiter casters
FSHC-6W1
169⁄16"
(42 cm)
SIDE VIEW
FRONT VIEW
221⁄4" (57 cm)
107⁄16"
(27 cm)
141⁄2" (37 cm)
Model Volts* Watts Amps Ship. Wt.
TQ-800 208 3330 16.0 52 lbs. (24 kg)
TQ-800
Model Volts Watts Amps Ship. Wt.
FSHC-1 120 1725 14.4 168 lbs. (76 kg)
223⁄4" (58 cm)
33"
(84 cm)
FRONT VIEW SIDE VIEW
363⁄4" (93 cm)
with 3" (8 cm)
diameter casters
34" (86 cm)
FSHC-1
Model Volts* Watts Amps Ship. Wt.
TK-135B 208 4300 20.7 88 lbs. (40 kg)
Location
of Cord
SIDE VIEW
141⁄8"
(36 cm)
22"
(56 cm)
FRONT VIEW
31⁄2" (9 cm)
33"
(84 cm)
Manual
Advance
TK-135B
* Other voltages available, consult factory. See product specification sheets for additional models.
•NEMA 5-20P for Canada
NEMA 5-15P
NEMA 6-20P
NEMA 5-20P
NEMA 6-30P
