Hatco FSHC-1 Application guide

FLAV-R-SAVOR®
Portable Holding Cabinet
REPLACEMENT
PARTS LIST
FSHC-1 FSHC-2
FSHC Series

Form No. FSHCRP - 1100 2 Printed in U.S.A.
"B"
"A"
TO "A"
TO "B"
HATCO FLAV-R-SAVOR®
HOLDING CABINETS
FSHC SERIES
Model Designation
FSHC-X F = Flav-R
S = Savor
H = Holding
C = Cabinet
X = Number of Doors
22
17, 18
9
24
36
16
24
26 23 25 29 27 28 11
12
4
4
2
14
15
32
34
13
30
33
35
1
31
21
20
8
20
10
5
37
7
6
39
38, 40

ITEM DESCRIPTION PART NO. QTY. ITEM DESCRIPTION PART NO. QTY.
1 Float Switch R02.01.029.00 1
2 Terminal Block 8-Pole 02.15.012.00 1
3 Motor Bearing Lube (not shown) 05.01.019.00 1
4 Knob, Control 05.30.019.00 2
5 Fill Cup w/Cover R05.30.050.00 1
6 Plastic Drain Tube Assy. R03.40.054.00 1
7 Temperature Drum Display 02.16.049.00 1
8 Hose, Reservoir 03.40.051.00 1
9 Wire Support Frame 04.17.122.00 2
10 Adjustable Angle Slide 04.17.144.00 14
11 Caster, Swivel, 3" (standard) 04.17.130.00 4
12 Mounting Bracket, Caster R04.14.221.00 4
13 Ceiling Drain Assy. R03.40.055.00 1
14 Temperature Control 02.16.002.00 1
15 Humidity Control 02.16.021.00 1
16 Cord Grip 02.20.206.00 1
17 Hood, Painted 04.17.193.00 1
18 Hood, Stainless Steel (optional) 04.17.196.00 1
19 Legs, Plastic (optional)
(not shown) 05.30.007.00 4
20 Hose Clamp 05.04.354.00 2
21 Connector, Hose R03.40.052.00 1
22 Wire Rack, 6-Shelf (optional) R04.17.143.00 1
23 Door Handle Assy. R05.30.012.00 1-2*
24 Hinge Kit Assy. R00.01.0110.00 1-2*
25 Door Gasket Assy. R00.01.0105.00 1-2*
26 Glass Door Assy. (complete) R00.01.0102.00 1-2*
27 Recessed Caster w/Hardware R04.17.180.00 4
28 Mounting Bracket
for Recessed Caster R04.17.181.00 2
29 Magnet, Door 05.30.005.00 1-2*
30 Gasket, Air Chamber 05.06.028.00 4'
31 Gasket, Water Chamber 05.06.028.00 4'
* FSHC-1 is a one door unit.
FSHC-2 is a two door unit.
PARTS COMMON TO ALL FSHC MODELS
32 Element, 600 Watt, Water Heating
33 Element, 1050 Watt, Air Heating†
34 Control Relay
35 Blower Motor‡
36 Power Cord w/Plug
37 Rocker Switch, On/Off
38 Indicator Light, Red
39 Indicator Light, Green
40 Indicator Light, Yellow
41 Hi-Limit, Air Chamber
(not shown)
42 Solenoid Valve (for auto-fill)
(optional) (not shown)
43 Terminal Block, 3-Pole
(not shown)
Wiring Diagram
R02.05.018.00
R02.05.017.00
02.01.043.00
R02.12.012.00
02.18.109.00
02.19.015.00
02.19.071R.00
02.19.070G.00
---
---
03.40.034.00
---
HS1-2227
R02.05.002.00
R02.05.007.00
02.01.028.00
R02.12.003.00
02.18.035.00
02.19.015.00
02.19.070R.00
02.19.070G.00
---
---
03.40.035.00
---
HS1-3231
R02.05.003.00
R02.05.008.00
02.01.043.00
R02.12.012.00
02.18.120.00
02.19.015.00
02.19.071R.00
02.19.070G.00
---
---
03.40.034.00
---
HS1-3229
R02.05.018.00
R02.05.017.00
02.01.043.00
R02.12.012.00
02.18.109.00
02.19.088.00
---
02.19.070G.00
02.19.071Y.00
R02.16.031.00
03.40.034.00
R02.15.030.00
HS1-4395
R02.05.003.00
R02.05.008.00
02.01.043.00
R02.12.012.00
02.18.120.00
02.19.088.00
---
02.19.070G.00
02.19.071Y.00
R02.16.031.00
03.40.034.00
R02.15.030.00
HS1-4396
PARTS SPECIFIC TO MODELS FSHC-1 & FSHC-2
ITEM DESCRIPTION 240V
60 Hz
220V
60V
120V
Canada
120V
60 Hz 220-230V CE
50/60 Hz 230-240V CE
50/60 Hz
R02.05.002.00
R02.05.007.00
02.01.028.00
R02.12.003.00
02.18.082.00
02.19.015.00
02.19.070R.00
02.19.070G.00
---
---
03.40.035.00
---
HS1-3231
† Units built before December, 1987 consult factory.
‡ 120 Volt units manufactured on or before June, 1988 use part number 02.12.003B.00.
Form No. FSHCRP - 1100 3 Printed in U.S.A.
Shaded area reflects export models only.
