TOAST-QWIK®
Electric Conveyor Toasters
TQ-10, TQ-15,
TQ-400, TQ-800, TQ-1200 Series
Installation &
Operating Manual
I&W #07.05.144.00
TOSTADORAS DE CORREA
TRANSPORTADORA ELECTRICA
Manual de Instalación y Operación
TOSTAPANE ROTATIVI ELETTRICI
Manuale di installazione e funzionamento
ELEKTRISCHE UMLAUFTOASTER
Installations- und Bedienungshandbuch
GRILLE-PAIN ELECTRIQUE À CONVOYEUR
Installation et Fonctionnement
ELEKTRISCHE TOASTERS MET TRANSPORTBAND
Handleiding voor Installatie en Bediening
Modello: Toast-Qwik
Modelo: Toast-Qwik
Modell: Toast-Qwik
Modèle: Toast-Qwik
Model: Toast-Qwik
®®
®
®
®

1
Form No. TQ2CEM-0903
AB
ILLUSTRATIONS
1
2
A
B
C
D
E
F
G
A Model TQ-10 A Modell TQ-10
B Model TQ-800 B Modell TQ-800
A Modelo TQ-10 A Modèle TQ-10
B Modelo TQ-800 B Modèle TQ-800
A Modello TQ-10 A Model TQ-10
B Modello TQ-800 B Model TQ-800
A NEMA 5-15P A NEMA 5-15P
B NEMA 6-20P B NEMA 6-20P
C AS 3112 C AS 3112
D NEMA 6-15P D NEMA 6-15P
E NEMA 6-30P E NEMA 6-30P
F CEE 7/7 Schuko F CEE 7/7 Schuko
G BS 1363 G BS 1363
A NEMA 5-15P A NEMA 5-15P
B NEMA 6-20P B NEMA 6-20P
C AS 3112 C AS 3112
D NEMA 6-15P D NEMA 6-15P
E NEMA 6-30P E NEMA 6-30P
F CEE 7/7 Schuko F CEE 7/7 Schuko
G BS 1363 G BS 1363
A NEMA 5-15P A NEMA 5-15P
B NEMA 6-20P B NEMA 6-20P
C AS 3112 C AS 3112
D NEMA 6-15P D NEMA 6-15P
E NEMA 6-30P E NEMA 6-30P
F CEE 7/7 Schuko F CEE 7/7 Schuko
G BS 1363 G BS 1363
TQ Models TQ-Modelle
Modelos TQ Modèles TQ
Modelli TQ TQ-Modellen
Plug Configurations Steckerkonfigurationen
Configuraciones del enchufe Configurations de prise
Configurazioni delle spine Stekkerconfiguraties
C
3
Dimensions Abmessungen
Dimensiones Dimensions
Dimensioni Afmetingen
TQ-400, -405, -800, -805 & Serie TQ-400, -405, -800,
1200 Series -805 und 1200
Series TQ-400, -405, -800, -805 Séries TQ-400, -405,
y 1200 -800, -805 & 1200
Serie TQ-400, -405, -800, -805 TQ-400, -405, -800, -805
& 1200 en 1200 serie
TQ-10 & TQ-15 Models Modelle TQ-10 und TQ-15
Modelos TQ-10 y TQ-15 Modèles TQ-10 & TQ-15
Modelli TQ-10 e TQ-15 Model TQ-10 en TQ-15
B
B
A
D
A
C
D

2Form No. TQ2CEM-0903
ILLUSTRATIONS
Front View – TQ-400 Model Shown Vorderansicht –
Modell TQ-400
Vista frontal – Se muestra Vue de face – Modèle TQ-400
el modelo TQ-400
Vista anteriore
– È illustrato Vooraanzicht
– Model TQ-
il modello TQ-400 400 afgebeeld
A
B
C
A Crumb Tray A Krümeltasse
B Toast Collector Pan B Toast-Auffangbehälter
C Discharge Chute C Ausstoßrutsche
A Bandeja para migas A Bac à miettes
B Recipiente para recoger B Bac de récupération de pain
las tostadas grillé
C Canal de descarga C Rampe de décharge
A Cassetto raccogli briciole A Kruimelschaal
B Vassoio di raccolta dei toast B Verzamelpan voor toast
C Scivolo di uscita C Afvoerplaat
A Stop Pins A Anschlagstifte
B Toast Crumb Tray B Krümelfach
A Pernos de retención A Goupilles d'arrêt
B Bandeja para migas
de las tostadas B Bac à miettes
A Spine di arresto A Aanslagpennen
B Cassetto raccoglibriciole B Kruimelschaal
A Adjust leg using a 14 mm (9/16") open-end wrench
and turning bottom of leg accordingly.
A Verstellen Sie die Füsselänge mit Hilfe eines 14 mm
(9/16" Zoll)-Gabelschlüssels; drehen Sie das untere Ende
des Füsses entsprechend.
A Ajuste la pata con una llave de boca de 14 mm (9/16" pulg)
girando la parte inferior de la pata como corresponde.
A Ajuster les pieds avec une clé de 14 mm (9/16" ème
de pouce), en tournant la base du pied dans le sens désiré.
A Regolazione del piedino utilizzando una chiave a bocca
14 mm (9/16") e ruotando adeguatamente il fondo del piedino.
A De poot bijstellen met behulp van een steeksleutel van 14 mm
(9/16") en de onderkant van de poot dienovereenkomstig
draaien.
Adjustable Legs Verstellbare Füße
(TQ-10 & TQ-15 Models Only) (nur Modelle TQ-10 und TQ-15)
Patas ajustables (Sólo para los Pieds réglables (Modèles
modelos TQ-10 y TQ-15) TQ-10 & TQ-15 seulement)
Piedini regolabili (solo sui Verstelbare poten
modelli TQ-10 e TQ-15) (Alleen model TQ-10 en TQ-15)
6
Toast Feed Ramp Toast-Zufuhrrampe
Rampa de alimentación de Rampe d'entrée du pain
las tostadas
Scivolo di alimentazione Voedingsoploopstuk
7
Toast Crumb Tray Krümelfach
Bandeja para migas de las tostadas Bac à miettes
Cassetto raccoglibriciole Kruimelschaal
A
B
8
TQ-10 & TQ-15 Front Discharge Vordere Ausgabe, TQ-10
und TQ-15
Descarga delantera de TQ-10 Décharge avant des
modèlesy TQ-15 TQ-10 & TQ-15
Uscita anteriore, modelli Afvoer aan voorkant,
TQ-10 e TQ-15 model TQ-10 en TQ-15
4
5

3
ILLUSTRATIONS
Form No. TQ2CEM-0903
TQ-10 & TQ-15 Rear Discharge Hintere Ausgabe, TQ-10 und
TQ-15
Descarga trasera de TQ-10 Décharge arrière des modèles
y TQ-15 TQ-10 & TQ-15
Uscita posteriore, Afvoer aan achterkant,
modelli TQ-10 e TQ-15 model TQ-10 en TQ-15
A Collector Pan A Auffangbehälter
B Discharge Chute B Ausstoßrutsche
A Recipiente para recoger A Bac de récupération
las tostadas
B Canal de descarga B Rampe de décharge
A Vassoio di raccolta A Verzamelpan
B Scivolo di uscita B Afvoerplaat
10
TQ-400, -800 & -1200 Series Vordere Ausgabe,
Front Discharge Serie TQ-400, -800 und -1200
Series TQ-400, -800 y -1200 Décharge avant des séries
descarga delantera TQ-400, -800 & -1200
Uscita anteriore, modelli Serie Afvoer aan voorkant,
TQ-400, -800 e -1200 TQ-400, -800 en -1200 serie
TQ-400, -800 & -1200 Series Hintere Ausgabe, Serie
Rear Discharge TQ - 400, -800 und -1200
Series TQ-400, -800 y -1200 Décharge arrière des séries
descarga trasera TQ-400, -800 & -1200
Uscita posteriore, modelli Serie Afvoer aan achterkant,
TQ-400, -800 e -1200 TQ-400, -800 en -1200
serie
B
A
A Color Control A Bräunungsgradregelung
B Top Heat On/Off Switch B OBERHITZE-Schalter
C Bottom Heat On/Off Switch C UNTERHITZE-Schalter
A Control de color A Commande de coloration
B Interruptor B Commande de l'élément
TEMPERATURA SUPERIOR chauffant supérieur
C Interruptor C Commande de l'élément
TEMPERATURA SUPERIOR chauffant inférieur
A Regolatore di doratura A Kleurregeling
B Interruttore di regolazione B Warmteschakelaar BOVEN
di temperatura del lato
superiore
C Interruttore di regolazione C Warmteschakelaar ONDER
di temperatura del
lato inferiore
12
Control Panel – TQ-10 Bedienfeld – Modelle TQ-10
& TQ-15 Models und 15
Panel de control – Modelos Panneau de commande –
TQ-10 y 15 Modèles TQ-10 & 15
Pannello comandi – Regelpaneel –
Modelli TQ-10 e 15 model TQ-10 en 15
BC
A
A Top Heat Control A Oberhitze-Wärmeregler
B Color Control B Steuerung Bräunungsgrad
C Bottom Heat Control C Unterhitze-Wärmeregler
D Power Save Mode D Stromsparmodus
E On/Off Switch E Betriebsschalter
A Control de temperatura superior A Commande d'élément
chauffant supérieur
B Control de color B Contrôle de coloration
C Control de temperatura inferior C Commande d'élément
chauffant inférieur
D Modo de Ahorro de Energía D Mode Économie d'énergie
E Interruptor de encendido/ E Interrupteur marche/arrêt
apagado
A Regolatore temperatura A Warmteregeling boven
lato superiore
B Regolatore di doratura B Kleurregeling
C Regolatore temperatura C Warmteregeling onder
lato inferiore
D Modalità riduzione consumo D Energiebesparingsmodus
energetico
E Interruttore On/Off E Aan/uit-schakelaar
ON
POWER SAVE
TOP
HEAT
BOTTOM
HEAT COLOR CONTROL
OFF
13
Control Panel – TQ-400, -800, Bedienfeld – Serie TQ-400,
and -1200 Series -800 und -1200
Panel de control – Series Panneau de commande –
TQ-400,-800, y -1200 Séries TQ-400, -800 et -1200
Pannello comandi – Modelli Serie Regelpaneel – TQ-400,
TQ-400, -800 e -1200 -800 en -1200 serie
B
CE
A
D
9
11

CAUTIONS
To avoid any injury or damage locate the unit at the proper
counter height, in an area that is convenient for use.
The location should be level to prevent the unit
or its contents from accidentally falling, and strong enough
to support the weight of the unit.
Do not place anything on top of the toaster; doing so could
damage toaster or subject personnel to possible injury.
The toasting of coated or buttered products such as garlic
bread, cheese sandwiches and sweet rolls is NOT
recommended. Residue will reduce toaster performance
and could possibly ignite inside the toaster.
When setting up the unit for operation, make sure power
to the unit is off and the toaster is at room temperature.
Failure to do so could result in personal injury.
4
WARNINGS
Plug toaster into a properly grounded electrical outlet
of the correct voltage, size, and plug configuration.
If the plug and receptacle do not match, contact a qualified
electrician to determine the proper voltage and size,
and install the proper electrical outlet.
To avoid any injury, turn the power switch OFF, unplug
the unit from the power source and allow to cool before
performing any maintenance.
For safe and proper operation, the unit must be located
at a reasonable distance from combustible walls
and materials. If safe distances are not maintained,
discoloration or combustion could occur. Do not locate
toaster under shelving or closer than 305 mm (12")
from the ceiling.
INTRODUCTION
CONTENTS
The Hatco Toast-Qwik®Electric Conveyor Toaster is specially
designed to accelerate the toasting operation. Products for toasting
pass through a heating chamber for rapid and thorough toasting
of products. Moisture and sugar content and thickness of bread
product effect the ability to achieve the perfect toasted product.
Conveyor speed and temperature determines the toasting color.
Hatco toasters are built with quality to meet the demands
of foodservice operations and provide years of trouble-free
performance. The metal-sheathed tubular heating elements
are guaranteed against breakage and burnout for two years.
This manual provides the installation, safety and operating
instructions for the Toast-Qwik Electric Conveyor Toasters.
We recommend all installation, operating and safety instructions
appearing in this manual be read prior to installation or operation
of your Hatco Electric Conveyor Toaster. Safety instructions that
appear in this manual after a warning symbol and the words
WARNING or CAUTION printed in bold face are very important.
WARNING means there is the possibility of serious injury
or death to yourself or others. CAUTION means there
is the possibility of minor or moderate injury. CAUTION without
the symbol signifies the possibility of equipment or property
damage only.
Hatco Toast-Qwik Electric Conveyor Toaster is a product
of extensive research and field testing. The materials used were
selected for maximum durability, attractive appearance and optimum
performance. Every unit is thoroughly inspected and tested
prior to shipment.
Form No. TQ2CEM-0903
IMPORTANT! Read the following important safety instructions to avoid personal injury or death, and to avoid
damage to the equipment or property.
Illustrations....................................................................................1
Introduction ...................................................................................4
Important Safety Instructions......................................................4
Model Descriptions........................................................................5
All Models .............................................................................5
Power Save Mode with Indicator Light.................................5
ColorGuard System................................................................5
Specifications..................................................................................6
Plug Configurations...............................................................6
Dimensions.............................................................................6
Electrical Rating Charts ........................................................7
Installation......................................................................................9
Assembly................................................................................9
Location .................................................................................9
Set-Up ....................................................................................9
The instructions in English begin on page.....................................................................................4
Deutsche Anweisungen beginnen auf Seite.................................................................................13
Las instrucciones en Espanol comienzan en la pagina................................................................22
Les instructions en Francais commencent a la page ...................................................................31
Le istruzioni in Italiano iniziano dalla pagina.............................................................................40
Nederlandse instructies beginnen op bladzijde ...........................................................................49
Operation......................................................................................10
TQ-10 & TQ-15 Models......................................................10
TQ-400, -405, -800, -805, -800H & -1200 Models.............10
TQ-400BA, -800BA & -800HBA Models...........................10
Maintenance.................................................................................11
General.................................................................................11
Cleaning ...............................................................................11
Lubrication...........................................................................11
Hatco Limited Warranty ............................................................12
Important Owner Information ...................................Back Cover
IMPORTANT SAFETY INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS
5
Form No. TQ2CEM-0903
CAUTIONS
Some exterior surfaces on the unit will get hot. Use caution
when touching these areas to avoid injury.
To avoid damage to the unit or injury to personnel always
operate toaster with crumb tray installed.
To avoid any injury, do not remove the crumb tray
for cleaning until toaster is cool.
Unit is not weatherproof. For safe and proper operation
the unit must be located indoors where the ambient air
temperature is a minimum of 70°F (21°C) and a maximum
of 85°F (29°C).
CAUTIONS
Do not locate the toaster in an area subject to excessive
temperatures or grease from grills, fryers, etc. Excessive
temperatures could cause damage to the unit. Do not place
toaster in an area that restricts air flow around the front
or rear of the unit. Do not place toaster in direct discharge
path of air conditioning vent or makeup air vent.
Use only non-abrasive cleaners. Abrasive cleaners could
scratch the finish of your Toast-Qwik toaster marring its
appearance and making it susceptible to soil accumulation.
WARNINGS
Allow a minimum of 25 mm (1") clearance along
the sides. Allow a clearance of 305 mm (12") along the front
and rear discharge to ensure proper operation and safety.
To prevent any injury or damage do not pull unit
by power cord.
To prevent any injury, discontinue use if power cord
is frayed or worn.
This appliance is not of jet-proof construction. Do not use
jet-clean-spray to clean this appliance.
If service is required on this unit, contact your Authorized
Hatco Service Agent, or contact the Hatco Service
Department at 800-558-0607 or 414-671-6350;
fax [phone] or International fax [phone].
This product has no “user” serviceable parts. To avoid
damage to the unit or injury to personnel, use only
Authorized Hatco Service Agents and Genuine Hatco Parts
when service is required.
Genuine Hatco Replacement Parts are specified to operate
safely in the environments in which they are used. Some
aftermarket or generic replacement parts do not have
the characteristics that will allow them to operate safely
in Hatco equipment. It is essential to use Hatco Replacement
Parts when repairing Hatco equipment. Failure to use Hatco
Replacement Parts may subject operators of the equipment
to hazardous electrical voltage, resulting in electrical
shock or burn.
MODEL DESCRIPTIONS
ALL MODELS
All Toast-Qwik Electric Conveyor Toasters are fast, reliable
and versatile, toasting 300 to 1200 slices of bread product per hour
depending on the specific model. The front or rear discharge lets
the operator place Toast-Qwik toaster where it is most convenient.
Every Toast-Qwik toaster includes a toast collector pan, toast feed
ramp, removable crumb tray and factory attached 1829 mm (6')
cord and plug.
TQ-10 MODEL
The TQ-10 model allows for toasting of bread products up
to 38 mm (1-1/2") thick and 245 mm (9-5/8") wide. Capacity
is up to 300 slices per hour for bread or bun products. The TQ-10
comes equipped with 102 mm (4") adjustable legs.
TQ-15 MODEL
The TQ-15 model allows for toasting of moist or dense bread
products up to 38 mm (1-1/2") thick and 245 mm (9-5/8") wide.
Capacity is up to 240 slices per hour for bread or bun products.
The TQ-15 comes equipped with 102 mm (4") adjustable legs.
POWER SAVE MODE WITH INDICATOR
LIGHT
All TQ-400, TQ-800 and TQ-1200 series toasters have a Power
Save mode. During the Power Save mode the indicator light
on the control panel will flash. While the light is flashing the toaster
is operating at 50% power. Full power can be restored within
5 minutes by pushing any button or adjusting any control knob.
COLORGUARD SYSTEM
All TQ-400, TQ-800 and TQ-1200 series toasters use a patented
ColorGuard Sensing System that monitors and automatically adjusts
conveyor speed during high usage periods to assure toast
color uniformity.
TQ-400 MODEL
The TQ-400 model allows for toasting of bread products
up to 38 mm (1-1/2") thick and 245 mm (9-5/8") wide. Capacity
is up to 350 slices per hour for bread or bun products.
TQ-405 MODEL
The TQ-405 model allows for toasting of moist or dense bread
products up to 38 mm (1-1/2") thick and 245 mm (9-5/8") wide.
Capacity is up to 240 slices per hour for bread or bun products.
TQ-400BA MODEL
The TQ-400BA model allows for quick single-sided toasting
of sliced bagels or bun products up to 38 mm (1-1/2") thick
and 245 mm (9-5/8") wide. Most products can be toasted in as little
as 45 seconds. Capacity is up to 400 bagel halves per hour. Toasts
cut side facing up.
TQ-800 MODEL
The TQ-800 model allows for toasting of bread products up
to 38 mm (1-1/2") thick and 245 mm (9-5/8") wide. Capacity
is up to 800 slices per hour for bread or bun products.
TQ-805 MODEL
The TQ-805 model allows for toasting of moist or dense bread
products up to 38 mm (1-1/2") thick and 245 mm (9-5/8") wide.
Capacity is up to 550 slices per hour for bread or bun products.
TQ-800H MODEL
The TQ-800H model has a 76 mm (3") wide opening allowing
for toasting of bread products up to 70 mm (2-3/4") thick
and 245 mm (9-5/8") wide. Capacity is up to 800 slices per hour
for bread or bun products.

MODEL DESCRIPTIONS
6 Form No. TQ2CEM-0903
DIMENSIONS – TQ-10 & TQ-15 MODELS DIMENSIONS – TQ-400, -405, -800, -805 &
-1200 SERIES
PLUG CONFIGURATIONS
Units are supplied from the factory with an electrical cord and plug
installed. Plugs are supplied according to the applications. See 3 .
WARNING
Plug unit into a properly grounded electrical outlet
of the correct voltage, size and plug configuration. If the plug
and receptacle do not match, contact a qualified electrician
to determine the proper voltage and size and install the proper
electrical outlet.
WARNING
To prevent any injury or damage do not pull unit
by power cord.
WARNING
To prevent any injury, discontinue use if power cord is frayed
or worn.
TQ-800BA MODEL
The TQ-800BA model allows for quick single-sided toasting
of sliced bagels or bun products up to 51 mm (2") thick
and 245 mm (9-5/8") wide. Most products can be toasted in as little
as 30 seconds. Capacity is up to 800 bagel or bun halves per hour.
Toasts cut side facing up.
TQ-800HBA MODEL
The TQ-800HBA model is designed to provide the flexibility
and performance to toast one side of sliced bagels or bun products
in as little as 30 seconds. Capacity is more than 800 bagel or bun
halves per hour. Toasts cut side facing up. Maximum product size
allowed is 70 mm (2-3/4") thick and 245 mm (9-5/8") wide.
TQ-1200 MODEL
The TQ-1200 is a high speed toaster which has an accelerated
conveyor system allowing faster toasting during periods
of high demand. Two slices of bread products can be toasted
in as little as 15 seconds. This model is capable of toasting bread
products up to 38 mm (1-1/2") thick and 245 mm (9-5/8") wide.
SPECIFICATIONS
Width Depth Leg Height Height
Model (A) (B) (C) (D)
TQ-10 368 mm 451 mm 102 mm 349 mm
(14-1/2") (17-3/4") (4") (13-3/4")
TQ-15 368 mm 451 mm 102 mm 349 mm
(14-1/2") (17-3/4") (4") (13-3/4")
Width Depth Leg Height Height
Model (A) (B) (C) (D)
TQ-400 368 mm 451 mm 25 mm 381 mm
(14-1/2") (17-3/4") (1") (15")
TQ-405 368 mm 451 mm 25 mm 381 mm
(14-1/2") (17-3/4") (1") (15")
TQ-400BA 368 mm 451 mm 25 mm 381 mm
(14-1/2") (17-3/4") (1") (15")
TQ-800 368 mm 58 cm 25 mm 419 mm
(14-1/2") (22-3/4") (1") (16-1/2")
TQ-805 368 mm 578 mm 25 mm 419 mm
(14-1/2") (22-3/4") (1") (16-1/2")
TQ-800H 368 mm 578 mm 25 mm 419 mm
(14-1/2") (22-3/4") (1") (16-1/2")
TQ-800BA 368 mm 578 mm 25 mm 419 mm
(14-1/2") (22-3/4") (1") (16-1/2")
TQ-800HBA 368 mm 578 mm 25 mm 419 mm
(14-1/2") (22-3/4") (1") (16-1/2")
TQ-1200 368 mm 578 mm 25 mm 419 mm
(14-1/2") (22-3/4") (1") (16-1/2")

Model Voltage Hertz Watts Amps Plug Configuration Shipping Weight
TQ-10 120 60 1800 15.0 NEMA 5-15P* 15 kg (34 lbs.)
208 60 1830 8.8 NEMA 6-15P 15 kg (34 lbs.)
240 60 1830 7.6 NEMA 6-15P 15 kg (34 lbs.)
200 50/60 2070 10.4 AS 3112 15 kg (34 lbs.)
220-230 (CE) 50/60 1866-2040 8.5-8.9 See Note 15 kg (34 lbs.)
230-240 (CE) 50/60 2040-2221 8.9-9.3 See Note 15 kg (34 lbs.)
SPECIFICATIONS
7
Form No. TQ2CEM-0903
ELECTRICAL RATING CHART – TQ-10 MODELS
ELECTRICAL RATING CHART – TQ-400 SERIES
* NEMA 5-20P for Canada
NOTE: TQ-10 220-230 Volt (CE) and 230-240 Volt (CE) available with either CEE 7/7 Schuko, BS 1363 or AS 3112 plug.
See Plug Configurations for details.
NOTE: TQ-15 220-230 Volt (CE) and 230-240 Volt (CE) available with either CEE 7/7 Schuko, BS 1363 or AS 3112 plug.
See Plug Configurations for details.
Shaded area reflects export models only.
Shaded area reflects export models only.
NOTE: TQ-400, TQ-405 and TQ-400BA 220-230 Volt (CE) and 230-240 Volt (CE) available with either CEE 7/7 Schuko, BS 1363
or AS 3112 plug. See Plug Configurations for details.
Shaded area reflects export models only.
ELECTRICAL RATING CHART – TQ-15 MODELS
* NEMA 5-20P for Canada
Model Voltage Hertz Watts Amps Plug Configuration Shipping Weight
TQ-15 220-230 (CE) 50/60 2131-2330 9.7-10.1 See Note 15 kg (34 lbs.)
230-240 (CE) 50/60 2040-2221 8.9-9.3 See Note 15 kg (34 lbs.)
Model Voltage Hertz Watts Amps Plug Configuration Shipping Weight
TQ-400 120 60 1800 15.0 NEMA 5-15P* 21 kg (46 lbs.)
208 60 2230 10.7 NEMA 6-15P 21 kg (46 lbs.)
240 60 2230 9.3 NEMA 6-15P 21 kg (46 lbs.)
200 50/60 2064 10.3 AS 3112 21 kg (46 lbs.)
220-230 (CE) 50/60 1860-2030 8.5-8.8 See Note 21 kg (46 lbs.)
230-240 (CE) 50/60 2030-2210 8.8-9.2 See Note 21 kg (46 lbs.)
TQ-405 220-230 (CE) 50/60 2131-2330 9.7-10.1 See Note 21 kg (46 lbs.)
230-240 (CE) 50/60 2030-2210 8.8-9.2 See Note 21 kg (46 lbs.)
TQ-400BA 120 60 1780 14.8 NEMA 5-15P* 21 kg (46 lbs.)
208 60 1880 9.0 NEMA 6-15P 21 kg (46 lbs.)
240 60 1880 7.8 NEMA 6-15P 21 kg (46 lbs.)
200 50/60 1848 9.2 AS 3112 21 kg (46 lbs.)
220-230 (CE) 50/60 1765-1930 8.0-8.4 See Note 21 kg (46 lbs.)
230-240 (CE) 50/60 1930-2100 8.4-8.8 See Note 21 kg (46 lbs.)

8Form No. TQ2CEM-0903
SPECIFICATIONS
ELECTRICAL RATING CHART – TQ-800 SERIES
ELECTRICAL RATING CHART – TQ-1200 MODELS
Model Voltage Hertz Watts Amps Plug Configuration Shipping Weight
TQ-1200 208 60 4030 19.4 NEMA 6-30P 24 kg (52 lbs.)
240 60 4030 16.8 NEMA 6-30P 24 kg (52 lbs.)
NOTE: TQ-800, TQ-805, TQ-800H, TQ-800BA and TQ-800HBA 220-230 Volt (CE) and 230-240 Volt (CE) available with either
CEE 7/7 Schuko, BS 1363 or AS 3112 plug. See Plug Configurations for details.
Shaded area reflects export models only.
Model Voltage Hertz Watts Amps Plug Configuration Shipping Weight
TQ-800 208 60 3330 16.0 NEMA 6-20P 24 kg (52 lbs.)
240 60 3330 13.9 NEMA 6-20P 24 kg (52 lbs.)
200 50/60 3080 15.4 AS 3112 24 kg (52 lbs.)
220-230 (CE) 50/60 3046-3330 13.8-14.5 See Note 24 kg (52 lbs.)
230-240 (CE) 50/60 3330-3625 14.5-15.1 See Note 24 kg (52 lbs.)
TQ-805 230-240 (CE) 50/60 3330-3625 14.5-15.1 See Note 24 kg (52 lbs.)
TQ-800H 208 60 3330 16.0 NEMA 6-20P 24 kg (52 lbs.)
240 60 3330 13.9 NEMA 6-20P 24 kg (52 lbs.)
200 50/60 3080 15.4 AS 3112 24 kg (52 lbs.)
220-230 (CE) 50/60 3046-3330 13.8-14.5 See Note 24 kg (52 lbs.)
230-240 (CE) 50/60 3330-3625 14.5-15.1 See Note 24 kg (52 lbs.)
TQ-800BA 208 60 3280 15.8 NEMA 6-20P 24 kg (52 lbs.)
240 60 3280 13.7 NEMA 6-20P 24 kg (52 lbs.)
200 50/60 3033 15.1 AS 3112 24 kg (52 lbs.)
220-230 (CE) 50/60 2817-3080 12.8-13.4 See Note 24 kg (52 lbs.)
230-240 (CE) 50/60 3080-3354 13.4-14.0 See Note 24 kg (52 lbs.)
TQ-800HBA 208 60 3280 15.8 NEMA 6-20P 24 kg (52 lbs.)
240 60 3280 13.7 NEMA 6-20P 24 kg (52 lbs.)
200 50/60 3033 15.1 AS 3112 24 kg (52 lbs.)
220-230 (CE) 50/60 2817-3080 12.8-13.4 See Note 24 kg (52 lbs.)
230-240 (CE) 50/60 3080-3354 13.4-14.0 See Note 24 kg (52 lbs.)

ASSEMBLY
1. Remove unit from box.
2. Remove information packet. To prevent delay
in obtaining warranty coverage, fill out and mail
in warranty card.
3. Remove tape from Discharge Chute, Crumb Tray and Toast
Collector Pan. See 4 .
4. (TQ-10 & TQ-15 models only) If unit is not level, use 14 mm
(9/16") open-end wrench to adjust the foot of each leg until unit
is level.
LOCATION CAUTION
Do not locate the toaster in an area subject to excessive
temperatures or grease from grills, fryers, etc. Excessive
temperatures could cause damage to the unit. Do not place
toaster in an area that restricts air flow around the front or rear
of the unit. Do not place toaster in direct discharge path of air
conditioning vent or makeup air vent.
WARNING
For safe and proper operation, the unit must be located
a reasonable distance from combustible walls and materials.
If safe distances are not maintained, discoloration
or combustion could occur. Do not locate toaster under shelving
or closer than 305 mm (12") from the ceiling.
WARNING
Allow a minimum of 25 mm (1") clearance along the sides.
Allow a clearance of 305 mm (12") along the front and rear
discharge to ensure proper operation and safety.
CAUTION
To avoid any injury or damage locate the unit at the proper
counter height, in an area that is convenient for use.
The location should be level to prevent the unit or its contents
from accidentally falling, and strong enough to support
the weight of the unit.
CAUTION
Do not place anything on top of the toaster; doing so could
damage toaster or subject personnel to possible injury.
9
Form No. TQ2CEM-0903
INSTALLATION
SET-UP CAUTION
Unit is not weatherproof. For safe and proper operation the unit
must be located indoors where the ambient air temperature
is a minimum of 70°F (21°C) and a maximum of 85°F (29°C).
CAUTION
The toasting of coated or buttered products such as garlic
bread, cheese sandwiches and sweet rolls is NOT recommended.
Residue will reduce toaster performance and could possibly
ignite inside the toaster.
CAUTION
When setting up the unit for operation, make sure power
to the unit is off and the toaster is at room temperature. Failure
to do so could result in personal injury.
Toast Feed Ramp
The toast feed ramp is installed at the factory and can be used
in two positions. See 6 .
1. When in the upright position, the toaster is set for automatic
feed. Bread products enter the toaster by placing them
on the feed ramp and releasing.
2. For manual feeding of product, tip the feed ramp until it rests
on top of the unit. In this position bread products can be
manually loaded by placing directly on the conveyor belt.
CAUTION
Some exterior surfaces on the unit will get hot. Use caution
when touching these areas to avoid injury.
Toast Crumb Tray
Install toast crumb tray directly below the conveyor belt and below
the stop pins. Insert until the front of the crumb tray meets the stop
pins. See 7 .
CAUTION
To avoid damage to the unit or injury to personnel always
operate toaster with crumb tray installed.
CAUTION
To avoid any injury, do not remove the crumb tray for cleaning
until toaster is cool.
Front or Rear Discharge
Toast-Qwik units can be set up so toasted product discharges
at either the front or the rear of the unit.
TQ-10 & TQ-15 MODELS ONLY
The TQ-10 & TQ-15 models use a one piece discharge
chute/collector pan. The installation location determines
discharge area.
For front discharge install toaster chute from the front
of the toaster with the curved end inward and the rear lip
of the chute on the rear most pins. See 8 .
For rear discharge install toaster chute from the rear
of the toaster with the curved end in, and the lip of the chute over
the inside set of pins. See 9 .
TQ-400, -800 & -1200 SERIES
TQ-400, -800 and -1200 series toasters use a separate discharge
chute and collector pan.
For front discharge install the chute first by placing the curved
end inward until the rear lip of the chute is on the upper most set
of pins and the front slots on the chute are on the inside set of pins.
Position the collector pan, with the open end in first, over
the remaining sets of pins. Align slanted notches over the pins
and lower into place. See 10 .
For rear discharge the TQ-400, -800 and -1200 series toasters
do not use the discharge chute. If the chute is installed remove it.
To set-up toaster for rear discharge position, install the collector
pan, with the open end first, over the set of pins at the rear
of the unit. Align the straight notches over the pins and lower into
place. See 11 .

10 Form No. TQ2CEM-0903
OPERATION
TQ-10 & TQ-15 MODELS
1. Plug toaster into a properly grounded electrical outlet
of the correct voltage, size and plug configuration. See
SPECIFICATIONS for details.
2. To toast the top and bottom sides
of the bread, place the TOP HEAT and BOTTOM HEAT
switches in the ON position.
To toast on the top side only, place the TOP HEAT switch
in the ON position and the BOTTOM HEAT switch
in the OFF position.
To toast on the bottom side only, place the TOP HEAT
switch in the OFF position and the BOTTOM HEAT switch
in the ON position.
See Figure 12 .
3. Turn the COLOR CONTROL to the lightest position while
the unit heats up.
NOTE: Allow approximately 15 to 20 minutes
for a warm-up period.
4. After warm-up period, set the COLOR CONTROL
to the medium position and toast two slices of bread product
then re-adjust the COLOR CONTROL to the desired setting.
NOTE: To toast moist products such as English Muffins, rye bread
or whole wheat, slow the conveyor by turning the COLOR
CONTROL knob to a darker setting (clockwise).
TQ-400, -405, -800, -805, -800H & -1200 MODELS
1. Plug toaster into a properly grounded electrical outlet
of the correct voltage, size and plug configuration. See
SPECIFICATIONS for details.
2. Place the On/Off switch in the ON position.
See 13 .
3. Turn the TOP HEAT Control and BOTTOM HEAT Control
clockwise to the highest setting.
4. Turn the COLOR CONTROL to the lightest position while the
toaster heats up.
NOTE: Allow approximately 15 to 20 minutes
for a warm-up period.
5. After warm-up period, toast two slices of bread product. Adjust
the COLOR CONTROL if needed.
NOTE: If toasted bread is too dark with the Color Control
set on the lightest setting, adjust the bottom and top heat controls
as needed. (Allow 15 to 20 minutes for toaster to re-adjust to new
setting before resuming operation.)
NOTE: To toast moist products such as English Muffins, rye bread
or whole wheat, slow the conveyor by turning the Color Control
knob to a darker setting (clockwise).
NOTE: When toasting on a single-sided product such
as a bun or bagel place the product with the cut side facing
up. Adjust the Bottom Heat Control to a light setting, toast two
slices of bread product and adjust the Top and Bottom Heat Control
as needed.
TQ-400BA, -800BA & -800HBA MODELS
NOTE: TQ-400BA, -800BA and -800HBA toasters are designed
specifically for toasting one side of a bread product, such as a bun
or bagel. These models toast with the cut side facing up.
1. Plug toaster into a properly grounded electrical outlet
of the correct voltage, size and plug configuration. See
SPECIFICATIONS for details.
2. Place the On/Off switch in the ON position.
See 13 .
3. Turn the TOP HEAT Control clockwise to the highest setting.
Turn the BOTTOM HEAT Control counter-clockwise
to the lowest setting.
4. Turn the COLOR CONTROL to the lightest position while the
toaster heats up.
NOTE: Allow approximately 15 to 20 minutes
for a warm-up period.
5. After warm up period, toast two slices of bread product. Adjust
the COLOR CONTROL if needed.
NOTE: If cut-side of bread product is too dark with the Color
Control set on the lightest setting, adjust the Top Heat Control
as needed. (Allow 15-20 minutes for toaster to re-adjust to new
setting before resuming operation.)
POWER SAVE MODE WITH INDICATOR
LIGHT
All TQ-400, -800 and -1200 series toasters have a built-in Power
Save Mode with Indicator light feature. This feature allows the
toaster to go into stand-by and reduces power to the heating
elements by 50%. During the Power Save Mode the indicator light
on the control panel will flash.
To activate press the POWER SAVE Mode button until
the indicator light flashes. See 13 .
NOTE: To place toaster back into full operation push the Power
Save button or turn any knob until the indicator light stops flashing
and stays on. Allow a minimum of 2-3 minutes before toasting. Unit
is back up to full power within 10 minutes.
COLORGUARD SYSTEM
All TQ-400, -800 and -1200 series toasters use a patented
ColorGuard Sensing System that monitors and automatically adjust
conveyor speed during high usage periods to assure toast
color uniformity.
NOTE: The ColorGuard Sensing System is inoperable for
approximately ten minutes after any heat adjustments are made.

MAINTENANCE
11
Form No. TQ2CEM-0903
GENERAL
The Hatco Toast-Qwik Electric Conveyor Toasters are designed
for maximum durability and performance, with
minimum maintenance.
WARNING
To avoid any injury, turn the power switch OFF, unplug the
unit from the power source and allow to cool before performing
any maintenance.
CLEANING WARNING
This appliance is not of jet-proof construction. Do not use
jet-clean-spray to clean this appliance.
Exterior
To preserve the bright finish of the unit, it is recommended
that the exterior surfaces be wiped daily with a damp cloth.
Stubborn stains may be removed with a good stainless steel cleaner
or a non-abrasive cleaner. Hard to reach areas should be cleaned
with a small brush and mild soap.
CAUTION
Use only non-abrasive cleaners. Abrasive cleaners could scratch
the finish of your Toast-Qwik toaster marring its appearance
and making it susceptible to soil accumulation.
Toast Crumb Tray & Toast Collector Pan
Remove from unit and wash with soap and water,
then rinse.
Toast Feed Ramp
Press in the two wire spokes and remove guide from unit. Wipe
clean with a soft, damp cloth or soak the guide in a mild solution
of 227 milliliters of ammonia and 3.785 liters of water (1 cup and
1 gallon). Re-install guide by aligning wire spokes
with holes in toaster.
Bottom Heating Reflector
The bottom heating element reflector has slots which allow bread
crumbs to drop through to the crumb tray. Over an extended period
of use bread crumbs may buildup on the reflector and not drop
through onto the tray. To remove buildup, allow the toaster to cool
and wipe the crumbs onto the crumb tray using a bristle brush.
LUBRICATION
The conveyor gear motor and conveyor system
are permanently lubricated and require no lubrication.
WARNING
If service is required on this unit, contact your Authorized
Hatco Service Agent, or contact the Hatco Service Department
at 800-558-0607 or 414-671-6350; fax [phone]
or International fax [phone].
WARNING
This product has no “user” serviceable parts. To avoid damage
to the unit or injury to personnel, use only Authorized Hatco
Service Agents and Genuine Hatco Parts when service
is required.
WARNING
Genuine Hatco Replacement Parts are specified to operate
safely in the environments in which they are used. Some
aftermarket or generic replacement parts do not have the
characteristics that will allow them to operate safely in Hatco
equipment. It is essential to use Hatco Replacement Parts when
repairing Hatco equipment. Failure to use Hatco Replacement
Parts may subject operators of the equipment to hazardous
electrical voltage, resulting in electrical shock or burn.

Form No. TQ2CEM-090312
HATCO LIMITED WARRANTY
1. PRODUCT WARRANTY
Hatco warrants the products that it manufactures (the “Products”)
to be free from defects in materials and workmanship, under normal
use and service, for a period of one (1) year from the date
of purchase when installed and maintained in accordance with
Hatco’s written instructions or 18 months from the date of shipment
from Hatco. Buyer must establish the product’s purchase date
by returning Hatco’s Warranty Registration Card or by other means
satisfactory to Hatco in its sole discretion.
Hatco warrants the following Product components to be free from
defects in materials and workmanship from the date of purchase
(subject to the foregoing conditions) for the period(s)
of time and on the conditions listed below:
a) One (1) Year Parts and Labor PLUS One (1)
Additional Year Parts-Only Warranty:
Toaster Elements (metal sheathed)
Drawer Warmer Elements (metal sheathed)
Drawer Warmer Drawer Rollers and Slides
Food Warmer Elements (metal sheathed)
Infra-Black®Elements (metal sheathed)
Display Warmer Elements (metal sheathed air heating)
Holding Cabinet Elements (metal sheathed air heating)
b) One (1) Year Parts and Labor PLUS Four (4)
Additional Years Parts-Only Warranty on
pro-rated terms that Hatco will explain at
Buyer’s Request:
Powermite®Gas Booster Heater Tanks
Mini Compact Tanks (stainless steel)
3CS and FR Tanks
c) One (1) Year Parts and Labor PLUS Four (4)
Additional Years Parts-Only Warranty PLUS
Five (5) Year Parts-Only Warranty
on pro-rated terms that Hatco will explain
at Buyer’s Request:
Booster Heater Tanks (Castone®)
d) One (1) Year Parts-Only Warranty for
components not installed by Hatco:
Accessory Components (including but not
limited to valves, gauges and remote switches)
THE FOREGOING WARRANTIES ARE EXCLUSIVE
AND IN LIEU OF ANY OTHER WARRANTY, EXPRESSED
OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY
IMPLIED WARRANTY OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE OR PATENT
OR OTHER INTELLECTUAL PROPERTY RIGHT
INFRINGEMENT. Without limiting the generality of the foregoing,
SUCH WARRANTIES DO NOT COVER: Coated incandescent
light bulbs, fluorescent lights, lamp warmer heat bulbs, glass
components, Product failure in booster tank, fin tube heat
exchanger, or other water heating equipment, caused by liming,
sediment buildup, chemical attack or freezing, Product misuse,
tampering or misapplication, improper installation, application
of improper voltage, or recalibration of thermostats
or high limit switches, or transportation damage.
2. LIMITATION OF REMEDIES AND DAMAGES
Hatco’s liability and Buyer’s exclusive remedy
hereunder will be limited solely, at Hatco’s option,
to repair or replacement by a Hatco-authorized
service agency (other than where Buyer is located outside
of the United States or Canada, in which case Hatco’s liability
and Buyer’s exclusive remedy hereunder will be limited solely
to replacement of part under warranty) with respect to any claim
made within the applicable warranty period referred to above.
Without limiting the generality of the foregoing, all portable
Products (as defined in N.S.F. 4-4.28.4) shall be delivered by Buyer,
at its sole expense, to the nearest Hatco-authorized service agency
for replacement or repair. Hatco reserves the right to accept or reject
any such claim in whole or in part. Hatco will not accept the return
of any Product without prior written approval from Hatco,
and all such approved returns shall be made at Buyer’s sole
expense. HATCO WILL NOT BE LIABLE, UNDER ANY
CIRCUMSTANCES, FOR CONSEQUENTIAL OR INCIDENTAL
DAMAGES, INCLUDING BUT NOT LIMITED TO LABOR
COSTS OR LOST PROFITS RESULTING FROM THE USE
OF OR INABILITY TO USE THE PRODUCTS OR FROM THE
PRODUCTS BEING INCORPORATED IN OR BECOMING
A COMPONENT OF ANY OTHER PRODUCT OR GOODS.

Form No. TQ2CEM-090313
NOTES

HATCO CORPORATION
P.O. Box 340500, Milwaukee, WI 53234-0500 U.S.A.
[phone] [phone]
Parts & Service Fax [phone] Int’l. Fax [phone]
www.hatcocorp.com
Part No. 07.04.367.00 Form No. TQ2CEM-0903
Printed in U.S.A. September 2003
IMPORTANT OWNER INFORMATION
Record the model number, serial number, voltage and purchase date
of your unit in the spaces below. Please have this information
available when calling Hatco for service assistance.
Model No.______________________________________________
Serial No. ______________________________________________
Voltage ________________________________________________
Date of Purchase ________________________________________
Schreiben Sie die Modellbezeichnung, die Seriennummer,
die Spannung und das Kaufdatum in die folgenden Zeilen. Haben
Sie bitte dies Information zur Hand, wenn Sie Hatco wegen einer
Service-Unterstützung anrufen.
Modellbezeichnung ______________________________________
Seriennummer __________________________________________
Spannung ______________________________________________
Kaufdatum______________________________________________
Indicare il numero del modello, il numero di serie, la tensione
di alimentazione e la data di acquisto della propria unità negli spazi
di seguito. Queste informazioni dovranno essere fornite nel
momento in cui verrà richiesta l’assistenza Hatco.
N. del modello __________________________________________
N. di serie ______________________________________________
Tensione di alimentazione ________________________________
Data di acquisto ________________________________________
Noteer het modelnummer, serienummer, de spanning en de
aankoopdatum van uw apparaat in de ruimte onderaan. Zorg ervoor
dat u deze informatie ter beschikking hebt als u Hatco voor
service belt.
Modelnr. ______________________________________________
Serienr. ________________________________________________
Spanning ______________________________________________
Aankoopdatum __________________________________________
Anote el número de modelo, número de serie, voltaje y fecha
de compra de su unidad en los espacios a continuación. Por favor,
tenga esta información disponible cuando llame a Hatco para
recibir asistencia técnica.
Modelo No. ____________________________________________
Serie No. ______________________________________________
Voltaje ________________________________________________
Fecha de compra ________________________________________
Noter le numéro de modèle, le numéro de série, le voltage et
la date d’achat de votre appareil ci-dessous. Veuillez avoir cette
information à portée de la main si vous appelez Hatco pour
assistance.
Modèle No. ____________________________________________
Numéro de série ________________________________________
Voltage ________________________________________________
Date d’achat ____________________________________________
