TOAST-QWIK ® ELECTRIC CONVEYOR TOASTERS
Models TQ-400, -400BA, -400H, -800, -800BA, -800H, -800HBA, -1200, -1800, -1800BA, -1800H, -1800HBA, -10
The Hatco Toast-Qwik is an economical
conveyor toaster with fast, dependable
and versatile toasting, offering 350 to
1800 slices per hour. Hatco toasters
utilize conveyor speed, not temperature
to determine toasting color. This method
allows for instant adjustment of toasting
time to match the bread product
being toasted.
FLEXIBILITY
For uniformly colored golden-brown toast,
as well as bagels, buns, and English
muffins, Toast-Qwik Conveyor Toasters
provide the optimum in features, quality
and value. The electronic controls
precisely regulate both top and bottom
heating elements for perfect toasting
every time. The exclusive, patented
ColorGuard sensing system monitors
cabinet temperature and adjusts conveyor
speed during high usage periods to
assure uniform toast. The power save
mode with indicator light saves energy
and money during slow periods.
Hatco versatility offers standard and
bagel models, as well as versions with
a taller opening for thicker products
and a high-speed model. The efficient
design of front or rear discharge allows
Toast-Qwik to be placed where it is
most convenient – for sending product
to operator side or customer/server.
Hatco Toast-Qwik toasters feature
permanently lubricated ball bearing motor
and heating elements guaranteed against
burnout and breakage for two years.
QUALITY
The following features assure the finest
performance for years to come:
• ColorGuard sensing system assures
toast uniformity for TQ-400, -800,
-1200, and -1800 series.
• Electronic infinite controls regulate
top and bottom heat.
• Easy-to-load rack with front or
rear discharge.
• Power save mode conserves energy
and saves money.
•
Models with 2" or 3" (51 or 76 mm) high
openings for all types of bread products.
• Aluminum toast collector tray for
TQ-400, -800, -1200, and -1800 series
prevents condensation.
• Insulation and an interior fan provide
cool surface temperatures.
METAL SHEATHED HEATING ELEMENTS GUARANTEED
AGAINST BURNOUT AND BREAKAGE FOR TWO YEARS.
ANSI/NSF 4
Model TQ-400
Model TQ-10
Model TQ-800HBA
Model TQ-800H
Model TQ-1800H
For lower volume applications,
the Toast-Qwik TQ-10
model is an
economical conveyor toaster with the
capacity of up to 300 slices per hour.
Features include independent controls
for upper and lower elements allowing
single- or double-side toasting,
conveyor speed to determine the
toast color, and an easy-to-load rack
with front or rear discharge. Durable
painted steel
top and aluminized
steel construction assures years of
trouble-free service.
Product Flow

ITEM#
TOAST-QWIK ®
ELECTRIC CONVEYOR TOASTERS
Models TQ-400, -400BA, -400H, -800, -800BA, -800H, -800HBA, -1200, -1800, -1800BA, -1800H, -1800HBA, -10
HATCO CORPORATION P.O. Box 340500 Milwaukee, WI 53234-0500 U.S.A. • [phone] • [phone]
Fax [phone] • Int’l. Fax [phone] • www.hatcocorp.com • E-mail: [email protected]
Form No. TQ-1006(S) Printed in U.S.A.
Model 120V 208V 240V
TQ-400 15.0 amps ➀➁*10.7 amps ➂9.3 amps ➂
TQ-400BA 14.8 amps ➀➁* 9.0 amps ➂7.8 amps ➂
TQ-400H — 10.7 amps ➂9.3 amps ➂
TQ-800, -800H — 16.0 amps ➃13.9 amps ➂➃*
TQ-800BA, -800HBA — 15.8 amps ➃13.7 amps ➂➃*
TQ-1200 — 19.4 amps ➄16.8 amps ➄
TQ-1800 —21.4 amps ➄18.5 amps ➄
TQ-1800H — 22.4 amps ➄19.4 amps ➄
TQ-1800BA, -1800HBA — 22.0 amps ➄19.1 amps ➄
TQ-10 15.0 amps ➀➁* 8.8 amps ➂7.6 amps ➂
DIMENSIONS
TQ-400, -400BA: 141⁄2"W x 173⁄4"D x 147⁄8"H (368 x 451 x 378 mm).
TQ-400H: 141⁄2"W x 173⁄4"D x 157⁄8"H (368 x 451 x 403 mm).
Tray extends 21⁄2" (64 mm) in rear.
TQ-800 Series, -1200:
141⁄2"W x 223⁄4"D x 165⁄8"H (368 x 578 x 422 mm).
Tray extends 61⁄2" (165 mm) in rear.
TQ-1800 Series: 181⁄2"W x 223⁄4"D x 165⁄8"H (470 x 578 x 422 mm).
Tray extends 61⁄2" (165 mm) in rear.
TQ-10: 141⁄2"W x 173⁄4"D x 133⁄4"H (368 x 451 x 349 mm).
Maximum Product Size:
TQ-400, -400BA, -800, -800BA, -1200: 95⁄8"W x 13⁄4"H (244 x 44 mm).
TQ-400H, -800H, -800HBA: 95⁄8"W x 23⁄4"H (244 x 70 mm).
TQ-1800, -1800BA: 141⁄4"W x 13⁄4"H (362 x 44 mm).
TQ-1800H, -1800HBA: 143⁄8"W x 23⁄4"H (365 x 70 mm).
TQ-10: 95⁄8"W x 11⁄2"H (244 x 38 mm).
VOLTAGE
TQ-400 Series, -800 series, -1200, -10: 120, 208, and 240 volts,
60 Hz, single phase.
TQ-1800 Series: 208 and 240 volts, 60 Hz, single phase.
CORD LOCATION
Bottom right corner on back of unit.
PLUG CONFIGURATIONS
OPTIONS (NOT FOR RETROFIT)
❑Automatic Power Save Mode (TQ-400, -800, -1200, -1800
Series only)
❑Extended Feed Guide (Adds 3" (76 mm)) (TQ-400, -800,
-1200, -1800 Series only)
❑Control Cover
SPECIFICATIONS
133⁄4"
(349 mm)
4"
(102 mm)
SIDE VIEW
FRONT VIEW
173⁄4" (451 mm)
103⁄8"
(264 mm)
141⁄2" (368 mm)
PRODUCT SPECS
Conveyor Toaster
The electric Conveyor Toaster shall be a Hatco Model ....as
manufactured by the Hatco Corporation, Milwaukee, WI
53234 U.S.A.
The toaster shall have the capacity to toast up to ....pieces per
minute and it shall be rated at ....kW, ....volts, single phase.
The toaster shall be of stainless steel (or aluminized TQ-10)
design and shall include a front mounted control panel with
state-of-the-art electronic top and bottom heat controls,
ColorGuard sensing system (patented), variable speed control,
power save mode with indicator light and a toast collector pan
(except TQ-10).
The toaster will have metal sheathed heating elements and
factory attached UL listed cord and plug.
TQ-10 will have a durable painted steel top and aluminized steel
construction with controls for power, heating elements, and
conveyor speed.
ACCESSORIES
❑ 20 Amp Receptacle, 125V (NEMA 5-20R)
❑ 20 Amp Receptacle, 250V (NEMA 6-20R)
❑30 Amp Receptacle, 250V (NEMA 6-30R)
†Toasting capacity may vary by product. Toasting of coated products is
not recommended.
•120 volts only. 2.2 kW for 208 and 240 volt models.
▼
BA models toast one side only.
Toast-Qwik can be shipped United Parcel Service or Roadway
Package System.
Model kW Type Cap./Min.†Shipping Weight
TQ-400 1.8•All 6 slices 46 lbs. (21 kg)
TQ-400BA▼1.8 Bagels or Buns 6 slices 46 lbs. (21 kg)
TQ-400H 2.2 All 6 slices 48 lbs. (22 kg)
TQ-800 3.3 All 14 slices 52 lbs. (24 kg)
TQ-800BA▼3.3 Bagels or Buns 14 slices 52 lbs. (24 kg)
TQ-800H 3.3 All 14 slices 52 lbs. (24 kg)
TQ-800HBA▼3.3 Bagels or Buns 14 slices 52 lbs. (24 kg)
TQ-1200 4.0 All 20 slices 52 lbs. (24 kg)
TQ-1800 4.4 All 30 slices 75 lbs. (34 kg)
TQ-1800BA▼4.6 Bagels or Buns 30 slices 75 lbs. (34 kg)
TQ-1800H 4.6 All 30 slices 75 lbs. (34 kg)
TQ-1800HBA
▼4.6 Bagels or Buns 30 slices 75 lbs. (34 kg)
TQ-10 1.8 All 5 slices 34 lbs. (15 kg)
NEMA 5-15P
Selector Chart
(Based on serving 2 slices per customer.)
AMP RATING & PLUG SUPPLIED
Model TQ-10
Models TQ-400, -800, -1200, -1800 Series
*➁➃ For Canada.
➀
➄
➁➂
➃
NEMA 5-20P NEMA 6-15P
NEMA 6-20P
SIDE VIEW
FRONT VIEW
TQ-400 Series
173⁄4" (451 mm)
TQ-800, -1200, -1800 Series
223⁄4" (578 mm)
TQ-400, -400BA
147⁄8" (378 mm)
TQ-400H
157⁄8" (403 mm)
TQ-800, -1200,
-1800 Series
165⁄8" (422 mm)
TQ-400, -800, -1200 Series
141⁄2" (368 mm)
TQ-1800 Series
181⁄2" (470 mm)
TQ-400, -800, -1200 Series
103⁄8" (264 mm)
TQ-1800 Series
143⁄8" (365 mm)
NEMA 6-30P
Number of Serving Time
Customers TQ-400, -400BA, TQ-800, -800BA, TQ-1200 TQ-1800, -1800H,
-400H, TQ-10 -800H, -800HBA -1800BA, -1800HBA
30 12 Minutes 5 Minutes 3 Minutes 2 Minutes
60 24 Minutes 9 Minutes 6 Minutes 4 Minutes
90 36 Minutes 13 Minutes 9 Minutes 6 Minutes
120 48 Minutes 18 Minutes 12 Minutes 8 Minutes
