TOAST-RITE®
ELECTRIC CONVEYOR TOASTERS
Models TRH-50, TRH-60
The Hatco Toast-Rite is a perfect
alternative to pop-ups. Toast-Rite
features instant color control on every
toasted product. Conveyor speed, not
temperature, determines toast color.
You get faster, more uniform results slice
after slice.
Multiple heating elements assure
continuous toasting. If an element should
fail, Toast-Rite will keep operating at
a slightly lower production rate.
FLEXIBILITY
All Hatco Toast-Rite models include
a
heated toast storage area that holds
toast
at serving temperatures and
eliminates condensation, preventing
soggy toast.
Toast-Rite toasts everything from bread
to buns, bagels to English muffins,
...even frozen waffles.
Every Toast-Rite model features a
speed
control, manual advance (can be
ordered without), and factory attached
4' (1219 mm)
cord and plug as standard
equipment. All
heating elements are
guaranteed against burnout and
breakage for two years.
QUALITY
The following features assure the finest
performance for years to come:
• Capacities of up to 8/min = 480
or 10/min = 600 slices per hour.
• Select the degree of golden brown
color desired and Hatco’s color
sensing system holds it automatically,
slice after slice.
• All Toast-Rite models include
a heated toast storage area designed
to maintain serving temperatures and
prevent condensation.
• Stainless steel construction is built for
years of trouble-free service.
• Multiple heating elements assure
continuous toasting and are
guaranteed against burnout and
breakage for two years.
• Designed to maximize operating
efficiency and lower costs, Toast-Rite
is fully insulated. The fiberglass heat
barrier reflects heat back into the
toasting area.
• Toast-Rite features a power saving
thermostat for energy savings during
non-peak times.
• Each Toast-Rite model features
a speed control, manual advance,
and a 4' (1219 mm) cord with plug.
METAL SHEATHED HEATING ELEMENTS GUARANTEED
AGAINST BURNOUT AND BREAKAGE FOR TWO YEARS.
Model TRH-60
Insulated
Panels
Variable
Speed
Conveyor
Vented Motor
Compartment
Heavy-Duty
Gear Motor
Multiple
Heating
Elements
Manual
Advance
Speed
Control
Selector
Switch
Heated Toast
Storage Area
Easy-To-
Remove
Baskets
Stainless
Steel
Finish

ITEM#
SPECIFICATIONS
PRODUCT SPECS
Conveyor Toaster
The electric Conveyor Toaster shall be a Hatco Model ....as
manufactured by the Hatco Corporation, Milwaukee, WI
53234 U.S.A.
The toaster shall have the capacity to toast up to ....
pieces per minute and it shall be rated at ....kW, ....volts,
single phase.
The toaster shall be of stainless steel design and shall include a
front mounted control panel with a toast selector knob, variable
speed control knob, and a toast collector pan.
The toaster will have multiple metal sheathed heating elements
and an impedance protected motor. It shall be complete with
factory attached UL listed 4' (1219 mm) cord and plug.
TOAST-RITE®
ELECTRIC CONVEYOR TOASTERS
Models TRH-50, TRH-60
OPTIONS (NOT FOR RETROFIT)
❑Control Cover
Model 120V 208V 240V
TRH-50 22.8 amps ➀13.2 amps ➁11.4 amps ➁
TRH-60 — 18.5 amps ➁➂* 16.0 amps ➁
†Toasting capacity may vary by product. Toasting of coated products is
not recommended.
Model kW Type Cap./Min.†Shipping Weight
TRH-50 2.7 Bread or Buns 8 slices 60 lbs. (27 kg)
TRH-60 3.8 Bread or Buns 10 slices 60 lbs. (27 kg)
(Based on serving 2 slices per customer.)
DIMENSIONS
All Models: 171⁄2"W x 275⁄8"D x 161⁄4"H (445 x 702 x 413 mm).
Tray Extends 5" (127 mm).
Basket Size: 10" x 45⁄8" (254 x 117 mm).
Maximum Bread Product Thickness: 11⁄4" (32 mm).
VOLTAGE
208 and 240 volts, 60 Hz, single phase (use NEMA 6-20P,
model TRH-60, 208 volts, use NEMA 6-30P for Canada).
Model TRH-50 available in 120 volts – with a NEMA 5-30P plug.
Export voltages available.
CORD LOCATION
Bottom right of center on back of unit.
PLUG CONFIGURATIONS
Selector Chart
AMP RATING
5" (127 mm)
171⁄2" (445 mm)
FRONT VIEW
275⁄8" (702 mm)
161⁄4"
(413 mm)
Location
of Cord
Manual Advance
SIDE VIEW
Product Flow
*➂For Canada.
➃& ➄Export only.
NEMA 5-30P
➀
➃➄
➁➂
NEMA 6-20P NEMA 6-30P
CEE 7/7 Schuko BS-1363
HATCO CORPORATION P.O. Box 340500 Milwaukee, WI 53234-0500 U.S.A. • [phone] • [phone]
Fax [phone] • Int’l. Fax [phone] • www.hatcocorp.com • E-mail: [email protected]
Form No. TR-1006(S) Printed in U.S.A.
ACCESSORIES
❑4" (102 mm) Adjustable Legs (4)
❑ 20 Amp Receptacle, 250V (NEMA 6-20R)
❑30 Amp Receptacle, 125V (NEMA 5-30R)
❑30 Amp Receptacle, 250V (NEMA 6-30R)
Number of Model Model
Customers TRH-50 TRH-60
30 8 Minutes 6 Minutes
60 15 Minutes 12 Minutes
90 22 Minutes 18 Minutes
120 29 Minutes 24 Minutes
