TOAST KING®
ELECTRIC CONVEYOR TOASTERS
Models TK-72, TK-100, TK-135B, TK-155B
The Hatco Toast King conveyorized
toaster combines fast heat-up, uniform
toasting, and dependable performance
to handle peak serving periods. Toast
King features three basket access for
fast loading and a vented top to keep
heat away from the operator.
Hatco toasters utilizes conveyor speed,
not temperature to determine toasting
color. This method allows for instant
adjustment of toasting time to match
the bread product being toasted.
FLEXIBILITY
Models TK-72 and TK-100 are bread
or bun toasters that feature instant color
control on every toasted product – even
frozen waffles and French toast. Toast
King toasts buns up to 51⁄2" (140 mm)
wide and “Texas Toast” up to 11⁄4"
(32 mm) thick.
Model TK-135B is perfect for high-speed
bun-only operations. Buns come out
tender, uncrushed, and toasted to a
crisp golden brown. Heats the entire
bun, while toasting only the cut side.
Model TK-155B is specially developed
for toasting the 3-part hamburger bun.
Exclusive heat zones allow it to toast
both sides of the center part of a 3-part
bun and only the cut side of the top and
bottom portion – all in one operation.
QUALITY
The following features assure the finest
performance for years to come:
• Capacities of up to 720 or 1550 slices
per hour.
• Select the degree of golden brown
color desired and Hatco’s color
sensing system holds it automatically,
slice after slice.
• All Toast King models include
a heated
toast storage area designed
to maintain
serving temperatures and
prevent condensation.
• Multiple heating elements assure
continuous toasting and are
guaranteed against burnout and
breakage for two years.
• Designed to maximize operating
efficiency and lower costs, Toast King
is fully insulated. The fiberglass heat
barrier reflects heat back into the
toasting area.
• Toast King features a power-saving
thermostat for energy savings during
non-peak times.
• Each Toast King model features
a speed control, manual advance,
and a 4' (1219 mm) cord with plug.
METAL SHEATHED HEATING ELEMENTS GUARANTEED
AGAINST BURNOUT AND BREAKAGE FOR TWO YEARS.
Model TK-72
Model TK-135B

ITEM#
Location
of Cord
SIDE VIEW All Models
175⁄8" (448 mm)
TK-72
22" (559 mm)
TK-100, -135B, & -155B
FRONT VIEW
31⁄2" (89 mm)
33"
(838 mm)
171⁄2" (445 mm)
Manual Advance
TOAST KING®
ELECTRIC CONVEYOR TOASTERS
Models TK-72, TK-100, TK-135B, TK-155B
HATCO CORPORATION P.O. Box 340500 Milwaukee, WI 53234-0500 U.S.A. • [phone] • [phone]
Fax [phone] • Int’l. Fax [phone] • www.hatcocorp.com • E-mail: [email protected]
Form No. TK-1006(S) Printed in U.S.A.
OPTIONS (NOT FOR RETROFIT)
❑Control Cover
SPECIFICATIONS
PRODUCT SPECS
Conveyor Toaster
The electric Conveyor Toaster shall be a Hatco Model ....as
manufactured by the Hatco Corporation, Milwaukee, WI
53234 U.S.A.
The toaster shall have the capacity to toast up to ....pieces per
minute and it shall be rated at ....kW, ....volts, single phase.
The toaster shall be of stainless steel design and shall include a
front mounted control panel with a toast selector knob, variable
speed control knob, and a toast collector pan.
The toaster will have multiple metal sheathed heating elements
and an impedance protected motor. It shall be complete with
factory attached UL listed 4' (1219 mm) cord and plug.
DIMENSIONS
TK-72: 171⁄2"W x 175⁄8"D x 33"H (445 x 448 x 838 mm).
TK-100, TK-135B, TK-155B: 22"W x 175⁄8"D x 33"H
(559 x 448 x 838 mm).
Basket size: TK-72: 10"W x 45⁄8"H (254 x 117 mm).
TK-100, -135B, -155B: 141⁄2"W x 45⁄8"H (368 x 117 mm).
Tray extends: 31⁄2" (89 mm).
Maximum Bread Product Thickness: 11⁄4" (32 mm).
VOLTAGE
208 and 240 volts, 60 Hz, single phase, standard.
Export voltages available.
CORD LOCATION
Bottom left side on back of unit.
PLUG CONFIGURATIONS
Model kW Type Cap./Min.†Shipping Weight
TK-72 4.0 Bread and Buns 12 slices 76 lbs. (35 kg)
TK-100 5.0 Bread and Buns 16 slices 88 lbs. (40 kg)
TK-135B 4.3 Buns Only 22 slices 88 lbs. (40 kg)
TK-155B 5.0 3-Part Buns 25 slices 88 lbs. (40 kg)
Number of Model Model Model Model
Customers TK-72 TK-100 TK-135B TK-155B
30 5 Min. 4 Min. 3 Min. 3 Min.
60 10 Min. 8 Min. 6 Min. 5 Min.
90 15 Min. 11 Min. 8 Min. 7 Min.
120 20 Min. 15 Min. 11 Min. 9 Min.
150 25 Min. 19 Min. 14 Min. 12 Min.
(Based on serving 2 slices per customer.)
Model 208V 240V
TK-72 19.4 amps ➁16.8 amps ➁
TK-100 24.0 amps ➁21.0 amps ➁
TK-135B 20.7 amps ➁17.9 amps ➀➁*
TK-155B 24.0 amps ➁20.8 amps ➁
AMP RATING
Product
Flow
BS-1363CEE 7/7 SchukoNEMA 6-20P NEMA 6-30P
➀➁➂➃
*
➁For Canada.
➂& ➃ Export only.
†Toasting capacity may vary by product. Toasting of coated products is
not recommended.
Selector Chart
ACCESSORIES
❑Baskets for Jumbo 51/2" (140 mm) Buns (9 per Toaster)
❑4" (102 mm) Adjustable Legs (4)
❑20 Amp Receptacle, 250V (NEMA 6-20R)
❑30 Amp Receptacle, 250V (NEMA 6-30R)
