Hatteland HT B07CD STD User manual

User Manual HT B07CD STD
Updated: 29 Apr 2010 Doc Id: INB100032-1 (Rev 14)
Created:363
Approved: 6987
For models:
-A1, -B1
Slim
User Manual
HT B07CD STD - Maritime Stand-alone Computer
USER MANUAL
Hatteland Display AS, Åmsosen, N-5578 Nedre Vats, Norway
Tel: [phone] - [e-mail] - www.hatteland-display.com
Please visit www.hatteland-display.com for the latest electronic version of this manual.

Copyright © 2010 Hatteland Display AS
Aamsosen, N-5578 Nedre Vats, Norway
Information in this manual is copyrighted to the respective owners. All rights are reserved by
Hatteland Display AS. This information may not, in whole or in part, be copied, photocopied, reproduced,
translated or reduced to any electronic medium or machine-readable form without the prior written consent
of Hatteland Display AS.
The products described, or referenced, herein are copyrighted to the respective owners.
The products may not be copied or duplicated in any way. This documentation contains proprietary
information that is not to be disclosed to persons outside the user’s company without prior written consent
of Hatteland Display AS.
The copyright notice appearing above is included to provide statutory protection in the event of
unauthorized or unintentional public disclosure.
All other product names or trademarks are properties of their respective owners !
WARNING: This is a class A product. In a domestic environment this product may cause radio interference
in which case the user may be required to take adequate measures.

3
IND100206-15
INB100032-1 (Rev 14)
Contents
Contents................................................................................................. 3
Contents of package ..................................................................................4
General ................................................................................................... 5
About this manual ......................................................................................6
About Hatteland Display ............................................................................6
hatteland-display.com ................................................................................6
Contact Information....................................................................................6
Computers introduction..............................................................................7
Basic Construction - Fanless Stand-alone Computers ..............................8
Product Labels (Examples)........................................................................9
Installation............................................................................................ 11
Installation and mounting of computers ...................................................12
Cables......................................................................................................12
Conguring DC power input housing connector ...........................12
Ferrites.....................................................................................................13
Physical Overview - HT B07CD STD.......................................................14
Specications ...................................................................................... 19
Specications - HT B07CD STD ..............................................................20
Technical Drawings ............................................................................. 21
Technical Drawings - HT B07CD STD-A1................................................22
Technical Drawings - Mounting bracket ...................................................23
Technical Drawings - Accessories..................................................... 25
Technical Drawings - Mounting bracket/cable tension relievers ..............26
Appendixes .......................................................................................... 27
Pin Assignments - Common Connectors .................................................28
Basic Trouble-shooting ............................................................................31
HT B07 / HT B08 Specic Trouble-shooting ............................................32
Declaration of Conformity ........................................................................33
Return Of Goods Information...................................................................34
Terms .......................................................................................................35
Revision History .......................................................................................38

4
IND100207-2
INB100032-1 (Rev 14)
Item Description Illustration
FS-CABLE EU
1 pcs of power cable European Type F “Schuko” to IEC.
Length 1.8m
Note: Power cable not included with the DC model.
EUR TYPE F
IEC
80099
1 pcs of power cable US Type B plug to IEC.
Length 1.8m
Note: Power cable not included with the DC model.
US TYPE B IEC
VE013-A
1 pcs of Standard DVI to RGB/VGA Signal Cable.
DVI-I Male to HD-15 DSUB Male - Length 2.0m
HD DRIVER DVD
Documentation/Drivers/Software DVD for factory installed components like
mainboard, IDE, network etc.
Menu and Driver
browser for
Microsoft® Windows®
INB100032-1 or -2
1 pcs of User Manual
Note: Separate documentation for third party components, mainboard etc.
available on attached DVD. This printed manual only covers specific
information for Hatteland Display products and not third party components.
Test Reports papers:
1 pcs of Product Declaration
1 pcs of Computer Checklist
1 pcs of BurnInTest Certificate
This product is shipped with:
Contents of package
Package may also include:
Item Description Illustration
HT 00215 OPT-A1
Recovery Image - USB Memory stick
Note: Available as an accessory from manufacturer.
HT 00244 OPT-A1
Mounting Bracket RAL 9011.
HT 00228 OPT-A1
Mounting Bracket with cable relief, RAL 9011.

5INB100032-1 (Rev 14)
General

6
Hatteland Display AS
IND100077-1
INB100032-1 (Rev 14)
General
About this manual
The manual contains electrical, mechanical and input/output signal specications. All specications in this manual,
due to manufacturing, new revisions and approvals, are subject to change without notice. However, the last update
and revision of this manual are shown both on the frontpage and also in the “Revision History” chapter. Please use
that as a reference.
Furthermore, for third party datasheet and user manuals, please see dedicated interactive DVD (where included)
delivered with the product or contact our sales/technical/helpdesk personnel for support.
About Hatteland Display
Hatteland Displayis the leading technology provider of specialized display and computer products, delivering high
quality, unique and customized solutions to the international maritime, naval and industrial markets.
The company represents innovation and quality to the system integrators world wide. Effective quality assurance and
investment in sophisticated in-house manufacturing methods and facilities enable us to deliver Type Approved and Mil
tested products. Our customer oriented approach, technical knowledge and dedication to R&D, makes us a trusted
and preferred supplier of approved solutions, which are backed up by a strong service network.
hatteland-display.com
You will nd our website full of useful information to help you make an informed choice as to the right product for your
needs. You will nd detailed product descriptions and specications for the entire range on offer be it Series 1, Series
2, Computers & Panel Computers, Military solutions as well as the range of supporting accessories. The site carries
a wealth of information regarding our product testing and approvals in addition to company contact information for our
various ofces around the world, the global service centers and the technical help desk, all ensuring the best possible
support wherever you, or your vessel, may be in the world.
Contact Information
Head ofce, Vats / Norway:
Hatteland Display AS
Åmsosen
N-5578 Nedre Vats, Norway
Tel: [phone]
Fax: [phone]
[e-mail]
Sales ofce, Frankfurt / Germany:
Hatteland Display GmbH
Werner Heisenberg Strasse 12,
D-63263 Neu-Isenburg, Germany
Tel: [phone]
Fax: [phone]
Sales ofce, Oslo / Norway:
Solbråveien 20-22
N-1383 Asker
Norway
Tel: [phone]
Fax: [phone]
Sales ofce, Aix-en-Provence / France:
Hatteland Display SAS
31 Parc du Golf, 350,
Avenue JRGG de la Lauzière - CS 90519
13593 Aix-en-Provence Cedex 3, France
Tel: [phone]
Fax: [phone]
Sales ofce, San Diego / USA:
Hatteland Display Inc.
11440 W. Bernardo Court, Suite 300
San Diego, CA 92127, USA
Tel: [phone]
Fax: [phone]
For an up-2-date list, please visit www.hatteland-display.com/locations

7
Computers
IND101057-2
INB100032-1 (Rev 14)
General
Computers introduction
Hatteland Display’s range of type-approved marine computers is
designed to perform in harsh environments while providing the
performance and flexibility you expect. We offer rack mount and black
box/standalone computer solutions for every need. Our computers are
used by system integrators, boat builders and end-users and can be
found on all vessel types, all over the world.
If you are looking for a high quality marine computer for navigation,
monitoring or entertainment solutions, Hatteland Display can fulfil your
high expectations at a reasonable cost.
Our computer range covers all eventualities and requirements. We offer
a wide range of processor choices, HDD and power options, and solid
state technology, neatly engineered within industry standard form factors
such as 19” rack mount, 2U, 3U and 4U.
We continually develop our marine computers portfolio to make the best
use of emerging computer technology so you can be sure that your
Hatteland Display computer offers the power needed to run modern
applications, with the flexibility to be installed wherever you want, for any
marine use.
Designed to perform in harsh environments...
Winner of Red Dot awards 2009 / 2007
In 2009 the Hatteland Display HT C01 standalone computer won
a prestigous Red Dot Award with Honourable Mention distinction,
sucessfull detail solution.
The Design Zentrum Nordrhein Westfalen in Germany has been marking
outstanding international product design with its famous and highly
regarded dot since 1955. The Red Dot Product Design Award is an
annual international awards scheme where products from all industries
are chosen for their innovative visual and industrial design.
In 2007 the Hatteland Display Series 2 Display/Panel Computers
range won the Red Dot Award for the overall design and modular
backpack concept, which docks into the screen at the back, comprises
either the typical display connections or a fully equipped panel computer.
Even the computer backpack can operate on its own as a stand-alone
computer.

8
IND100077-60
INB100032-1 (Rev 14)
General
Basic Construction
Fanless Stand-alone Computers
Basic Construction - Fanless Stand-alone Computers
General illustration
Chassis with
cooling block
Powermodule Chassis
Power Module
uDOC Flash Disk(s)
Memory
Duo Processor
Mainboard
Power Input
Compact Flash Disk*
* Please note that compact ash disk is NOT part of a
factory standard dened product, but available optionally
or included with a custom product solution.
User Controls label
Front plate
with Serial Number Label
Bottom chassis plate
Row of connectors
Connector plate

9
IND100240-3
INB100032-1 (Rev 14)
General
Product Labels (Examples)
Warranty Label
This label may be present on the product (hardware dependent). If you are to perform service
on a unit still under warranty, the warranty will be void if this label is attempted removed, re-
glued or removed completely. This label is usually located on the back of the product and
covers an mechanical gap/edge or protects a key screw. This is to enable service departments
determine if there has been any unauthorized service on a product still under warranty.
Serial Number Label Layout
Product Type Manufacturer & Country
Barcode (TYP+SNO)
Input Voltage & Power Rating Manufactured Date yyyymmdd
Serial Number Label Placement (front)
B07 B08
Serial Number Label Nomenclature
AA AXXAA AAA-AX-XXXXXX NOMENCLATURE - A=Letters, X=Numbers
HT B07CD STD-A1-000135 Example
|| ||||| ||| || ||||||
|| ||||| ||| || ¤----- Serial Number. Due to revisions, numbers may be 1 to 7 digits
|| ||||| ||| ¤¤------- Power Input ID (A1=AC, A2=DC)
|| ||||| ¤¤¤---------- Standard Product Term ID / Reserved Customer ID
|| |||¤¤-------------- Processor Type (CD=Core Duo) / Reserved Customer ID
|| |¤¤---------------- Electronics / Mainboard / Technology Revision ID
|| ¤------------------ Chassis Size ID (B=Blackbox Computer)
¤¤-------------------- Manufacturer ID / Product Series ID

10 INB100032-1 (Rev 14)
This page left intentionally blank

11 INB100032-1 (Rev 14)
Installation

12
IND100210-1
INB100032-1 (Rev 14)
Installation
Installation and mounting of computers
1. Units may be intended for various methods of installation or mounting (rack mounting, panel mounting,
bracket mounting, ceiling/wall mounting); for details, please see the relevant mechanical drawings.
2. Adequate ventilation is a necessary prerequisite for the life of the unit. The air inlet and outlet openings must
denitely be kept clear; coverings which restrict ventilation are not permissible. The product might be without
any ventilation aperatures which means pt.2 does not apply.
3. Exposure to direct sunlight can cause a considerable increase in the temperature of the unit, and might under
certain circumstances lead to overtemperature. This point should already be taken into consideration when
the bridge equipment is being planned (sun shades, distance from the windows, ventilation, etc.)
4. Space necessary for ventilation, for cable inlets, for the operating procedures and for maintenance, must be
provided.
5. To further improve the cooling of the unit we recommend installing Cooling Fans underneath blowing upwards
into the unit air inlet. This may be required in high temperature applications and also when there is reason to
expect temperature problems due to non-optimal way of mounting.
6. For DC powered computer units proper grounding must be achieved by connecting a wire from the unit’s
ground (GND) screw (as indicated on the unit with a icon) to the grounding in your installation setup.
The wire should have a cross sectional area of at least 6mm2. The GND screw is located near the
other I/O connectors. Please review the “Physical Overview” chapter for further help.
General mounting instructions
1. The useful life of the components of all Electronics Units generally decreases with increasing ambient
temperature; it is therefore advisable to install such units in air-conditioned rooms. If there are no such
facilities, these rooms must at least be dry, adequately ventilated and kept at a suitable temperature in order
to prevent the formation of condensation inside the unit.
2. With most Electronic Units, cooling takes place via the surface of the casing. The cooling must not be
impaired by partial covering of the unit or by installation of the unit in a conned cabinet.
3. In the area of the wheel house, the distance of each electronics unit from the magnetic standard compass or
the magnetic steering compass must not be less than the permitted magnetic protection distance. This
distance is measured from the centre of the magnetic system of the compass to the nearest point on the
corresponding unit concerned. The exact distance is often mentioned in the specic product specications.
4. Transportation damage, even if apparently insignicant at rst glance, must immediately be examined and be
reported to the freight carrier. The moment of setting-to-work of the equipment is too late, not only for
reporting the damage but also for the supply of replacements.
Cables
Use only high quality shielded signal cables. For RGB/DVI cables use only cables with separate coax for Red, Green
and Blue.
Conguring DC power input housing connector
Note: Only applicable for certain models!
For installations that require DC power input, use the provided
2-pin DC Power Input housing with internal cable screw terminal.
1: Open the housing
2: Unmount the fasteners. (FIG 1)
3: Mount power cables to screw terminal (FIG 2). Note polarity!
4: Secure the cable tightly with fasteners (FIG 3, FIG 1)
5: Close the housing
Note: Please check polarity before connecting any cables
to the screw terminal.
General Installation Recommendations
Screw terminal
FIG 1
FIG 2
FIG 3
+ -
+ -
+
-

13
IND100210-1
INB100032-1 (Rev 14)
General Installation Recommendations
Installation
Ferrites
On selected products, the ferrites prevent high frequency
electrical noise (radio frequency interference) from exiting or entering
the equipment. To verify if your product require this, please see the
“Physical Overview” chapter in this manual. The ferrites are part of
the contents of the package also specied in the “Contents Of
Package” chapter early in this manual. The ferrites must be
mounted on specic cables to fully comply with the Type
Approvals!
The ferrites should be mounted (clipped in place on the cable as
shown in illustration) as close as possible to the cable connector
on the rear side of the computer product. Open up the ferrite,
place the cable inside as shown in FIG1, and then gently close it
until a click can be heard (FIG2).
FIG1
To computer
FIG2
To computer

14 INB100032-1 (Rev 14)
IND100133-25
Reset Button: (Hard Reset)
To reset the computer in case of severe software failure, press this button (it is mounted behind
the edge of the casing, to access it use a screwdriver or a pen), This reset button is a hard reset
which means the operating system will NOT be warned. Using this reset method may damage les
and / or operating system in worst case scenarios. Precaution should be taken when using this.
To perform a safe software reset, press either the power button, or use the operating system own
reset functionality if possible.
Power Button & Power LED:
To turn ON the computer, press down button and release it immediately. The power indication
(LED) will turn green and any operating system will automatically boot. To turn OFF the computer,
press down this button and hold it for 3 seconds. The operating system may require additionally
tasks to be performed before computer shuts down and turns off the unit.
Hard Disk LED (HDD LED):
The hard disk indication (LED) will turn orange when there occur read / write activity to / from the
hard disk.
Internal Disk Device:
The B07 unit can use 1 x SDD 2.5” or 2 x uDOC (4GB+) storage device as the main data
storage (hard drive). The operating system and all other les will be placed on this, normally visible
as drive C: This device is normally factory installed option. The storage device are mounted inside
the unit and are not visible/accessible externally.
Front / internal area of computer
Reset Button Power Button HDD LED Power LED
Physical Overview - HT B07CD STD
Internal Disk Device

15 INB100032-1 (Rev 14)
IND100133-25
PS/2 Mouse and PS/2 Keyboard INPUTS:
Connect the PS/2 mouse cable to the PS/2 5P Connector (female) marked with MS.
Connect the PS/2 keyboard cable to the PS/2 5P Connector (female) marked with KB.
Network INPUT/OUTPUT:
Supports 10/100Mbps Ethernet (LAN). Suitable for twisted pair cables CAT.5E. Make sure the
network cable connector ”clicks” into the RJ-45 connector.
USB1,2,3,4 INPUT/OUTPUT:
Supports any USB1.1 (12Mbps) or USB2.0 (480Mbps) compliant peripherals. Drivers for most
USB devices are usually included in operating system or on separate installation CD’s delivered
with Third Party products. USB 1.1 devices will operate in USB 1.1 mode (12 Mbps).
IEEE1394 Firewire INPUT/OUTPUT:
Supports any compliant Firewire peripherals. Drivers for most Firewire devices are usually
included in operating system or on separate installation CD’s delivered with Third Party products.
Firewire operates with 400 Mbps.
Connector area of computer
Physical Overview - HT B07CD STD
Power Input
USB 1,2
Mouse Port
Keyboard Port COM2
COM1Network LAN
FireWire SPDIF
USB 3,4
Audio Line In, Line Out, Mic
I/O Connector
DVI-I DVI-D
CF Reader
Composite Out
S-VHS Out

Physical Overview - HT B07CD STD
16 INB100032-1 (Rev 14)
IND100133-25
COM1 Serial Port INPUT/OUTPUT:
Supports RS-232 using D-SUB 9P Male connectors. Fasten the cable to the connector using the
provided screws on the cable housing itself.
COM2 Serial Port INPUT/OUTPUT:
Supports RS-232/422/485 (opto isolated) using D-SUB 9P Male connectors. Fasten the cable to
the connector using the provided screws on the cable housing itself.
DIGITAL INPUT/OUTPUT:
1 x D-SUB 9P Male connectors. This is a digital i/o interface with 3 channels available. This is a
feature connector and is primarily reserved for future and custom applications. But, in general it
can be congured for use with custom applications where external signals may need to be
monitored or controlled via custom software. Fasten the cable to the connector using the provided
screws on the cable housing itself.
DVI-I and DVI-D OUT:
Connect your DVI cables to the DVI-I or DVI-D 24P Connectors (female) on the rear side of the
unit. The DVI-I connector can function as regular RGB OUT by using a DVI-I > RGB/VGA
adapter. DVI-D connector is strictly for DVI use only. Screw the DVI cables to the connectors and
make sure you don’t bend any of the pins inside the cable connector when connecting. Please see
graphics card manual available on attached documentation CD.
Power INPUT:
The internal AC power module supports both 115VAC/60Hz and 230/50Hz power input using a
standard IEC European power plug.
CompactFlash Reader:
CompactFlash Reader supports Type I & II cards. Insert the card gently into the slot with the logo
facing upwards. The card is removed by pressing the EJECT button next to the card slot. A wide
range of card sizes are supported. Cards inserted into this slot can also be booted.

Physical Overview - HT B07CD STD
17 INB100032-1 (Rev 14)
IND100133-25
TV OUT / COMPOSITE OUT:
Connect your composite video signal cable into the RCA jack plug. This will output/clone
the DVI output, or be software configured to show full screen video playback whilst leaving the
operating system desktop free for other uses.
TV OUT / S-VIDEO OUT:
Connect your S-Video (SVHS) video signal cable into the mini 4-way din plug. It can only be
inserted one way and make sure you don’t bend any of the pins inside your cable.
This will output/clone the DVI output, or be software configured to show full screen video playback
whilst leaving the operating system desktop free for other uses.
Audio INPUT/OUTPUT:
All connectors are 3.5” Jack Stereo. AC’97 audio support. Either function as Stereo Line In, Stereo
Line Out and Stereo MIC In or as 6-channel surround out where conguration is as follows:
Line In - Rear Sound L/R
Line Out - Front Sound L/R
Mic In - Center/Subwoofer Sound.
These settings can be modied within the audio driver software.
SPDIF OPTICAL TOSLINK OUTPUT:
Enables optical transfer of the audio signal out to any optical SPDIF compliant equipment with
the appropriate cable. The optical interface is protected behind 2 mini hinged plastic doors which
will slide away when a connector/cable is inserted gently.

18 INB100032-1 (Rev 14)
This page left intentionally blank

19 INB100032-1 (Rev 14)
Specications

20 INB100032-1 (Rev 14)
IND100129-78
Specications - HT B07CD STD
PRODUCT SPECIFICATIONS - HT B07CD STD
2/2
T E C H N I C A L D E S C R I P T I O N
A P P R O V A L S & C E R T I F I C A T E S
These products have been tested / type approved by the following classification societies:
EN60945 4th (IEC945 4th) ClassNK - Nippon Kaiji Kyokai DNV - Det Norske Veritas GL - Germanischer Lloyd
IACS E10 BV - Bureau Veritas ABS - American Bureau of Shipping LRS - Lloyd's Register of Shipping
Power Specifications:
Physical Specifications:
• 268.00 (W) x 59.00 (H) x 310.00 (D) mm
• 10.55" (W) x 2.32" (H) x 12.20" (D)
• Weight: 4 kg (approx)
• Aluminium Cooling Chassis
• Mounting Plate (HT 00244 OPT-A1) included in delivery as standard.
Connector Type:
Note: All specifications are subject to change without prior notice!
Compass Safe Distance: HT B07CD STD Standard: 60cm Steering: 30cm
Computer Specifications: (Standard Model) Connector Type:
• Installed OS : None, please specify when ordering
• Processor : 1 x Intel® Core Duo™ processor (Dual Core 1.66GHz, 667MHz FSB, 2MB L2 Cache)
• Graphics : On-board Intel® GMA950 Graphics Chipset - Dual DVI (DVI-I & DVI-D) 1 x DVI-I & 1 x DVI-D
• System Chipset : Intel® 945GME with ICH7M
• BIOS : Award BIOS
• Expansion Slots : 1 x MiniPCI-Express socket
• Compact Flash : 1 x CompactFlash Reader Type I/II with eject button
• Ethernet : 2 x 10/100Mbps Realtek RTL8100C-LF with Wake-On-Lan 2 x RJ-45
• Serial Ports : 1 x RS-232 (Opto isolated) + 1 x RS-232/422/485 2 x DB9M
• Firewire : 1 x IEEE1394 Firewire 400Mbps - TI TSB43LV22 1 x IEEE1394 FireWire
• USB Ports : 4 x USB ports - Supports 2.0 & 1.1 4 x USB Type A
• Keyboard Port : Standard PS/2 mini DIN connector 1 x PS/2
• Mouse Port : Standard PS/2 mini DIN connector 1 x PS/2
• Audio : AC-97, 6-channel, LINE IN, LINE OUT, AMPLIFIED LINE OUT (8-ohm 2W) 3.5mm 3 x JACKS & 1 x SPDIF
• Video Outputs : 1 x Composite + 1 x S-VIDEO 1 x RCA & 1 x SVHS
• Speaker : On-board
• Power Manager : ACPI/APM
• Digital IO Interface : 3 x Digital IO Channels 1 x DB9M
• Other features : WatchDog Timer 256 segments, Temperature Monitoring
Power Supply Options:
• 115VAC/60Hz or 230VAC/50Hz : Model HT B07CD STD-A1/B1 (100W) STD IEC
• Power Consumption - Operating : 35W (approx)
• Memory : Upgradeable to 4GB RAM DDR2 667MHz option - (2 DIMM sockets on-board)
• Storage#1 : 2 x uDOC Flash Disk Option - Up to 4GB available and future support for larger sizes possible.
• Storage#2 : 1 x 2.5” Hard Disk (Flash SSD) Option (32GB each). RAID 0 & 1 - When available.
Note: These options are factory installed.
Available Component Options:
Environmental Considerations:
• Operating : Temperature -15 deg. C to +55 deg. C
Humidity up to 95%
• Storage : Temperature -20 deg. C to +60 deg. C
Humidity up to 95%
Safety Considerations:
Even although the test conditions for bridge units provide for a maximum
operating temperature of 55°C, continuous operation of all electronic
components should, if possible, take place at ambient temperatures of only
25°C. This is a necessary prerequisite for long life and low service costs.
M E C H A N I C A L D E S C R I P T I O N
HT B07 STD-A1 : As specified in "Computer Specifications (Standard Model) above.
HT B07 STD-B1 : As -A1 model including: 1 x 60GB 2.5" SSD, 2 x 1GB of RAM and Microsoft® Windows® XP Professional w/SP2.
Available Standardized Models:
• HT 00244 OPT-A1 = Mounting Bracket, RAL 9011
• HT 00228 OPT-A1 = Mounting Bracket with cable relief, RAL 9011
• HT 00215 OPT-A1 = USB memory stick with recovery image
Available Accessories:
