Hauck LVG SERIES User manual

TABLE OF CONTENTS
Subject Page
LVG-9
These instructions are intended to serve as guidelines covering the installation, operation, and maintenance of Hauck equipment. While
every attempt has been made to ensure completeness, unforeseen or unspecified applications, details, and variations may preclude
covering every possible contingency. WARNING: TO PREVENT THE POSSIBILITY OF SERIOUS BODILY INJURY, DO NOT USE OR
OPERATE ANY EQUIPMENT OR COMPONENT WITH ANY PARTS REMOVED OR ANY PARTS NOT APPROVED BY THE
MANUFACTURER. Should further information be required or desired or should particular problems arise which are not covered
sufficiently for the purchaser's purpose, contact Hauck Mfg. Co.
WARNING
These instructions are intended for use only by
experienced, qualified combustion start-up personnel.
Adjustment of this equipment and its components, by
unqualified personnel, can result in fire, explosion,
severe personal injury, or even death.
A. General Information……………………………………………………………………... 2
B. Receiving and Inspection………………………………………………………………. 2
C. Capacities………………...……………………………………………………………… 3
D. Dimensions………………………………………………………………………………. 6
E. Installation……………………………………………………………………………….. 6
F. Operation………………………………………………………………………………… 7
G. Maintenance……………………………………………………………………………... 7
GAS LIMITING ORIFICE VALVES
LVG SERIES
INSTRUCTIONS
HAUCK MANUFACTURING CO., 100 North Harris Street Cleona, PA 17042 717-272-3051
4/14 www.hauckburner.com Fax: [phone]

Page 2
LVG-9
A. GENERAL INFORMATION
The Hauck LVG Series Limiting Orifice Gas Valves are designed for use with each burner in a
multiple furnace application. They allow fine gas flow adjustment of individual burners to
achieve the desired air/gas ratio at each burner. The standard LVG series valves can be used
as straight through type valves, and are designed for use with any commercial fuel gas.
B. RECEIVING AND INSPECTION
Upon receipt, check each item on the bill of lading and/or invoice to determine that all
equipment has been received. A careful examination of all parts should be made to ascertain if
there has been any damage in shipment.
WARNING
This equipment is potentially dangerous with the possibility of serious personal injury
and property damage. Hauck Manufacturing Company recommends the use of flame
supervisory equipment and fuel safety shutoff valves. Furthermore, Hauck urges rigid
adherence to National Fire Protection Association (NFPA) standards and insurance
underwriter’s requirements. Operation and regular preventative maintenance of this
equipment should be performed only by properly trained and qualified personnel.
Annual review and upgrading of safety equipment is recommended.

Page 3
LVG-9
Notes
1. Capacities based on natural gas at 0.60 s.g. and 60°F (or 0°C).
2. Pressure drop measured across full open valve.
3. Maximum inlet pressure is 15 psig (1034 mbar)
4. For natural gas leakage rates with valve fully closed, consult Hauck.
Pipe 1"wc 2"wc 4"wc 6.9"wc 13.8"wc 20.8"wc 27.7"wc
Size 2.5 mbar 5 mbar 10 mbar 17.2 mbar 34.3 mbar 51.8 mbar 69 mbar
LVG 505E 1/2 NPT 275 410 575 757 1,055 1,290 1,470
LVG 507E 3/4 NPT 405 590 815 1,070 1,520 1,855 2,120
LVG 510D 1 NPT 635 870 1,230 1,625 2,245 2,750 3,155
LVG 512D 1-1/4 NPT 1,070 1,520 2,160 2,840 4,020 4,890 5,630
LVG 515D 1-1/2 NPT 1,500 2,140 3,000 3,930 5,560 6,740 7,680
LVG 520D 2 NPT 2,560 3,520 5,010 6,565 9,080 11,120 12,700
LVG 525A 2-1/2 NPT 3,985 5,630 7,970 10,480 14,830 18,160 20,960
LVG 530A 3 NPT 5,215 7,830 14,330 13,720 19,420 23,770 27,440
LVG 540A 4"FLG 9,370 13,240 18,740 24,640 34,880 42,700 49,270
PRESSURE DROP
Model No.
C. CAPACITIES
NATURAL GAS
Full Open Valve Capacity

Page 4
LVG-9
C. CAPACITIES (Continued)
0
20
40
60
80
100
012345678910
Percentage ofMax. Flow
No. of Turns Open
LVG 510D (1")
Percentage of Maximum Flow vs No. of
Turns Open
0
20
40
60
80
100
0123456789101112
Percentage of Max. Flow
No. of Turns Open
LVG 512D (1 1/4")
Percentage of Maximum Flow vs No. of
Turns Open
0
20
40
60
80
100
0123456789101112131415
Percentage of Max. Flow
No. of Turns Open
LVG 515D (1 1/2")
Percentage of Maximum Flow vs No. of
Turns Open
0
20
40
60
80
100
0123456789101112131415
Percentage of Max. Flow
No. of Turns Open
LVG 520D (2")
Percentage of Maximum Flow vs No. of
Turns Open
0
20
40
60
80
100
01234567
Percentage of Max. Flow
No. of Turns Open
LVG 505E (1/2")
Percentage of Maximum
Flow vs No. of Turns Open
0
20
40
60
80
100
012345678
Percentage of Max. Flow
No. of Turns Open
LVG 507E (3/4")
Percentage of Maximum Flow vs No. of
Turns Open

Page 5
LVG-9
C. CAPACITIES (Continued)
0
10
20
30
40
50
60
70
80
90
100
0 2 4 6 8 10 12 14 16 18 20 22 24
Percentage of Max. Flow
No. of Turns Open
LVG 525A (2 1/2")
Percentage of Maximum Flow vs No. of Turns Open
0
10
20
30
40
50
60
70
80
90
100
0 2 4 6 8 10 12 14 16 18 20 22 24
Percentage of Max. Flow
No. of Turns Open
LVG 530A (3")
Percentage of Maximum Flow vs No. of Turns Open
0
10
20
30
40
50
60
70
80
90
100
0 4 8 1216202428323640
Percentage of Max. Flow
No. of Turns Open
LVG 540A (4")
Percentage of Maximum Flow vs No. of Turns Open

Page 6
LVG-9
D. DIMENSIONS
See appropriate Dimension sheet for detailed dimensional information.
E. INSTALLATION
The LVG valves are designed as straight through valves and feature an arrow indicating the
intended direction of flow.
Install the LVG in the gas line as close to the burner as possible, downstream of a shutoff valve,
gas orifice meter and gas controlling valve, and in an area that allows easy access to the
valve’s adjusting mechanism.
NOTE
Tighten all connections to ANSI/ASME B1.20.1 specifications.
X7026
(NOT TO SCALE)

Page 7
LVG-9
F. OPERATION
The LVG series valves can be used with any clean commercial fuel gas.
For flow adjustment, remove the hex screw cap from the valve. Using a flat-head screwdriver
(1/4" allen wrench on LVG 525 – 540 sizes), adjust the piston assembly until the desired flow
rate is achieved. Counterclockwise rotation increases gas flow.
G. MAINTENANCE
All LVG series valves are designed for maintenance free operation. Under normal usage, no
service should be necessary. For the LVG 505 - 520 size valves, the entire piston cartridge may
be removed for inspection or maintenance of the valve orifice. Remove the cartridge by
unscrewing the brass hex connection. Replace the cartridge when complete.
IMPORTANT
Replace the hex screw cap when adjustment is complete to seal the valve.
