HAUL MASTER 60533 Assembly instructions

60533
Visit our website at: http://www.harborfreight.com
Email our technical support at: [email protected]
Specifications
Capacity 600 lb. tongue weight
Hitch Ball 1-7/8″
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference. 21d
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright© 2021 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
To ol s r eq ui r ed f o r as s em bl y a nd se rvice m ay not be in cluded.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.

Page 2 For technical questions, please call 1-888-866-5797. Item 60533
Important Safety Information
1. Study, understand, and follow all
instructions before operating this device.
2. Do not exceed rated capacity.
3. Use only on hard level surface.
4. Before moving a trailer, assure that the
load is centered and coupler secured.
5. No alterations shall be
made to this product.
6. Wear ANSI-approved safety goggles
and heavy-duty work gloves
during assembly and use.
7. Keep clear of trailer’s path while
placing on and removing from dolly,
and while moving.
8. Use as intended only.
Do not use for aircraft purposes.
9. Inspect before every use;
do not use if parts loose or damaged.
10. Be aware of dynamic loading!
Sudden load movement may briefly create
excess load causing product failure.
11. Read trailer owner’s manual and
instruction manual for Tongue Jack
(not included) before use.
12. Do not work under Trailer while on Dolly.
13. Keep area free of spectators and do not
allow anyone on trailer while on Dolly.
14. Use wheel chocks when raising front
of trailer for placement onto Dolly.
15. Assemble only according to instructions.
Improper assembly can create hazards.
16. Keep assembly area clean and well lit.
17. Weight capacity and other product
capabilities apply to properly and
completely assembled product only.
18. Do not assemble when tired
or when under the influence of
alcohol, drugs or medication.
19. This product is not a toy. Do not allow
children to play with or near this item.
20. Maintain product labels and nameplates.
These carry important safety information.
If unreadable or missing, contact
Harbor Freight Tools for a replacement.
Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section
at the beginning of this document including all text under subheadings therein
before set up or use of this product.
Assembly
1. Attach V-Support (17), Connector (2),
and Brace (3) to Handle (7) using
three Bolts (10), Washers (8),
Lock Washers (16), and Nuts (11).
2. Attach Connector (2) under Axle Base (1),
using two Bolts (10), Washers (8),
Lock Washers (16), and Nuts (11).
3. Attach Brace (3) to Axle Base (1),
using Bolt (18), Washer (19),
Lock Washer (15), and Nut (12).
4. Slide the Wheels (4) over the ends of
the Axle Base (1) and secure in place
with Washers (6) and Cotter Pins (5).
Bend Cotter Pins into place.

Page 3For technical questions, please call 1-888-866-5797.Item 60533
Operation
1. Check Dolly tire inflation
and correct as needed.
Inflation pressure is marked on tires.
2. Chock trailer wheels to keep them from
rolling. Chocks sold separately.
3. Use a Tongue Jack (sold separately)
to raise the Trailer’s tongue.
4. Place Dolly in position under raised
coupler. Lower coupler slowly onto
Dolly and secure it to Dolly.
5. Use Handle to guide vehicle to location.
Parts List and Diagram
Part Description Qty
1 Axle Base 1
2 Connector 1
3 Brace 1
4 Wheel 2
5 Cotter Pin 2
6 Washer 2
7 Handle 1
8 Washer Ø10 5
Part Description Qty
9 Coupler Ball 1
10 Bolt M10x55 3
11 Nut M10 5
12 Nut M12 1
13 Bolt M18x40 1
14 Lock Washer Ø18 1
15 Lock Washer Ø12 1
16 Lock Washer Ø10 5
Part Description Qty
17 V-Support 1
18 Bolt M12x30 1
19 Flat Washer Ø12 1
20 Handle Grip 2
21 Bolt M10x30 2
22 Washer Ø10 1
22
21

PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS DOCUMENT AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER
OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE
BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR
THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE
MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS
REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS,
AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF
HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO,
OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Record Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not available
individually as replacement parts. Specify UPC 792363605335 when ordering parts.
