Havis-Shields Flip Down Rear Step Option KK-ST-FLIP Configuration guide

INSTALL INSTRUCTIONS KK-ST-FLIP
FLIP DOWN REAR STEP OPTION
(For Rear Permanent Mount Step order with KK-x-ST-RP)
TOOLS REQUIRED:
Ratcheting wrench
Standard socket set
Open-end wrench set
Power drill
Drill bit set
HARDWARE:
QTY DESCRIPTION PART #
10 ½” x 1 ½” Hex head bolt GSM33050
4 ½” x 3 ½” Hex head bolt GSM33055
32 ½” Flat washer GSM31012
10 ½” Lock washer GSM31030
4 ½” Nylock nut GSM30020
10 ½” Hex nut GSM30011
2 ¼” Stainless nylock nut GSM30046
SUB ASSEMBLY:
1. Confirm receipt of all parts.
2. Flip down portion of step will come assembled.
3. Slide Support Channels into the Step.
4. Bolt together using (4) ½” x 4” Hex Head Bolts, ½” Nylock Nuts, ½” Flat Washers.
Note: Be sure that flat side of Support Channels face towards outside of vehicle
INSTALLATION:
1. MOUNT FRAME BRACKETS:
• Determine Driver and Passenger side Frame Brackets using view on final page.
• Line brackets up with holes in frame rail of vehicle.
• Bolt brackets to frame using (4) ½” x 1 ½” Hex Head Bolts, ½” Hex Head Nuts,
½” Flat Washers, and ½” Lock Washers
• Do not tighten hardware at this time.
Note: FORD VANS Only:You must use a spacer between the Frame Rail and the Frame
Bracket on the forward mounting holes. Use (2) ½” Supplied flat washers
2. MOUNT STEP AND RAIL ASSEMBLY:
• Step can be mounted at various heights.
• With height determined, loosely bolt Assembly to Frame Brackets using (6)
½” x 1 ½” Hex Head Bolts, ½” Hex Head Nuts, ½” Flat Washers, and ½” Lock
Washers
3. FINAL SQUARING:
• With step square at desired height, tighten all hardware.

KK-ST-FLIP-INST-6-07
• Start with the Frame Brackets and then check for square again.
• Proceed to tighten Support Channels to Frame Brackets then Frame Brackets to Step
Plate.
Note: There are numerous holes in the step brackets for other Vehicle applications.
IF FLIP PORTION OF STEP WAS ODERED SEPARATELY USE THE FOLLOWING:
INSTALLATION:
1. MOUNT FLIP DOWN STEP:
• Remove ½” hardware located on frame brackets of existing step.
• Install (4) flip down step adapter plates reusing ½” hardware removed from
permanent rear step.
• Attach 2nd step to existing adapter plates using (2)-1 per side-½” x 3 ½” Hex bolt,
washer, nylon spacer and nylock nut.
• Tighten hardware.
• Attach spring latch onto existing rear step using ¼” x ¾” Stainless Carriage bolt and
nylock nuts. Some models do not contain prepunched hole for spring latch..
• Mount rubber bumbers to existing step.
• Using outer pre-punched holes, attach rubber bumbers to existing step using #10 x ¾”
machine screw and nylock nuts. Do not overtighten.

KK-ST-FLIP-INST-6-07
