INSTALL INSTRUCTIONS S-CM-112-IMP-1
RADIO RELOCATION HOUSING
2006-2009 CHEVROLET IMPALA
TOOLS REQUIRED:
Ratcheting wrench
Socket set
Screwdriver set
T-20 torx bit
HARDWARE:
QTY DESCRIPTION PART #
2 Upper backing plate CM001620
1 Radio mounting bracket CM001622-IMP
8 #8 x 3/8” T-20 torx screw CM86508
2 #10 Keps nut GSM30028
Always!
¾Read all instructions before installing any Havis-Shields Equipment Corp products.
¾Check for obstructions (Wire, brake lines, fuel tank, etc.) before drilling any holes!
¾Use hardware provided with install kit
¾For product support, visit the Install Instructions Section of our website at
http://havis.com/Installation/Installation.html

Remove lower plastic trim panel and
disconnect cable from lighter plugs.
Attach mounting bracket to AM/FM radio
and install torx screws to hold radio.
Remove AM/FM radio screws, wire
harness and antenna.
Remove trim around AM/FM radio and
thermostat controls.
S-CM-112-IMP-1_INST_11-08
2

Mount “hat” bracket to studded mounting
plates.
Mount assembled AM/FM radio bracket
and radio to main relocation housing. Slide studded mounting plates into the
slots used previously to hold the trim
p
anel that contained the li
g
hter
p
lu
g
s.
Attach main relocation housing to
mounting “hat”.
Final assembly
S-CM-112-IMP-1_INST_11-08
3
