INSTALL INSTRUCTIONS C-VS-0309-F250
VEHICLE SPECIFIC CONSOLE
1999-2007 FORD F-250, 350, 450, 550
TOOLS REQUIRED:
Ratcheting wrench
Sockets Set
Cutting tool (if necessary)
Screwdriver set
T-20 torx it
HARDWARE:
QTY DESCRIPTION PART
2 ¼” x 1 ¼” Hex head olt GSM33003
2 ¼” Flat washer GSM31005
2 ¼” Serrated nut GSM30023
4 #8 x ¼” Phillips flat head sheet metal GSM33178
1 Torx Screw kit C-HK-1
Always!
 Read all instructions efore installing any Havis-Shields Equipment Corp products.
 Check for o structions (Wire, rake lines, fuel tank, etc.) efore drilling any holes!
 Use hardware provided with install kit
 For product support, visit the Install Instructions Section of our we site at
http://havis.com/Installation/Installation.html, email [e-mail] or call
1-800-524-9900.

C-VS-0309-F250_INST_4-07
2
View of Ford F-Series dash oard
Remove upper portion of
dash oard as shown a ove
Remove enough to expose hex
screws holding lower portion of
dash oard
Remove (2) upper hex screws
located under the upper portion of
the trim.
Remove plastic trim piece as
shown a ove
Remove (2) screws as shown
a ove

C-VS-0309-F250_INST_4-07
3
Remove lower trim panel Remove plugs on optional rake
control switch. (If necessary)
Remove rake control switch from
lower trim panel. This will reinstall
into console. (Equipment racket
sold separately)
Remove two hex screws on each
side of cup holder racket
Remove (2) screws on lower side
of lower trim panel. The insert
this screw attaches to will be
removed. See later instruction.
Remove (2) hex screw as shown
a ove. Notice location.
Current view of installation Attach upper portion of con
sole to
dash using screws that held top of
lower trim panel
Remove optional auxiliary
switches from trim panel

C-VS-0309-F250_INST_4-07
4
Complete installation of
C-VS-0309-F250 console
Complete installation of C-VS-0309-F250
console w/ accessories (Sold separately)
-Brake controller/Aux Switching equipment
racket (C-EB30-F50-1P)
-Mic Clip Bracket (C-MCB w/ C-MC)
-Cup holder (C-CUP2-E-C with additional “L”
racket # CM93086 )
Remove this screw clip to allow a
¼” olt to fit into this hole
Attach lower portion of console
using ¼” x 1 ¼” hex olt, washer
and serrated nut
