Havis DS-PAN-401 User manual

DS-PAN-401
Havis Rugged Mobile Docking Station
For Panasonic CF52 Toughbook
D5-0031-IS-A
www.havis.com
1-800-524-9900

Havis is pleased to provide these set-up instructions to aid in the proper
installation and use of the DS-PAN-401 docking station for the Panasonic CF52
laptop.
For questions regarding the set-up of your DS-PAN-401 docking station, please
contact Havis at 1-800-524-9900 or visit www.havis.com for additional
product support and information.
Before Beginning Related Products
WARNING
!
• NEVER STOW OR MOUNT THE DS-PAN-401 DIRECTLY IN A VEHICLE
AIRBAG DEPLOYMENT ZONE.
• DO NOT USE COMPUTER WHILE DRIVING.
www.havis.com • 1-800-524-9900
110
READ ALL INSTRUCTIONS THOROUGHLY BEFORE BEGINNING INSTALLATION.
CAUTION
!
Precautions
• Do Not Place Containers of Liquid or Metal Objects on Top of
The Docking Station
• If a Malfunction Occurs, Immediately Unplug the Power Supply and
Remove the Laptop
• Use Only the Specied Power Supply With This Docking Station
• Do Not Store The Docking Station Where There is a Lot of Water, Moisture,
Steam, Dust, Oily Vapors, etc.
• Do Not Connect Cables Into Ports Other Than What They Are Specied For
• Do Not Leave The Docking Station in A High Temperature Environment
(over 120° F) for a Long Period of Time
Havis oers a wide variety of accessory products specically or use
with the DS-PAN-401 docking station. For more information or to
order please visit www.havis.com.
• HUB-USB3-E
Rugged Ethernet hub
• DS-DA-402
Screen stiener to help reduce screen vibration
• LPS-103
120 W power supply
• LPS-202
120W power supply mounting kit
• DS-DA-101
USB powered light

Table of Contents
Hardware Kit……………………………………………………………………………………………………………….2
Name and Function of Parts………………………………………………………………………………………3
Installation…………………………………………………………………………………………………………………..4
Cable Management.5
Installation of Power Supply (Optional)7
Operation - Docking.8
Operation - Undocking..9
Related Products………………………………………………………………………………………………………..10
Hardware Kit
The hardware kit includes:
1. Zip Ties (4)
2. 1/4”-20 Screws (3)
3. M5 Button Head Screws (3)
3. Keys (2)
Operation - Undocking
www.havis.com • 1-800-524-9900
9
10 2

1). If previously locked, unlock dock using supplied key.
2). Press center of barrel lock to unlatch docking station.
3). Once unlatched grab both sides of computer and
carefully lift out of dock, rear end rst.


Tools Required For Installation:
• 3 mm Hex Drive ( For attaching
mounting bracket to docking station
with M5 Screws )
• 5/32 Hex Drive ( For attaching
mounting bracket to motion device
with 1/4” -20 screws)
1
2
3
4

Power Supply Input 15.6V DC-In
Dimensions 14.35” ( 36.2 cm) W x 12.95” ( 32.9 cm ) D x 3.0” ( 7.7 cm ) H
Weight 5.9lbs ( 2.7kg )
Operating Environment 5° C to 35° C ( 41° F to 95°F )
Storage Environment -20° C to 60° C ( -4° F to 140° F )
Specications Operation - Docking
www.havis.com • 1-800-524-9900
38
Name and Function of Parts
    
Ethernet/RJ45 USB 2.0 DB9 Serial VGA Power Input



4). With computer seated on dock pull latch handle forward
until latched.
5). If desired secure computer by locking barrel lock with
supplied key.
1). Ensure docking station is unlatched by depressing button
in the barrel lock.
2). Load front of computer into dock rst, ensuring
computer’s handle extends under vinyl capped front hold-
down brackets on dock. Take care to center computer in dock
when lowering.
3). Lower back of laptop down onto docking connector.


Front Latching Handle
Barrel Lock/Dock Release
Docking
Connector Head

Front Hold-down
Brackets

Front Latching Handle
CAUTION
!
Do Not Force Laptop Onto Connector if There is Resistance -
Check Alignment With Brass Locator Pins


Brass Locator Pin
Brass
Locator Pin
{

InstallationInstallation of Power Supply (Optional)
www.havis.com • 1-800-524-9900
7
84
1). Power o computer, disconnect all cables from computer.
2). Using Havis LPS- 103 (120W power supply) connect
output cable of power supply to input of docking station.
3). Place LPS- 103 power supply where convenient and safely
ax using either LPS-202 bracket kit or cable ties.
5). Route and strain relieve input and output cables to
enable motion where necessary and anchor to
prevent damage from pinching, kicking, yanking, etc.
1). Remove the mounting bracket from the docking station.
Next install the bracket to the motion device using (3) 1/4“-
20 button head screws (supplied). Torque screws to 13.4Nm
(120 in-lbs) ± 10%.
2). Install the docking station to the mounting bracket using
(4) M5 button head screws (supplied). Torque screws to 2.8
Nm (25 in-lbs) ± 10%.
NOTE:
LPS-202 allows for mounting of
power supply on either right hand or
left hand side of docking station.


LPS-202
LPS-103
NOTE:
It is recommended to use a drop
of medium strength (blue) thread
locking adhesive applied to the
threads of the fasteners.

1/4” - 20 Screws (3)


Mounting Bracket
Typical Motion
Device Example

M5 Screws (4)

Cable Management
www.havis.com • 1-800-524-9900
56
Cable Management - Continued
1). Tip the dock to a position that is comfortable to
work with.
2). Install all cables that are necessary for computing needs.
3). Use tie wraps through integral loops in rear of dock to
strain relieve connectors.
4). Gather all cables to one side and tie o to unused holes
on underside of dock.
5). Create a service loop with cables to ensure that no
tension is on the connectors and to enable intended motion.
6). Tie o cables onto a stationary part of the
mounting system.
7). Add additional ties as needed to secure cables.

Tie o on stationary part
of the mounting system



Integral loops for
strain relieving
This loop must be large
enough to allow full range
of rotation and extension
without yanking connections.
Use as many ties as necessary
to protect each connection

Tie o to bracket


