hawa EKU-DIVIDO GR User manual

Zubehör / Accessories/Accessoires Art. No.
Bodenführung 1x 042.3033.071
Bottom guide
Guidage au sol 65x37mm
TX 25
Ø 5,5
Art. No. 042.3045.001
A
Montageanleitung
Mounting instructions
Instructions de montage
DIVIDO
®
100
Bodenführung | Bottom guide | Guidage au sol
Anforderungen erfüllt nach
DIN-EN 1527 - 6 2 0 - 0 - 1 3
12 I 2010 I 788.2000.128 1/4

PORTA
®
60 |100
Bodenführung | Bottom guide | Guidage au sol
System: Optionale 4-Punkt-
Führung zu obenlaufenden
Anwendungen
System: Optional 4 point guide
system for top running applications
Système: En option guidage à 4
points pour les applications avec
roulement en haut
EKU-DIVIDO GR | GRM | GR Synchro
Hawa Sliding Solutions AG, Untere Fischbachstrasse 4, 8932 Mettmenstetten, Switzerland
Tel. [phone], Fax [phone], [e-mail], www.hawa.com

Zubehör / Accessories/Accessoires Art. No.
Bodenführung 1x 042.3033.071
Bottom guide
Guidage au sol
Adapter, Kunststoff, anthrazit, für Holztüren, zu 042.3033.071 1x 042.3036.001
Bottom guide adapter, plastic, anthracite, for wooden doors, for 042.3033.071
Adaptateur pour guidage au sol, plastique, anthracite, pour portes en bois,
pour 042.3033.071
65x37mm
90x40mm
55
25
Ø 4 x 60
Ø 3
TX 25
40
min. 90
18
12 I 2010 I 788.2000.128 2/4



A
System: Optionale 4-Punkt-
Führung zu obenlaufenden
Anwendungen
System: Optional 4 point guide
system for top running applications
Système: En option guidage à 4
points pour les applications avec
roulement en haut
DIVIDO
®
100
Bodenführung | Bottom guide | Guidage au sol
PORTA
®
60 |100
Bodenführung | Bottom guide | Guidage au sol
EKU-DIVIDO H | HM | H Synchro
EKU-PORTA H | HM

HHH
H
M
S
TH = H –63 (S) –40 (M)
TH = H –63 (S) –40 (M)
TH = H –71 (S) –48 (M)
TH = H –73 (S) –50 (M)
TH = H –71 (S) –48 (M)
HHHHH
38
S S M
S M S
+5
–1
12 I 2010 I 788.2000.128 3/4
TH
TB
TB:
2 T TB = (Bi + 30mm) :2
3 T TB = (Bi + 60mm) :3
4 T TB = (Bi + 90mm) :4
5 T TB = (Bi +120mm) :5
6 T TB = (Bi +150mm) :6
TB:
2 T TB = (Bi + 7mm) :2
3 T TB = (Bi + 14mm) :3
4 T TB = (Bi + 21mm) :4
5 T TB = (Bi + 28mm) :5
6 T TB = (Bi + 35mm) :6
29 29
TB TB
TB
51
22
29
TB
TB TB
77
TH = H – 63
Glas/Glass/Verre & 8mm Holz/Wood/Bois = TH –104
10mm Holz/Wood/Bois = TH –102
TH = H – 63
Glas/Glass/Verre & 8mm Holz/Wood/Bois = TH – 104
10mm Holz/Wood/Bois = TH – 102
Glas/glass/verre = Y– 61
Holz/wood/bois = Y– 59
Glas/glass/verre = X– 61
Holz/wood/bois = X– 59
Glas/glass/verre = X– 61
Holz/wood/bois = X– 59 Glas/glass/verre = Z–18
Holz/wood/bois = Z–16
Glas/glass/verre = Y– 61
Holz/wood/bois = Y– 59
TH TH
YZX
YX
DIVIDO
®
100
Bodenführung | Bottom guide | Guidage au sol
PORTA
®
60 |100
Bodenführung | Bottom guide | Guidage au sol
EKU-DIVIDO H | GR |
H Synchro | GR Synchro
EKU-PORTA H
EKU-DIVIDO HM | GRM
EKU-PORTA HM

12 I 2010 I 788.2000.128 4/4
50
250
LM
Ø 4
LM
LM
5
25
Ø3x25 Ø4
15
9
51
LM –15
37
SW 2,5
TX 10
T
042.3038
042.3040
042.3041
8
38
042.3080 042.3089
042.3081
042.3038
042.3082
042.3038
042.3040
042.3037
042.3038
042.3039
042.3041
042.3038
28
8
51 68
8
38
8
11476
8
13
13
13
13
6
13
8
8
10 10
6
20
Einbaubeispiele / Mounting examples / Exemples de montage
042.3041
042.3037
042.3039
042.3090.081
2x
DIVIDO
®
100
Bodenführung | Bottom guide | Guidage au sol
PORTA
®
60 |100
Bodenführung | Bottom guide | Guidage au sol
