Hay Arcs Wall User manual

DESIGN BY MULLER VAN SEVEREN
– INSTRUCTION MANUAL –
ARCS WALL SWITCH

 INTRODUCTION 
The Arcs Wall Lamp is part of a series of arched
designs created for HAY by Belgian duo Muller Van
Severen. Formed from a continuous chain of curved
arches that create an elegant, scalloped silhouette, the
lamp provides a soft, ambient up and down light that
plays with shapes and shadows. The lamp is easy to
mount and is available in two variants – depending on
the type of use or installation requirements: the Arcs
Wall Sconce with integrated cord design or the Arcs
Wall Switch with switch and cable. Arcs is crafted in
solid steel and is available in several different colours
or with a mirror surface. The different mounting
solutions give the lamp a versatile quality, making it
suitable for corridors and large spaces, as well as a
bedside lamp or in small corners.

TECHNICAL DATA
This product is fitted with an E14 LED bulb
fitting. HAY recommends using this product
with LED bulbs, max. 8W. HAY will not
accept any responsibility for any accidents,
injuries or damages that occur due to the
use of incorrect bulbs.
ATTENTION
Ensure that the power supply to the
circuit has clearly been turned OFF before
installing the product. In some countries,
electrical installation must be carried out
by authorised electricians/contractors;
please check with your local authority for
guidance.
The product must not be modified in any
way. HAY accepts no responsibility for
any products that have been modified
or tampered with. If the external flexible
cable or cord of this luminaire is damaged,
it should be exclusively replaced by a
qualified electrician in order to avoid an
electrical hazard. This lamp is designed for
indoor use only.
CARE AND MAINTENANCE
The product can be cleaned with a soft
damp cloth and mild detergent, or a dry
microfibre cloth. Do not use alcohol or any
other solvents to clean the product and
avoid using abrasive or rough sponges.
Ensure that the power supply has been
turned OFF before cleaning the product.
 PARTS  CARE AND MAINTENANCE 

 PARTS 
Shade Junction box Backplate
UK converter Top and side
mounting screws
Wall plugs and
screws
Plastic plug

1.
Before installing the lamp, make sure that the power is turned off. Mark the
position of where the lamp should be placed on the wall and drill two holes using
the correct type of drill for the wall you are drilling into.
The holes on the backplate can be used as guides, to ensure the correct
distance between the holes.

2.
Insert the wall plugs. Ensure you use the correct type of wall plug for the type of
wall the lamp is to be mounted on. Once the wall plug is in place, you are ready
to mount the backplate with the included screws.

3.
Place the junction box over the backplate, before inserting and fastening the
supplied mounting screws on each side of the junction box. Make sure it is fixed
firmly in place. Take care not to overtighten the screws, as this could damage
the threads.

4.
Place the lamp shade carefully on the junction box. Place the shade so that it
sits behind the bottom tab on the mounting bracket, and ensure it sits in place.
Move the shade in towards the wall and align the top screw with the top tab of
the junction box.
A A
D D
DRAWN

5.
Tighten the top screw carefully, until the shade sits firmly up against the wall.
When the top screw is tightened, the bottom of the shade pulls upwards and
locks behind the bottom tab of the mounting bracket. Once this step is done, the
shade should sit firmly in place.

6.
For UK customers, insert the EU plug into the converter provided. Close the converter
over the EU plug with the pins secured in the internal spring clip contacts. Screw the
converter together to ensure the UK plug is secure.
1
2
3

7.
Turn the power back on and test that the lamp is working.

6.
Ensure that the power is off and screw an E14 bulb into the bulb fitting.

OPTIONAL
This lamp is sold with an trailing cable. If the lamp is to be mounted directly onto
a power outlet/junction box, the trailing cable can be removed and the exit hole
plugged with the included plastic cap. This task should exclusively be performed
by a qualified electrician in order to avoid an electrical hazard. HAY will not
accept any responsibility for any accidents, injuries or damages that occur due
to incorrect wiring.

Havnen 1 8700 Horsens Denmark
[phone] / [e-mail]
19042021
