– INSTRUCTION MANUAL –
DESIGN BY PIERRE CHARPIN
PC LINEAR

 GENERAL INFORMATION 
TECHNICAL DATA
This product is supplied with an integrated LED
light source. The expected lifespan of the LED
light source is 25,000 hours, which equates to
810 years of general use. When the light source
reaches its end of life, the whole luminaire should
be replaced. For dimming, please check which
wall mounted dimmers are compatible with the
included LED driver.
FITTING TYPE | Integrated LED
POWER W | 28W
COLOUR TEMPERATURE | 2800K warm white
ATTENTION
Ensure that the power supply to the circuit has
clearly been turned OFF before installing the
product. In some countries, electrical installation
must be carried out by authorised electricians/
contractors; please check with your local
authority for guidance.
The product must not be modified in any way.
HAY accepts no responsibility for any products
that have been modified or tampered with. The
external flexible cable or cord of this luminaire
cannot be replaced. If the cord is damaged,
the luminaire should be replaced. This lamp is
designed for indoor use only.
CARE AND MAINTENANCE
The product can be cleaned with a soft damp
cloth and mild detergent, or a dry microfibre
cloth. Do not use alcohol or any other solvents
to clean the product and avoid using abrasive or
rough sponges. Ensure that the power supply has
been turned OFF before cleaning the product.

 PARTS 
Lamp with suspension
wire & cable
Ceiling capMounting bracket
LED driver Suspension mount

1.
Unpack all the parts and check that you have received all the
parts listed. Mark the position of the holes to be drilled (104 cm apart)
on the ceiling.
104 cm

2.
Drill the holes using the correct type of drill for the ceiling you are drilling into.
3.
Insert the wall plugs. Ensure you use the correct type of wall plugs for
the type of ceiling.

4.
Fix the suspension mount to the ceiling using the provided screws.
Disassemble the suspension mount as shown below and insert each screw into
the suspension mount, screwing them firmly into place.

5.
Once the suspension mounts are firmly in place, the lamp is ready to be mounted.
Start by pulling the suspension wire through the disassembled suspension mount
(step 1). Guide the wire though the fixed suspension mount and through the exit hole
on the side (step 2). Screw the disassembled suspension mount together with the
part that is fixed to the ceiling (step 3). The suspension wire is now safely in place
(step 4). Repeat on the other side.
Step 1
Step 3
Step 2
Step 4

6.
Level the lamp by adjusting the wire. Pull the wire to shorten it or press the tab
of the suspension mount to release it. It is recommended that two persons
perform this step.

7.
Once the lamp is in place, the excess wire trailing from the exit hole can be cut.
Note that once the wire has been cut, the lamp can no longer be lowered.

8.
Drill holes using the correct type of drill for the ceiling you are drilling into.
Fix the bracket with the attached driver to the ceiling using the provided screws.

9.
Pull the cable through the ceiling cap before connecting the cable to the driver.

10.
To secure the cable to the mounting bracket, start by loosening the screws on
the cable clamps that are mounted on the mounting bracket, and pass the cable
through. Once the cable is in place, tighten the screws again.

11.
Wiring to mains power: Taking one wire at at a time, insert the correct wires into
the corresponding slots on the terminal block, while pressing down on the small
button next to them. The live mains wire should be inserted into the slot marked
L and the neutral mains wire into the slot marked N. If you are unsure of the
polarity of the wires, then we recommend you contact a certified electrician.
LL
NN
LEDLED
--
++
L
N

12.
Wiring to lamp: Insert the red cable (+) into the slot on the red terminal block
(+). Insert the black cable (-) into the slot on the black terminal block (-). It is
important that the wires are correctly connected. HAY accepts no responsibility
for any damage due to incorrect wiring of the lamp.
NOTICE
Black cable (-) in black terminal block (-)
Red cable (+) in red terminal block (+)
LL
NN
LEDLED
--
++
LED
-
+

13.
Place the ceiling canopy over the LED driver and mounting bracket.
There are cable exit holes for the mains wires on either side of the ceiling cap.

14.
Fix the ceiling cap to the bracket using the provided screws.

 CARE & MAINTENANCE 
Our Care & Maintenance offers guidance for optimal
maintenance of your HAY product. It includes advice
and instructions on cleaning and caring for specific
materials to prolong the life of your lighting.
Please find our Care & Maintenance
guide by scanning the QR code
You can find more relevant information
on PC Linear by scanning the QR code
You can also find the same information here
hay.dk/downloads
