Hay Matin Floor User manual

– INSTRUCTION MANUAL –
DESIGN BY INGA SEMPÉ
MATIN FLOOR

 GENERAL INFORMATION 
TECHNICAL DATA
This product is supplied with an integrated LED
module (2800K warm white, 200300 lumens).
The expected lifespan of the LED modules is
25,000 hours. When the light source reaches its
end of life, the whole luminaire should be replaced.
FITTING TYPE | Integrated LED
POWER W | 10W
COLOUR TEMPERATURE | Warm white
HAY will not accept any responsibility for any
accidents, injuries or damages that occur due to
the use of incorrect bulbs.
ATTENTION
In some countries, electrical installation must be
carried out by authorised electricians/contractors;
please check with your local authority for
guidance. The product must not be modified in
any way. HAY accepts no responsibility for any
products that have been modified or tampered
with. This lamp is designed for indoor use only.
CARE AND MAINTENANCE
Do not use wet or damp cloths for cleaning
and maintaining the shade. Please use a dry,
lint-free cloth or duster to remove any dirt. The
frame can be cleaned with a soft damp cloth
and mild detergent. Do not use alcohol or any
other solvents to clean the product. The external
flexible cable or cord of this luminaire cannot be
replaced; if the cord is damaged, the luminaire
should be destroyed. Ensure that the power
supply has been turned OFF before cleaning the
product.

 PARTS 
Shade
Top screw
Top stem
Bottom stem
Base Power supply adapter
Inline switch
Set screws
Allen key

1.
Unpack all the parts and check that you have received all the parts listed.
Slide the bottom stem onto the base, as shown below.
2.
Insert one of the set screws into the back of the bottom connecting piece and
screw it firmly in place, using the supplied tool. You will find the set screws and tool
in the small fitting bag.

3.
Slide the top stem onto the bottom stem, as shown below.

4.
Insert the set screw into the back of the central connecting piece and screw it
firmly in place, using the supplied tool.

5.
Screw the top screw into the top cap, as shown below.
Do not fully screw it in place yet.

6.
Clip the cable into the cable clip, which is located on the stem, and in
the groove on the back of the central connecting piece and the bottom
connecting piece.

7.
Remove the shade from its packaging and spread out the bottom while
simultaneously pushing it down over the top screw, so that it rests on top of
the top cap. Gently push the top of the pleated shade underneath the
top screw, so that it is wedged between the top screw and top cap.

8.
Once the shade is in place, gently adjust the pleats at the top so they
are evenly spread out, as shown below. Once the shade is as illustrated,
the top screw can be fully tightened.

9.
Plug the trailing cable into the power supply. Attach the correct adapter
for your region. The lamp is now ready to use.

10.
The lamp’s inline switch has a three-step dimmable feature. The first push sets the
lamp to maximum brightness, the second push to medium brightness and the third
push to lowest brightness. The fourth push turns the lamp off.
40%
70%
100%

 CARE & MAINTENANCE 
Our Care & Maintenance offers guidance for optimal
maintenance of your HAY product. It includes advice
and instructions on cleaning and caring for specific
materials to prolong the life of your lighting.
Please find our Care & Maintenance
guide by scanning the QR code
You can find more relevant information
on Matin Floor by scanning the QR code
You can also find the same information here
hay.dk/downloads

13092022
