Haylou X1 Neo User manual

HAYLOU X1 Neo
True Wireless Earbuds
User Manual

Overview
LED
Type-C
charging port
Mic
Charging
contacts

How to Wear
Gently insert the earbud into the ear canal,
adjust the earbud to the most comfortable
wearing state.
When calling, adjust Mic towards mouth to gain
better talking experience.

How to Charge
Plug in the charging cable to charge the earbuds
and the charging case at the same time.
When the charging case is not fully charged,
the LED flashes white slowly. When it is fully
charged, the LED flashes solid white.
For first time use, please remove the isolation
film on the charging contacts of both earbduds.
Then fully charge the charging case and earbuds.
Remove
isolation film

Power-on
1. Put the earbuds back into the charging case,
they will automatically power off (LED flashes
solid white when the earbuds are charging,
then LED goes out when fully charged)
2. The earbuds power off outside the charging
case: they will automatically power off if not
connected to the device within 3 minutes
(LED flashes solid white for 1s)
Power-off
Take the earbuds out from the charging case,
they will automatically power on.
LED flashes white quickly
when powering on
1. LED flashes solid white when the
earbuds are charging, then LED
goes out when fully charged;
2. LED flashes solid white for 1s.

Haylou X1 Neo
10:00 4G
Bluetooth
Turn on Bluetooth
Visibility
Visible to all Bluetooth devices nearby
Device name
Available Devices
How to Pair
Automatic connection: Take two earbuds out
from the charging case simultaneously, they will
enter pairing state when LEDs on both earbuds
flash white quickly.
Open device Bluetooth and search for
"Haylou X1 Neo", then click it to connect.
Put the earbuds back into the charging case and
repeat the above operation if the connection fails.
After the first connection, the earbuds can be
automatically connected to the last paired
device when powering on (Bluetooth needs to be
turned on).

Switch between mono and stereo mode:
It is stereo mode after two earbuds are
successfully connected. Put one back into the
case to power off, the other will enter mono mode.
Or pick it up again to resume stereo mode.
Manual connection:
When LEDs on both earbuds flash white quickly,
turn on device Bluetooth to connect.

Functions
Click the left/right MFB
Answer/End a call
Double click the left/right MFB
Reject a call
Double click the left MFB
Skip track backward
Press and hold the left/right MFB for 2s
Turn on/off gaming mode
Click the left/right MFB
Play/Pause music
Double click the right MFB
Skip track forward

Restore Factory Settings
1. The earbuds are outside the charging case,
powered on and not connected to the device;
2. Quickly click both earbuds for three times at the
same time, then press and hold for 3s, they will
power off after LEDs flash solid white for 1s;
3. After resetting, put the earbuds into the
charging case and close the lid, then open the lid
and take them out again;
4. Follow the pairing steps to complete Bluetooth
connection.
Audio only Outputs from Single Earbud
It's unusual indeed, please refer to the following
operation steps if the situation occurs:
1. Put the earbuds back into the charging case,
and then take them out again to connect.
2. Refer to the reset steps to reconnect the
Bluetooth device.
Other Charging Problems
1. The white LED goes out when the earbuds are
fully charged.
2. When the charging case is out of power, the
earbuds cannot be charged and keep the
original connecting status.
3. LED flashes solid white when the charging case
is fully charged.

Basic Parameters(earbuds)
Operation range: 10m (open space with no
obstacle)
Battery capacity: 30mAh(single earbud)
Charging time: approx. 1.5h
Playing time: approx. 5h
Standby time: approx. 60h
Input parameter: 5V 100mA
Battery type: li-ion
Bluetooth version: V5.3
Basic Parameters(charging case)
Input parameter: 5V 500mA
Output parameter: 5V 150mA
Charging time: approx. 2h
Battery capacity: 310mAh
Battery type: li-ion
1. The earbuds are outside the charging case,
powered on and not connected to the device;
2. Quickly click both earbuds for three times at the
same time, then press and hold for 3s, they will
power off after LEDs flash solid white for 1s;
3. After resetting, put the earbuds into the
charging case and close the lid, then open the lid
and take them out again;
4. Follow the pairing steps to complete Bluetooth
connection.
Package Overview
Earbuds, charging case,
Charging cable, user manual.
Earbud model：Haylou X1 Neo
Earbud name: True wireless earbuds

Caveats
Warning
1. Do not disassemble, repair or modify the
product for any reason, as this may cause fire
or even completely destroy the product.
2. Do not expose the product to environments
where the temperature is too low or too high
(below 0°C or above 45°C).
3. Keep the indicators away from the eyes of
children and animals while using the
earphones.
4. Do not use this product during thunderstorms.
Thunderstorms may cause the product to
malfunction and increase the risk of electric
shocks.
5. Do not wipe and clean the earphones or their
case with alcohol or other volatile liquids.
6. Avoid any contact with liquids.
Note
1. Please read this user manual carefully before
using the product and please properly store
it.
2. When using for the first time, please fully
charge this product.
3. Please charge the product, in case it has not
been used over two weeks.

4. Please use certificated charger.
5. Do not wear earphones for a long term to
protect your hearing.
6. Do not wear earphones in any situations with
potential risks as wearing them may reduce
your perception to the outside world.
Daily maintenance
Please do not shower with earbuds. Do not
wear them in rainy day. Do not leave them in
washing machine or other extreme situations.
Clean them with dry cloth.

Model Number
Date of Purchasing
User' s Name
User' s Phone
User' s Address
Shop' s Name
Shop' s Address
Comments
Warranty Card
Warranty Period
12 months after you purchase this item.
( or you may inquire your local shopper for
more details.)
Free Service
Supposing any defects caused by quality issues
occur within the warranty period, please take
this warranty card and purchase receipts to
your distributor for free exchange service.
Free exchange service will not be accessed
under following circumstances:
1. Damages caused by unauthorized
disassembly.

Manufacturer: Dongguan Liesheng Electronic
EU DECLARATION OF CONFORMITY
Hereby, Dongguan Liesheng Electronic Co., Ltd.
declares that the radio equipment type haylou
X1 Neo is in compliance with Directive 2014/53/EU.
Co., Ltd.
Address: Room 401-410, Building 1, No.
86 Hongtu Road, Nancheng District,
Dongguan City, Guangdong, China
2. Defects or physical damages caused by
leaking or dropping off.
3. Damages by act of God.
Supposing your item is within any damages
or defects except the above circumstances,
please return to us or your distributor for free
repairing.
