Hayward OmniLogic Wireless Terminal User manual

v
OmniLogic
Wireless Terminal
QUICK START GUIDE
6 Easy
Steps
Step 1 Step 2 Step 3
Step 4 Step 5 Step 6
Charge the Wireless Terminal Check MSP Firmware Version Check Latest Firmware
Version on the Web
Go to “Wireless” Menu Connect To Home
Wireless Network Check Wireless Terminal Firmware Version
The following steps should be performed ONLY with the Wireless Terminal
placed in the charging cradle, or after charging for at least 8 hours. If a rm-
ware upgrade is needed, it must be completed while in the charging cradle.
NOTE: The Wireless Terminal will take 12 seconds to reboot when placed in
the charging cradle if the battery is fully discharged.
®
Before connecting the Wireless Terminal to the OmniLogic system, verify
that you have the latest OmniLogic MSP rmware version. The rmware
version displayed in “System Info” should be the same as the latest version
available for download on the web. Follow the screens above to locate your
MSP rmware version and go to Step 3 to nd the latest rmware version
on the web.
SYSTEM INFO
msp id:3233
component HUA version
MSP
MP
Relays
VSP
Wired Wall Mo..
00-46-01-21-a0
1-65-0-2a-d4
3-10-0-0-1
10-0-0-0-4e
33-41-1-e7-42
R 2.0.1
R 1.0.2
R 1.0.2
R 3.0.4
R.2.0.0
SYSTEM
conguration
1 / 2
cong wizard
system info
backup cong
restore cong
display
network
web server
date/time
cong
themes
ºF
air
71º F
90
SPA
MSP version is displayed To nd the latest available rmware
version, go to www.hayward.com/
rmware and select “OmniLogic”
from the “Select Product” drop-
down menu and “HLBASE” from
the “Select SKU” drop-down menu.
Select the “Firmware Updates” tab.
A list of all the latest rmware versions available for download appear. Note
the rmware version located in the “Local MSP” box. If the version matches
your current version located in Step 2, then move on to Step 4. If not, then
go to Side B of this sheet to perform a rmware upgrade of your MSP.
With the latest MSP version loaded to your OmniLogic, Touch “OK” at the
welcome screen below from your Wireless Terminal to enter the wireless
conguration screen.
NOTE: This following procedure assumes that your OmniLogic system is
already connected to your home wireless network.
The wireless conguration screen will display all available wi networks. Se-
lect the desired network from the list and input your password on the screen
as shown below. Press the check mark to save your selection. Your Wireless
Terminal is now congured to your home wireless network and will automat-
ically pair with your OmniLogic system.
NOTE: The Wireless Terminal will
only connect to an OmniLogic that
is on the same network.
Now that your Wireless Terminal is connected to the OmniLogic system,
the nal step is to verify that the rmware version of the Wireless Terminal
matches that of the MSP.
To nd the current rmware version of the Wireless Terminal, go to the Om-
niLogic and follow the same screens shown in Step 2. Then go to the web-
site (Step 3) and verify that the latest rmware version matches that of your
Wireless Terminal (shown as “Wi- Term” in the list below). If they match,
congratulations, you are nished conguring your Wireless Terminal to your
OmniLogic. If they do NOT match, follow the steps on Side B of this sheet to
perform a rmware upgrade to your Wireless Terminal. The unit must be in
the charging cradle when performing a rmware upgrade.
SYSTEM INFO
msp id:3233
component HUA version
MSP
MP
Relays
VSP
Wi-fi Term
00-46-01-21-a0
1-65-0-2a-d4
3-10-0-0-1
10-0-0-0-4e
33-41-1-e7-42
R 3.0.0
R 1.0.2
R 1.0.2
R 3.0.4
R 3.0.0 Wireless Terminal rmware
version
Charge the
Wireless
Terminal
Check latest
MSP Firmware
Version
Upgrade MSP
if Necessary
Connect to
Home Wireless
Network
Check latest
Wireless Terminal
Firmware Version
Upgrade
Wireless Terminal
if Necessary
Side A
MSP rmware version
configuration
Welcome to the Hayward Wireless Remote
Press OK to setup your new remote.
OK
en
q
a
bc
d
e
f g h
i
j k l
mn
o pr
s
t u
v
w
x
y
z
ABC
.?123 space
←
password
Please enter [yourwifi] network password
WIRELESS
connection
Smith Home Wifi
Network Connections dynamic
ON

Step 1 Step 2 Step 3
Step 4 Troubleshooting
Download Latest
Firmware Version Insert USB into the MSP
and Enter Service Mode Press Upgrade and Select Component to be Upgraded
Start the Upgrade
092677 RevC
If a rmware upgrade to your MSP or Wireless Terminal is required...
WARNING - Inserting and removing the USB thumb drive requires re-
moval of the front panel. Verify that all power is removed to the Omni-
Logic system before removing the front panel.
From your computer: To begin upgrading your MSP or your Wireless Ter-
minal (they should have same rmware version), navigate to the website as
shown in Step 3 on Side A of this sheet. Insert your USB thumb drive (not
included) into the computer. Click on the orange download button located in
the box of the component that you are upgrading. Save the rmware le to the
USB drive. Download the “Wired Terminal” rmware shown below (Wired and
Wireless Terminals use the same rmware).
When Upgrading your MSP (Step 3, Side A), select:
When Upgrading your Wireless Terminal (Step 6, Side A), select:
NOTE: It is best if you download the rmware in Chrome, Firefox or Safari
browsers. If you download in Internet Explorer, once your download is com-
plete, please remove the “.TXT” extension from the le on the USB drive.
Remove the USB drive from the computer once the download is nished.
Verify that power is removed to the OmniLogic system and remove the front
panel. Insert the USB drive into the side of the MSP.
Replace the front panel and then power on the OmniLogic system. When
the system nishes powering back on, enter Service Mode by following the
screens below.
daylight favorites
alarm lights
º
F
air
71º F
82
shut down
service
mode
simple
mode
features
o
NOTE: Do not choose Timed Service Mode when upgrading a device. If you
DO choose Timed Service Mode, be sure to dedicate enough time so that the
upgrade will have time to nish. Upgrading a Wireless Terminal can take a
few minutes.
Follow the screens below to begin the upgrade for the device.
SERVICE MODE
main screen
daylight sysinfo
upgrade
cong
select device
component HUA current version
MSP 00-46-01-21-a0 R 1.5.0
MP 1-65-0-2a-a6 R.1.0.4
COMPONENT
selection
Wifi Term 33-41-1-e7-42 R 2.0.0
select device
component HUA current version
MSP 00-46-01-21-a0 R 1.5.0
MP 1-65-0-2a-a6 R 1.0.4
COMPONENT
selection
Wifi Term 33-41-1-e7-42 R 2.0.0
select le
USB/
FILE
selection
...\
Press “Upgrade” button in Ser-
vice Mode menu
Select the device to be up-
graded
Press the check mark Press “USB” to view the rm-
ware les on the USB drive
Follow the screens below to nish upgrading the device. Note that the system
will restart after upgrading the MSP, not after upgrading the Wireless Terminal.
select file
USB/
MSP_AR_R020100
FILE
selection
...\ select file
USB/
MSP_AR_R020100
FILE
selection
...\
ready to upgrade
component firmware file
MSP MSP_AR_R020100
UPGRADE
firmware
0%
success ready to restart
component firmware file
MSP MSP_AR_R020100
UPGRADE
firmware
100%
Select the rmware le that
you downloaded from the web
Press the check mark
Press the check mark to
begin the upgrade
Press the check mark to
nish the upgrade once
it reaches 100%
No Conguration: If the Wireless Terminal displays the “Searching for Omni-
Logic” screen shown below, then the OmniLogic system is not discovering the
Wireless Terminal. To troubleshoot this issue, follow the steps below.
1. Verify that the OmniLogic and the Wireless Terminal are using the same
version rmware. If not, upgrade both to the latest versions available at
www.hayward.com/rmware.
2. Verify that the OmniLogic is connected to your home network and that it
can be controlled by web or mobile application. Refer to the OmniLogic
manual for information on how to troubleshoot your home network con-
nection.
2. Verify that the Wireless Terminal is connected to your home network.
Refer to page 3 in your HLWIRELESS manual. You may need to “forget”
the previously congured access point and reconnect to the network.
Side B
If the problem persists after following these steps, call the Hayward Technical
Service Department at (908)-355-7995 for assistance.
