HLX-LOC-DSP
Replacement Local Terminal for OmniLogic
Installation Manual
HLX-LOC-DSP
Contents
Description............................1
Installation............................1
092558 RevA
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS

Description
The HLX-LOC-DSP is a replacement Local Terminal (touchscreen) for the OmniLogic pool control-
ler.
Installation
DANGER of Death, Injury or Property Damage if procedure not followed. This accessory
connects to the OmniLogic panel beneath the dead front. Dead front removal is required for this
installation. Power to the OmniLogic panel MUST be shut off before the dead front is removed.
This means a complete shutdown of power to the entire OmniLogic panel.
1. Ensure that power is removed from OmniLogic.
2. Remove the dead front to expose the OmniLogic Main Board.
3 Remove the Local Terminal by first unplugging its ribbon cable.
Unplug Local Terminal ribbon cable
1
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS

4. Pull straight out on the Local Terminal to separate it from the mount. To prevent the mount
from detaching from the Main Board, you may have to hold down on the mount while lifting
the Local Terminal.
5. Insert the HLX-LOC-DSP onto the top of the mount as shown below.
6. Re-insert the ribbon cable.
7. Replace the dead front and power up the OmniLogic.
Confirm that the Local Terminal is fully functional and secure.
HLX-LOC-DSP
Mount
OmniLogic Main Board
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
2
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
2
