HBX THRUSTER 12889 User manual

FOUR WHEEL DRIVE SYSTEM
--SOLID REAR AXLE WITH INDEPENDENT FRONT SUSPENSION CHASSIS
--TWO SPEED TRANSMISSION (SWITCHABLE)
1/12TH S C A L E 4 W D BATTERY POWERED TWO S P E E D TRANSMISSION TRUCK
The THRUSTER is powered by a powerful RC390 brushed motor and it is equipped with the solid
rear axle with an independent front suspension chassis system. It is delivered by two speed
transmission which can be fulfilled by the additional servo and switchable with the help of the
3-Channel Radio.
TRUCK 400mm 230mm 170mm 255mm
FRONT INDEPENDENT SUSPENSION
REAR AXLE DESIGN
OIL FILLED SHOCKS
BALL BEARINGS THROUGHOUT
METAL DIFF. GEARS
TWO SPEED TRANSMISSION
SPLASH-PROOF ESC/RECEIVER
SPARE WHEEL EQUIPMENT

1

BECOMING FAMILIAR WITH YOUR TRUCK
The THRUSTER is powered by a powerful RC390 brushed motor and it is equipped with the solid rear
axle with an independent front suspension chassis system. It is delivered by two speed transmission
which can be fulfilled by the additional servo and switchable with the help of the 3-Channel Radio.
SPARE WHEEL
THE ADDITIONAL SERVO
(FOR TWO SPEED
TRANSMISSION SWITCH)
SEALED GEARBOX&
SLIPPER CLUTCH
OIL FILLED SHOCKS
AGILE STEERING
SERVO
SPLASH-PROOF
ESC/RECEIVER
(3-Channel)
-FRONT SUSPENSION CHASSIS
/REAR AXLE
-METAL DIFF. GEARS
-BALL BEARINGS THROUGHOUT
THE ENTIRE TRUCK
-POWERFUL RC 390 MOTOR
-OIL FILLED SHOCKS
-SOLID CHASSIS PROTECTION
-SPRAYED/ PLATED WHEELS
-HIGH GRIP OFF-ROAD TYRES
PERFECT FOR RUNNING ON
ANY TERRAIN
-AGGRESSIVE REAR RACK
FOR A SPARE WHEEL
INSTALLATION
-REAR AXLE OVERCOMING
THE OBSTACLES EASILY
-SOLID FRONT BUMPER
PROVIDES RELIABLE
PROTECTION AGAINST
COLLISION
- FRONT SUSPENSION DESIGN
-TWO SPEED TRANSMISSION
IS PRECISELY FULFILLED BY
THE ADDITIONAL SERVO.
2

To drive your car, switch on the radio controller, and then the receiver.
Your car is automatically bound with the radio controller when both the radio controller and
the receiver are switched on.
Install a fully charged battery pack to your car first. (Please refer to the instruction how to charge the
battery pack on Page 6.)
3
Steering Wheel: It proportionally operates the right and the left steering control of the model.
Battery Compartment: It requires 2pcs of AA size batteries, which are not included in the box.
Power Switch: It is applied to turn ON or turn OFF the radio controller.
Steering Trim: It is applied to adjust the center trim of the steering servo.
Steering Reverse: It allows you to electronically switch the direction of the steering servo travel.
Trigger: Pull the trigger to accelerate, release it to decelerate, and push it to brake. Centre
the trigger and push it a second time to reverse.
Power/Binding Indicator: It blinks rapidly when the radio controller is switched on. It indicates that the
radio controller is seeking to bind with the receiver. When binding is completed, the indicator stops blinking
and becomes bright on. When the radio controller is under low battery power, the indicator goes two
flashes in alternation. If it is the case, you must replace with the new batteries.

4

STOPPING YOUR CAR
TURN OFF THE RECEIVER ON YOUR CAR TURN OFF THE RADIO CONTROLLER
To stop running your car, turn off the receiver , and then the radio controller.
NOTE: Always remove the battery pack from the car when not in use.
AUX. Button:
AUX. Button makes two speed transmission
switchable.
It is fulfilled by the additional servo (as
shown in the figure). Each press on AUX. Button
allows for the change between slow and high speed
transmission.
We warmly recommend that the change of
the speed is performed when
the car runs at a slow speed.
5

CHARGING THE BATTERY PACK FOR CAR
1)Connect your battery to the charger with the aid of the balancer in between.
2)Plug the charger into a charging socket.
Both the red and the green indicator on the balancer are bright on when the battery pack is being
charged.
The red indicator going out, the green indicator remains bright when the battery is fully charged.
The charging time is 3-3.5 hours.
3) Do not charge your battery pack unattended.
4) Do not overcharge your battery pack.
5) Use ONLY the committed charger and the balancer provided in the package.
6

-This R/C vehicle is intended for persons over 14 years of age. Children under 14 years of age should
only operate this car under supervision by an adult.
-To avoid losing control of your car, do not operate near other electric remote controlled products.
-Please operate your vehicle in a spacious area. Never operate your vehicle in crowded street.
-This product is fully assembled at factory. We do not take any responsibility for damage and/or
accidents that occur as the result of custom modifications and/or incorrect operation.
Thank for purchasing our product.
This product is an authentic remote controlled vehicle (RC vehicle). It is not a toy.
Read and understand this instruction manual thoroughly before operating the vehicle.
If you are not familiar with RC vehicles, we recommend that seek out RC experts for reliable
advice.
WARNINGS
Please completely read and understand the entire manual before using, assembling and/or
disassembling your remote controlled car.
