H O L L Y WO O D C O N T R O L S I N C .
the above exclusions or limitations may
not apply to you.
No other warranty, written or verbal, is
authorized by the Company. This war-
ranty gives you specific legal rights and
you may also have other rights which vary
from state to state.
For service during the warrantee period
you must first contact the Company for
an Return Merchandise Number (RMA)
number. The Company will help you deter-
mine which part requires service and ask
that you return that component ONLY.
The Company, at it’s option, will repair or
replace the components and return them
to you free of charge. All returned com-
ponents must be accompanied by a RMA
number issued by the Company and be
returned by insured prepaid freight.
Products returned without a Company
issued RMA will not be accepted. The
Company is not responsible for merchan-
dise damaged in transit. Evident or con-
cealed damage made in transit should be
reported at once to the delivery carrier
and a claim filed with them.
The Company reserves the right to
change or modify the operation, design,
components and description of this sys-
tem without notice.
Hollywood Controls Inc (“the Company”)
warrants the HC0109 HH Air Machine
Gun r against defects in material or
workmanship for one year from date of
original purchase. The Company, at it’s
option, will repair or replace the compo-
nents and return them to you free of
charge.
This warranty is extended only to the
original purchaser on record with the
Company.
Your remedy is limited to this warranty
policy. This warranty only covers prod-
uct failure that occurs due to defects in
material and workmanship occurring
during the normal expected use of the
product. It does not cover damage
caused by accident, misuse, abuse, lack
of reasonable care, alterations or im-
proper installation.
There are no expressed warranties ex-
cept as described above.
THE COMPANY SHALL NOT BE LI-
ABLE FOR INCIDENTAL, SPECIAL OR
CONSEQUENTIAL DAMAGES RE-
SULTING FROM THE USE OF THIS
PRODUCT OR ARISING OUR OF ANY
BREACH OF THIS WARRANTY. ALL
IMPLIED WARRANTIES, IF ANY, IN-
CLUDING IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE, ARE
LIMITED IN DURATION TO THE DU-
RATION OF THIS EXPRESS WAR-
RANTY. Some states do not allow the
exclusion or limitation of incidental or
consequential damages, or limitations on
how long an implied warranty lasts, so
OneYear Limited Warranty
Phone:
Toll-free: 888-318-2380
sales@hollywoodcontrols.com
© 2013 Hollywood Controls Inc 03/13 R1
HA ND HE LD A IR MAC H IN E G UN ASSY
Handheld Air Machine Gun Assy
Hollywood Co ntrols Inc.
Assembly Instructions
We strive to make our equipment as
reliable and long-lived as possible.
To this end, we have revised the con-
nection hardware between the HC0109
gun and the trigger hose to provide
longer service and better reliability.
While the quick-connect hardware was
convenient, there was a potential for
winding up the RCA trigger cable and
forcing it to disconnect.
The revised connection relies on several
methods to make the connection tight
and remain rigidly fastened. Please fol-
low assembly steps carefully.
The new Gun has a 1/2” F-NPT PVC air
connection. This mates with a 1/2” M-
NPT metal barbed fitting on the hose.
The metal barb is fastened with hose
clamps. The entire coupling is protected
with a rubber tube. The PVC fitting is
positively locked to the metal fitting by
a set screw.
Assembly Tools:
•Slip-Joint Pliers
•3/32” Allen Wrench Key
Safety Precautions 1
General Description 1
Warrantee 2
Index:
Model: HC0109 Handheld Air Machine Gun & Trigger Hose
Safety Precautions
•DO NOT alter or remove labels.
•DO NOT place objects in the barrel
outlet.
•DO NOT point at face.
•DO NOT get components wet.
•DO NOT connect to devices supplying
power to the RCA plug.
Assembly Steps
1. Carefully thread the hose fitting on
to the PVC gun fitting. DO NOT
CROSS-THREAD! Tighten first by
hand, then, using the slip-joint pli-
ers, firmly seat the metal fitting
against the rubber gasket in the
PVC fitting until it will turn no fur-
ther.
2. Tighten the 10-32 Allen set screw
against the threads of the metal
fitting with the Allen wrench. Be
firm, but do not over tighten! The
gun and hose should now be rigidly
connected. If there is movement of
the barb in the hose , tighten the
hose clamps further.
3. Extend the rubber protective hose
over the metal and PVC joint.
4. Open up the loop in the RCA retain-
ing band on the hose end RCA cable.
Slip this over the gun RCA connec-
tor and plug the cables together.
This will improve the retention of
the RCA connectors during use.
Tuck any excess cable inside the
protective rubber tubing at the
open end.
