Hd electric V-detect User manual

Operating & Instruction Manual

Making

the

Invisible

Visible®

V-DETECT

and ACCESSORIES

UTILITY GRADE VOLTAGE DETECTOR

1475 Lakeside Drive • Waukegan, Illinois 60085 U.S.A.

847.473.4980 • fax 847.473.4981 • www. DEFirstResponder.com

GENERAL DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

IMPORTANT SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

OW TO USE IT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

BATTERY C ARGING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

TEC NICAL SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

MAINTENANCE AND CARE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

LIMITED WARRANTY AND LIMITATION OF LIABILITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

GENERAL DESCRIPTION

The V-Detect Utility Grade Voltage Detector detects voltage at a distance from live

unshielded conductors on overhead and underground power distribution systems.

They have been tested and operate to a voltage of 870kV line-to-line at a detection

distance from the conductor greater than the nominal ten inches.

V-Detect Utility Grade Voltage Detectors have user selectable voltage ranges covering

the range from secondary voltages to the highest transmission voltages.

Accessories may include a holster, charging cord for charging the unit from

a car or truck, a 115-240VAC wall charger adapter and a carrying case.

OPERATIONAL IMPAIRMENT

If the V-Detect Utility Grade Voltage Detector is used in a manner not described in

this instruction manual, the protection and effective operation of this equipment

may be impaired.

Operating & Instruction Manual

V-DETECT

and ACCESSORIES

UTILITY GRADE VOLTAGE DETECTOR

IMPORTANT SAFETY INFORMATION

Rea an un erstan these instructions prior to use. These operating instructions

are not a substitute for proper training in the use of this equipment.

• Only trained, professional operating personnel should use the instrument. The

voltages this instrument operates at are dangerous and lethal. Severe injury or death

can occur if improperly used.

• Risk of electrocution is inherent in or around high voltage.

• Always use proper high voltage procedures, including personal protective equipment,

when working near or around high voltage equipment or conductors.

• Do not exceed the maximum voltage rating.

• The V-Detect Utility Grade Voltage Detector must be used with a hotstick

of the appropriate length for the voltage being measured per your company

and OS A published requirements.

• Do not touch the instrument during use. The housing should be considered to be

at the same voltage as the conductor.

• Prior to using, inspect the instrument for any physical damage, cleanliness and check

for proper working order by pressing the ON button and checking that all voltage

range lights turn on in turn and that the unit stays on following the self test.

• Never allow another high voltage or grounded conductor to contact the instrument

during use. Keep the housing free and clear of all structures at all times.

• Bridging the housing from line-to-ground or line-to-line may cause a fault and arc.

• The V-Detect Utility Grade Voltage Detector does not detect voltages less than the

lowest voltage range setting on the instrument. Always use proper safety procedures.

• Lack of a voltage indication does not

mean the conductor is dead or grounded.

• Grounded equipment or lines can

appear to be live when in close

proximity to energized conductors.

• The V-Detect Utility Grade Voltage Detector

is a proximity sensing device. Voltage detection

distance is not affected by insulation on

conductors such as on tree wire or spacer wire.

• Voltage readings are sensitive to

geometry. Read and understand the

OW TO USE IT section of this manual

(page 5) before using the instrument.

• The instrument detects AC voltage only.

It does not detect DC voltage such as

charged capacitors or cable.

Rea an un erstan the labeling on

the pro uct before procee ing.

OW TO USE IT

1 CONNECT TO A SUITABLE HOTSTICK: The V-Detect Utility Grade Voltage Detector

will accept either a shotgun stick or a universal spline connection.

2 TURN IT ON: Press the ON/OFF button and verify that the instrument turns on all

voltage range lights one at a time from the lowest range to the highest, returns to

the lowest range and then turns on the voltage indicating lights and beeper. The

presence of the lights and beeper indicates that the instrument is detecting an

internally generated voltage to test the entire circuit. If the V-Detect Utility Grade

Voltage Detector stays on following this test it has passed the self test and is ready

to use. If it turns off after this test then it has not passed the self test and must be

recharged or serviced. While the instrument is on it will emit a very short beep

and flash of the lights once every FOUR SECONDS.

3 SELECT A VOLTAGE RANGE: Use the up and down arrows to select a voltage range.

The lowest range setting is indicated by the lowest voltage range shown on the label.

Always select a voltage range at or just below the voltage of the conductor to be tested.

The lowest voltage range shown on the label is line to ground voltage. All higher ranges

are line to line voltage.

Voltage Range Buttons

Up and Down

Voltage Sensing Zone

Voltage Indicating

Lights and Beeper

On/Off Button

Charger Port

otstick Connection:

Shotgun or

Universal Spline

OW TO USE IT continued

4 DETECT VOLTAGE: Move the V-Detect Utility Grade Voltage Detector toward the

conductor to be tested. The nominal detection distance for all voltage ranges

above the lowest setting is 10 inches from the tip of the unit (marked

SENSING ZONE on Page 5). Below the lowest range, the nominal sensing

distance is three inches. Always keep the instrument perpendicular to the

conductor and choose a portion of the conductor free of any apparatus.

Voltage detection is indicated by flashing lights and beeper.

If voltage is detected, do not further approach or contact the conductor.

If voltage is not detected, continue to approach the conductor with the

V-Detect Utility Grade Voltage Detector until the SENSING ZONE end

contacts the conductor.

For increased sensitivity or greater sensing distance, select a voltage range

lower than the voltage of the conductor to be tested. Never select a voltage

range higher than the voltage of the conductor to be tested, as sensing

distance will be reduced or diminished.

NEVER allow prolonged arcing between an energized conductor and

the instrument. This will damage the housing of the unit.

NEVER bridge between conductors with the housing.

This may result in an arc and/or fault.

NEVER select a voltage range above the voltage of the conductor

to be tested. The instrument may not detect voltage on the

conductor being tested.

NEVER assume a conductor is deenergized or grounded if the instrument

does not detect voltage.

ALWAYS make sure the instrument is turned on before use. It does not turn

on automatically.

ALWAYS align the instrument perpendicular to the conductor being tested

and approach the conductor with the SENSING ZONE end.

5 TURN IT OFF: To turn the V-Detect Utility Grade Voltage Detector off, press

the ON/OFF button. If the instrument is left on and does not detect voltage

for 30 minutes, it will shut itself off. This automatic shut-off is accompanied

by beeping an flashing of the lights as a warning to the user.

The instrument can be returned to the accessory holster after use and should

be returned to the protective carrying case for longer term storage.

BATTERY C ARGING

The instrument is powered by an internal lithium battery of the same type

used in cell phones. It has a long life, many charge cycles and no memory

effect. It will indicate battery charge when it is turned on and has completed

the self test as follows:

• Slowly beeps once every four seconds

indicating the battery charge is good.

• Beeps faster at once per second indicating

the battery charge is low and should be

recharged soon. The unit can be used for

up to 10 minutes in this condition and will

then shut off automatically. It cannot be

turned on again until the battery has

been charged.

Charge the instrument using the charger

cord. Apply the plug end of the cord to

a 12VDC automotive jack or use the

115-240VAC adapter. Charge is indicated

on the face of the unit by the voltage range

lights turning on in sequence. A full charge

of a low battery can take up to three hours.

When the charge is complete only the highest voltage range light will remain

on. After three hours, this light will turn off. The battery cannot be overcharged.

A quick fifteen minute charge to a low battery will allow one day of use under

typical conditions. A full charge will allow more than one week of continuous

use under typical conditions.

If the instrument will not turn on, try charging it for fifteen minutes.The battery

may be drained down too far to be able to power on.If it still will not turn on

then the battery may need to be replaced. For battery replacement contact

D Electric Company at 847-473-4980 or by email at [email protected]xtron.com

to order a replacement battery.

Lithium Battery Use an Disposal

• Charge the battery only with the D Electric supplied charger.

• Do not disassemble, open, crush, bend, deform, puncture or shred the internal battery.

• Contact your local recycling center or D Electric for proper battery disposal.

• Improper battery use may result in a fire, explosion or other hazard.

Charging Cord

12VDC Charger Plug

115-

240VAC

Charging

Adapter

TEC NICAL SPECIFICATIONS

OPERATING VOLTAGE RANGE:

• VDET-4: 50VAC to 500kVAC in 2 ranges

VOLTAGE SENSING DISTANCE:

• VDET-4: 3 inches at 50V LO range, 10 inches at 4kV I range

When used above the maximum range of 500kV up to 870kV, sensing distance increases

with increasing voltage; when held perpendicular to conductor under test with SENSING

ZONE facing live conductor.

DIMENSIONS: 11”L x 3”W x 2”D

(28 cm x 7.6 cm x 5 cm)

WEIGHT: 11oz. (0.31 kg)

OPERATING FREQUENCY: 25 z-400 z

BEEPER SOUND

PRESSURE LEVEL: 100 db.

BATTERY LIFE: One week of typical

daily use after full charge.

BATTERY CHARGING CURRENT:

0.5A maximum at 12VDC.

ENCLOSURE MATERIAL: Supertough Nylon UL 94- B

PRINTED CIRCUIT BOARDS: FR-4 UL94V-0

ENVIRONMENTAL CONDITIONS

CONDITIONS: Indoor and outdoor use

ALTITUDE: Up to 6,566 ft. (2000M)

OPERATING TEMPERATURE:

-20°F to +140°F (-29°C to +60°C)

HUMIDITY: 95% to +60°C (non-condensing)

OVERVOLTAGE CATEGORY: II Non-contact

POLLUTION DEGREE: PD4

ACCESSORIES

PTVDET PROOF TESTER® FOR

VDETECT UTILITY GRADE VOLTAGE DETECTOR

The PT-VDET Proof Tester Voltage Detector Tester is for use on the V-Detect. This tester

generates high voltage AC for testing the V-Detect. To use, turn on the V-Detect and set

it for the lowest range, hold the Tester in one hand and the V-Detect in the other. Apply

the top of the V-Detect to the metal end plate on the Tester. Press and hold the

TEST button on the Tester. A properly operating V-Detect

will indicate voltage with continuous flashing lights and

beeping sound. For best results, hold the PT-VDET with

a tight grip and wrap your fingers around it. If the

V-Detect does not indicate voltage, do not use it

and return it to D Electric Company for service.

CAUTION: This Tester generates high voltage

AC for testing V-Detect AC voltage detectors.

There is no danger of electric shock when this

tester is used as directed. Discontinue use and

return to DE for service if the housing is cracked

or broken, or if the battery cover is lost.

CAUTION: igh Voltage

WARNING: Do not use this tester except as directed.

Do not use to test equipment other than specified

V-Detect Utility Grade Voltage Detectors. Do not apply to energized circuits or equipment.

Do not operate this Tester without the battery cover and do not open the housing. Refer

all servicing to the factory. Failure to follow these instructions may lead to electric shock,

severe injury or death.

MAINTENANCE AND CARE

STORAGE - It is recommended for protection that the instrument and its accessories

are stored in the carrying case.

CLEANING INSTRUCTIONS - To clean, wipe with a damp cloth with water.

Do not use harsh chemicals or solvents.

CLEANLINESS - The molded housing is very rugged, but it should be kept clean and free

of dirt, grease and any other foreign materials. If the housing surface integrity has been

compromised in any way, remove from service and return to factory for repair or replacement.

DAMAGE - If you suspect any mechanical or electrical damage, do not use the

instrument and arrange for repair by returning to the factory.

CALIBRATION & TESTING - Regular calibration is not required.

There is no calibration adjustment.

SERVICE - Return to D Electric Company for service.

MANUFACTURING LOCATION - D Electric Company • Waukegan, IL. 60085, USA

ACCESSORIES continued

A. PRXCORD CHARGE CORD

Charge cord with 12VDC automotive jack.

B. PRXXF TRANSFORMER

115-240VAC transformer to plug

PRX-CORD into 115-240VAC wall outlet.

C. PRXHS CARRYING HOLSTER

Carrying holster with belt clip

and restraining strap.

D. PRXCS CARRYING CASE

Carrying case; holds V-Detect, PRX- S

and charge cords.

E. B2 CARRYING BAG

Padded, zippered carrying bag with strap;

holds V-Detect, PRX- S and charge cords.

F. HOTSTICKS

A range of hotsticks are available

in lengths starting at 4’. Contact

D Electric for more details.

LIMITED WARRANTY AND LIMITATION OF LIABILITY

This warranty applies to all products sold by D Electric Company (the "Products"); provided, however, that the term Products does not include any

third party products purchased through D Electric Company, for which no warranties are made (the "Third Party Products"). Third Party Products

may be subject to a separate manufacturer's warranty; [should you have any question regarding whether a separate warranty applies, please contact

D Electric Company].

NOTICE: READ T IS LIMITATION OF WARRANTY AND LIABILITY BEFORE BUYING OR USING T E PRODUCTS CONTAINED EREIN.

It is impossible to eliminate all risks associated with the use of the Products. Risks of serious injury or death, including risks associated with electrocution,

arcing and thermal burns, are inherent in work in and around energized electrical systems. Such risks arise from the wide variety of electrical systems

and equipment to which Products may be applied, the manner of use or application, weather and environmental conditions or other unknown factors,

all of which are beyond the control of D Electric Company.

D Electric Company does not agree to be an insurer of these risks, and shall have no liability for any claims arising from such risks.

W EN YOU BUY OR USE T ESE PRODUCTS, YOU AGREE TO ACCEPT T ESE RISKS.

D Electric Company warrants to the original purchaser that the Products (excluding any third party products purchased through D Electric Company,

for which no warranties are made) will be free from defects in material and workmanship, under normal use and regular service, and preventative

maintenance for a period of one (1) year (ten (10) years for DE Capacitor Controls) from the date of shipment (the “Warranty Period”). Should any failure

to conform with this warranty be found during the Warranty Period, you must notify D Electric Company of your claim within thirty (30) days of discovery,

and within the Warranty Period. Your failure to give notice of claims of breach of warranty within the Warranty Period shall be deemed an absolute and

unconditional waiver of claims for such defects. D Electric Company will have no responsibility to honor claims received after the date the applicable

Warranty Period expires.

Upon notice of your claim, D Electric Company will provide a return authorization number, and further instructions on how to return the product for

service. You must follow D Electric Company’s instruction. You are responsible for all Product removal, handling, re-installation, and shipping (both

to and from D Electric Company). Products returned for repair, as well as repaired or replacement Products shall be sent postage / freight prepaid. After

receipt of a product which D Electric Company determines is defective, D Electric will, at its option, either (1) repair (or authorize the repair of) the

Product or (2) replace the Product, subject to the following: The Products are made using parts sourced from a variety of manufacturers. Due to the rapidly

changing technology environment, parts may become obsolete / unavailable over time (end of life). In the event that a Product cannot be repaired or

replaced due to unavailability of parts, D Electric Company will use commercially reasonable efforts to obtain substitute parts or conduct work around

design, but cannot guarantee its ability to do so.

Items not found defective will be returned at your expense, or failing receipt of instruction from you on return of such items within five (5) business days

of our notice to you that the product is not defective, D Electric may dispose of the product at its discretion and with no liability to you. D Electric

Company’s determination of defects is final. Products repaired or replaced during the Warranty Period shall be covered by the foregoing warranties for

the remainder of the original Warranty Period or ninety (90) days from the date of delivery of the repaired or replaced Products, whichever is longer.

LIMITATIONS:

This warranty is void in the event of misuse, alteration, faulty installation, or misapplication of the product.

This warranty does not cover failure of product or components due to any ACT OF NATURE; lightning, floods, hurricanes, tornadoes or any other such

catastrophic events.

D Electric Company does not warrant any third party products or associated hardware or their performance or suitability for use and application. Such

items are provided “as-is”.

All repairs must be authorized by D Electric Company. Unauthorized repairs will not be reimbursed under any circumstances.

D Electric Company is not required to make replacement or loaner equipment available while Products are being repaired or replaced, or to compensate

you for any in/out labor charges or expenses associated with removal, handling or re-installation of the Products.

TO T E MAXIMUM EXTENT PERMITTED BY LAW, T IS WARRANTY AND T E REMEDIES SET FORT ABOVE ARE EXCLUSIVE AND IN LIEU OF ALL OT ER

WARRANTIES, REMEDIES AND CONDITIONS, W ET ER ORAL OR WRITTEN, EXPRESS OR IMPLIED. D ELECTRIC EXPRESSLY DISCLAIMS ALL OT ER

WARRANTIES OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING WIT OUT LIMITATION IMPLIED WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE,

MERC ANTABILITY AND NON-INFRINGEMENT.

IN NO EVENT S ALL D ELECTRIC COMPANY BE LIABLE FOR ANY INDIRECT, INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES RESULTING FROM T E

USE OR ANDLING OF T ESE PRODUCTS. T IS S ALL INCLUDE BUT, NOT LIMITED TO, LOST PROFITS OR REVENUE, LOSS OF USE OF T E PRODUCTS,

COST OF SUBSTITUTE PRODUCTS, FACILITIES OR SERVICES, OR DOWNTIME.

IN NO EVENT S ALL D ELECTRIC COMPANY AVE ANY LIABILITY FOR ANY T IRD PARTY PRODUCTS OR ASSOCIATED ARDWARE, OR

CUSTOMER-OWNED SYSTEMS, EQUIPMENT OR SOFTWARE.

D Electric Company must have prompt notice of any claim so that an immediate product inspection and investigation can be made. Buyer and all

users shall promptly notify D Electric Company of any claims, whether based on contract, negligence, strict liability, or other tort or otherwise be barred

from any remedy.
