HDanywhere HKSP0104CAT-UK User manual

HKSP0104CAT-UK
1xinput,4xoutput
HDTVmultiroomHub
(TwinWire)
Model: HKSP0104CAT-UK
User Manual
1
HKHKSP0104CAT-UK User Manual

HKSP0104CAT-UK
Thank you for choosing this HDanywhere product.
Please read this manual fully before attempting to set-up your
Matrix.
Contents
Page 3 Getting started
Page 4 Connecting up your multiroom system
Page 6 Completing your set-up
Page 7 Troubleshooting
Page 8 Specifications
Page 10 Replacement Warranties and Guarantee
2
HKHKSP0104CAT-UK User Manual

HKSP0104CAT-UK
Getting started
Unpack your box and make sure that you have received all of the essential components from
HDanywhere.
●1 x Central hub unit
●4 x Receiver units
●User Manual
●5VDC power supply
●4 x IR TX cables (IR emitter/blaster)
●4 x IR RX ‘magic eye’ cables (from 30KHz to 56KHz IR receiver)
●1 x hub IR extension RX cable
Before you set-up your multiroom system, please ensure that you
complete the following:
●Ensure that any manufacturer HDMI link or CEC protocols such as Samsung Anynet
Link, Sony Bravia Link, Panasonic Viera Link etc are switched to “off” on both the
source devices and HDTVs that are to be connected to the Matrix.
●Switch off all intended HDMI source devices and HDTVs and unplug them from the
mains.
3
HKHKSP0104CAT-UK User Manual

HKSP0104CAT-UK
Panel Descriptions
Connecting your Multiroom Hub
ENSURE: That you only connect/disconnect HDMI and Cat5e/6 cabling while the
matrix unit and the source/display devices are powered off.
1.Connect the HDMI input source device into the HDMI ‘Source Input’ port.
2.Connect the corresponding Cat5e/6 cables (1 & 2) from each HDTV location to the
correct dual RJ45 TV output ports.
3.Connect the corresponding Cat5e/6 cables (1 & 2) to the correct dual RJ45 input
ports on the HDTV Receiver at each TV location.
4.Connect a HDMI cable from the Receiver to the desired HDMI input port on the
HDTV.
N
O
T
E
:
●For Blu-ray 3D ‘High Speed’ rated HDMI cables must be used (usually
under 8m in length)
●Connect your most commonly watched HDTV location device to the TV1
output.
●HDMI cables over 15m in length are not recommended.
4
HKHKSP0104CAT-UK User Manual

HKSP0104CAT-UK
IR Remote Control passback connection
1.Connect an IR RX cable using the 3.5mm jack on each HDTV Receiver. (also referred
to as ‘magic eyes’)
2.Stick/position the magic eye somewhere where it will be in sight of the remote
control during use at each HDTV location.
3.Connect the 3.5mm jack IR emitter cable to the IR TX output on the front of the
Central Hub.
4.Position the IR emitter/blaster somewhere in front of the source device so that the
IR blasts emitted can be ‘seen’ by all the source device’s IR receiving window.
C
E
C
N
O
T
E
:
All CEC controls such as Bravia Sync, Viera Link, Samsung Anynet, are NOT
available when using the HDanywhere system. As stated on page 3,
manufacturer HDMI link or CEC protocols should be switched to “off” on
any source devices or HDTVs connected to the Matrix.
5
HKHKSP0104CAT-UK User Manual

HKSP0104CAT-UK
Powering on your system for the first time
The very first power on/initialisation of the system is crucial to future operation and
performance. The central hub incorporates a small memory. This memory stores the initial
handshake negotiations and authentications between the source and all connected HDTVs.
●Power the HDTVs on at the mains. Bring out of standby mode and select the correct
HDMI channel that the Receiver unit’s HDMI cable is connected to.
●Power on the HDMI source device at the mains and bring it out of standby mode.
(NB Sky HD takes one minute or so)
●Connect the power cable to the central hub and power it on at the mains switch.
●Finally power on the central hub by using the manual power ‘on’ switch located on
the front panel.
If at any time a connected source device or HDTV changes HDMI port number or is
replaced with a different model, a factory reset and re-initialisation of the central
hub is recommended.
To perform the hard reset:
Power down every device connected to the central hub – the source + all HDTVs.
Now power down the central hub unit itself. Leave off at the mains for at least
10–15 minutes. Finally connect and power on the hub again as if doing it for the very
first time.
Completing your set-up
After completing the process above, all HDTVs should be displaying the HDMI source device
video and audio.
The system is designed to be powered on constantly, using a low power
consumption. In some cases when the hub has been powered off fully at the mains,
the process above may need to be repeated to sync the HDTVs again with the
HDMI source device.
6
HKHKSP0104CAT-UK User Manual

HKSP0104CAT-UK
Troubleshooting
For the majority of problems that you may encounter when using your multiroom system a
reset of the central hub should resolve any issues.
To perform the hard reset:
Power down every device connected to the Matrix – all sources + all HDTVs. Now power
down the Matrix unit itself. Leave off at the mains for at least 10–15 minutes. Finally connect
and power on the Matrix again as if doing it for the very first time.
ISSUE: No/intermittent picture on HDTV, blocky images or sparkles
Fault finding:
Drop the output resolution of the source device down to 1080i or 720p. If the picture
appears correctly on the HDTV this indicates a bandwidth issue with the HDMI cable run. The
available bandwidth is too low for 1080p transmission.
This can be caused by:
●Poor quality HDMI cabling or internal cable strand breakages caused by poor
production or installation bending/strain/damage.
●HDMI cable distance is too long even for the eyefix chipset to drive
Possible fixes:
●Upgrade to better quality HDMI cable.
●Reduce HDMI cable length
●Add a HDMI Repeater on the end of the long HDMI cable runs to revive the signal
ISSUE: IR remote control not working via extender
This can be caused by:
●IR TX cable and IR RX cable connected the wrong way round on the Transmitter and
Receiver units.
7
HKHKSP0104CAT-UK User Manual

HKSP0104CAT-UK
Specifications
These specifications may change or be improved without notice. HDcable may not be held
responsible for discrepancies.
Operating Temperature Range
-15 to +55°C (5 to 131 °F)
Operating Humidity Range
5 to 90 % RH (no condensation)
Input Video Signal
5.0 volts p-p
Input DDC Signal
5 volts p-p (TTL)
Video Format Supported
DTV/HDTV; 1080p/1080i/720p/576p/480p/576i/480i, VESA
formats
All 3D formats inc 3D over HDMI 1080p60
4K x 2K
Up to 48-Bit Deep Colour
Audio Format Supported
Dolby-HD, DTS-HD, up to 7.1 channel
Output Video
HDMI 1.4a + HDCP
Processor Bandwidth Support
2.67 (x3) 8.03 Gbit/s
I/O Cable Distance
15-20m 24AWG (all HD Cable Ltd HDMI cable models
supported)
Power Supply
DC5V (8x8 model 15V)
Power Consumption
120mwtts (Max.)
Dimensions (mm)
317 × 156 × 28
Mass (Main unit)
1145g
IR Wavelength & Frequency
Wavelength: 940nm IR frequency: 38KHZ
8
HKHKSP0104CAT-UK User Manual

HKSP0104CAT-UK
Hereby, HD Cable Ltd declares that this HDMI connectivity device is in compliance with the essential
requirements and other relevant provisions of the following Directives: 2006/95/EC (LVD Directive);
2004/108/EC (EMC Directive); 999/5/EC (R&TTE Directive).
Warning
Toreducetheriskoffire,electricshockorproductdamage:
9
HKHKSP0104CAT-UK User Manual

HKSP0104CAT-UK
One-Year Replacement Warranty & Guarantee
We offer a one-year worldwide replacement guarantee covering HDcable electronic devices.
You can use our freepost returns service to send your faulty device back to us.
If you need to use this guarantee contact HD Cable Customer Services:
[email protected]
01684 576 348
WarrantyDetails
If your HDcable product does not work properly because of a defect in materials or workmanship, HD Cable Ltd                 
(referred to as “the warrantor”) will, for the length of the period indicated as below, (One Year) which starts with               
the date of original purchase (“Limited Warranty period”), at its option either (a) repair your product with new or                 
refurbished parts, or (b) replace it with a new or a refurbished product. The decision to repair or replace will be                   
madebythewarrantor.
This Limited Warranty is extended only to the original purchaser and only covers product purchased as new.
A purchase receipt or other proof of original purchase date is required for Limited Warranty service.
This Limited Warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES NOT
COVER normal wear and tear or cosmetic damage. The Limited Warranty ALSO DOES NOT COVER damages or
failures which are caused by products not supplied by the warrantor, or failures which result from accidents,
misuse, abuse, neglect, mishandling, misapplication, alteration, faulty installation, set-up adjustments,
maladjustment of consumer controls, improper maintenance, power line surge, lightning damage,
modification, or service by anyone other than a Factory Service Centre or other Authorised Service, or
damage that is attributable to acts of God.
There are no express warranties except as listed under “limited warranty coverage”. The warrantor is not
liable for incidental or consequential damages resulting from the use of this product, or arising out of any
breach of this warranty. (As examples, this excludes damages for lost time, cost of having someone remove or             
reinstall an installed unit if applicable, travel to and from the service location, loss of or damage to media or                  
images,dataorotherrecordedcontent.Theitemslistedarenotexclusive,butareforillustrationonly.)
10
HKHKSP0104CAT-UK User Manual

HKSP0104CAT-UK
Got an idea on how we can improve our manuals?
Do you think we could have explained something better or simpler?
Let us know and receive a 10% discount voucher! Email [email protected]
Last manual revision: 28/04/11
 HD Cable Ltd
HDcable.co.uk, HDanywhere™ and the HDTV emblem are trademarks of HD Cable Ltd.
HDMI, the HDMI Logo are trademarks of HDMI Licensing LLC.
The details in this manual are correct at the time of going to print. The specification and features are subject to
change without notice. No responsibility can be accepted for damage caused to connected devices as a result of the
use of the HDMI Splitter.
HD Cable Ltd. 23 Link Business Centre, Malvern, Worcestershire WR14 1UQ.
10.Referallservicingtoqualifiedservicepersonnel.
9.Onlyuseattachments/accessoriesspecifiedbythemanufacturer.
8.Protectthepowercordfrombeingwalkedonorpinchedparticularlyatplugs.
7.Unplugthisapparatusduringlightningstormsorwhenunusedforlongperiodsoftime.
5. Do not place sources of naked flames, such as lighted candles, on the unit.
4. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
3. To prevent risk of electric shock or fire hazard due to overheating, do not obstruct the unit’s ventilation openings with newspapers, tablecloths,
curtains, and similar items.
11
HKHKSP0104CAT-UK User Manual

HKSP0104CAT-UK
2. Do not install or place this unit in a bookcase, built-in cabinet or in another confined space. Ensure the unit is well ventilated.
6. Clean this apparatus only with dry cloth.
1. Do not expose this apparatus to rain, moisture, dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the
apparatus.
Power ON/OFF
3.5mm IR emitter port
System Reset
Front
Back
WARNING!
DO NOT HOT-PLUG HDMI CABLES. ALWAYS FULLY POWER OFF THE MATRIX UNIT
BEFORE CONNECTING AND RECONNECTING HDMI CABLES.
12
HKHKSP0104CAT-UK User Manual

HKSP0104CAT-UK
FAILURE TO DO THIS WILL RESULT IN CRITICAL DAMAGE TO THE MATRIX THAT IS
NOT COVERED UNDER WARRANTY.
HDTV location active indicator LEDS
Source device HDMI input
DC5V Power Input
Dual RJ45 outputs for each HDTV location
