Headrush Gigboard User manual

SPECIFICATIONS

Footswitches (4) footswitches with color LEDs

Knobs (1) 300°master volume knob

(1) 360°navigation/data encoder

Display (1) full-color LED-backlit display with touch interface

6.9” / 176 mm (diagonal)

5.9” x 3.7” / 150 x 93 mm (width x height)

Connectors (1) 1/4” (6.35 mm) TS input (guitar)

(1) 1/4” (6.35 mm) TRS input (expression pedal)

(1) 1/4” (6.35 mm) TS input (expression pedal toe switch)

(1) 1/8” (3.5 mm) stereo input (auxiliary device)

(1) 1/4” (6.35 mm) TRS output (external amp switch)

(1) 1/4” (6.35 mm) TRS input (send)

(1) 1/4” (6.35 mm) TRS output (return)

(1) 5-pin MIDI input

(1) 5-pin MIDI output/thru

(1) USB Type-B port

(1) IEC power input

Power

Connection DC power adapter input

Input Voltage 19 VDC, 3.42 A, center-positive

Dimensions

(width x depth x height)

12.96" x 8.88" x 2.64"

32.92 x 22.56 x 6.71 cm

Weight 7.14 lbs.

3.24 kg

SERVICE MANUAL

MODEL:

GIGBOARD

DISASSEMBLY PROCEDURE

Ĳį

ĲįĲį

Ĳį DISASSEMBLE THE BOTTOM PANEL

(A) REMOVE 6 PCS SCREW FROM THE TOP HOUSING..

(B) REMOVE 3 PCS

SCREW FROM THE TOP HOUSING.

(C)REMOVE 3 PCS SCREW FROM THE TOP HOUSING.

(Fig1)

ĳĳ

ĳ.DISASSEMBLE THE REAR PANEL PCB

(A) REMOVE 3 PCS SCREW FROM THE REAR PANEL PCB ASS’Y.

(B) REMOVE 9 PCS NUT FROM THE REAR PANEL PCB ASS’Y

(Fig2)

ĴĴ

Ĵ. DISASSEMBLE THE CARRIER BOARD PCB ASS’Y.

(A)REMOVE 2 PCS SCREW FROM THE REAR PANEL PCB ASS’Y..

(B)REMOVE 2 PCS SCREW FROM THE CARRIER BOARD PCB ASS’Y.

(Fig3)

ĵĵ

ĵ.

DISASSEMBLE THE ADPTER PCB ASS’Y

(A) REMOVE 2 PCS SCREW FROM THE ADPTER PCB ASS’Y.

(Fig4)

Ķį

ĶįĶį

ĶįDISASSEMBLE THE TOP PCB ASS’Y

(A) REMOVE 2 PCS KNOB FROM THE VR PCB ASS’Y

(B) REMOVE 2 PCS NUT FROM THE VR PCB ASS’Y

(D) REMOVE 8 PCS SCREW FROM THE TOP PCB ASS’Y

(E) REMOVE 5 PCS NUT FROM THE TOP PCB ASS’Y.

(F) REMOVE 5 PCS SCREW FROM THE TOP PCB ASS’Y.

(Fig5)

6.6.

DISASSEMBLE THE 7INCH CTP+TFT.

(A) REMOVE 4 PCS SCREW FROM THE TOP HOUSING.

(B) REMOVE 5 PCS SCREW FROM THE TOUCH PANEL HOLDER.

(Fig6)

WIRING DIAGRAM

(US/EU/UK/AUS/JIS/NZ/CCC/CA)

PACKING DIAGRAM

(US/EU/UK/AUS/JIS/NZ/CCC/CA)

EXPLODE DIAGRAM

(US/EU/UK/AUS/JIS/NZ/CCC/CA)

EQUENCIAL NO EXPLODE DIAGRAM WILL BE MARKED ON REF.COLUMM OF BOM LIST

HG02MAO01 BOM

LEVEL

P/N DESCRIPTION QTY

REF

0 HG02MAO01 GigBoard AC100~240V/60/50HZ(USA) 0

1 AL9-79-075211 Carrier Board PCB Assembly(HG02) 1

2 AL0-17-0102 RES ARRAY 4X1K 1

R90

2 AL2-49-0070 Diode BAV70 5

D4,D7,D11,D14,D20

2 AL2-51-0140 Schottky Barrier Rectifiers Diode 1

D35

B140-13-F SMA

2 AL2-51-4401 Transistor 2N4401 NPN SOT-23 (Transistor 12

Q14,Q16~Q20,Q23,Q24,Q26~Q29

MMBT4401LT1 NPN SOT-23)

2 AL2-51-4403 Transistor 2N4403 PNP SOT-23 1

Q30

2 AL2-54-0138 Mosfet BSS138 N-CH SOT-23 2

Q5,Q13

2 AL4-15-0006 HEADER SIL 6P 0.1 1

2 AL7-01-0045 Crystal 32.768KHZ HMR-200 SMD 1

2 AL9-40-0752G Carrier Board PCB 8 Layer FR-4 156*120mm 1

2 BAS0305030A SMT Holder(M3*3) 2

Z1,Z2

2 BTCR122001 Lithium Coin CR1220 1

(BAY1)

2 CS101J5002NPO CCAP SMD 100pF/50V 5% 0402 NPO 12

C125,C127~C131,C138~C143

2 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 1

C115

2 CS102J5002NPO CCAP SMD 1nF/50V ± 5% 0402 NPO 13

C74,C118~C121,C123,C124,C132~C137

2 CS102J5003NPO CCAP SMD 1nF/50V 5% 0603 NPO 3

C112,C168,C169

2 CS104K1602X7R CCAP SMD 0.1uF/16V 10% 0402 X7R 14

C5,C6,C9,C33,C34,C61,C66,C67,C81,C88

C104,C116,C176,C180

2 CS104K2502X5R CCAP SMD 0.1UF/25V 10% 0402 X5R 2

C164,C165

2 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 6

C3,C23,C82,C84,C98,C111

2 CS105K1002X5R CCAP SMD 1uF/10V 10% 0402 X5R 2

C38,C65

2 CS105K1603X7R CCAP SMD 1uF/16V 10% 0603 X7R 3

C77,C96,C175

2 CS105K2505X7R CCAP SMD 1uF/25V 10% 0805 X7R 1

C95

2 CS105K5006X7R CCAP SMD 1UF/50V 10% 1206 X7R 1

2 CS106K1003X5R CCAP SMD 10uF 10% 10V 0603 X5R 2

C102,C117

2 CS106K1605X5R CCAP SMD 10uF/16V 10% 0805 X5R 1

2 CS106K2506X5R CCAP SMD 10UF/25 ±10% 1206 X5R 7

C85,C93,C99,C110,C170,C171,C174

2 CS107M0606X5R CCAP SMD 100uF 20% 6.3V 1206 X5R 1

C60

2 CS120J5002NPO CCAP SMD 12PF/50V±5% 0402 NPO 1

C64

2 CS181J5003NPO CCAP SMD 180PF 50V 50% 0603 NPO 1

C83

2 CS220J5003NPO CCAP SMD 22pF/50V 5% 0603 NPO 1

C24

2 CS222K5002X7R CCAP SMD 2.2nF/50V 10% 042 X7R 1

C97

2 CS226M0603X5R CCAP SMD 22uF/6.3V 20% 0603 X5R 4

C86,C87,C108,C109

2 CS330J5003NPO CCAP SMD 33pF/50V 5% 0603 NPO 1

2 CS333K5003X7R CCAP SMD 0.033uF/50V 10% 0603 X7R 1

C89

2 CS475K1003X5R CCAP SMD 4.7uF 10% 10V 0603 X5R 2

C41,C69

2 CS475K2506X7R CCAP SMD 4.7uF/25V 10% 1206 X7R 3

C91,C92,C94

2 CS476M1006X5R CCAP SMD 47UF/10V 20% 1206 X5R 1

C63

2 CS561J5003NPO CCAP SMD 560pF/50V 5% 0603 NPO 2

C113,C114

2 CS822K5003X7R CCAP SMD 8.2nF/50V 10% 0603 X7R 1

C90

2 DIBAV99 DIODE HIGH-SPEED DUAL BAV99 SOT-23 19

D3,D6,D12,D15~D18,D22~D25,D27~D34

2 DIEN1N4148WSM Diode SMD 2

D8,D10

2 DISDBAT54CSM Zener Diode BAST54C 1

D19

2 DISDPMEG3050BEP Shottky diode PMEG3050BEP SOD128 1

2 DISR26 Schottky Barrier Rectifier 1

D26

2 DIZDAZ5825-01F Transient Voltage Suppressor 5V AZ5825-0 1

D21

1F 0402

2 DIZDRCLAMP0524P Transient Voltage Suppressor Diode 2

U55,U56

RCLAMP524PATCT QFN-10

2 DIZDSMA6J24CA Transient Voltage Suppressor Diode 2

D1,C182

SMA6J24CA

2 DIZDTPD2EUSB30A Transient Voltage Suppressor Diode 2

U21,U29

TPD2EUSB30ADRTR SOT-3

2 ECS15725FLE ECAP 150UF/25V 8*10MM SMD Low ESR 1

C126

2 ECS47650D Capacitor Electrolytic 47uf/50v D Type 1

C172

2 EVA1704489 Rubber Foam Pad 5x20 2

(MS1-8)

2 FCN1T03003101 FCN Down Touch ZIF SMD Pitch=0.3mm 31pin 1

J10

HIROSE

2 FCN1T0502201 FCN DOWN Touch ZIF SMD pitch=0.5mm 22P 2

J14,J23

2 GELS606C-0100 Heat-Sinking Cream 0.01

2 IC74AHC1G126DBV IC 74AHC1G126DBV SOP5 2

U39,U40

2 IC74LVC1G14DBVR IC SN74LVC1G14DBVR SOT-23 1

U47

2 ICAP3031KTR-G1 IC AP3031KTR-G1 SOT-23-6 1

U16

2 ICHYM8563 IC Timer RTC Serial I2C HYM8563 SOP-8 1

U25

2 ICLM1117MPX-1.8 IC REG Voltage LM1117MPX-1.8 SOT-223 1

2 ICMP2315 IC MP2315 TSOT23-8 2

U1,U6

2 ICSN74HCU04PWR IC SN74HCU04PWR HEX Iuverter TSSOP-14 1

U37

2 ICTPS40304DRCT IC REG Voltage Controller TPS40304DRCT 1

VSON-10

2 ICYH107M01 AL9-79-0780+Program(HG02) 1

(J27)

3 AL9-79-0780 rodxa-rock2 CG 1G/8G 1

(J27)

2 JK0BS12B2AA002R Con Battery Holder CR1220 1

BAT1

2 JK0KUSBXHTBS1NO B-TYPE USB Jack 90°(Orange) 1

2 JK0MM70314310B1 Socket 314Pin 0.5mm MXM3.0 CARD EDGE 1

J27

SHIELD

2 JKKD-01H2T-20 DC Jack 2.0mm 160W 90°DIP 1

2 LDKPT-1608SURCK Liquid-emitting Diode Red SMD 0603 2

LED1,LED2

angle 120°

2 MT0701849 Ground Plate(Top Housing) 1

(MS1-8)

2 MT0701850 Ground Plate(Top Housing) 1

(MS1-8)

2 MT0703238 Heat Sink 1

(MS1-8)

2 MT0703240 Copper Plate 1

(MS1-8)

2 MT0704493 SMT Holder(M3*9.0) 4

Z7~Z10

2 MT13044232 Fixed Plate(L) 1

2 MT13044233 Fixed Plate(R) 1

2 RS000004J06 RES 0ȍ5% SMD 1206 17

R1,R58,R107,R108,R125~R130,R165

R173~R178

2 RS000010J03 RES 0ȍ5% SMD 0603 13

L10~L12,L15~L17,R20,R171,R172,R180

R181,R191,R213

2 RS000016J02 RES 0ȍ5% SMD 0402 10

R57,R151~R154,R208,R222~R225

2 RS000210F03 RES 2ȍ1% SMD 0603 1

R190

2 RS001016F02 RES 10ȍ1% SMD 0402 2

R59,R122

2 RS001K10F03 RES 1K 1% SMD 0603 7

R9,R43,R88,R89,R91,R185,R216

2 RS001K16F02 RES 1K 1% SMD 0402 10

R55,R98,R99,R121,R146,R147,R157,R168

R205,R206

2 RS001M16F02 RES 1M 1% SMD 0402 1

R150

2 RS002010F03 RES 20ȍ1% SMD 0603 2

R102,R119

2 RS002M10F03 RES 2Mȍ1% SMD 0603 1

R73

2 RS010010F03 RES 100ȍ1% SMD 0603 2

L13,L14

2 RS010K10F03 RES 10K 1% SMD 0603 5

R23,R61,R63,R64,R66

2 RS010K16F02 RES 10K 1% SMD 0402 12

R14,R26,R53,R60,R69,R83,R114,R132,R148

R158,R159,R184

2 RS015K10F03 RES 15K 1% SMD 0603 1

R15

2 RS015K16F02 RES 15K 1% SMD 0402 1

R54

2 RS020010F03 RES 200ȍ1% SMD 0603 1

R149

2 RS020K16F02 RES 20K 1% SMD 0402 1

R117

2 RS023716F02 RES 237ȍ1% SMD 0402 1

R68

2 RS049910F03 RES 499ȍ1% SMD 0603 2

R72,R202

2 RS075K10F03 RES 75K 1% SMD 0603 1

R16

2 RS100K10F03 RES 100K 1% SMD 0603 5

R62,R109,R113,R118,R145

2 RS100K16F02 RES 100K 1% SMD 0402 7

R28,R38,R52,R84,R94,R105,R124

2 RS121K16F02 RES 121Kȍ1% SMD 0402 1

R136

2 RS12K710F03 RES 12.7K 1% SMD 0603 1

R101

2 RS19K110F03 RES 19.1K 1% SMD 0603 1

R193

2 RS1K3710F03 RES 1.37K 1% SMD 0603 1

R182

2 RS1K3716F02 RES 1.37K 1% SMD 0402 1

R70

2 RS1K8710F03 RES 1.87K 1% SMD 0603 1

R188

2 RS22K110F03 RES 22.1K 1% SMD 0603 1

R92

2 RS2K2110F03 RES 2.21K 1% SMD 0603 1

R110

2 RS2K7416F02 RES 2.74K 1% SMD 0402 1

R65

2 RS33K210F03 RES 33.2K 1% SMD 0603 1

R104

2 RS36K510F03 RES 36.5K 1% SMD 0603 1

R93

2 RS40K210F03 RES 40.2K 1% SMD 0603 1

R100

2 RS47K516F02 RES 47.5K 1% SMD 0402 4

R41,R42,R203,R204

2 RS47R510F03 RES 47.5ȍ1% SMD 0603 2

R111,R112

2 RS4K7510F03 RES 4.75K 1% SMD 0603 1

R189

2 RS4K7516F02 RES 4.75Kȍ1% SMD 0402 1

R71

2 RS51K110F03 RES 51.1K 1% SMD 0603 1

R27

2 RS8K8716F02 RES 8.87K 1% SMD 0402 1

R67

2 RU0704445 Rubber Knob 1

(MS1-8)

2 RU0704447 Silicon Rubber Washer 1

(MS1-8)

2 SC0306RINI Screw M3X6 PPN 12

(Z1,Z2,Z7~Z10)

2 SWEVQ11L05R Switch Tact 5mm 160g Horizonta DIP 2

S2,S3

2 SWSP70030F13F1 Switch Power Push Dual Row NON-Shorting 1

2 TE10200502 Connector (5P Socket)180° 1

J22

2 TE10200601 Connector in Header 180°Pitch:2.00mm 1

Single Row 6P DIP

2 TE612000202 Terminal 2P 2.0 180° 1

J19

2 TE612000402 Terminal(4P)180° 1

J13

2 TR2N7002LT3G MOSFET N-Channel 2N7002LT1G SOT-23 1

2 TRBSZ100N03MS Power MOSFET N-Channel BSZ100N03MS 1

TSDON-8

2 TRCSD18537NQ5A Power MOSFET N-Channel CSD18537NQ5A 1

SON-8

2 TRDMG2305UX Trans power p-chan mosfet DMG2305UX 20V 1

Q12

4.2A SOT-23

2 TRDMP3099L MOSFET DMP3099L P-CHAN 30V 3.8A SOT-23 1

2 TRFDD4685 MOSFET FDD4685 P-CH TO-252 1

2 UHMPZ1608S331A Bead 330ȍ1.7A 25% SMD TDK 1

2 UHMSCDRI64-2R2N Inductor 2.2uH 3.3A DCR:0.024ȍ6.2*5.9 1

2 UHMSCDRI64-4R7M Inductor 4.7uH 2.2A DCR:0.03ȍ6.2*5.9mm 2

L1,L5

2 UHSQD105T-751 Common Inductor 700ȍ±35% 10.3X8mm 1

2 UHXAL7070332ME Inductor 3.3uH 19A SMD 7.2*7.5mm 1

1 BASPO10X6.2X5 Holder 5

1 CA040218004 USB 2.0 1.8M A/B Black CORE 1

1 CN0220002508 Flat Cable 2pin pitch 2.0mm Single Row 1

Length 250mm Female/Female

1 CN0620001301 Flat Cable 6Pin Pitch 2.0mm Single Row 1

Length 130mm Female Header/Female

Header

1 CN1220001502 Flat Cable 12Pin Length 150mm Female/Fem 1

ale Header

1 EVA1504493 EVA 1

1 FFC2205000501 FFC 22Pin Pitch:0.5mm Length:50mm 2

1 LAC22MAO87 Serial Number Label 1

1 LAC53MAO86 Safety Label 1

1 LAC62MAO76 Softwave Barcode Label 1

1 LAC62MAO88 Bar Code Label(CODE39) 0.5

1 LAC62MAO89 Bar Code Label(GTIN14) 0.5

1 LAC63DAM92 MCS Label 1

1 LAC67MAR681 Label(Circle Limpid) 2

1 LAC67YAH261 Label ĳ8mm Green 1

1 MT133004401 Top Housing(Printing-Painting) 1

2 MT1330044 Top Housing 1

1 MT133036701 Bottom Housing(Painting) 1

2 MT1330367 Bottom Housing 1

1 MT1504343 Holder 2

1 OT7459135101 FPC 31pin pitch:0.3mm Length:150mm 1

1 OTUMO-9135MD-1T 7Inch CTP+TFT Assembly 1

1 PHG02MAO01 Pack Assembly 1

2 AL7-51-1410-D Safety Manual 1

2 AL7-91-1002 Gel Silica 1

2 CGHG02310MAO01 Gift Box 1

2 CTHG02513MAO01 Shipping Carton 0.5

2 GEMAO12 Headrush Celestion Download Card 1

2 GEMAO13 DRIVER Download Card 1

2 OPHG02MAO01 Instuction Book 1

2 PE150350BO Poly Bag 150*350mm 1

2 PE230370402B07 Poly Bag 230*370mm 1

2 PLHG0201 Polyfoam(LEFT) 1

2 PLHG0202 Polyfoam(RIGHT) 1

2 SD50042000 Soft Sheet 1

1 PT1304373 Light PiPe 1

1 PT13044150 Touch Panel Holder 1

1 PT13106188 Large Knob CAP 1

1 PT1310618901 Knob 1

1 PT1510611001 Power Button(Painting) 1

2 PT15106110 Power Button 1

1 PW63100UC01 AC Power SUPPLY Cord 1M UL+CSA 1

1 RU1530608 Rubber Foot 4

1 SC0306RINI Screw M3X6 PPN 6

1 SC0308F2IBI Screw M3X8 HFB 5

1 SC0308PBNI Screw 20

1 SC0308WBNI Screw M3X8Xĭ8 PPWN W/Washer Tapping 5

1 SC0310F2BBI Screw M3X10 HFB Tapping 26

1 SPSAFSP065REBN2 Switching ADAPTOR 19V/3.42A UC/EU/UK 1

1 TWAA812893J01 Footswitch Assembly 4

2 CN0220000503 Flat Cable Multicolored 2P Pitch 2.0mm 4

Dual Row Length 50mm Line/Female

2 SWPB-24B-4 Switch Power Push Single Row 4

1 TWPC17A02601 TOP PCB Assembly 1

2 PC17A026 TOP PCB 2 Layer FR-4 312*165mm ENTEK 1

2 TWPC17A026A01 TOP PCB Assembly 1

3 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 9

C20~C28

3 CS102J5003NPO CCAP SMD 1nF/50V 5% 0603 NPO 3

C5,C10,C11

3 CS103J2503NPO CCAP SMD 0.01UF/25V 5% 0603 NPO 2

C18,C19

3 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 9

C1,C2,C4,C7,C8,C12,C14,C15,C29

3 CS105K2503X7R CCAP SMD 1UF/25V ±10% 0603 X7R 2

C3,C13

3 CS300J5003NPO CCAP SMD 30pF/50V 5% 0603 NPO 2

C16,C17

3 CS475K1003X5R CCAP SMD 4.7uF 10% 10V 0603 X5R 2

C6,C9

3 ICSN74LV595APWR IC 74LV595A 8-bit SERIAL SHIFT W/LATCHES 2

U1,U3

TRI-STATE TSSOP-16

3 ICYH106M13 IC(ICSTM32F401RBT6+ProgramV1.00)TQFP-64 1

4 ICSTM32F401RBT6 IC STM32F401RBT6 LQFP-64 1

(U2)

3 LDVW1DE1BB7C3C3 Liquid-emitting Diode Red/Green/Blue SMD 4

LED1~LED4

3.2x2.8mm

3 RS000010J03 RES 0ȍ5% SMD 0603 3

R1,R11,R15

3 RS010K10F03 RES 10K 1% SMD 0603 10

R2,R20,R22,R25~R31

3 RS016210F03 RES 162ȍ1% SMD 0603 4

R4,R10,R17,R21

3 RS33R210F03 RES 33.2 1% SMD 0603 4

R8,R16,R19,R24

3 RS49R910F03 RES 49.9ȍ1% SMD 0603 5

R3,R5,R6,R9,R12

3 RS56R210F03 RES 56.2ȍ1% SMD 0603 4

R7,R14,R18,R23

3 SWDC11B20214A6 SWITCH ROTATIONAL ENCODE 20 PUDSE 1

ENC1

PUSH-ON SWITCH

3 TE622001201 Pin Header 90°Pitch:2.00mm Single Row 1

12P DIP

3 TE682000201 Pin Header 90°Pitch:2.0mm Single Row 4

J3,J4,J6,J7

2Pin SMD

3 TE682000501 Pin Header 90°Pitch:2.0mm Single Row 5 1

Pin SMD

3 TE962542001 Terminal 20P 2.54mm 1

3 UHBLM15AG102SN1 Inductor Bead 1000ȍ200mA 0402 3

FB1,FB2,FB3

3 VRR10301535 Potentiometer potary volume:10K 1B shaft 1

VR1

Length:15mm single unit

3 XTM08000X6F1 Crystal 8MHZ 49US SMD Fundamental 1

2 TWPC17A026B01 ADAPTER PCB Assembly 1

3 FCN1T0500802 FCN Top Contact ZIF SMD Pitch0.5mm 8P 1

3 TE682000602 Pin Header 90°Pitch:2.0mm Single Row 1

6Pin SMD

3 UHBLM18AG102SN1 BEAD 1000ȍ100MHZ 6

L1~L6

1 TWPC17A02701 REAR PANEL PCB Assembly 1

2 AL2-50-4149 Diode Single 1N4148 100V 200mA SOT-23 7

D9~D15

2 AL2-51-4401 Transistor 2N4401 NPN SOT-23 (Transistor 9

Q2,Q9,Q10,Q11,Q18,Q21,Q22,Q24,Q25

MMBT4401LT1 NPN SOT-23)

2 AL2-51-4403 Transistor 2N4403 PNP SOT-23 4

Q12,Q14,Q20,Q23

2 AL2-54-0138 Mosfet BSS138 N-CH SOT-23 1

Q15

2 AL2-61-7885 IC UA7805CKTTR Positive-Voltage 1

U11

Regulator TO-263

2 AL2-71-0072 IC TL072CDR Low-Noise Jfet-Input 1

Operational Amplifiers Soic-8

2 AL4-00-0002 MIDI Jack 8P 90°Female 2

J5,J6

2 CS100J5003NPO CCAP SMD 10pF/50V 5% 0603 NPO 1

C11

2 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 13

C45,C49,C58,C60,C61,C63,C65,C82,C87

C89,C90,C93,C94

2 CS101J5006NPO CCAP SMD 100PF/50V 5% 1206 NPO 5

C217,C218,C219,C220,C222

2 CS102J5003NPO CCAP SMD 1nF/50V 5% 0603 NPO 16

C10,C19,C27,C31,C44,C48,C70,C72,C91,C92

C105,C106,C115,C116,C203,C204

2 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 41

C5,C7,C9,C12,C13,C17,C23,C32,C35,C39

C46,C47,C50~C57,C64,C68,C73~C81

C84~C86,C121,C199~C202,C209,C210

2 CS106K1003X5R CCAP SMD 10uF 10% 10V 0603 X5R 4

C14,C15,C16,C37

2 CS106K2506X5R CCAP SMD 10UF/25 ±10% 1206 X5R 2

C40,C41

2 CS106K5006X5R CCAP SMD 10U/50V ±10% 1206X5R 5

C21,C24,C25,C26,C122

2 CS200J5003NPO CCAP SMD 20pF/50V 5% 0603 NPO 1

C33

2 CS220J5003NPO CCAP SMD 22pF/50V 5% 0603 NPO 1

2 CS221J5003NPO CCAP SMD 220pF/50V 5% 0603 NPO 3

C29,C59,C66

2 CS272J5003NPO CCAP SMD 2.7nF/50V 5% 0603 NPO 2

C62,C67

2 CS330J5003NPO CCAP SMD 33pF/50V 5% 0603 NPO 2

C109,C114

2 CS392J5005NPO CCAP SMD 3.9nF/50V 5% 0805 NPO 2

C102,C181

2 CS471J5003NPO CCAP SMD 470pF/50V 5% 0603 NPO 5

C100,C104,C112,C180,C184

2 CS474K1603X7R CCAP SMD 0.47uF/16V 10% 0603 X7R 2

C8,C30

2 CS475K5006X7R CCAP SMD 4.7uF/50V 10% 1206 X7R 1

C36

2 CS681J5003NPO CCAP SMD 680pF/50V 5% 0603 NPO 3

C1,C18,C20

2 DIBAV99 DIODE HIGH-SPEED DUAL BAV99 SOT-23 2

D7,D8

2 DIENMMBD4148CA Diode Single MMBD4148CA 100V 200mA SOT-2 1

D41

2 DIPHLTV-356T-B optical coupler Diode LTV-356T-B 1

2 DISDBAT54SSM Diode BAT54S 30V 0.2A SOT-23 6

D1~D4,D6,D18

2 DISDSS16T3G Schottky Diode SS16T3G 60V 1A SMA 2

D16,D17

2 DIZDSMA6J24CA Transient Voltage Suppressor Diode 2

D19,D20

SMA6J24CA

2 ECS10625B ECAP 10UF/25V 4*5.3MM SMD 5

C69,C71,C88,C103,C110

2 ECS22616C Capacitor Electrolytic 22uF/16V C type 2

C38,C42

SMD

2 ECS22625CLE ECAP 22UF/25V 5*5.3mm SMD Low ESR 9

C4,C6,C22,C28,C34,C83,C119,C120,C123

2 ECS33525BNP ECAP Non-Polar 3.3uF/25V 4*5.4mm SMD 1

2 ECS47725GLE ECAP LOWESR 470UF/25V 10*10MM SMD 2

C196,C198

2 FCN1T0502201 FCN DOWN Touch ZIF SMD pitch=0.5mm 22P 2

J2,J4

2 IC74AHC541PW IC 74AHC541PW Octal Buffer/Line driver 1

U15

3-state output TSSOP-20

2 IC74LVC2G17DBV IC74LVC2G17DBV SOT-23 1

2 ICAK4621EFP-E2 IC CODEC AK4621 2-IN 2-OUT 24-BIT 192KHZ 2

U1,U16

VSOP-30

2 ICLM317 IC LM317 1.5A SOT-223 1

U25

2 ICLMR23630 IC SWITCHING REGULATOR SMT HSOIC-8-PAD 2

U2,U5

2 ICMCP6002I-SN IC OPAMP MCP6002I/SN(S08) 1

2 ICNJM4580D INTEGRATED CIRCUIT 1

U23

2 ICNJM4580M IC NJM4580M DMP8 9

U10,U12~U14,U18~U21,U24

2 ICSN74LV4040APW IC SN74LV404APW TSOP16 1

2 JK6K6J60A06E3K 6.3ĳStero JACK 7P 90°DIP Female 1

2 JKJY-3536L 3.5ĳphone Jack 5pin 90° 1

J10

2 JKK6J80LAA12E2K TRS Jack 13P 90°Female Dual 4

J8,J12,J14,J20

2 MT11044128 Fixed Plate 3

M1,M2,M3

2 PC17A027 REAR PANEL PCB 4-Layer FR-4 1.6T 186*96 1

2 RS000008J05 RES 0ȍ5% SMD 0805 9

R65,R67,R70,R72,R76,R77,R102,R115,R123

2 RS000010J03 RES 0ȍ5% SMD 0603 4

R10,R12,R125,R127

2 RS001002F10 RES 10ȍ1% 1/2W SMD 1210 1

R122

2 RS001K08F05 RES 1K 1% SMD 0805 1

R87

2 RS001K10F03 RES 1K 1% SMD 0603 9

R37,R40,R92,R116,R142,R146,R147

R151,R180

2 RS001M10F03 RES 1M 1% SMD 0603 1

2 RS002K04F06 RES 2K 1% SMD 1206 4

R50,R148,R149,R153

2 RS010004F06 RES 100ȍ1% SMD 1206 7

R104,R225,R227,R229,R231,R232,R235

2 RS010010F03 RES 100ȍ1% SMD 0603 18

R2,R54,R56,R57,R59,R60,R61,R69,R81,R86

R94,R101,R113,R114,R118,R119,R120,R121

2 RS010K08F05 RES 10K 1% SMD 0805 1

R79

2 RS010K10F03 RES 10K 1% SMD 0603 29

R14,R16,R17,R21,R25,R28,R33,R45,R48,R49

R55,R58,R63,R64,R68,R71,R75,R85,R99,R133

R141,R143,R155,R157,R158,R159,R160

R240,R241

2 RS010M10F03 RES 10M 1% SMD 0603 1

2 RS015010F03 RES 150ȍ1% SMD 0603 4

R91,R96,R184,R189

2 RS022110F03 RES 221ȍ1% SMD 0603 3

R32,R36,R42

2 RS024010F03 RES 240ȍ1% SMD 0603 1

R124

2 RS034810F03 RES 348ȍ1% 1/10W SMD 0603 2

R130,R131

2 RS078710F03 RES 787ȍ1% SMD 0603 3

R128,R129,R132

2 RS07K510F03 RES 7.5K 1% SMD 0603 4

R23,R83,R98,R108

2 RS100K10F03 RES 100K 1% SMD 0603 11

R15,R34,R62,R66,R78,R107,R117,R144

R150,R156,R226

2 RS12K110F03 RES 12K1 1% SMD 0603 2

R103,R112

2 RS13K710F03 RES 13.7K 1% SMD 0603 2

R106,R110

2 RS15K810F03 RES 15.8K 1% SMD 0603 1

R38

2 RS1K0210F03 RES 1.02K 1% SMD 0603 2

R82,R97

2 RS22K110F03 RES 22.1K 1% SMD 0603 2

R19,R29

2 RS2K3210F03 RES 2.32K 1% SMD 0603 1

R43

2 RS2K4910F03 RES 2.49K 1% 1/10W SMD 0603 4

R31,R84,R90,R111

2 RS2K6108F05 RES 2.61K 1% SMD 0805 1

R126

2 RS309K10F03 RES 1K 309% SMD 0603 1

R73

2 RS33K210F03 RES 33.2K 1% SMD 0603 1

R39

2 RS3K0110F03 RES 3K01 1/10W SMD 1/10W 0603 2

R1,R8

2 RS3K1610F03 RES 3.16K 1% SMD 0603 2

R80,R93

2 RS3K3210F03 RES 3.32K 1% SMD 0603 9

R74,R88,R89,R95,R100,R178,R179,R188,R194

2 RS3K7410F03 RES 3.74K 1% SMD 0603 8

R3,R5,R9,R11,R22,R26,R47,R52

2 RS3K8310F03 RES 3.83K 1% SMD 0603 2

R105,R109

2 RS47K510F03 RES 47.5K 1% SMD 0603 1

R41

2 RS47R510F03 RES 47.5ȍ1% SMD 0603 3

R27,R30,R135

2 RS4K7510F03 RES 4.75K 1% SMD 0603 3

R20,R35,R46

2 RS4K9910F03 RES 4.99K 1% SMD 0603 4

R51,R140,R152,R154

2 RS51K110F03 RES 51.1K 1% SMD 0603 1

R18

2 RS82K510F03 RES 82.5K 1% SMD 0603 1

R44

2 RS90R910F03 RES 90.9ȍ1% SMD 0603 4

R4,R13,R24,R53

2 SRHFD3-3 Relay HFD 3/3 2

K1,K2

2 TE612000202 Terminal 2P 2.0 180° 1

2 TE612001201 Pin Header 180°Pitch:2.00mm Single Row 1

12P DIP

2 TR2SD2704 TRANSISTOR 2SD2704 SOT-23 9

Q1,Q5,Q6,Q7,Q8,Q13,Q16,Q17,Q19

2 TRFDS4435BZ MOSFET P-chann FDS4435BZ SOIC-8 30r 8.8 1

2 UHBLM15AG102SN1 Inductor Bead 1000ȍ200mA 0402 5

FB1~FB5

2 UHBLM18AG102SN1 BEAD 1000ȍ100MHZ 4

FB6~FB9

2 UHDRRI125-101M Inductor, 100UH±20% 1.3A SMD 1

2 UHMPSZ0630-4R7M Inductor 4.7UH 9A±20% 6.6x7.4x3mm SMD 1

2 UHPID1205-471K Inductor 470UH 0.83A±10% 12x12x6mm SMD 1

2 XTM245760E01 CRYSTAL OSCILLATOR 24.576MHZ SMD 7x5mm 1

1 WRUSB05200025W2 Isolation Cable USB2.0 5Pin Single Row 1

Pitch 2.0mm Length 250mm

REV 1.03

HG02

Gigboard Test Procedure

V1.03

REV 1.03

Materials Needed:

-(1) Expression Pedal

-(1) Latching Sustain footswitch pedal

-(1) 1/4” TS male to 1/4” TS male cable

-(1) 1/4” TRS male to 1/4” TRS male cable

-(1) 1/4” TRS Y male to 2x RCA male cables

-(1) RCA female to 1/4” male TS adapter

-(1) 1/8” TRS male to 1/8” TRS male cable

-CD player/mp3 player and test music

-(2) Studio monitors

-(1) 1/4” TRS male to 1/8” TRS female adapter

-(1) 1/8” TRS male to RCA Y female adapter

-(1) RCA cable

-(1) RCA female to 1/4” TS adapter

Test App Notes:

-The tests should be followed in order.

-Most tests have instructions at the top of their page. Any tests that do not have instructions are

detailed in this document.

REV 1.03

Switch

TEST

Press each button and footswitch one at a time

REV 1.03

Encoder

TEST

Rotate the large Encoder slowly first in a clockwise direction, then once the arrow has changed direction,

rotate the encoder counter clockwise

Other manuals for Gigboard

Table of contents

Other HEADRUSH Recording Equipment manuals

HEADRUSH

HEADRUSH Gigboard User manual

HEADRUSH

HEADRUSH Looperboard User manual

HEADRUSH

HEADRUSH PRIME User manual

HEADRUSH

HEADRUSH Looperboard User manual

Popular Recording Equipment manuals by other brands

TIR

TIR ControlFX Director quick start guide

Bticino

Bticino 323008 quick start guide

Flame

Flame MIDI TALKING SYNTH user manual

Warm Audio

Warm Audio BUS-COMP manual

Art

Art SGX LT manual

Yaesu

Yaesu FAS-I-4R manual

Roland

Roland R-07 owner's manual

Anybus

Anybus CompactCom B40 Network guide

Akai

Akai S950 Service manual

Sony

Sony BDX-N1000 Operation manual

Steinberg

Steinberg CI2 Benutzerhandbuch

Peak

Peak PCAN-USB Hub user manual

Vestax

Vestax TR-1 Service manual

mikroElektronika

mikroElektronika 4-20mA R click quick start guide

Car-Interface.com

Car-Interface.com CI-VL2-N902 manual

Midas

Midas DL251 Operator's manual

Merging

Merging ramses msc arc installation guide

Lexicon

Lexicon Lambda owner's manual
