HealthyAir Source Capture HA-SCV-G1-WS User manual

Source Capture®Vent
Single Inlet
Owner’s Manual: HA-SCV-G1-WS
Patent Pending
Healthy Air Inc.
800-259-2535
www.HealthyAir.com

HealthyAir®
Model HA-SCV-G1-WS
Source Capture®Vent
Single Inlet
Patent Pending
Table of Contents
Installation Notice
1
Technical Specifications
1
Packaging Reference
2
Component Reference
3
Installation Instructions
4-12
Operation Guidelines
13
Maintenance
14
1-Yeart Limited Warranty
15
Product Registration Form
16
www.HealthyAir.com

1
I. Installation Notice
Read the Owner's Manual and Installation Instructions carefully.
Failure to follow these instructions could cause a malfunction of the
vent or unsatisfactory performance. Follow a regular service and
maintenance schedule for efficient operation.
For safety reasons, unplug the power cord from the electric outlet
socket under the following conditions:
When not in use for a long period of time
When cleaning
When moving the air purifier
II. Technical Specifications
Model Number
HA-SVC-G1-WS
Rated Voltage
12V DC
Power
Consumption
3W
Weight
3 lbs. (1.4 kg)
Base
Dimensions
8”x2”x6”
(200x50x150 mm)

2
III. Packaging Reference
The Source Capture Vent is shipped in one (1) package that contains
the following contents:
Source Capture Vent –Single Unit
Power Adapter
Cover Plate (optional)
Flange (optional)

3
IV. Component Reference
1. Inlet Vent
2. Light Switch
3. Pop-Up Knob
4. LED Light
5. Outlet Port
6. Power Socket
7. Access Cover
8. Mounting Bracket
9. Housing

4
V. Installation Instructions
5.1 To mount the Source Capture®Vent, cut an opening in table-top or
preferred mounting surface. The dimensions of the cut-out are
8-3/8” x 2-1/2”, as shown in Fig. 1.
Fig. 1 - Cut-Out Dimensions
5.2 To flush-mount the vent, such that the top of the unit is flush with
the table top or surface, produce a 3/16” rebate around the
perimeter of the cut-out, as shown in Fig. 2.
Fig. 2 –Rebate for Flush-Mount

5
V. Installation Instructions
5.3 Unscrew the two (2) Thumb Screws to remove the two (2)
Mounting Brackets from the unit, as shown in Fig. 3.
Fig. 3 –Remove Mounting Brackets
5.4 Remove the Access Cover from bottom of the Source Capture®
Vent, as shown in Fig. 4.
Fig. 4 –Remove Access Cover

6
V. Installation Instructions
5.5 Install the Source Capture®Vent in the table by inserting it into the
cut-out, as shown in Fig. 5.
Fig. 5 –Install Source Capture®Vent
5.6 Reattach the two (2) Mounting Brackets to the unit by screwing in
the Thumb Screws, as shown in Fig. 6.
Fig. 6 –Reattach Mounting Brackets

7
V. Installation Instructions
5.7 Slide the Mounting Brackets up against the bottom of the table.
Then tighten the Thumb Screws to secure the Mounting Brackets,
as shown in Fig. 7.
Fig. 7 –Secure Mounting Brackets
5.8 The Source Capture®Vent should now be firmly installed in the
table or mounting surface
Fig. 8 –Source Capture®Vent Installed

8
V. Installation Instructions
5.9 Push the Pop-Up Knob down to release it, as shown in Fig. 9.
Fig. 9 –Release Pop-up Knob
5.10 Grab the Pop-Up Knob and pull it straight up to pull the Inlet Vent
from the Housing component. Pull the Inlet Vent up as far as it
goes, such that it is in the active position as shown in Fig. 10.
Fig. 10 –Inlet Vent in Active Position

9
V. Installation Instructions
5.11 Remove the Access Cover, which is secured by two magnets,
from the bottom of the unit. There are two (2) Outlet Ports on the
unit, with one on each side of the Housing. Generally, one shall
be blanked-off and the other used for connection with a duct to
the HealthyAir®Air Purification System. Install the Blank-Off Plate
on one side and the Outlet Flange on the other side, by passing
them thru the opening at the bottom of the Housing, as shown in
Fig. 11.1, and mounting them on the (4) Stud Screws,
respectively. Using the Hex Nuts, tighten and secure the Outlet
Flange and the Blank-Off Plate. Finally, reinstall the Access
Cover.
Note that, there are four types of Outlet Flanges available; a
Single Circular Outlet Flange, Dual Circular Outlet Flange
Oval Outlet Flange, and Rectangular Outlet Flange.
Fig. 11.1 –Installation of Blank-Off Plate and Outlet Flange

10
V. Installation Instructions
Fig. 11.2 –Outlet Flange Options
5.12 Duct the outlet of the Source Capture®Vent to the inlet of the
HealthyAir®Air Purification System, as shown in Fig. 12.
Note that, the HealthyAir®Air Purification System can either
be located near the table or in a remote location, and the duct
geometry and size will naturally vary depending on the type of
Outlet Flange utilized and the required duct length.
Fig. 12 –Duct Connection to HealthyAir®Unit

11
V. Installation Instructions
5.13 Plug the Power Adaptor into the Power Socket, located on the
bottom of the unit, to power the LED light.
Fig. 13 –Plug-in Power Cord
If the Source Capture®Vent is directly installed on the
HealthyAir®System, as shown in Fig. 13.2, the LED Cord
located in the Housing can be directly plugged into the LED
Cord located in the inlet of the HealthyAir®System.
Installation with HealthyAir®Ceiling Mount System: Note that, the
Source Capture®Vent may also be integrated with the
HealthyAir®Ceiling Mount Source Capture System, as shown
in Fig. 14. Contact Healthy Air Inc. for additional information
for custom installations.

12
V. Installation Instructions
Fig. 13.2 –Connect LED Cord to LED Cord in HealthyAir®System
Fig 14 –Connection to HealthyAir®Ceiling Mount System

13
VI. Operation Guidelines
Optimal Effectiveness
For optimal effectiveness all work that generates fine particulate
and fumes should be performed within 12”, and preferably 6”, of
the inlet of the Source Capture®Vent.
Activation of Source Capture®Vent
6.1 Plug the Power Cord into the Power Socket, located on the
bottom of the side panel of the unit, and then plug the other
end of the cord into a wall power socket.
6.2 To position the Source Capture®Vent in the active-state,
simply push the spring-loaded Pop-up Knob located on the top
panel of the unit, grab the knob, and pull the knob straight up to
pull the Inlet Vent from the Housing Component.
6.3 Turn the LED light on by pressing the On/Off Switch located on
the face on the Inlet Vent.
6.4 Power on the HealthyAir®Air Purification System to generate
airflow and activate the Source Capture®Vent.

14
VII. Maintenance
Cleaning Source Capture®Vent Housing
Once a month inspect the Housing for particulate accumulation. To
do so, first unplug the PowerAdaptor from the power socket and
then place a waste container below the Access Cover to catch any
dust that drops down after the Access Cover is removed.
Once the Access Cover is removed, empty the Housing of all
debris. A vacuum cleaner may be used to suck all the dust out of
the Housing.
After the Housing have been satisfactorily cleaned, replace the
Access Cover and plug the Power Adaptor into the power socket.
The unit is then ready for operation.

15
Healthy Air Inc. 1-Year Limited Warranty
Healthy Air Inc. only makes this 1-Year Limited Warranty ("Limited
Warranty") to the original retail purchaser who submits the enclosed
Warranty Registration Card within 10 days of purchase by email to
[e-mail].
This Limited Warranty applies only to the repair or replacement of any
manufactured or supplied part of this product which, upon inspection by
Healthy Air Inc. authorized personnel, proves to have failed in normal use
due to defects in material or workmanship.
The sole responsibility of Healthy Air Inc. under this Limited Warranty is,
in its sole discretion, to either repair or replace a duly registered product
(or defective part thereof) with the same or a comparable model within a
reasonable period of time, subject to the following exclusions, limitations,
statutory rights and warranty claim procedures.
This Limited Warranty is exclusive, and Healthy Air Inc. expressly
disclaims all other or additional warranties, whether written or oral,
expressed or implied, including, but not limited to, warranties of
merchantability, workmanship, or fitness for a particulate purpose.
Retain proof of purchase and the original box and packing materials.
Exclusions to the Warranty
This Limited Warranty does not apply, or is void, as to any product or part
damaged by (1) accident, misuse, abuse, or lack of reasonable care or
normal maintenance; (2) installation or operation under conditions other
than those recommended by Healthy Air Inc.; (3) subjecting the product to
any but the specified voltage; (4) servicing or disassembly by
unauthorized personnel; (5) removing or defacing the serial number; or (6)
modifying the original factory-assembled unit in any way.
This Limited Warranty does not apply to shipping charges for product
shipped to or from the manufacturer or designated distributor in
connection with warranty claims nor does it apply to any damages that
occur during such shipment.
This Limited Warranty does not apply to installation, removal,
reinstallation, and/or related expenses. This Limited Warranty does not
apply to replacement filters.

16
Healthy Air Inc.
1-Year Limited Warranty
Product Registration Form
Please complete the Product Registration Form and submit it to
Healthy Air Inc. within ten (10) days of the original purchase, to
validate 1-Year Limited Warranty.
Submit the completed form via email by sending a scanned image or
photograph to [e-mail].
Note that, the Model Number and Serial Number are written on the
sticker located at the bottom of the side panel of the unit.
Please contact us at [phone] or visit www.HealthyAir.com for
Customer Service and Orders.
