Heat & Glo Heat&Glo RUTHERFORD-36 User manual

1
Owner’s Manual
Installation and Operation
DO NOT DISCARD THIS MANUAL
NOTICE
• Important operating
and maintenance
instructions included.
• Leave this manual with
party responsible for
use and operation.
• Read, understand
and follow these
instructions for safe
installation and
operation.
DO NOT
DISCARD
Installation and service of this fireplace
should be performed by qualified personnel.
Hearth & Home Technologies suggests NFI
certified or factory-trained professionals, or
technicians supervised by an
NFI certified professional.
Fire Risk
• For use with solid wood fuel or decorative
gas appliance only.
• Do not install unvented gas logs.
WARNING
If the information in these instruc-
tions is not followed exactly, a
fire may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of
this or any other appliance.
• Do not overfire. Overfiring will void your
warranty.
• Comply with all minimum clearances to
combustibles as specified. Failure to
comply may cause house fire.
WARNING WARNING
Hot screen/mesh and glass doors will cause burns.
• Do not touch screen/mesh or glass doors until cooled
• NEVER allow children to touch screen/mesh or glass
doors
• Keep children away
• CAREFULLY SUPERVISE children in same room as
fireplace.
• Alert children and adults to hazards of high
temperatures.
High temperatures may ignite clothing or other flammable
materials.
• Keep clothing, furniture, draperies and other flammable
materials away.
HOT SURFACES!
Screen/mesh, glass doors and
other surfaces are hot during
operation AND cool down.
Heat & Glo • RUTHERFORD-36 • 4059-341 Rev D • 03/09
Models:
RUTHERFORD-36
Wood Burning Fireplace

2
Read this manual before installing or operating this fireplace.
Please retain this owner’s manual for future reference.
Homeowner Reference Information
Model Name: Date purchased/installed:
Serial Number: Location on fireplace:
Dealership purchased from: Dealer phone:
Notes:
We recommend that you record the following pertinent
information about your fireplace:
Listing Label Information/Location
The model information regarding your specific fireplace can be found on the rating plate located on the smoke shield of
the fireplace.
Congratulations!
FIREPLACE NO.
MODEL NO.
MODEL NO.
MFG. DATE
WARNING: RISK OF
FIRE DAMAGE. REPLACE
GRATE WITH HEARTH & HOME
TECHNOLOGIES INC.
FIRECHAMBER INTENDED FOR USE WITH HEARTH & HOME TECHNOLOGIES INC. LISTED FIREPLACE PARTS. SEE INSTALLATION AND
OPERATING INSTRUCTIONS FOR THIS MODEL. ONLY HEARTH & HOME TECHNOLOGIES INC. GLASS DOOR KITS CAN BE INSTALLED ON THIS UNIT.
FIREPLACE ALSO FOR USE
IN MANUFACTURED HOMES
YES NO
CLEARANCE TO
COMBUSTIBLES:
CHIMNEY
2 IN. MIN.
FIREBOX
IN.
MIN.
FAN KIT
MODEL NO.
&RATED AT
115 VOLTS, 50/60 Hz., AMP.
DO NOT OVERFIRE. USE ONLY: SOLID WOOD FUEL OR
LISTED DECORATIVE GAS APPLIANCE. DO NOT USE A
FIREPLACE INSERT OR OTHER PRODUCTS NOT
SPECIFIED FOR USE WITH THIS PRODUCT. IF DOORS
ARE USED OPERATE FIREPLACE WITH DOORS FULLY
OPEN OR CLOSED ONLY. WHEN BURNING A
DECORATIVE GAS APPLIANCE IN THE FIREPLACE,
ADJUST DAMPER TO THE FULLY OPEN POSITION.
WARNING! THIS FIREPLACE HAS NOT BEEN TESTED WITH AN UNVENTED
GAS LOG SET. TO REDUCE THE RISK OF FIRE OR INJURY, DO NOT
INSTALL AN UNVENTED GAS LOG SET INTO FIREPLACE.
WARNING! THIS APPLIANCE IS NOT FOR USE AS COOKING EQUIPMENT.
IF INSTALLATION OR OPERATING INSTRUCTIONS ARE MISSING
CONTACT: HEARTH & HOME TECHNOLOGIES INC.,
1915 W. SAUNDERS ST., MT. PLEASANT, IA 52641.
Grate Fireplace
Model
Serial
Number
Heat & Glo • RUTHERFORD-36 • 4059-341 Rev D • 03/09
Congratulations on selecting a Heat & Glo wood burning
fireplace. The Heat & Glo fireplace you have selected is
designed to provide the utmost in safety, reliability and ef-
ficiency.
As the owner of a new fireplace, you’ll want to read and
carefully follow all of the instructions contained in this
owner’s manual. Pay special attention to all cautions and
warnings.
This owner’s manual should be retained for future refer-
ence. We suggest you keep it with your other important
documents and product manuals.
The information contained in this owner’s manual unless
noted otherwise, applies to all models and gas control
systems.
Your new Heat & Glo wood burning fireplace will give you
years of durable use and trouble-free enjoyment. Welcome
to the Heat & Glo family of fireplace products!

3
Safety Alert Key:
• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury.
• CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
• NOTICE: Indicates practices which may cause damage to the fireplace or to property.
!
Table of Contents
1 Listing and Code Approvals
A. Appliance Certification. . . . . . . . . . . . . . . . . . . . . . . . . 5
B. Non-Combustible Materials . . . . . . . . . . . . . . . . . . . . . 5
C. Combustible Materials. . . . . . . . . . . . . . . . . . . . . . . . . 5
2 Operating Instructions
A. Your Fireplace . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
B. Seasoned Wood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
C. Starting a Fire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
D. Grate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
E. Firescreen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
F. Flue Damper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
G. Outside Air. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
H. Molded Brick Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
I. Glass Doors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
J. Vented Gas Log Sets & Gas Log Lighters. . . . . . . . . . 8
K. Optional Components . . . . . . . . . . . . . . . . . . . . . . . . . 8
L. Clear Space. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
M. Wood Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3 Maintainance and Service
A. Disposal of Ashes . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
B. Chimney Inspection/Cleaning . . . . . . . . . . . . . . . . . . 10
C. Check Firebox Molded Brick Panel . . . . . . . . . . . . . . 11
D. Inspect Grate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
E. Glass Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4 Troubleshooting Guide
5 Getting Started
A. Typical Fireplace System. . . . . . . . . . . . . . . . . . . . . . 13
B. Design and Installation Considerations . . . . . . . . . . . 14
C. Draft. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
D. Negative Pressure. . . . . . . . . . . . . . . . . . . . . . . . . . . 14
E. Locating your Fireplace & Chimney. . . . . . . . . . . . . . 15
F. Tools and Supplies Needed. . . . . . . . . . . . . . . . . . . . 16
G. Typical Fireplace Components . . . . . . . . . . . . . . . . . 16
H. Inspect Fireplace and Components. . . . . . . . . . . . . . 16
6 Framing & Clearances
A. Select Fireplace Location . . . . . . . . . . . . . . . . . . . . . 17
B. Clearances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
C. Sidewalls/Surrounds . . . . . . . . . . . . . . . . . . . . . . . . . 19
D. Frame the Fireplace . . . . . . . . . . . . . . . . . . . . . . . . . 19
7 Installation of Fireplace
A. Things to Consider . . . . . . . . . . . . . . . . . . . . . . . . . . 20
B. Position the Fireplace . . . . . . . . . . . . . . . . . . . . . . . . 20
C. Place Protective Metal Hearth Strips. . . . . . . . . . . . . 20
D. Level Fireplace . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
E. Install Outside Air Kit . . . . . . . . . . . . . . . . . . . . . . . . . 22
8 Chimney Assembly
A. Chimney Requirements. . . . . . . . . . . . . . . . . . . . . . . 24
B. Using Offsets/Returns . . . . . . . . . . . . . . . . . . . . . . . . 25
C. Assemble Chimney Sections. . . . . . . . . . . . . . . . . . . 26
D. Install Ceiling Firestops . . . . . . . . . . . . . . . . . . . . . . . 27
E. Install Attic Insulation Shield . . . . . . . . . . . . . . . . . . . 28
F. Cut Out Hole in Roof . . . . . . . . . . . . . . . . . . . . . . . . . 29
G. Complete Installation. . . . . . . . . . . . . . . . . . . . . . . . . 29
H. Install Flashing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
I. Chimney Termination Requirements . . . . . . . . . . . . . 30
9 Chase Installations
A. Construct the Chase . . . . . . . . . . . . . . . . . . . . . . . . . 31
B. Install Fireplace & Chimney. . . . . . . . . . . . . . . . . . . . 32
C. Install Chase Top . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
D. Install Termination Cap . . . . . . . . . . . . . . . . . . . . . . . 33
10 Shrouds
A. Radiation Shield . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
B. Field Constructed Shrouds . . . . . . . . . . . . . . . . . . . . 35
11 Installation of Molded Brick Panel
A. Install Hearth Molded Brick Panel . . . . . . . . . . . . . . . 37
B. Install Side Molded Brick Panel/Traditional . . . . . . . . 37
C. Install Back Molded Brick Panel/Traditional . . . . . . . 37
D. Install Side Molded Brick Panel - Herringbone . . . . . 38
E. Install Back Molded Brick Panel - Herringbone . . . . . 38
F. Install Mortar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
G. Install Screens. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
12 Finishing
A. Non-Combustible Materials . . . . . . . . . . . . . . . . . . . . 40
B. Combustible Materials. . . . . . . . . . . . . . . . . . . . . . . . 40
C. Hearth Extension. . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
D. Finishing Material . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
E. Combustible Mantel . . . . . . . . . . . . . . . . . . . . . . . . . 44
F. Mantel, Adding Extra Support . . . . . . . . . . . . . . . . . . 45
G. Sidewalls/Surrounds . . . . . . . . . . . . . . . . . . . . . . . . . 46
13 Accessories
A. Gas Log/Lighter Provision . . . . . . . . . . . . . . . . . . . . . 47
B. Wood Burning Inserts . . . . . . . . . . . . . . . . . . . . . . . . 47
14 Reference Materials
A. Fireplace Dimensions . . . . . . . . . . . . . . . . . . . . . . . . 48
B. Optional Components . . . . . . . . . . . . . . . . . . . . . . . . 49
C. Chimney Components. . . . . . . . . . . . . . . . . . . . . . . . 50
D. Service Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
E. Contact Information . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Note: An arrow ( ) found in the text signifies change in content.
Î
Heat & Glo • RUTHERFORD-36 • 4059-341 Rev D • 03/09

4
Warranty
Heat & Glo • RUTHERFORD-36 • 4059-341 Rev D • 03/09

5
Heat & Glo • RUTHERFORD-36 • 4059-341 Rev D • 03/09

6
1
1 Listing and Code Approvals
Notice: This fireplace is tested and approved as a decorative
fireplace. It should not be factored as a primary heat source
in residential heating calculations.
WARNING! Risk of Fire! Hearth & Home Technologies
disclaims any responsibility for, and the warranty and
agency listing will be voided by the actions below.
DO NOT:
• install or operate damaged fireplace
• modify fireplace
• install other than as instructed by Hearth & Home
Technologies
• operate the fireplace without fully assembling all
components
• overfire
• install an unvented gas log set
• install any component not approved by Hearth &
Home Technologies
• install parts or components not Listed or approved
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage.
For assistance or additional information, consult a qualified
installer, service agency or your dealer.
B. Non-Combustible Materials
• Materials which will not ignite and burn, composed of any
combination of the following:
- Steel - Iron
- Brick - Tile
- Concrete - Slate
- Glass - Plasters
• Materials reported as passing ASTM E 136, Standard
Test Method for Behavior of Metals, in a Vertical Tube
Furnace at 750° C
C. Combustible Materials
• Materials made of or surfaced with any of the following
materials:
- Wood - Compressed paper
- Plant fibers - Plastic
• Any material that can ignite and burn; flame proofed or
not, plastered or un-plastered
Heat & Glo • RUTHERFORD-36 • 4059-341 Rev D • 03/09
A. Appliance Certification
This fireplace system has been tested and listed in accor-
dance with UL 127 standards by Underwriters Laboratories
Inc. for installation and operation in the United States.
This fireplace may be installed in sleeping rooms EXCEPT
in manufactured homes. If installed with a gas log set, pro-
visions for the National Fuel Gas Code must be met.
This fireplace has been tested and listed for use with
the optional components specified in this manual. These
optional components may be purchased separately and
installed at a later date. Installation of an outside air kit will
require significant reconstruction and is best if installed at
the time of fireplace installation.
Heat & Glo is a registered trademark of Hearth & Home
Technologies Inc.

7
2
2 Operating Instructions
WARNING! DO NOT operate fireplace before reading and understanding operating instructions. Failure to operate fireplace
according to operating instructions could cause fire or injury.
User Guide
WARNING
Hot screen/mesh and glass doors will cause burns.
• Do not touch screen/mesh or glass doors until cooled
• NEVER allow children to touch screen/mesh or glass doors
• Keep children away
• CAREFULLY SUPERVISE children in same room as fireplace.
• Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other flammable materials.
• Keep clothing, furniture, draperies and other flammable materials away.
HOT SURFACES!
Screen/mesh, glass doors and other surfaces are hot during operation AND cool down.
Gas Log Set
Gas Log Lighters
(not shown)
Section 2.J.
Firescreen
(not shown)
Section 2.E.
Glass Doors
(not shown)
Section 2.I.
Grate
Section 2.D.
Molded Brick Panels
Section 2.H.
Outside Air Control Handles
Section 2.G.
Turn handle to unlock,
pull towards the inside
of the fireplace to open.
Reverse steps to close & lock.
Flue Damper
Section 2.F.
UP to Open
DOWN to Close
Hearth
Clear Space
Section 2.L.
Wood Fuel
Section 2.M.
Mantel
Figure 2.1 General Operating Parts
A. Your Fireplace
If you expect that children may come into contact with this fireplace, we recommend a barrier such as a decorative
screen. See your dealer for suggestions.
Heat & Glo • RUTHERFORD-36 • 4059-341 Rev D • 03/09

8
D. Grate
This fireplace is designed to be used with the grate sup-
plied with this unit or one approved by HHT. The grate will
deteriorate over time and will need occasional replacement.
WARNING! Risk of Fire! Use only the factory-supplied
integral grate.
• Keeps logs in place.
• Allows proper air circulation around the fire.
E. Firescreen
The firescreen is provided to control sparks. Keep it closed
when the fireplace is in use.
WARNING! Risk of Fire or Burns!
• Screen will not prevent burning materials from falling
out.
• Screen pulls or handles may be hot.
F. Flue Damper
• Refer to Figure 2.1 for location of control.
• Must be in fully open position (handle up toward the top
of the fireplace) during operation of the fireplace.
• Before lighting the fireplace, verify fully open position by
looking up from the inside of the fireplace.
WARNING! Risk of Fire and Asphyxiation! Open
damper prior to operating fireplace. A closed damper
overfires the fireplace and will cause smoke and flames
to spill into the room.
H. Molded Brick Panel
• The molded brick panel is shipped separately, but required
to contain heat and provide an attractive interior.
• It will deteriorate over time and will need occasional
replacement. Small hairline cracks and discoloration are
normal and do not affect its safety.
• Cracks in the mortar may occur and do not affect the
safety of the unit. If mortar falls out of the joints and metal
is exposed, replace or patch the mortar.
• (See Molded Brick Panel Maintenance, Section 3.C.)
WARNING! Risk of Fire! DO NOT burn fireplace without
molded brick panel. Use only molded brick panel supplied
by Hearth & Home Technologies, Inc.
• The first three or four fires should be of moderate size to
allow the oils and binders to be burned from the fireplace
and molded brick panel, and paint to cure. You may notice
an industrial odor the first few fires. This is considered
normal.
• Use well-seasoned wood (see Section 2.M.).
• Open the flue damper to a fully open position.
• Open outside air.
• Place crumpled or twisted paper under the fireplace
grate.
• Loosely arrange kindling or small pieces of wood to form
a ‘tent’ on the fireplace grate.
• Pre-warm the flue to establish a draft to help reduce smoke
spillage during start-up. Hold a rolled up piece of burning
newspaper under the flue damper for a few moments.
• Light the crumpled paper to ignite the kindling.
• Add small pieces of wood until a hot bed of embers has
been established.
• Add a minimum of three average size pieces of split
firewood, placed to allow combustion air and flames
between them.
C. Starting a Fire
NOTICE: You must establish a good draft to prevent smoke
spillage into the room.
WARNING! Risk of Fire! Keep combustible materials,
gasoline and other flammable vapors and liquids clear of
the fireplace.
DO NOT:
• store flammable materials close to the fireplace
• use gasoline, lantern fuel, kerosene, charcoal lighter
fluid or similar liquids to start or “freshen up” a fire in
this fireplace.
Keep all flammable liquids well away from the fireplace while
it is in use. Combustible materials may ignite.
B. Seasoned Wood
Properly seasoned wood is important for successful opera-
tion of your fireplace. Most woodburning fireplace problems
are caused by burning wet, unseasoned wood.
Seasoned firewood is wood that is cut to size, split and air
dried to a moisture content of around 20%.
Imagine a wooden bucket that weighs about eight pounds.
Fill it with a gallon of water, put it in the fireplace and try to
burn it. This sounds ridiculous but that is exactly what you
are doing if you burn unseasoned wood.
A tree cut down a year ago and not split is likely to have
almost as high a moisture content now as it did when it was
cut.
Please refer to Section 2.M. for more detail.
CAUTION! Odors and vapors released during initial op-
eration may be irritating to sensitive individuals. Open
windows for air circulation.
G. Outside Air
• Refer to Figure 2.1 for location of controls.
• Outside air doors should be in the fully opened position
during operation of the fireplace.
• Before lighting the fireplace, turn both handles & pull out
to open. Reverse steps to close and lock.
NOTICE: Do not substitute for HHT mortar. Other materials
may stain the molded brick panels.
Heat & Glo • RUTHERFORD-36 • 4059-341 Rev D • 03/09

9
WARNING! Risk of Fire and Smoke! Fireplaces equipped
with doors should be operated only with doors fully open
or doors fully closed. If doors are left partly open, gas and
flame may be drawn out of the fireplace opening.
FULLY OPEN
CORRECT
PARTLY CLOSED
INCORRECT
PARTLY OPEN
INCORRECT
FULLY CLOSED
CORRECT
Figure 2.2 Operating Positions of Bi-fold Doors
WARNING! Risk of Fire! Install ONLY doors approved by
Hearth & Home Technologies, Inc.
• Glass and screen doors are optional.
• Refer to Figure 2.2 for proper use.
I. Glass Doors J. Vented Gas Log Sets & Gas Log Lighters
• Optional
• Vented gas logs or gas log lighters can be installed in
this fireplace. Follow the instructions provided with the
accessory for operation.
K. Optional Components
• Other options may be available
• Consult your dealer/distributor
L. Clear Space
WARNING! DO NOT place combustible objects in front of
the fireplace. High temperatures may ignite clothing, furni-
ture or draperies.
• DO NOT place combustible objects within 48 in. (121.9 cm)
of the front of fireplace. See Figure 2.3.
• Mantel - avoid placing candles and other heat-sensitive
objects on mantel or hearth. Heat may damage these
objects.
24 in. (61.0 cm)
Clear Space
Sides of Fireplace Opening
48 in. (121.9 cm)
Clear Space
Front of Fireplace
Figure 2.3 Clear Space
WARNING! Risk of Fire or Asphyxiation!
• DO NOT install unvented gas logs.
• Damper must be locked open.
• Gas flame may generate fumes.
WARNING! Risk of Fire! DO NOT install and or use any
component not approved by Hearth & Home Technolo-
gies Inc.
Heat & Glo • RUTHERFORD-36 • 4059-341 Rev D • 03/09

10
M. Wood Fuel
Hardwood vs Softwood
Your fireplace performance depends on the quality of the
firewood you use.
• Seasoned wood contains about 8,000 BTUs per pound .
• Hard woods are more dense than soft woods.
• Hard woods contain 60% more BTUs than soft woods.
• Hard woods require more time to season, burn slower and
are harder to ignite.
• Soft woods require less time to dry, burn faster and are
easier to ignite.
• Start the fire with soft wood to bring the fireplace up to
operating temperature and to establish draft.
• Add hard wood for slow, even heat and longer burn
time.
The majority of the problems fireplace owners experience
are caused by trying to burn wet, unseasoned wood.
• Wet, unseasoned wood requires energy to evaporate the
water instead of heating your home, and
• Evaporating moisture cools your chimney, accelerating
formation of creosote.
WARNING! Risk of Fire!
• DO NOT burn wet or green wood.
• Wet, unseasoned wood can cause accumulation of
creosote.
Moisture
Storing Wood
Steps to ensure properly seasoned wood:
• Stack wood to allow air to circulate freely around and
through woodpile.
• Elevate wood pile off ground to allow air circulation
underneath.
• Smaller pieces of wood dry faster. Any piece over 6 in.
(152 mm) in diameter should be split.
• Wood (whole or split) should be stacked so both ends of
each peice are exposed to air. More drying occurs through
the cut ends than the sides.
• Store wood under cover to prevent water absorbtion
from rain or snow. Avoid covering the sides and ends
completely.
Seasoned Wood
• Cut logs to size
• Split to 6 in. (152 mm) or less
• Air dry to a moisture content of around 20%
- Soft wood - about nine months
- Hard wood - about eighteen months
NOTICE: Seasoning time may vary depending on drying
conditions.
WARNING! Fire Risk! DO NOT store wood:
• in front of the fireplace.
• in space required for loading or ash removal.
Soft woods Hard woods
• Douglas Fir • Oak
• Pine • Maple
• Spruce • Apple
• Cedar • Birch
• Poplar
• Aspen
• Alder
Processed Solid Fuel Firelogs
Manufactured firelogs may be used with this fireplace.
Hearth & Home Technologies Inc. recommends the use of
UL Classified processed fuel firelogs. Follow the manufac-
turer’s lighting and safety instructions.
Using firelogs may require more frequent chimney inspec-
tion and cleaning.
Do not poke or stir the logs while they are burning. Use
only firelogs that have been evaluated for the application in
manufactured fireplaces and refer to firelog warnings and
caution markings on packaging prior to use.
Heat & Glo • RUTHERFORD-36 • 4059-341 Rev D • 03/09

11
3
3 Maintainance and Service
A. Disposal of Ashes
Frequency: When they reach bottom of grate
By: Homeowner
B. Chimney Inspection/Cleaning
Frequency: At least twice a year during heating season or
as recommended by a certified chimney sweep
By: Certified chimney sweep
Figure 3.1 Chimney & Termination Cap Cleaning
WARNING! Risk of Fire! Ashes could contain hot embers.
• Place ashes in a metal container with a tight-fitting lid.
• The closed container should be placed on a non-
combustible floor or on the ground, well away from all
combustible materials, pending final disposal.
• If the ashes are disposed of by burial in soil or otherwise
locally dispersed, they should be retained in the closed
container until all cinders have thoroughly cooled.
WARNING! Risk of Fire! Ignited creosote is extremely
HOT. Prevent creosote buildup.
Refer to Figure 3.1 to remove/reinstall termination caps.
Creosote - Formation and Need for Removal
When wood is burned slowly, it produces tar and other
organic vapors, which combine with expelled moisture to
form creosote. The creosote vapors condense in the rela-
tively cool chimney flue of a slow-burning fire. As a result,
creosote residue accumulates on the flue lining. When
ignited this creosote makes an extremely hot fire.
WARNING! Risk of Fire! A chimney fire can permanently
damage your chimney system and nearby structures.
In the event of a chimney fire, Hearth & Home Technolo-
gies Inc. recommends
• replacement of the chimney, and
• inspection of the adjacent structure to the provisions of
NFPA Level III inspection criteria
The chimney shall be inspected at least twice a year during
the heating season to determine when a creosote buildup
has occurred.
When creosote has accumulated it shall be removed to
reduce the risk of a chimney fire.
Heat & Glo • RUTHERFORD-36 • 4059-341 Rev D • 03/09
Chimney
Remove 4 screws
and lift top pan off.
Cap
Slip
Section
ST1175
Square Termination Cap
Cap
Remove screws,
lift top cover. Top Cover
TR11/TR11T/TR11-TV
Round Termination Cap TCT1175
Terra Cotta
Termination Cap
Remove 2 screws from
the front and back and
lift the top off.

12
C. Check Firebox Molded Brick Panel
Frequency: After each ash removal
By: Homeowner
D. Inspect Grate
Frequency: After each ash removal
By: Homeowner
Inspect grate for:
• Warping or sagging 1-1/2 in. (38 mm) or more
• Broken welds
• Burn-through of grate bars
For safe operation, replace only with the approved grate
from Hearth & Homes Technologies Inc.
WARNING! Risk of Fire! Inspect fireplace molded brick
panel. Crumbling, deteriorated molded brick panel can al-
low overheating of surrounding materials.
E. Glass Cleaning
Frequency: As desired
By: Homeowner
Clean glass with a non-abrasive commercially available
cleaner or ashes:
• Light deposits
- Use household glass cleaner
• Heavy deposits
- Use wood ash on damp cloth or,
- Use commercial fireplace glass cleaner (consult with
your dealer)
CAUTION! Handle glass assembly with care. Glass is
breakable.
• Avoid striking, scratching or slamming glass
• Avoid abrasive cleaners
• Do not clean glass while it is hot
Expansion and contraction will cause minor cracking of the
molded brick panel. This is normal. The panel will require
periodic replacement depending on use.
The panels should be replaced if
• Cracks exceed ¼ inch (6 mm) in width,
• Metal is exposed behind a panel,
• Large pieces of panel fall out.
NOTICE: Do not substitute for HHT mortar. Other materials
may stain the molded brick panels.
Heat & Glo • RUTHERFORD-36 • 4059-341 Rev D • 03/09

13
4
4 Troubleshooting Guide
Start Fire Problems Possible Cause Solution
Can’t get fire started
Excessive smoke or spillage
Burns too slowly
Smolders, sizzles
Not enough kindling/paper or no
kindling/paper
Use dry kindling, more paper. Arrange kindling & wood for
air movement.
Damper closed/not fully open Open damper.
Not enough air for fire to ignite Check for restricted cap/shroud.
Check for flue blockage.
Pre-warm flue before starting fire (refer to starting fire
section).
Check for adequate vent height (refer to chimney assembly
section).
Open window below the fireplace towards the wind.
Open outside air doors.
Wood condition is too wet, too large Use dry, seasoned wood (refer to wood fuel section).
Bed of coals not established before
adding wood
Start with paper & kindling to establish bed of coals (refer to
starting fire section).
Flue blockage such as birds’ nests or
leaves in termination cap
Have chimney inspected for creosote and cleaned by a
certified chimney sweep.
Down draft or negative pressure
Competition with exhaust devices
Do not use exhaust fans during start-up (refer to negative
pressure section).
Open window below the fireplace towards the wind.
Fire burns too fast Extremely dry or soft wood Mix in hardwood.
Mix in less seasoned wood after fire is established (refer to
wood fuel section).
No glass doors Add glass doors to slow down air flow.
Overdrafting Check for correct vent height; too much vertical height
creates overdrafting.
Check location of vent termination (refer to chimney
assembly section).
Heat & Glo • RUTHERFORD-36 • 4059-341 Rev D • 03/09

14
Non-combustible
roof flashing maintains
minimum clearance
around chimney
Additional lateral
support for chimney
above roof (or enclosed
in chase) if needed
(Section 8.A.)
Ceiling firestop
on floor of attic
(Section 8.D.)
Support straps
on rafter supports
chimney (not shown)
Termination cap
(Sections 8.I., 9.D.)
Chimney penetrates roof
preferably without affecting
roof rafters (Section 8.H.)
Offset/Return (with hanger straps)
(Section 8.B.)
Framing headed off
in ceiling joists (Section 8.D.)
Enclosed space above
and around fireplace (Section 6.B.)
Mantel and surround (Section 12.E.)
Decorative facing
and trim (Sections 12.D., 12.F.)
Hearth extension
(Sections 12.C., 12.D.)
Factory-built fireplace
Protective metal
hearth strip(s) (Section 7.C.)
Combustible
framing/header
on top of
V-shaped
standoffs
(spacers)
(Section 6.D.)
Chimney system
(Section 8)
Attic insulation shield (not shown) must
be used here to keep insulation away
from chimney if attic is insulated
(Section 8.E.)
Storm Collar
(Section 9.D.)
Outside Air
(both sides)
5
5 Getting Started
A. Typical Fireplace System
Figure 5.1 Typical Fireplace System
Installer Guide
Heat & Glo • RUTHERFORD-36 • 4059-341 Rev D • 03/09

15
B. Design and Installation Considerations
Draft is the pressure difference needed to vent fireplaces
successfully. When a fireplace is drafting successfully, all
combustion by-products are exiting the home through the
chimney.
Considerations for successful draft include:
• Preventing negative pressure
• Location of fireplace and chimney
Before installing, determine the following:
• Where the fireplace is to be installed.
• The vent system configuration to be used.
• Gas supply piping.
• Framing and finishing details.
• Whether optional accessories are desired.
NOTICE: Check building codes prior to installation.
• Installation MUST comply with local, regional, state and
national codes and regulations.
• Consult insurance carrier, local building inspector, fire
officials or authorities having jurisdiction over restrictions,
installation inspection and permits.
Negative pressure results from the imbalance of air avail-
able for the fireplace to operate properly. It can be stron-
gest in lower levels of the house.
Causes include:
• Exhaust fans (kitchen, bath, etc.)
• Range hoods
• Combustion air requirements for furnaces, water heaters
and other combustion appliances
• Clothes dryers
• Location of return-air vents to furnace or air conditioning
• Imbalances of the HVAC air handling system
• Upper level air leaks such as:
- Recessed lighting
- Attic hatch
- Duct leaks
To minimize the effects of negative air pressure:
• Ensure adequate outdoor air for all combustion appliances
and exhaust equipment
• Ensure furnace and air conditioning return vents are not
located in the immediate vicinity of the fireplace
• Avoid installing the fireplace near doors, walkways or small
isolated spaces
• Recessed lighting should be a “sealed can” design
• Attic hatches weather stripped or sealed
• Attic mounted duct work and air handler joints and seams
taped or sealed
• Basement installations should be avoided
WARNING! Risk of Asphyxiation! Negative pressure can
cause spillage of combustion fumes and soot. Fire must
draft properly for safe operation.
NOTICE: Hearth & Home Technologies assumes no
responsibility for the improper performance of the fireplace
system caused by:
• Inadequate draft due to environmental conditions
• Downdrafts
• Tight sealing construction of the structure
• Mechanical exhausting devices
• Improper positioning of the chimney in a not-recommended
location on the roof.
NOTICE: Hearth & Home Technologies Inc. recommends the
use of direct vent appliances in basements.
D. Negative Pressure
C. Draft
NOTICE: The fireplace provides some outside air for
combustion. Other methods may be necessary if more air
is required.
Heat & Glo • RUTHERFORD-36 • 4059-341 Rev D • 03/09

16
Marginal Location:
• Below peak
Location NOT recommended:
• Not the highest point of the roof
• Wind loading possible
Multi-level Roofs
Windward
Leeward
Recommended Location:
• Above peak
Recommended:
• Insulated exterior chase
in cooler climates
Recommended Location:
• Above peak
• Inside heated space
Location NOT recommended:
• Too close to tree
• Below adjacent structure
• Lower roof line
• Avoid outside wall
Marginal Location:
• Wind loading possible
Figure 5.1 Recommended Chimney Locations
Location of the fireplace and chimney will affect perfor-
mance.
• Install within the warm air space enclosed by the building
envelope. This helps to produce more draft, especially
during lighting and die-down of the fire.
• Penetrate the highest part of the roof. This minimizes the
effects of wind loading.
• Locate termination cap away from trees, adjacent
structures, uneven roof lines and other obstructions.
• Minimize the use of chimney offsets.
• Consider the fireplace location relative to floor and ceiling
and attic joists.
• Take into consideration the termination requirements in
Section 8 and Section 9.
E. Locating your Fireplace & Chimney
NOTICE: Locating the fireplace in an area of considerable
air movement can cause intermittent smoke spillage from
fireplace. Do not locate fireplace near
• frequently open doors
• central heat outlets or returns
DO NOT install in a basement.
Heat & Glo • RUTHERFORD-36 • 4059-341 Rev D • 03/09

17
Before beginning the installation be sure the following tools
and building supplies are available:
Reciprocating saw Framing material
Pliers Non-combustible sealant
Hammer Gloves
Phillips screwdriver Framing square
Flat blade screwdriver Electric drill and bits
Plumb line Safety glasses
Level Tape measure
1/2-3/4 in. length, #6 or #8 self-drilling screws
Misc. screws and nails
H. Inspect Fireplace and ComponentsF. Tools and Supplies Needed
WARNING! Risk of Fire and/or Explosion! Damaged
parts could impair safe operation. DO NOT install dam-
aged, incomplete or substitute components. Keep fireplace
dry.
• Remove fireplace from pallet.
• Remove fireplace and components from packaging and
inspect for damage.
• Remove the hearth molded brick panel, screens and grate
from inside the unit.
• Vent system components, doors, remaining molded brick
panels and mortar are shipped in separate packages.
• Report to your dealer any parts damaged in shipment.
• Read all the instructions before starting the installation.
Follow these instructions carefully during the
installation to ensure maximum safety and benefit.
G. Typical Fireplace Components
• Hearth Molded brick panel
- Molded brick panel kit must be installed, but is sold
separately
• Grate Assembly
• Outside Air Kits
- Duct must be installed, but sold separately
Heat & Glo • RUTHERFORD-36 • 4059-341 Rev D • 03/09

18
6
6 Framing & Clearances
A
F
D
BC
5/8 in. (16 mm) all
configurations
1-1/2 in. min. air space
from fireplace to
combustible materials.
1/2 in. min. air space at
nailing flanges.
Note:
In an exterior chase
or projecting into a
garage
Across a
corner
As a
room
divider Along a wall
78 in.
(1981 mm)
G
B
E
Note: In addition to these
framing dimensions, also
reference the following
sections:
• Clearances (6.B.)
• Framing (6.D.)
• Mantel Projections
(6.C)
• Fireplace Dimensions
(14.A.)
48 in.
(1219 mm)
MINIMUM
24 in. (610 mm)
from fireplace opening to
any perpendicular wall
A
B
G
G
B
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)))))))))))))))
)
)
)
)
)
)
)
)))))))))))))))
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
)
))
)
)
)
))
)))
)
)
)
)
)
Model # A B C D E F G
in. 72 47 7/8 89 1/8 44 5/8 20 3/8 63 1/8 28 1/2
mm 1829 1216 2264 1133 518 1603 724
BIR36
Figure 6.1 Fireplace Locations
A. Select Fireplace Location
NOTICE: Both outside air kits MUST be
installed.
Heat & Glo • RUTHERFORD-36 • 4059-341 Rev D • 03/09

19
B. Clearances
WARNING! Risk of Fire! You must comply with all minimum air space clearances to combustibles as specified in Fig-
ure 6.2. DO NOT pack required air spaces with insulation or other materials.
Heat & Glo • RUTHERFORD-36 • 4059-341 Rev D • 03/09
(insulation)
Attic
Insulation
Shield
(ceiling)
(roof)
(attic)
(ceiling)
Ceiling Firestop
Offset/Return (secured
with hanger straps)
Storm Collar
Roof Flashing
1-1/2 in. (38 mm) to back &
sides of appliance
(except at nailing flanges
where it is 1/2 in. [13 mm])
Must have 2 in. (51 mm)
minimum clearance
to header
0 in.
to floor
2 in. (51 mm) min.
Shaded areas
represent
2 in. (51 mm) min.
air space clearance
required around pipe
Combustible Object
48 in.
1219 mm
Figure 6.2 Air Space Clearances

20
D. Frame the Fireplace
Figure 6.4 shows typical framing using combustible materials (2x4 lumber shown).
• Observe all required air space clearances to combustible materials as shown in Figure 6.2.
18 1/2 in.
[470 mm]
19 3/4 in.
[500 mm]
4 in.
[102 mm]
50° angle
39° angle
24 in.
[610 mm]
BRICK
FRONT
FLUSH
FRONT
24 in.
[610 mm]
22 3/8 in.
[568 mm]
46 7/8 in.
(1191 mm)
36 in.
[914 mm]
Note: Grid depicts 1 inch squares.
Figure 6.3 Mantel Leg, Surround or Wall Projection (acceptable on both sides of opening)
B
C
A
2 in. (51 mm)
min. air space
clearance
from chimney.
Header MUST NOT be notched!
D
D = extra space needed for outside air connection.
If outside air duct has no bend, this dimension may be
reduced as long as minimum clearances are met.
D
AB*C**D
in. 47 7/8 28 1/2 74 1/4 12
mm 1216 724 1886 305
Model #
* If interior of chase will be drywalled, add the thickness to this meaurement.
** Adjust header height for raised floor under fireplace.
RUTHERFORD-36
The fireplace header cannot be positioned until
after the fireplace assembly is in place.
Framing must be extended straight up, all
the way to the ceiling.
Figure 6.4 Framing the Fireplace
C. Sidewalls/Surrounds
• Locate adjacent combustible sidewalls a minimum of 24 in. (610 mm) from fireplace opening.
• Mantle leg, surround, stub wall, whether combustible or non-combustible, may be constructed as shown in Figure 6.3.
Heat & Glo • RUTHERFORD-36 • 4059-341 Rev D • 03/09
