Heat-N-Glo 6000 GDVFL Assembly instructions

WARNING
IF THE INFORMATION IN
THESE INSTRUCTIONS IS
NOT FOLLOWED EXACTLY, A
FIRE OR EXPLOSION MAY
RESULT CAUSING PROPERTY
DAMAGE, PERSONAL INJURY,
OR LOSS OF LIFE.
- Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of this
or any other appliance.
-What to do if you smell gas
 Do not try to light any appliance.
 Do not touch any electrical switch.
 Do not use any phone in your building.
 Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
 If you cannot reach your gas supplier, call the
fire department.
- Installation and service must be performed by a
qualified installer, service agency, or the gas
supplier.
Heat-N-Glo Fireplace
Models:
6000 GDVFL
6000 XLS
U.S. Patents 4,793,322; 4,875,464; 5,000,162 and Patents Pending
Canadian Patent 1,297,746
Installers Guide
WARNING: IMPROPER
INSTALLATION, ADJUSTMENT,
ALTERATION, SERVICE OR
MAINTENANCE CAN CAUSE
INJURY OR PROPERTY DAMAGE.
REFER TO THIS MANUAL. FOR
ASSISTANCE OR ADDITIONAL
INFORMATION CONSULT A
QUALIFIED INSTALLER, SERVICE
AGENGY, OR THE GAS SUPPLIER.
A.G.A. Design Certified/CGA Certified and
Underwriters Laboratories Listed. See
Approvals Tabel on Page 1.
446-982-A 8/97
READ THIS MANUAL BEFORE INSTALLING
OR OPERATING THIS APPLIANCE. THIS
INSTALLERS GUIDE MUST BE LEFT WITH
APPLIANCE FOR FUTURE REFERENCE.
1.This appliance may be installed in an
aftermarket, permanently located,
manufactured (mobile) home, where
not prohibited by local codes.
2. This appliance is only for use with the
type of gas indicated on the rating
plate. This appliance is not convertible
for use with other gases, unless a
certified kit is used.
Please contact your Heat-N-Glo Fireplace
dealer for any questions or concerns. For the
number of your nearest Heat-N-Glo dealer,
please call 612-890-8367.
Printed in U.S.A.
Copyright 1997,
Heat-N-Glo Fireplace Products, Inc.
6665 West Highway 13, Savage, MN 55378

i
SAFETY AND WARNING INFORMATION
READ and UNDERSTAND all instructions carefully before starting the installation.
FAILURE TO FOLLOW these installation instructions may result in a possible fire
hazard and will void the warranty.
Prior to the first firing of the fireplace, READ the Using Your Fireplace section of the
Owners Guide.
DO NOT USE this appliance if any part has been under water. Immediately CALL a
qualified service technician to inspect the unit and to replace any part of the control
system and any gas control which has been underwater.
THIS UNIT IS NOT FOR USE WITH SOLID FUEL.
Installation and repair should be PERFORMED by a qualified service person. The
appliance and venting system should be INSPECTED before initial use and at least
annually by a professional service person. More frequent cleaning may be required due
to excessive lint from carpeting, bedding material, etc. It is IMPERATIVE that the units
control compartment, burners, and circulating air passageways BE KEPT CLEAN to
provide for adequate combustion and ventilation air.
Always KEEP the appliance clear and free from combustible materials, gasoline, and
other flammable vapors and liquids.
NEVER OBSTRUCT the flow of combustion and ventilation air. Keep the front of the
appliance CLEAR of all obstacles and materials for sevicing and proper operations.
Due to the high temperature, the appliance should be LOCATED out of traffic areas and
away from furniture and draperies. Clothing or flammable material SHOULD NOT BE
PLACED on or near the appliance.
Children and adults should be ALERTED to the hazards of high surface temperature and
should STAY AWAY to avoid burns or clothing ignition. Young children should be
CAREFULLY SUPERVISED when they are in the same room as the appliance.
These units MUST use one of the vent systems described in the Installing the Fireplace
section of the Installers Guide. NO OTHER vent systems or components MAY BE USED.
This gas fireplace and vent assembly MUST be vented directly to the outside and MUST
NEVER be attached to a chimney serving a separate solid fuel burning appliance. Each
gas appliance MUST USE a separate vent system. Common vent systems are
PROHIBITED.
INSPECT the external vent cap on a regular basis to make sure that no debris is
interfering with the air flow.
The glass door assembly MUST be in place and sealed, and the trim door assembly
MUST be in place on the fireplace before the unit can be placed into safe operation.
DO NOT OPERATE this appliance with the glass door removed, cracked, or broken.
Replacement of the glass door should be performed by a licensed or qualified service
person. DO NOT strike or slam the glass door.
The glass door assembly SHALL ONLY be replaced as a complete unit, as supplied by
the gas fireplace manufacturer. NO SUBSTITUTE material may be used.
DO NOT USE abrasive cleaners on the glass door assembly. DO NOT ATTEMPT to
clean the glass door when it is hot.
Turn off the gas before servicing this appliance. It is recommended that a qualified
service technician perform an appliance check-up at the beginning of each heating
season.
Any safety screen or guard removed for servicing must be replaced before operating
this appliance.
LIMITED10YEAR WARRANTY
HEAT-N-GLOGASFIREPLACE PRODUCTS
Inordertopresumptively establish the dates to which your HEAT-N-GLO Limited 10 Year Warranty runs, you
mustmailthecompleted warranty card to HEAT-N-GLO FIREPLACE PRODUCTS, INC., 6665 West
Highway13,Savage,MN 55378,within60days of the date of fireplace installation. Ifyoufailto do so, you
mayberequiredto prove the date of installation before warranty work can be performed.
Thewarrantyexclusionsand limitations of liability are effective upon installation of the fireplace.
Subjecttothe conditions set forth herein, HEAT-N-GLO FIREPLACE PRODUCTS, INC. ("HEAT-N-GLO")
extendsthefollowingwarranty with respect to HEAT-N-GLO Gas Fireplace Products.
IfHEAT-N-GLOisreasonably satisfiedthat anypart orportion ofthe fireplacecovered bythis LimitedWarranty
isdefectivein material or workmanship under normal use and service as described in the Owners Guide,
HEAT-N-GLOwilltakethe following actions:
1.Ifthe defectisreported duringthe firstyearfrom thedateof installation(stainless steelburnersand fiberlogs
arecoveredfor3years),HEAT-N-GLOwill replaceor repairthe defectivecomponents atits soleexpense. The
decisionwhetherto replace a component shall be made at HEAT-N-GLO's sole discretion. ThisLimited
Warrantydoesnot cover components broken during shipping, misuse or careless handling. HEAT-N-GLO
shallbenotresponsibleforanyindirect, incidental,orconsequentialdamagesorforanycosts otherthanthose
incurredbyHEAT-N-GLOto repair or replace the defective component. Ifcomponents(including venting)
otherthanfactoryapprovedcomponentsare used, allwarranty and liabilityon the fireplace isvoided. Defects
reportedafterthe first year will not be covered by warranty unless they fall within the purview of
paragraph2or3 below.
2.Ifthe following defects are reported during the second year after the date of installation, HEAT-N-GLO will
supplyreplacementpartsatthe currentwholesale price: defectiveelectrical ormanual components,optional
componentsoraccessories,and glass panels (not including glass panels broken during misuse or careless
handling).HEAT-N-GLOshall not be responsible for any labor, transportation or other costs. Furthermore,
HEAT-N-GLOshallnotbe liable for any indirect, incidental or consequential damages.
3.HEAT-N-GLOwillreplace orrepaira defectivefireboxor heatexchanger,at anytimeduring the10years from
thedate of installation. Thedecision whether to replace the defective component shall be made at
HEAT-N-GLO'ssole discretion. HEAT-N-GLOshall not be responsible for any indirect, incidental or
consequentialdamagesorfor any costs other than those incurred by HEAT-N-GLO to repair or replace the
defectivecomponent.
ThisLimitedWarranty is the exclusive remedy available to you. IfHEAT-N-GLOcannoteffectively resolve a
warrantyproblemin an expedient and cost-effective manner, it can discharge its entire warranty liability by
refundingthepriceof the product to you.
Productsmadebyothermanufacturers, whethersoldwiththefireplaceoradded thereafter,areNOTcoveredby
thisLimitedWarranty. The use of other unauthorized components will make this warranty null and void. This
LimitedWarrantywillalso be void if the appliance is not installed by a qualified installer in accordance with the
InstallersGuide. Furthermore, the Limited Warranty will be voidifthe fireplace is not operated, at all times,
accordingtotheOwnersGuide furnishedwith thefireplace. Any servicework mustbe performedbyauthorized
servicerepresentatives.
EXCEPTTO THE EXTENT PROVIDED BY LAW, NO OTHER EXPRESS OR IMPLIED WARRANTIES,
INCLUDINGWARRANTIESOFMERCHANTABILITYOR FITNESSFORAPARTICULARPURPOSE,SHALL
APPLYTOTHEFIREPLACEPRODUCT. In Statesthat donot allowlimitations onhow longan impliedwarranty
lasts,ordonotallowexclusion ofindirect damages,those limitationsor exclusionsmay notapply toyou. You may
alsohaveadditionalrights not covered in this Limited Warranty.
HEAT-N-GLOreservestherightto make changes at any time, without notice, in design, material, specifications
andprices.It also reserves the right to discontinue styles and products.

ii
Table of
Contents
Safety and Warning Information ...................... i
Section 1: Approvals and Codes ..................... 1
Approval Listings and Codes................................ 1
Appliance Certification ...................................... 1
Installation Codes ............................................... 1
High Altitude Installations ................................ 1
Section 2: Getting Started ................................ 2
Introducing the Heat-N-Glo Gas Fireplaces........ 2
Pre-installation Preparation ................................... 2
Section 3: Installing the Fireplace .................. 5
Step 1 Locating the Fireplace ............................. 5
Step 2 Framing the Fireplace.............................. 6
Step 3 Installing the Vent System ...................... 7
A. Vent System Approvals ................................ 7
B. Installing Vent Components ...................... 13
C. Vent Termination ......................................... 18
Step 4 Positioning, Leveling, and
Securing the Fireplace ........................... 23
Step 5 The Gas Control Systems ...................... 23
Step 6 The Gas Supply Line ............................. 24
Step 7 Gas Pressure Requirements .................. 25
Step 8 Wiring the Fireplace .............................. 26
Step 9 Finishing.................................................. 28
Step 10 Installing Trim, Logs, and
Ember Material....................................... 29
Installing the Trim............................................. 29
Positioning the Logs ......................................... 30
Placing the Ember Material ............................. 30
Step 11 Before Lighting the Fireplace .............. 32
Step 12 Lighting the Fireplace .......................... 32
After the Installation ............................................. 32
Section 4: Maintenance and Servicing ........ 33
Section 5: Replacement Parts
and Accessories ............................. 35
Replacement Parts................................................. 35
Accessories ............................................................. 38

1
Approval Listings
and Codes
Appliance Certification
The Heat-N-Glo fireplace models discussed in this
Installers Guide have been tested to certification
standards and listed by the applicable laboratories.
CERTIFICATION
MODEL LABORATORY TYPE STANDARD
6000GDVFL A.G.A./CGA Direct Vent ANSI Z21.50CGA2.22
and Decorative
Underwriters
Laboratories
6000XLS A.G.A./CGA Direct Vent ANSI Z21.44/IR#41/CAN1-2.19
and Wall Furnace
Underwriters
Laboratories
Installation Codes
The fireplace installation must conform to local codes. Before installing the
fireplace, consult the local building code agency to ensure that you are in
compliance with all applicable codes, including permits and inspections.
In the absence of local codes, the fireplace installation must conform to the
National Fuel Gas Code ANSI Z223.1 (in the United States) or the CAN/CGA-
B149 Installation Codes (in Canada). The appliance must be electrically
grounded in accordance with local codes or, in the absence of local codes with
the National Electric Code ANSI/NFPA No. 70 (in the United States), or to the
CSA C22.1Canadian Electric Code (in Canada).
These models may be installed in a bedroom or bed-sitting room in the U.S.A.
and Canada.
High Altitude Installations
A.G.A./CGA Design Certified and U.L. Listed gas fireplaces are tested and
approved for elevations from 0 to 2,000 feet in the U.S.A. and from 0 to 4,500
feet in Canada.
When installing this fireplace at an elevation above 2,000 feet (in the United
States), it may be necessary to decrease the input rating by changing the
existing burner orifice to a smaller size. Input should be reduced four percent
(4%) for each 1,000 feet above sea level, unless the heating value of the gas has
been reduced, in which case this general rule will not apply. To identify the proper
orifice size, check with the local gas utility.
When installing this fireplace at an elevation between 2,000 and 4,500 feet (in
Canada), the input rating must be reduced by ten percent (10%).
When installing this fireplace at an elevation above 4,500 feet (in Canada), check
with local authorities.
Consult your local gas utility for assistance in determining the proper orifice for
your location.
1
Approvals
and Codes

2
Introducing the
Heat-N-Glo
Gas Fireplaces
Heat-N-Glo direct vent gas fireplaces are designed to
operate with all combustion air siphoned from outside
of the building and all exhaust gases expelled to the
outside.
The information contained in this Installers Guide,
unless noted otherwise, applies to all models and gas
control systems.
Gas fireplace diagrams, including the dimensions, are
shown in this section.
Pre-installation
Preparation
This gas fireplace and its components are tested and
safe when installed in accordance with this Installers
Guide. Report to your dealer any parts damaged in
shipment, particularly the condition of the glass. Do
not install any unit with damaged, incomplete, or
substitute parts.
The vent system components and trim doors are
shipped in separate packages. The gas logs are
factory installed (Model 6000GDVFL) and are
packaged separately and must be field installed
(Model 6000XLS). Read all of the instructions
before starting the installation. Follow these
instructions carefully during the installation to
ensure maximum safety and benefit. Failure to
follow these instructions will void the owners
warranty and may present a fire hazard.
The Heat-N-Glo Fireplace Products, Inc. Warranty will
be voided by, and Heat-N-Glo Fireplace Products, Inc.
disclaims any responsibility for, the following actions:
 Installation of any damaged fireplace or vent system
component.
 Modification of the fireplace or direct vent system.
 Installation other than as instructed by Heat-N-Glo
Fireplace Products, Inc.
 Improper positioning of the gas logs or the glass
door.
 Installation and/or use of any component part not
manufactured and approved by Heat-N-Glo Fire-
place Products, Inc., not withstanding any indepen-
dent testing laboratory or other party approval of
such component part or accessory.
ANY SUCH ACTION MAY POSSIBLY CAUSE A
FIRE HAZARD.
2
Getting
Started

3
When planning a fireplace installation, its necessary to determine:
Where the unit is to be installed.
The vent system configuration to be used.
Gas supply piping.
Electrical wiring.
Framing and finishing details.
Whether optional accessoriesdevices such as a fan, wall switch, or remote
controlare desired.
If the fireplace is to be installed on carpeting or tile, or on any combustible
material other than wood flooring, the fireplace should be installed on a metal or
wood panel that extends the full width and depth of the fireplace.
Figure 1. Diagram of the6000 Series

4
3
Installing the
Fireplace
Step 1
Locating the
Fireplace
The diagram below shows space and clearance
requirements for locating a fireplace within a room.
Figure 2. Fireplace Dimensions, Locations, and
Space Requirements
Clearance Requirements
The top, back, and sides of the fireplace are defined
by stand-offs.
Minimum Clearances from the Fireplace to
Combustible Materials
Glass Back of Sides of Top of
Front Floor Fireplace Fireplace Fireplace Ceiling
36 inches 0 1/2 inch 1/2 inch 3-1/2 inches 31 inches
(914 mm) (13 mm) (13 mm) (89 mm) (787 mm)
The minimum clearance to a perpendicular wall
extending past the face of the fireplace is one inch (25
mm).
For 6000 Series Models, the back of the fireplace may
be recessed 21-1/2 inches (546 mm) into
combustible construction.

5
Minimum Clearances from the Vent Pipe to
Combustible Materials
For Vertical
For Horizontal Sections Sections At Wall Firestops
Top Bottom Sides Top Bottom Sides
3 inches 1 inch 1 inch 1 inch 2-1/2 inches 1/2 inch 1 inch
(75 mm) (25 mm) (25 mm) (25 mm) (63.7 mm) (13 mm) (25 mm)
For minimum clearances, see the direct vent
termination clearance diagrams on pages 19 and 21 in
this section.
Step 2
Framing the
Fireplace
Fireplace framing can be built before or after the
fireplace is set in place. Framing should be positioned
to accommodate wall coverings and fireplace facing
material. The diagram below shows framing reference
dimensions.
CAUTION MEASURE FIREPLACE DIMENSIONS, AND
VERIFY FRAMING METHODS AND WALL
COVERING DETAILS, BEFORE FRAMING
CONSTRUCTION BEGINS.
A
B
C
Framing should be
constructed of 2 X 4
lumber or heavier.
The framing
headers may rest
on the fireplace
stand-offs.
Model A B C D
6000 Models 42 38-1/4 22 26-1/4
Figure 3. Framing Dimensions
NOTE: DIMENSIONS SHOWN IN INCHES

6
Step 3
Installing the
Vent System
A. Vent System Approvals
These appliances are approved to use D-series direct
vent pipe components and terminations. Approved
vent system components are labeled for identification.
NO OTHER VENTING SYSTEMS OR
COMPONENTS MAY BE USED. Detailed
installation instructions are included with each vent
termination kit and should be used in conjunction with
this Installers Guide. The drawing below shows vent
system components and terminations.
Identifying Vent Components
The vent systems installed on this gas fireplace may
include one, two, or three 90° elbow assemblies. The
relationships of vertical rise to horizontal run in vent
configurations using 90° elbows MUST BE strictly
adhered to. The rise to run relationships are shown in
the venting drawings and tables. Refer to the
diagrams on the next several pages.
Figure 4. Vent Components and Terminations
Vent system components
Vent system
termination kits

7
Figure 5. D-Series Direct Vent Component Specifications
(5-inch inner pipe/8 5/8-inch outer pipe)
NOTE: PIPES OVERLAP 1 3/8 INCHES (34.93 mm) AT EACH JOINT.
DV-90D
6 5/32
57/8
7 3/8
DV-45D
67/16
111/16
61/2
8 5/8
8 1/2
51/16
8/12115/8
8 5/8
1115/16
DV-36D
353/4
473/4
DV-48D
5 3/4
8 3/4
11 3/4
DV-12D
DV-09D
DV-06D
6-5/32"
(156 mm)
7-3/8" 5-7/8"
(187 mm) (149 mm)
8-1/2"
(216 mm)
8-5/8"
(220 mm)
11-15/16"
(303 mm)
11-5/8"
(295 mm) 11-1/16"
(281 mm) 6-1/2"
(165 mm)
8-5/8"
(220 mm)
5-1/16"
(129 mm)
8-1/2"
(216 mm)
6-7/16"
(164 mm)
35-3/4"
(908 mm)
47-3/4"
(1.2 m)
11-3/4"
(298 mm) 8-3/4"
(222 mm) 5-3/4"
(146 mm)
NOTE: PIPES OVERLAP 1-3/8 INCHES (34.93 mm) AT EACH JOINT.

8
Figure 6. Corner Installation
Models 6000XLS, and 6000GDVFL are tested and
approved to use 45° elbows in corner installations.
However, 90° elbows will result in better performance.
HORIZONTAL VENTING
H
Kit No. Max. Run
DVK-01D
DVK-01TRD 24" (610 mm)

9
Figure 7. Venting with One 90° Elbow
VENTING WITH ONE (1) 90°ELBOW
1´ MIN. (305 mm) 2´ MAX. (610 mm)
2´ MIN. (610 mm) 4´ MAX. (1.22 m)
3´ MIN. (914 mm) 6´ MAX. (1.86 m)
4´ MIN. (1.22 m) 8´ MAX. (2.48 m)
40´ MAX. (12.4 m) 8´ MAX. (2.48 m)

10
VENTING WITH TWO (2) 90°ELBOWS
V H H + H1
1´ MIN. (305 mm) 2´ MAX. (610 mm) 6´ MAX. (1.86 m)
2´ MIN. (610 mm) 4´ MAX. (1.22 m) 12´ MAX. (3.72 m)
3´ MIN. (914 mm) 6´ MAX. (1.86 m) 18´ MAX. (5.58 m)
4´ MIN. (1.22 m) 8´ MAX. (2.48 m) 24´ MAX. (7.74 m)
20´ MAX. (6.2 m) 8´ MAX. (2.48 m) 24´ MAX. (7.74 m)
(20´ (6.2 m) CANADA)
Figure 8. Venting with Two 90° Elbows

11
Figure 9. Venting with three 90° elbows
VENTING WITH THREE (3) 90°ELBOWS
VENTING WITH THREE (3) 90°ELBOWS
1´ MIN. (305 mm) 2´ MAX. (610 mm) 5´ MAX. (1.52 mm)
2´ MIN. (610 mm) 4´ MAX. (1.22 m) 10´ MAX. (3.1 m)
3´ MIN. (914 mm) 6´ MAX. (1.86 m) 15´ MAX. (4.65 m)
4´ MIN. (1.22 m) 8´ MAX. (2.48 m) 20´ MAX. (6.2 m)
8´ MAX. (2.48 m) 20´ MAX. (6.2 m)
NOTE: V + V, MAX. 40´ (12.4 m)
1´ MIN. (305 mm) 2´ MAX. (610 mm) 5´ MAX. (1.52 mm)
2´ MIN. (610 mm) 4´ MAX. (1.22 m) 10´ MAX. (3.1 m)
3´ MIN. (914 mm) 6´ MAX. (1.86 m) 15´ MAX. (4.65 m)
4´ MIN. (1.22 m) 8´ MAX. (2.48 m) 20´ MAX. (6.2 m)
20´ MAX. (6.2 m) 8´ MAX. (2.48 m) 20´ MAX. (6.2 m)

12
B. Installing Vent Components
1. Attach the First Vent Component to the
Starting Collars
To attach the first vent component to the starting
collars of the fireplace:
 Apply a 3/8 inch (9.5 mm) bead of stove cement
around the 5 inch (127 mm) fireplace starting collar.
 Make sure that the fireplace rope gasket supplied
with the fireplace seals between the first
8-5/8 inch (219 mm) vent component and the outer
fireplace wrap.
 Lock the vent components into place by sliding the
concentric pipe sections with four (4) equally
spaced interior beads into the fireplace collar or
previously installed component end with four (4)
equally spaced indented sections.
 When the internal beads of each 8-5/8 inch
(219 mm) outer pipe line up, rotate the pipe section
clockwise about one-quarter (1/4) turn. The vent
pipe is now locked together.
 The first 90° elbow installed in the vent system of a
rear venting fireplace MUST BE in a vertical posi-
tion.
1. Apply the stove ce-
ment.
2. Line up the internal
beads and rotate the
pipe sections clock-
wise until locked.
3. Lock the vent compo-
nents into place.
4. Check the seal on the
rope gasket.
Figure 10. Attaching the First Vent Component to
the Starting Collars
WARNING
A 3/8 INCH (9.5 MM) BEAD OF STOVE
CEMENT MUST BE PLACED AROUND
THE 5 INCH (127 MM) FIREPLACE
STARTING COLLAR BEFORE
ATTACHING THE FIRST VENT
COMPONENT. FAILURE TO SEAL THIS
JOINT MAY CAUSE THE FIREPLACE TO
OPERATE IMPROPERLY. SEE THE
DIAGRAM .
STARTING
COLLAR
FIRST
VENT
COMPONENT
STOVE
SEALANT
BEAD
3/8" (9.5 mm)
1 INCH (25.4 mm)
3/8 INCH (9.5 mm)

13
WARNING
ENSURE THAT THE FIBERGLASS
ROPE GASKET SUPPLIED WITH THE
FIREPLACE SEALS BETWEEN THE
FIRST VENT COMPONENT AND THE
OUTER FIREPLACE WRAP.
If the installation is for a termination cap attached
directly to the fireplace, skip to the sections, Install
Firestops and Vent Termination.
2. Continue Adding Vent Components
To continue adding vent components in accordance
with the pre-planned vent system configuration:
 Ensure that each succeeding vent component is
securely fitted and locked into the preceding com-
ponent in the vent system.
90° elbows may be installed and rotated to any point
around the preceding components vertical axis. If an
elbow does not end up in a locked position with the
preceding component, attach with a minimum of two
(2) sheet metal screws.
Continue adding vent
components, locking
each succeeding
component into place.
Figure 11. Adding Venting Components
3. Install Support Brackets
For Horizontal Runs - The vent system must be
supported every five (5) feet of horizontal run by a
horizontal pipe support.
To install support brackets for horizontal runs:
 Place the pipe supports around the vent pipe.
 Nail the pipe supports to the framing members.

14
For Vertical Runs - The vent system must be
supported every eight (8) feet (2.4 m) above the
fireplace flue outlet by wall brackets.
To install support brackets for vertical runs:
 Attach wall brackets to the vent pipe and secure the
wall bracket to the framing members with nails or
screws.
Use wall brackets to
support vertical runs
every 8 feet (2.4 m)
above the fireplace flue
outlet.
Figure 12. Installing Support Brackets
4. Install Firestops
For Horizontal Runs - Firestops are REQUIRED on
both sides of a combustible wall through which the
vent passes.
NOTE Model DVK-01TRD does not need an exterior
firestop on an exterior combustible wall.
To install firestops for horizontal runs that pass
through either interior or exterior walls:
 Cut a 12-inch by 12-inch (305 mm X 305 mm) hole
through the wall. The center of the hole is one (1)
inch (25.4 mm) above the center of the horizontal
vent pipe.
FLUE
OUTLET
FLUE
OUTLET
1 INCH MIN.
(25.4 mm)
1 INCH MIN.
(25.4 mm)
8 FT. (2.4 m)
WALL STUD
WALL BRACKET

15
 Position the firestops on both sides of the hole
previously cut and secure the firestops with nails or
screws.
 The heat shields of the firestops MUST BE placed
towards the top of the hole.
 Continue the vent run through the firestops.
1. Cut the 12-inch by
12-inch hole.
Figure 13. 12" x 12" Hole and Vent Pipe
2. Position the firestops.
3. Place the heat shield
to the top.
4. Continue the vent run.
Figure 14. Heat Shield, Interior and Exterior
Firestops
For Vertical Runs - One ceiling firestop is
REQUIRED at the hole in each ceiling through which
the vent passes.
To install firestops for vertical runs that pass through
ceilings:
 Position a plumb bob directly over the center of the
vertical vent component.
 Mark the ceiling to establish the centerpoint of the
vent.
VENT PIPE
1" (25.4 mm)
12"
(305 mm)
12"
(305 mm)
12"
(305 mm)
12"
(305 mm)
TRIM HEAT
SHIELD IF TOO
LONG, ADD TO
SHIELD IF TOO
SHORT.
TRIM HEAT
SHIELD IF TOO
LONG, ADD TO
SHIELD IF TOO
SHORT.
EXTERIOR
FIRESTOP
EXTERIOR
FIRESTOP
INTERIOR
FIRESTOP
INTERIOR
FIRESTOP
HEAT SHIELD

16
 Drill a hole or drive a nail through this centerpoint.
 Check the floor above for any obstructions, such as
wiring or plumbing runs.
 Reposition the fireplace and vent system, if neces-
sary, to accommodate the ceiling joists and/or
obstructions.
 Cut an 11-inch X 11-inch (280 mm X 280 mm) hole
through the ceiling, using the centerpoint previously
marked.
 Frame the hole with framing lumber the same size
as the ceiling joists.
1. Cut the 11-inch by
11-inch hole.
2. Add the new framing
members.
Figure 15. 11" x 11" Hole and New Framing
Members
If the area above the ceiling is NOT an attic, position
and secure the ceiling firestop on the ceiling side of
the previously cut and framed hole.
This shows a ceiling
installation.
Figure 16. Ceiling Firestop (Ceiling Side)
CEILING
NEW
FRAMING
MEMBERS
NEW
FRAMING
MEMBERS
EXISTING CEILING
JOISTS
EXISTING CEILING
JOISTS
CHIMNEY
HOLE
CHIMNEY
HOLE
11" (280 mm)
11" (280 mm)
JOIST
CEILING FIRESTOP
NAILS (4 REQUIRED)
CEILING

17
If the area above the ceiling IS an attic, position and
secure the firestop on top of the previously framed
hole.
This shows an attic
installation.
1. Keep insulation away
from the vent pipe at
least 1 inch (25 mm).
NAILS (4 REQUIRED)
CEILING FIRESTOP
RAFTER
CEILING
Figure 17. Attic Firestop
C. Vent Termination
For Horizontal Terminations - To attach and secure
the termination to the last section of horizontal vent:
 Rotate and interlock the ends as described at the
beginning of the Installing Vent Components sec-
tion.
 The termination kit should pass through the wall
firestops from the exterior of the building.
 Adjust the termination cap to its final exterior posi-
tion on the building.
WARNING
THE TERMINATION CAP MUST BE
POSITIONED SO THAT THE ARROW IS
POINTING UP.
For roundcap termination kits:
 Use the exterior pipelock hole provided on the round
flange of the wall firestop to secure the vent pipe in
place.
For trapezoidal cap termination kits:
 Using screws, secure the cap to the exterior wall
through the flanges built into the cap.
 Use a high-temperature sealant or fiberglass rope
gasket to seal between the 8-5/8 inch
(219 mm) pipe and exterior firestop.
