Hedler DF15 User manual

Thank you for choosing a Hedler light unit and your
con dence in the Hedler light system. Please, read
the following technical informations carefully
before using the light unit.
Codes are given in <Brackets>.
TECHNICAL DESCRIPTION
Light units of the HEDLER DF range are designed for professional use, they are assembled by applying precision methods and tested individually
for function and quality. The focusable daylight HEDLER DF15 is provided with an integrated U-bracket and a friction brake and a 5/8” Quick-
Lock light stand attachment. After loosening the hex key screws by approx. 2 turns, the U-bracket can be moved back and forth in its keyway
for gravity adjustment and it is turnable for right and left hand use.
The focusable daylight HEDLER DF15 uses AC of 230 - 250 V and the modern metal halide 150 W SE T bulbs, which can be re-ignited after 2 - 3
minutes while the cooling down has started by switching-off the light unit. As a special feature, the HEDLER DF15 does not have a fan, which
means it suits ideal for original sound recording.
On its front side, the aluminium housing holds the Fresnel lens with its protective grid. AdditionalIy there are the Uni-Adapt studs and the
QuickFit adapter for attaching re ectors. Interchangeable re ectors with bayonet ring can be attached in the following way: place the rim of the
ring into the guide grooves of the upper studs and the round opening over the cone-shaped bolt, and lock it by a turn to the left. To attach the
rotatable 4-Leaf barndoors or a MaxiSoft folding re ector, place the rim of the ring into the guide grooves of the upper studs, and then push
the complete re ector towards the QuickFit´s cone-shaped bolt until the ring locks in the bolt´s groove. Detach the re ector by lifting the
QuickFit´s handle, moving the lower side of the re ector away from the light unit´s housing, and then lifting the re ector´s ring out of the guide
grooves of the upper studs.
On the opposite side of the housing, one will  nd the ergonomically incorporated handgrip, the cable and the main switch. Additionally you will
 nd on the backside of the housing the focusing turning knob, which allows to adjust precisely and intuitively the size of the light beam from
spot- to  oodlight setting.
In addition to the parabolic re ector, bulb socket and ignitor, the housing accomodates the electronic ballast, which supplies stabilized voltage to
the bulb, ensures  icker-free light of constant intensity and a colour temperature of app. 6000 K. Besides that, it will extend the average bulb life
by app. 20 percent and reduce the power consumption by about 12 percent. Ignition is effected by 1 x 5 KV symmetrically, faulty bulbs will be
detected and switched off automatically. RF interference reduction meets all applicable EN 61000-3-2 standards.
HEDLER Systemlicht GmbH Heerstrasse 112 D-65594 Runkel / Lahn www.hedler.com
Telefon + 49 - (0) 6482 918 100 Telefax + 49 - (0) 6482 918 111 eMail [email protected]
Daylight DF15
H
e
d
l
e
r
B
l
i
t
z
-
u
n
d
D
a
u
e
r
l
i
c
h
t
l
e
u
c
h
t
e
n
:
h
o
h
e
L
e
i
s
t
u
n
g
,
e
r
s
t
k
l
a
s
s
i
g
e
Q
u
a
l
i
t
ä
t
!
Handmade in Germany
HEDLER®
Systemlicht

HEDLER Systemlicht GmbH Heerstrasse 112 D-65594 Runkel / Lahn www.hedler.com
Telefon + 49 - (0) 6482 918 100 Telefax + 49 - (0) 6482 918 111 eMail [email protected]
Daylight DF15
BULBS
To replace the bulb: please, make sure that the housing and the bulb of the DF15 has off before interchanging the bulb, otherwise there is a risk
of burning! Always disconnect the DF15 from the power supply before interchanging the bulb. Unscrew the socket screw of the cover plate
guard. The cover plate guard is located on the housings upper side, its socket screw is located at the  ange which faces towards the housings
backside. To unscrew the socket screw, use the socket wrench which was delivered with the DF15. After loosening the socket screw completely
remove the cover plate guard.
Turn the focusing knob until the DF15 has its maximum spot light position. Pull the defective bulb out of the socket, after doing so push the new
bulb carefully into the socket, oberving instructions by the bulb manufacturer.
After pushing the bulb into its socket, replace the cover plate guard. Make sure that its lug is located correctly into the housings notch. Afterwards
install the socket screw into the hosuings thread and tighten it hand-tight. Please, before taking the HEDLER DF15 in operation, make sure that
the cover plate guard is mounted correctly!
FRESNEL LENS
To replace the Fresnel lens: please, make sure that the housing of the DF15 has cooled off before interchanging the Fresnel lens, otherwise there
is a risk of burning! Always disconnect the DF15 from the power supply before interchanging the Fresnel lens. Unscrew the four socket screws
of the housings front plate and remove the front plate with the Fresnel lens. Unscrew the securing screws of the Fresnel lens and replace the
defective one with an original Hedler Fresnel lens only. After replacing the Fresnel lens tighten its securing screws hand-tight. Attach the front
plate at the housing and tighten the front plates four securing screws. Please, before taking the HEDLER DF15 in operation, make sure that the
front plate is mounted correctly!
FOCUSING the HEDLER DF15
To focus the HEDLER DF15s light beam turn the focusing knob anti clock-wise (increased  oodlight characteristic) or clock-wise (increased
spotlight characteristic) to adjust the light beams size.
ACCESSORIES
It is recommended to use light units of the Hedler range only in combination with an original HEDLER 4-Leaf barndoor or one of the HEDLER
accessory re ectors. This permits adjusting the light beam to the requirements of any situation. In addition to the re ectors MaxiNorm, MaxiSun,
MaxiBrite, MaxiBeauty and MaxiBackground or the MaxiSoft folding re ectors (=softboxes) 30 x 30cm, 50 x 50cm, 70 x 70cm, 90 x 90cm,
L110 x 45cm and Octagon 100cm, a 4-Leaf barndoor, re ex umbrellas and grids for several softboxes/re ectors are available. Additionally, the
MaxiSpot 65 and MaxiSpot 130 are available for effect lighting.
For detailed information and the possibilities of forming the light beam to special characteristics, consult the current Hedler catalogue, it will be
sent to you upon request free of charge, or visit our website with the latest information.
HEDLER WARRANTY
All Hedler equipment is fully guaranteed against any material or manufacturing defects for three years after date of purchase. Parts made out of
glass, glass covers, fuses, Tungsten halogen bulbs and  ash bulbs are not covered by this warranty.
MAINTENANCE and REPAIR
Used under normal professional conditions, Hedler daylight light units require no maintenance. If repair is required, please, contact your dealer,
the authorized distributor in your country or the Hedler factory directly. Please note, that a pre-dismantled light unit could cause increased
repair costs.
APPROVAL and UL STANDARDS for SAFETY
The HEDLER DF15 light unit is SEV Standard tested, sign Schweiz HD 504.
The HEDLER DF15 light unit does not have the UL (Underwriters Laboratories) Standards for Safety sign for the USA and Canada.
HEDLER®
Systemlicht
The HEDLER DF15 light unit does not have the UL (Underwriters Laboratories) Standards for Safety sign for the USA and Canada.
PLEASE NOTE - SPECIAL SET-UP ADVICE
The HEDLER DF15 has an up side and an underside, setting-up the light unit it is important to take care of the
correct position of these sides. The light unit is set-up correctly, if the QuickFit Adapter (located at the front
side of the housing) is located beneath the bulb respectively the safety glass (as shown on the photograph).
To ensure a continuous operation, the HEDLER DF15 has to be set-up / operated in the position described
respectively as shown on the photograph.
If you take the light unit in operation in an upside-down set-up, the internal automatic temperature safety
switch will (according to the ambient conditions) switch off the light unit after some operation time until it has
cooled down. This is not a failure or a maloperation of the HEDLER DF15, it is a protection shutoff for the
internal electronic ballast to prevent overheating.

Safety instructions
The following safety instructions are valid for Hedler light units and their accessory. Please, read these safety
instructions completely before setting up a Hedler light unit and/or putting Hedler light unit(s) into operation.
Please contact Hedler Systemlicht GmbH, 65594 Runkel directly, if you do have a technical question concerning
Hedler light units and/or Hedler accessories. Please keep these safety instructions close in reach, if neccessary you
can download them from our website www.hedler.com as a PDF.
Hedler light unit(s), Hedler reectors, softboxes, reex umbrellas and/or Hedler accessories are designed for
indoor use only. Never use Hedler light unit(s), Hedler reectors, softboxes, reex umbrellas and/or Hedler
accessories outdoors.
Setting up and Putting into operation
• Always use a Hedler light unit in combination with a steady and secure standing light stand. Always work
within the light stand´s loading capacity, especially if you are using, or plan to use, large and/or heavy folding
reectors.
• Set up a Hedler light unit - light stand combination on leveled oor only. Please make sure for tilt resistance
while setting up / taking down and while in operation. Please make sure for an antislip stand while setting up /
taking down and while in operation.
• If not taking care of this safety instructions there is in particular a serious risk of squeezing, cutting and/or
burning caused by overthrowing, slipping or other reason(s) because of uncontrolled/unwanted movements
of a light unit(s) while setting up / taking down and/or while in operation.
• Always use a double securing like a safety wire, if you mount a Hedler light unit overhead.
• Before putting a Hedler light unit into operation check all safety and/or positioning srews for being screwed in
securely and/or hand-tight.
• Always keep a minimum distance of 100 cm between the safety glass (or accessories) and any combustible
materials and/or any inammable liquids, gases or explosives when a Hedler light unit is in use.
• Never use a Hedler light unit near any inammable liquids, gases, materials or explosives that may be ignited
by heat or spark.
• Never store any combustible material(s) and/or any inammable liquids, gases or explosives near any Hedler
light unit(s).
• Never touch a Hedler light unit with wet hand and/or feet.
• Never use a Hedler light unit in extremely dusty nor in exceptionally humid and/or wet conditions.
• Never obstruct the forced air cooling (intakes or exhausts) in any way when the Hedler light unit is in use.
• Never obstruct the cooling intakes or exhausts in any way when the Hedler light unit is in use.
• Under no circumstances - do not block the cooling fan of a Hedler light unit.
• Never obstruct any opening of the housing of a Hedler light unit. Never stick any item(s) into any opening
of the housing of a Hedler light unit. Otherwise there is the serious risk of an electrical shock, of a failure
malfunction of the Hedler light unit, a short-circuit and/or a re.
• Never carry a Hedler light unit by it´s power cord and/or it´s accessories.
• Always avoid the risk of a trip hazard caused by the power cord(s).
• Always take care not to squeeze, to overrun, to stretch and/or to buckle the power cord of the Hedler light
unit.
• Always take care that the power cord of a Hedler light unit is not worn out and/or is damaged in any way.
• Always take care not to cause a damage of the power cord of a Hedler light unit because of thermic,
mechanical and/or chemical reason(s). Avoid such a risk under any circumstances.
• Never use a Hedler light unit with a defective power cord and/or plug. Replacement of a defective power
cord has to be done by Hedler Systemlicht GmbH or an authorized specialist shop only. Never use a Hedler
light unit with a „repaired“ power cord. A defective power cord must be replaced.
• Some of the Hedler continuous light units do have a high power consumption. Always take care, that the
power supply is designed for such a high power consumption.
HEDLER Systemlicht GmbH Heerstrasse 112 D-65594 Runkel / Lahn www.hedler.com
Telefon + 49 - (0) 6482 918 100 Telefax + 49 - (0) 6482 918 111 eMail [email protected]
Safety instructions
HEDLER®
Systemlicht

HEDLER Systemlicht GmbH Heerstrasse 112 D-65594 Runkel / Lahn www.hedler.com
Telefon + 49 - (0) 6482 918 100 Telefax + 49 - (0) 6482 918 111 eMail [email protected]
Safety instructions
HEDLER®
Systemlicht
Operation
• Never use a Hedler light unit with a defective safety glass, a defective Pyrex® cover, a defective ash bulb,
defective bulb(s) and/or defective fuse(s).
• Never put a Hedler light unit into operation with a defective safety glass, a defective Pyrex® cover, a
defective ash bulb, defective bulb(s) and/or defective fuse(s).
• In the case of a defect or damage of the safety glass, the Pyrex® cover, the bulb(s), the ash bulb and/or
the fuse(s) of a Hedler light unit (particularly while it is in operation): switch of the light unit immediately,
disconnect it from the power supply, let it cool down completely and replace the defective safety glass,
Pyrex® cover, the bulb(s) and/or fuse(s) with the intended original Hedler spare part. Changing/replacing a
ash bulb of a Hedler light unit is not allowed to be done by a customer. Changing/replacing of a ash bulb has
to done by Hedler Systemlicht GmbH only.
• Never use a Hedler light unit unattended.
• Always disconnect Hedler light unit(s) from the power supply if it/they is/are not in use or in operation.
• Hedler light units are not designed for the use as a room lighting.
• Never use a Hedler light unit for any reason other than photographic or cinematic lighting.
• While in operation avoid to jar heavily, moving jerkily and/or overthrowing Hedler light units - this could
cause breaking, fragmenting into parts and/or bursting of the bulb(s) and/or ash bulbs and/or parts made out
of glass; because of this there is a serious risk of cutting and/or burning in particular and the risk of damage to
property like combustion, discoloring/staining, sparking, and so on.
• In the case of overthrowing, falling down and/or jaring heavily a Hedler light unit it has to be checked by
Hedler Systemlicht GmbH or a specialist shop authorized by Hedler Systemlicht GmbH for damages.
Safety glass, Pyrex® cover and ash bulbs, bulbs and fuses
• Before performing any kind of maintenance work on the light unit - always disconnect the Hedler light unit from
the power supply and let cool down the light unit completely.
• Before changing a safey glass or a Pyrex® cover - always disconnect the Hedler light unit from the power supply
and let cool down the light unit completely.
• Before changing a bulb and/or fuse - always disconnect the Hedler light unit from the power supply and let cool
down the light unit completely.
• For replacing a safety glass or Pyrex® cover - use the intended original Hedler spare parts only.
• For replacing a bulb and/or fuse(s) - use the intended original Hedler spare parts only.
• Never use a „repaired“ fuse.
• Changing/replacing a ash bulb of a Hedler light unit is not allowed to be done by a customer. Changing/
replacing of a ash bulb has to be done by Hedler Systemlicht GmbH only.
Additional safety instructions
• Hedler light units produce a very intensive and bright beam of light: never look directly into the bulb and/or
ash bulb while it is in operation. Never light or ash directly into the eye(s) of a human or an animal, this can
cause permanent damage to the eye(s).
• Some Hedler light units and/or Hedler reectors, parts of softboxes and reex umbrellas and some
accessories can heat up extremely while in operation: there is a serious risk of burning. Do not touch these
parts while they are in operation.
• Please let cool down Hedler light units and/or Hedler reectors, parts of softboxes and reex umbrellas and
some accessories completely after using them and before packing them away: not doing so can cause serious
burnig and/or the risk of sparking.
• Not used as intended and/or in the case of inappropriate use of Hedler light units and/or Hedler reectors,
parts of softboxes and reex umbrellas and accessories there is the serious risk of a (deadly) electrical shock.
• Hedler light units, Hedler reectors, softboxes, reex umbrellas and/or Hedler accessories are no toys,
they are unsuitable for use by children. Always keep Hedler light units, Hedler reectors, softboxes, reex
umbrellas and/or Hedler accessories out of the reach of children.
