Heiman HM-715NVS-AC User manual

MAIN FEATURE
●
●
●
●
●
HIGH RELIABILITY SENSOR
AUTO RESET AFTER ALARM
MCU PROCESSING ADOPTED
AUTO DETECT SENSOR FAILURE
INDUCED GAS- NATURAL GAS / LPG
SMT DESIGN, HIGH STABILITY●
MANUAL FOR COMBUSTIBLE GAS DETECTOR
PRODUCT INTRODUCTION
The product is suitable for the safety of
residential house, villas, hotels, markets, boarding house etc.
The product is wall mounted gas detector with high
stability.(hereinafter called detector) It is used for
detecting leaking gas. Advanced semiconductor sensor is
adopted to ensure high stability and long life. It is convenient
for mounting.
，
40mA(low power consumption type )
Rating Power: 3W (AC 220V supply)
Warm-up Time: about 180S
Alarm Level: 10%LEL
Sound Level: 85dB/m
Operating Temperature: -10 +50
Environment Humidity: 95 RH (no congelation)
Installation Mode: wall mounted
Alarm Output: relay output/sound & flash alarm
RF 315MHz or 433MHz (wireless type)
Radio Distance: 100m in open area (wireless type)
Outline Size 115*72*35mm
Execute Criterion GB15322.2-2003
≤
≤
≥
℃ ～ ℃
≤ ％
：
：
Alarm Indicator: red LED flash
Failure Indicator: yellow LED on & beeper long- buzz
1
TECHNICAL SPECIFICATION
Operating Voltage DC9-24V or AC100- 240V
Static Current 90mA
30mA(low power consumption type )
Alarm Current 100mA
：
： ≤
≤
：≤
PRODUCT PROFILE
INSTALLATION
1. Please confirm the induced gas is heavier than air, or lighter
than air. The gas is heavier than air: LPG etc. The gas is
lighter than air: natural gas, marsh gas and etc.
2. Choosing the suitable position to install the Detector
according to the gas specific gravity. Detecting the gas
heavier than air: Installation height from floor: 0.3-
1.0m,Semi-diameter to gas source: <1.5m;Detecting the gas
lighter than air: Installation height from ceiling: 0.3-1.0m
,Semi-diameter to gas source: <1.5m.
3. Fix the screw into the wall firmly, then hang the detector.
4. Avoid installing the detector close to the following sources
of interference: direct air flow from vents, fans, doors,
windows, sources of steam, oil vapor, etc.
5. All wires installation must accord with the National and
Local effective laws and criteria. The wires must have the
suitable size and colorful marks for avoiding connecting
error. And unsuitable connection of wires will result in the
alarm error while gas leaking happened.
Powe r LED(green)
Working LED
Manipulator (optional accessory )
Manipulator
Control line
(Connect with detector)
Mechanical Arm
Rotat e Axis
Fi xi ng Pa rt
Electromagnetism valve (optional accessory)
Manual pole
Control line (connect with detector)
Test button
DETECTOR
DIAMETER:
3M
GAS OVEN
FLOOR
CEILING
FLOO R
M312-2EVer1.0
Ga s Convection Window

The Gas Detector can be used independently, or with
wired networks output functions.
1. Independently
(1) Choosing a suitable position to install the Detector
according to the INSTALLATION.
(2) With DC 12V or AC 220V power supply, the green LED
flashes once a second for about 3 minutes continuously,
that runs the inside sensor (warm-up state). After doing
that the green LED lights, that means the Detector comes
into normal working state.
2.In wired network
(1) Choosing a suitable position to install the Detector
according to the INSTALLATION. To connect the
Detector with the controller, with the N.C. or N.O. contact
optional accord with the controller system.
(2) With DC 12V or AC 220V power supply, the green LED
flashes once a second for about 3 minutes continuously,
that runs the inside sensor (warm-up state). After doing
that the green LED lights, that means the Detector comes
into normal working state.
3. While detecting the gas leaking, the red LED flashes, the
Buzzer sends out the alarm sound "Di Di", and output
the network signal. If the detector is connected with valve
or manipulator, it will drive them to shut off the gas pipeline
supply. The Detector will resume to the detecting state after
the gas dispersed.
4. For model series without driving manipulator ,it will enter
the test status when press the test button and exit when
loosen. For model series driving manipulator, it will enter
the test status after pressing the test button for more than 4
seconds. if less than 4 seconds, it is switch on /off the
manipulator function.
5. The buzzer long beeps and the yellow LED ON means the
inside sensor failure. Please cut off the power, and contact
the After-sales Service Center.
6. If the Detector runs disorderly, cut the power off and rerun
…
2
OPERATING INSTRUCTION
TERMINAL BLOCK FIGURE
TEST
Suggestion: the user must brush and clean the gas
convection holes with a little cleanser every three months, and
must retest the Detector after cleaning for preventing the
cleanser into the Detector.
NORMAL MAINTENANCE
The Detector alarms while the gas density in air exceed the
alarm level. The relative treatments as below:
1. Shut down the tube valve right away.
2. Open the window and make the air flow rapidly.
3. Extinguish all fire sources and do not use anything can make
fire, e.g. lighters, matches, etc.
4. Avoiding open or close the power all kinds of electric
Equipment.
5. Check the reason of gas leaking, and notice the relative
departments and professional persons in time.
EMERGENCY ALARM TREATMENT
NOTICE
1. The detector must be installed and connected correctly. It
can not work if without the power supply orderly.
2. P l ease period ic ally mainten ance accord ing t o the
directions.
3. The detector must have a test every half a year.
4. For various reasons, including, but not limited to, changes
in environ mental conditions, elect ric or electronic
disruptions and tampering, the Product may not perform as
expected. The user is advised to take all necessary
precautions for his/her safety and the protection of his/her
property.
To test the installed detector while using independently or
in network, you can give some gas around in distance of 5cm
t o t h e g a s c on ve ct i o n h ol e s b y u si ng u n- i g n i t io n
lighter. Testing frequentl y may r esult in reducing the
sensitivity of the Detector. The alarm density of gas is set
according with the criteria of GB15322.2-2003.The Detector
will stop alarm and resume to the detecting state while the gas
density reduced to lower than the alarm level. The alarm
output switches can connect with the defense input switches of
alarm system.
MANUAL FOR COMBUSTIBLE GAS DETECTOR
P1
Power input
P2 OUT 1 OUT2 SIG1 SIG2
NC/NO Valve/Manipulator
Note Free polar with pow er input but not with valve or manipulator：
+
-
M312-2EVe r1.0
LED INFORMATION
RED LED FLA SH GAS LEAKIN G
WARM-UP INSIDE SENSOR
GREEN LED Fla sh/ 0.5S o n 0.5S off
YELLOW LED ON SENS O R FAILURE
GREEN LED ON POWER LE D
