Heinner HVC-V1200BL User manual

VACUUM CLEANER
Model: HVC-V1200BL
www.heinner.ro
•Vacuum cleaner
•Power: 1200W
•Suction power: 240W

www.heinner.com 1200W, 50Hz, 220-240V
1
Before using the appliance, please read carefully this instruction manual and keep it for future
reference.
This instruction manual is designed to provide you with all required instructions related to the
installation, use and maintenance of the appliance.
In order to operate the unit correctly and safety, please read this instruction manual carefully
before installation and usage.
I. INTRODUCTION
II. PACKAGE CONTENT
➢Vacuum cleaner
➢Floor brush
➢Nozzle
➢User manual
➢Warranty card
Va multumim pentru alegerea acestui produs!

www.heinner.com 1200W, 50Hz, 220-240V
2
III. DESCRIPTION OF THE APPLIANCE
1. Modern and elegant design
2. Multiple air-filter system guarantees a hygienic cleaning
3. Drivers accessories: floor brush, nozzle etc
4. User-friendly wire rewinder pedal
IV. KNOW YOUR VACUUM CLEANER

www.heinner.com 1200W, 50Hz, 220-240V
3
V. IMPORTANT SAFETY INSTRUCTIONS
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
If the supply cord is damaged, it must be replaced by the manufacture or its service
agent or a similarly qualified person in order to avoid a hazard. For household use
only.
Do not use for absorbing detergent, kerosene, glass, needle, cigarette ash, water,
match etc.
The appliance should not be exposed to heat
Unplug the appliance from the mains supply. Socket after use and before every
cleaning pull the mains cable, in order to disconnect the appliance from the mains.

www.heinner.com 1200W, 50Hz, 220-240V
4
Do not put any object into openings. Do not use with any opening blocked. Keep the
appliance free of dust, lint, hair etc.
Do not use the vacuum cleaner without dust container or dust filter in place.
Do not vacuum any flour, cement etc, in order to avoid the overloads.
The appliance should only be cleaned with a dry or damp cloth ,it should never
immersed in water. Do not use any solvents for cleaning.

www.heinner.com 1200W, 50Hz, 220-240V
5
VI. ASSEMBLY VACUUM CLEANER
Connect the hose with vacuum cleaner
Insert flexible hose into the air-intake: Press the knob until it clicks into the position
Remove the flexible hose: Unplug the appliance and press the knob at the end of
the hose. Remove it from the air-intake opening.
Fit the telescopic to the angled pipe.
Fit the floor brush to the telescopic tube.

www.heinner.com 1200W, 50Hz, 220-240V
6
VII. OPERATION
A yellow mark on power cord shows the ideal cable length. Do not expend the cable
beyond the red mark. To rewind the power cord, press the rewinder pedal with one
hand and guide the cord with the other hand.
Press the power switch to switch the appliance on. Use the electronic speed adjusting
to control the suction power of the cleaner.
The suction power can be adjusted with the sliding control on the angled pipe too.
Put the telescopic tube into the fixing hook of the appliance when you have a break.
Caution: Do not transfer the appliance when the fixing hook is used.

www.heinner.com 1200W, 50Hz, 220-240V
7
VIII. CLEANING TOOLS
Crevice tool:
For cleaning corner edge and draws etc:
Where is difficult to reach, such as gaps and the keyboard, bookshelf and windows.
Sofa brush: For cleaning bed, sofa, couch etc.
Use of the selector on floor brush: Bristles extended for carpets. Bristles retracted for
hard floors.
If the angled pipe has blockage. Insert it into the air-intake and switch the appliance
on.

www.heinner.com 1200W, 50Hz, 220-240V
8
IX. CLEANING AND MAINTENANCE
Empty the dust container
1. After removing the flexible hose ,press the cover lock button and open the
dust container.
2. Remove the dust filter from the container.
3. Replace the dust filter in the container.
4. Close the dust container until it is locked in the position.
Change filter
Replace the motor filter: Open the dust container and remove the motor filter. Fix
the new filter in the position.
Replace the outlet filter: Detach the grille by pulling firmly away from the appliance,
remove the outlet filter and replace the new filter. Fix the grille again.
Clean the filter: Clean the filter in water and allow them to dry completely before
replace them.

www.heinner.com 1200W, 50Hz, 220-240V
9
X. ERROR DETECTION
Before you contact our services center, please check the following points:
Problem
Possible reason
Active
Motor does not start
-Power card not firmly
plugged into outlet
-Outlet damaged
-Cleaner not switch on
-Plug unit firmly
-Check the outlet
-Switch on the
appliance.
Suction power is weaker
-unit clogged
-Dust filter needs
cleaning
-Dust container not in
position
-Filter blocked
-Remove the
blockage
-Clean the dust
filter
-Close the dust
container
-Clean the filter
The wire can not be winded
completely .
The wire may diverge the wire
wheel.
Draw the wire a
little then rewind.
The wire can not be draw out.
The wire may wind disorder
Press the rewinder
button and try
again.
Speed adjust does not work
Appliance is defective
Repair the
appliance
(only specialist)
Power card winds unwanted
back
Rewind mechanisms is
defective
Repair the
appliance
(only specialist)
The dust container can not be
closed
Dust filter is not in the
position
Fix the dust filter
and try again
