Refrigerator Service and Maintenance Manual
i.Series®and Horizon Series™ - Undercounter
360398/A
Laboratory
i.Series
iLR105-GX
Horizon Series
HLR105-GX
Pharmacy
i.Series
iPR105-GX
Horizon Series
HPR105-GX
Blood Bank
i.Series
iBR105-GX
Horizon Series
HBR105-GX

Document Updates
The document is furnished for information use only, is subject to change without notice and should not be construed as a
commitment by Helmer Scientic. Helmer Scientic assumes no responsibility or liability for any errors or inaccuracies that may
appear in the informational content contained in this material. For the purpose of clarity, Helmer Scientic considers only the most
recent revision of this document to be valid.
Notices and Disclaimers
Condential / Proprietary Notices
Use of any portion(s) of this document to copy, translate, disassemble or decompile, or create or attempt to create by reverse
engineering or otherwise replicate the information from Helmer Scientic products is expressly prohibited.
Copyright and Trademark
Copyright © 2019 Helmer, Inc. Helmer®, i.Series®, i.C³®, Horizon Series™, and Rel.i™ are registered trademarks or trademarks of
Helmer, Inc. in the United States of America. All other trademarks and registered trademarks are the property of their respective
owners. Helmer, Inc., doing business as (DBA) Helmer Scientic and Helmer.
Disclaimer
This manual is intended as a guide to provide the operator with necessary instructions on the proper use and maintenance of
certain Helmer Scientic products.
Any failure to follow the instructions as described could result in impaired product function, injury to the operator or others, or void
applicable product warranties. Helmer Scientic accepts no responsibility for liability resulting from improper use or maintenance of
its products.
The screenshots and component images appearing in this guide are provided for illustrative purposes only, and may vary slightly
from the actual software screens and/or product components.
Helmer Scientic
14400 Bergen Boulevard
Noblesville, IN 46060 USA
www.helmerinc.com
Part No. 360398/A
Document History
Revision Date CO Supersession Revision Description
A 15 JAN 2019 14198 n/a Initial release.
* Date submitted for Change Order review. Actual release date may vary.

Helmer Scientic i.Series® and Horizon Series™Refrigerator - Undercounter Service and Maintenance Manual
360398/A 2
Contents
1 About This Manual...................................................................................4
1.1 Intended Audience...............................................................................4
1.2 Model Reference................................................................................4
1.3 Intended Use...................................................................................4
1.4 Safety Symbols and Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.5 Avoiding Injury..................................................................................6
1.6 Model and Input Power ...........................................................................6
1.7 Product Labels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
i.Series Information............................................................................8
2 InstallationandConguration .........................................................................8
2.1 Location Requirements ...........................................................................8
2.2 Placement and Leveling ..........................................................................8
2.3 Stacked Undercounter Units .......................................................................8
2.4 Connect Back-Up Power..........................................................................9
2.5 Prepare for Monitoring............................................................................9
2.6 CongureStorage ..............................................................................12
2.7 Optional Adapter Kits for Medication Dispensing Locks .................................................13
2.8 Reverse Door Hinges and Handle..................................................................14
3 Controls...........................................................................................18
3.1 Home Screen and Screensaver ...................................................................18
3.2 Home Screen Functions .........................................................................18
3.3 Alarm Reference ...............................................................................18
3.4 Settings ......................................................................................19
3.5 Sensor Calibration..............................................................................23
4 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4.1 Alarm Tests ...................................................................................28
4.2 Test and Replace Back-up Batteries ................................................................30
4.3 Check Probe Bottle .............................................................................31
4.4 LED Lamp Strip................................................................................31
4.5 Upper and Lower Door Hinge Cams ................................................................31
4.6 Display Board Battery ...........................................................................32
4.7 Upgrade System Firmware .......................................................................32
4.8 Clean the Refrigerator...........................................................................32
5 Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5.1 Refrigerant....................................................................................34
5.2 Remove / Replace Unit Cooler Cover ...............................................................34
6 Troubleshooting....................................................................................36
6.1 Access System Problems ........................................................................36
6.2 Chamber Temperature Problems ..................................................................36
6.3 Alarm Activation Problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
6.4 Condensation Problems .........................................................................37

Helmer Scientic i.Series® and Horizon Series™Refrigerator - Undercounter Service and Maintenance Manual
360398/A 3
7 i.Series Parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
8 Schematics ........................................................................................41
8.1 iBR, iPR and iLR Models.........................................................................41
Horizon Series Information.....................................................................43
9 InstallationandConguration ........................................................................43
9.1 Location Requirements ..........................................................................43
9.2 Placement and Leveling .........................................................................43
9.3 Stacked Undercounter Units ......................................................................43
9.4 Connect Back-Up Power.........................................................................44
9.5 Prepare for Monitoring...........................................................................44
9.6 CongureStorage ..............................................................................47
9.7 Optional Adapter Kits for Medication Dispensing Locks .................................................48
9.8 Reverse Door Hinges and Handle..................................................................48
10 Controls...........................................................................................52
10.1 Monitor and Control Interface .....................................................................52
10.2 Alarm Reference ...............................................................................54
10.3 Settings ......................................................................................55
11 Maintenance .......................................................................................59
11.1 Alarm Tests ...................................................................................60
11.2 Test and Replace Back-up Batteries ................................................................61
11.3 Check Probe Bottle (if installed) ...................................................................62
11.4 LED Lamp Strip................................................................................62
11.5 Upper and Lower Door Hinge Cams ................................................................62
11.6 Clean the Refrigerator...........................................................................62
12 Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
12.1 Refrigerant....................................................................................64
12.2 Remove / Replace Unit Cooler Cover ...............................................................64
13 Troubleshooting....................................................................................65
13.1 Access System Problems ........................................................................65
13.2 Chamber Temperature Problems ..................................................................65
13.3 Alarm Activation Problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
13.4 Condensation Problems .........................................................................66
14 Horizon Series Parts ................................................................................67
15 Schematics ........................................................................................70
15.1 HBR, HLR and HPR Models ......................................................................70
15.2 HBR, HLR and HPR Models (without Access Control) ..................................................71
15.3 HBR, HLR and HPR Models (with Access Control).....................................................72
Appendix A: Compliance ................................................................................73
Safety Compliance...................................................................................73
Environmental Compliance ............................................................................73
Appendix B: Warranty...................................................................................74

Helmer Scientic i.Series® and Horizon Series™Refrigerator - Undercounter Service and Maintenance Manual
360398/A 4
1 About This Manual
1.1 Intended Audience
This manual provides information on how to use i.Series®and Horizon Series™undercounter laboratory, blood bank, and pharmacy
refrigerators. It is intended for use by end users of the refrigerator and authorized service technicians.
1.2 Model Reference
Models are indicated by a distinguishing model number that corresponds to the series, type, number of doors, and capacity of the
refrigerator. For example, “iLR105-GX” refers to an i.Series Laboratory Refrigerator with 1 door and a capacity of 5 cu ft.
1.3 Intended Use
Note
This equipment has been tested and found to comply with the limits for a Class Adigital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required
to correct the interference at his own expense.
Helmerrefrigeratorsareintendedforthestorageofbloodproductsandothermedicalandscienticproducts.
1.4 Safety Symbols and Precautions
Symbols found in this document
The following symbols are used in this manual to emphasize certain details for the user:
Task Indicates procedures which need to be followed.
Note Provides useful information regarding a procedure or operating technique when using Helmer
Scienticproducts.
NOTICE Advises the user against initiating an action or creating a situation which could result in damage to
equipment; person injury is unlikely.
CAUTION Advises the user against initiating an action or creating a situation which could result in damage
to equipment or impair the quality of the products or cause minor injury.
WARNING Advises the user against initiating an action or creating a situation which could result in damage
to equipment and serious personal injury to a patient or the user.

Helmer Scientic i.Series® and Horizon Series™Refrigerator - Undercounter Service and Maintenance Manual
360398/A 5
Symbols found on the unit
The following symbols may be found on the refrigerator or refrigerator packaging:
Caution: Risk of damage to equipment or
danger to operator Earth / ground terminal
Caution: Hot surface Protective earth / ground terminal
Caution: Shock / electrical hazard Refer to documentation
Warning: Flammable material Caution: Unlock all casters
Warning:Crushingofhands/ngers
DD.1.5 370198-1/A
CAUTION - RISK OF FIRE OR EXPLOSION. DISPOSE OF
PROPERLY INACCORDANCE WITH FEDERAL OR
LOCAL REGULATIONS. FLAMMABLE REFRIGERANT
USED.
ATTENTION - RISQUE D’INCENDIE OU D’EXPLOSION.
ÉLIMINER DE FAÇON ADAPTÉE SELON LES
RÈGLEMENTS FÉDÉRAUX OU LOCAUX. UTILISATION
DE FLUIDE FRIGORIGÈNE INFLAMMABLE.
Caution: Dispose of properly
Warning: Cold surface below -30°C
DD.1.4A 370196-1/A
DANGER - RISQUE D’INCENDIE OU
D’EXPLOSION. UTILISATION DE FLUIDE FRIGORIGÈNE
INFLAMMABLE. A FAIRE RÉPARER UNIQUEMENT PAR
LE PERSONNEL D’ENTRETIEN QUALIFIÉ. NE PAS
PERCER LES TUBES FRIGORIFIQUES.
DANGER - RISK OF FIRE OR EXPLOSION.
FLAMMABLE REFRIGERANT USED. TO BE
REPAIRED ONLYBY TRAINED SERVICE
PERSONNEL. DO NOT PUNCTURE
REFRIGERANT TUBING. Danger: Repair only by trained service
personnel.
DD.1.6 370199-1/A
ATTENTION - TUBES FRIGORIFIQUES PERCÉS
ENTRAÎNANT UNRISQUE D’INCENDIE OU D’EXPLOSION.
SUIVRE ATTENTIVEMENTLES INSTRUCTIONS DE
MANIPULATION.UTILISATIONDE FLUIDE FRIGORIGÈNE
INFLAMMABLE.
CAUTION - RISK OF FIRE OR EXPLOSION DUE TO
PUNCTURE OF REFRIGERANT TUBING; FOLLOW
HANDLING INSTRUCTIONS CAREFULLY. FLAMMABLE
REFRIGERANT USED. Caution: Follow handling instructions
carefully.
DANGER - RISK OF FIRE OR EXPLOSION. FLAMMABLE
REFRIGERANT USED. DO NOT USE MECHANICAL
DEVICES TO DEFROST REFRIGERATINGEQUIPMENT.
DO NOT PUNCTURE REFRIGERANT TUBING.
DD.1.3 370195-1/A
DANGER - RISQUE D’INCENDIE OU D’EXPLOSION.
UTILISATION DE FLUIDE FRIGORIGÈNE INFLAMMABLE.
NE PAS UTILISER DE DISPOSITIFS MÉCANIQUES POUR
DÉGIVRER LES APPAREILSDE RÉFRIGÉRATION. NE
PAS PERCER LES TUBES FRIGORIFIQUES.
Danger: Do not use mechanical devices to
defrost.
CAUTION - RISK OF FIRE OR EXPLOSION. FLAMMABLE
REFRIGERANT USED. CONSULT REPAIR MANUAL /
OWNER’S GUIDE BEFORE ATTEMPTINGTO INSTALL OR
SERVICE THIS PRODUCT.ALL SAFETY PRECAUTIONS
MUST BE FOLLOWED.
DD.1.4B 370197-1/A
ATTENTION - RISQUE D’INCENDIE OU D’EXPLOSION.
UTILISATION DE FLUIDE FRIGORIGÈNE INFLAMMABLE.
CONSULTER LE MANUEL DE RÉPARATION / LE GUIDE
D’ENTRETIEN AVANT DE TENTER D’INSTALLER OU
D’ENTRETENIR CET APPAREIL.TOUTES LES
PRÉCAUTIONS DE SÉCURITÉ DOIVENT ÊTRE SUIVIES.
Caution: Consult instruction manual prior
to installation or service.
CAUTION - RISK OF FIRE OR EXPLOSION DUE TO
FLAMMABLE REFRIGERANT USED. FOLLOW HANDLING
INSTRUCTIONS CAREFULLY IN COMPLIANCE WITH U.S.
GOVERNMENT REGULATIONS.
DD.2.2 370203-1/B
ATTENTION - RISQUE D’INCENDIE OU D’EXPLOSION EN
RAISON DE L’UTILISATIONDE FLUIDE FRIGORIGÈNE
INFLAMMABLE. SUIVRE ATTENTIVEMENTLES
INSTRUCTIONS DE MANIPULATION CONFORMÉMENT
AUX RÈGLEMENTS DU GOUVERNMENT DES ÉTATS-UNIS.
Caution: Follow handling instructions
carefully in compliance with U.S. Government
regulations
Pantone 185 (Red)
Warning: Puncturing or opening refrigerant
circuit might be expected.
THIS UNIT IS INTENDED FOR USE IN COMMERCIAL,
INDUSTRIAL, OR INSTITUTIONAL OCCUPANCIESAS
DEFINED IN THE SAFETY STANDARD FOR
REFRIGERATION SYSTEMS,ANSI/ASHRAE 15.
DD.1.10 370202-1/A
CETTE UNITÉ EST DESTINÉE À UNE UTILISATION
COMMERCIALE, INDUSTRIELLE OU INSTITUTIONNELLE,
COMME DÉFINI DANS LA NORME DE SÉCURITÉ DES
SYSTÈMES FRIGORIFIQUES, ANSI/ASHRAE 15.
Intended use per ANSI/ASHRAE

Helmer Scientic i.Series® and Horizon Series™Refrigerator - Undercounter Service and Maintenance Manual
360398/A 6
1.5 Avoiding Injury
WARNINGS
• Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by
the manufacturer.
• Do not damage the refrigerant circuit.
Review safety instructions before installing, using, or maintaining the equipment.
♦Before moving unit, ensure door is closed and casters (if installed) are unlocked and free of debris.
♦Before moving unit, disconnect the AC power cord and secure the cord.
♦Never physically restrict any moving component.
♦Avoid removing electrical service panels and access panels unless so instructed.
♦Keep hands away from pinch points when closing the door.
♦Avoid sharp edges when working inside the electrical compartment and refrigeration compartment.
♦Ensure products are stored at recommended temperatures determined by standards, literature, or good
laboratory practices.
♦Proceed with caution when adding and removing product from the refrigerator.
♦Do not open multiple loaded drawers at the same time.
♦Use manufacturer supplied power cord only.
♦Avoid risk of ignition by using only manufacturer supplied components and authorized personnel when servicing the unit.
♦ Usingtheequipmentinamannernotspeciedbythemanufacturermayimpairtheprotectionprovidedbytheequipment.
♦Ensure product is stored safely, in accordance with all applicable organizational, regulatory, and legal requirements.
♦ Therefrigeratorisnotconsideredtobeastoragecabinetforammableorhazardousmaterials.
♦ Usecautionwhenmovingastackedconguration.
CAUTION
Decontaminatepartspriortosendingforserviceorrepair.ContactHelmerScienticoryourdistributorfordecontamination
instructions and a Return Authorization Number.
1.6 Model and Input Power
Note
Service information varies depending on the model and power requirements.
Table 1. Model and Input Power
Model Voltage Frequency Current Draw
105
115V 60 Hz 1.4 A
220-240V 50 Hz 0.85 A
220-240V 60 Hz 0.85 A
* Amperage values are subject to change. Refer to the product specication label on your unit for current values.

Helmer Scientic i.Series® and Horizon Series™Refrigerator - Undercounter Service and Maintenance Manual
360398/A 7
1.7 Product Labels
Thisinformationappearsontheproductspecicationlabel,locatedontherearoftherefrigeratortowardthebottomleftcorner.
The model also appears on a label located in the chamber on the upper side of the right wall.
Note
Informationcontainedinthisspecicationlabelvariesdependingonthemodelandpowerrequirements.
Sample Product Specication label.
Label Description
A Model (REF)
B Serial number
C Power requirements
C
B
A

Helmer Scientic i.Series® and Horizon Series™Refrigerator - Undercounter Service and Maintenance Manual
360398/A 8
i.Series Information
2 InstallationandConguration
2.1 Location Requirements
WARNING
Keep all ventilation openings in the enclosure or, in the structure for building-in, clear of obstruction.
♦ Hasagroundedoutletmeetingtheelectricalrequirementslistedontheproductspecicationlabel.
♦Is clear of direct sunlight, high temperature sources, and heating and air conditioning vents.
♦Has a minimum 3“ (76 mm) of space behind the refrigerator for clearance and feature access.
♦ Meetslimitsspeciedforambienttemperature(15˚Cto32˚C)andrelativehumidity.
2.2 Placement and Leveling
CAUTION
• To prevent tipping, ensure the casters (if installed) are unlocked and the door is closed before moving the refrigerator.
• Use of leveling feet or casters is required.
• Do not sit, lean, push or place heavy objects on top surface.
• Do not lean on or push down on an open door or extended drawers.
• To avoid damaging refrigerant tubing or risking refrigerant leak, use caution when moving or operating the unit.
1. Move refrigerator into place. Lock casters if installed.
2. Ensure refrigerator is level.
Note
Helmerrecommendstheuseoflevelingfeetandwallandoorbrackets(PN400472-2)forstabilization.ContactHelmer
Technical Service for parts and instruction.
2.3 Stacked Undercounter Units
CAUTION
• Forstackedconguration,bothunitsmusthavelevelingfeetinstalled.
• Back brace bars and front stabilizing brackets must be installed (Blue - PN 400821-1; Stainless Steel - PN 400821-2).
• When stacking units, place the heavier unit on the bottom.
• Do not open multiple loaded drawers at the same time.
• Do not lean on or push down on an open door or extended drawers.
Contact Helmer or your distributor for more information regarding the stacking kit and methods to secure both units to the wall
and/oroor.
i.Series

Helmer Scientic i.Series® and Horizon Series™Refrigerator - Undercounter Service and Maintenance Manual
360398/A 9
2.4 Connect Back-Up Power
The monitoring system and chart recorder each have a back-up battery system enabling a period of continuous operation if power
is lost.
Battery life varies by manufacturer, voltage level remaining as well as whether optional Access Control is installed. Providing full
power is available, Access Control is not installed and no battery-related alarms are active, back-up power for the monitoring
system is available for up to 20 hours (the Low Battery alarm will activate after approximately 18 hours of battery use). Providing
full power is available, back-up power for the monitoring system and optional Access Control system is available for up to
2.5 hours.
CAUTION
Before installing or replacing batteries, switch AC power and back-up battery switches OFF. Disconnect refrigerator from
AC power.
Notes
• The optional Access Control system uses the monitoring system back-up battery for back-up power in the event of
power failure.
• The monitoring system will start on back-up battery power alone. If the refrigerator was not previously connected to AC
power and the back-up battery is switched on, the monitoring system will begin running on back-up battery power.
• If AC power is lost, the monitoring system will automatically disable some features to prolong back-up battery power.
Data collection will continue until back-up battery power is depleted.
The back-up battery is located below the chamber, behind the right side panel. The panel cover must be removed to access
the battery.
Monitoring system back-up battery.
2.5 Prepare for Monitoring
The back-up battery switch is switched OFF for shipping. Switch the back-up battery switch ON to provide the monitoring system
and optional Access Control system with back-up power in the event of AC power failure.
Temperature Probes
Notes
• Temperature probes are fragile; handle with care.
• Remote probes may also be introduced through the existing port and immersed in existing probe bottles.
• External probes should not be routed into the chamber through the door opening as this may cause issues with the
door seal.
• Solid ballast (if installed) should be placed in the bracket in a horizontal position.
A solid ballast or probe bottle and container of glycerin have been provided with this unit. When using the probe bottle, mix the
glycerin with water to create a solution which simulates the product stored in the refrigerator. The product simulation solution
temperaturereectstheproduct’stemperatureduringnormaloperation.
The probe bottle should contain 4 oz. (120 mL) of product simulation solution at a 10:1 ratio of water to glycerin.
i.Series

Helmer Scientic i.Series® and Horizon Series™Refrigerator - Undercounter Service and Maintenance Manual
360398/A 10
Probe bottle with probe. Solid ballast with probe. Rear access port.
Fill Probe Bottle (if included)
1. Remove probe(s) from bottle and remove bottle from bracket.
2. Removecapandllwith4oz.(120mL)ofproductsimulationsolution.
3. Install cap and place bottle in bracket.
4. Replace probe(s), immersing at least 2” (50 mm) in solution.
Install Additional Probe Through Rear Port
1. Peel back putty to expose port.
2. Insert probe through port into chamber.
3. Insert probe into bottle or secure in ballast with thumbscrew.
4. Replace putty, ensuring a tight seal.
Chart Recorder (if included)
Note
• If chart recorder has been operating on battery power, the battery should be replaced to ensure the back-up source has
proper charge.
• For complete information, refer to the Temperature Chart Recorder Operation and Service Manual.
The chart recorder has a back-up battery system, enabling a period of continuous operation if power is lost. Battery life varies by
manufacturer as well as voltage level remaining. Providing full power is available, back-up power for the temperature chart recorder
is available for up to 14 hours.
Prior to use:
Route the chart recorder probe through the rear access port and place in bottle with primary monitor probe, or install in ballast and
secure with thumb screw.
Set up and Operation
Access chart recorder by pulling the door to open.
Install Battery
Connect the leads to the battery to provide back-up power to the chart recorder.
i.Series

Helmer Scientic i.Series® and Horizon Series™Refrigerator - Undercounter Service and Maintenance Manual
360398/A 11
Install / Replace Chart Paper
Notes
• For accurate temperature reading, ensure the current time is aligned with the time line groove when chart knob is
fully tightened.
• Contact Helmer Customer Service or your distributor to reorder chart paper; part number 220366 (52 sheets).
Chart recorder stylus and time line groove
1. Press and hold Cbutton.Whenstylusbeginstomoveleft,releasebutton.TheLEDashes.
2. When stylus stops moving, remove chart knob then move knob up and away.
3. Place chart paper on chart recorder.
4. Gently lift stylus and rotate paper so current time line corresponds to time line groove.
5. Hold chart paper in place while making sure the chart knob is fully tightened. (Failure to fully tighten the knob can result in paper
slipping and losing time.)
6. Press and hold C button. When stylus begins to move right, release button.
7. Conrmstylusismarkingonpaperandstopsatthecorrecttemperature.
8. Calibrate chart recorder to match primary temperature if needed and close recorder door.
External Monitoring Devices
The remote alarm interface is a relay switch with three terminals:
♦Common (COM)
♦Normally Open (NO)
♦Normally Closed (NC)
Terminals are dry contacts and do not supply voltage. Interface circuit is either normally open or normally closed, depending on
terminals used.
Requirements for your alarm system determine which alarm wires must connect to terminals.
CAUTION
• Theinterfaceontheremotealarmmonitoringsystemisintendedforconnectiontotheenduser’scentralalarm 
system(s) that uses normally-open or normally-closed dry contacts.
• Ifanexternalpowersupplyexceeding33V(RMS)or70V(DC)isconnectedtotheremotealarmmonitoringsystem’scircuit,
the remote alarm will not function properly and may cause damage to the control board or result in injury to the user.
The terminals on the remote alarm interface have the following maximum load capacity:
♦115V or 230V: 1 A at 33 V (AC) RMS or 70 V (DC)
Connect to Remote Alarm Interface
1. On the electrical box, locate the remote alarm terminals.
2. Connect remote alarm wires to appropriate terminals, according to requirements for your alarm system.
3. Use a cable tie to relieve strain on alarm wires (as necessary).
i.Series

Helmer Scientic i.Series® and Horizon Series™Refrigerator - Undercounter Service and Maintenance Manual
360398/A 12
2.6 CongureStorage
CAUTION
• Before moving drawers or shelves, ensure they are completely empty for safe lifting.
• Maximum drawer or shelf load is 100 lbs (46 kg).
Note
Before moving storage components, protect stored items in refrigerator from extended exposure to adverse temperature.
Product Loading Guidelines
When loading your refrigerator, take care to observe the following guidelines:
♦Never load refrigerator beyond capacity.
♦Always store items within shelves or drawers.
♦ Temperatureuniformityismaintainedbyaircirculation,whichcouldbeimpededifunitisoverlled,particularlyatthe
top or back. Ensure a minimum of 2” (50 mm) clearance is provided below the fan.
Note
Productsstackedagainstbackwallmayobstructairowanda󰀨ectperformanceofunit.
Drawers
Remove Drawer
1. Pull drawer out until it stops.
2. On the right rail, locate the release tab and press downward.
3. While holding the right release tab downward, locate the release tab on the left rail and press upward.
4. Pull drawer free of slides.
Install Drawer
1. Align end guides on drawer with slides.
2. Gently push drawer or basket into chamber until it stops.
3. Pull drawer out until it stops; check for smooth operation.
Move Drawer Slides
1. Using a screwdriver, remove bracket retainers.
2. Tap brackets upward to disengage standards.
3. Remove slides from standards.
4. Insert slides into standard at appropriate height.
5. Tap brackets downward to engage standards.
6. Using a screwdriver, install bracket retainers.
i.Series

Helmer Scientic i.Series® and Horizon Series™Refrigerator - Undercounter Service and Maintenance Manual
360398/A 13
Shelves
Remove Shelf
1. With one hand, lift front edge of the shelf from the front brackets.
2. With the other hand, reach under the shelf and bump rear edge of the shelf upward to disengage rear brackets.
Install Shelf
1. Insert shelf into chamber, placing it on brackets.
2. Gently bump rear edge of the shelf downward to engage brackets.
3. Pulling shelf forward gently; shelf should not disengage from rear brackets
Move Shelf Brackets
1. Using a screwdriver, remove bracket retainers.
2. Tap brackets upward to disengage standards.
3. Remove brackets from standards.
4. Insert brackets into standard at appropriate height.
5. Tap brackets downward to engage standards.
6. Using a screwdriver, install bracket retainers.
2.7 Optional Adapter Kits for Medication Dispensing Locks
Contact Helmer Technical Service or your distributor for service documentation pertaining to medication dispensing locks.
i.Series

Helmer Scientic i.Series® and Horizon Series™Refrigerator - Undercounter Service and Maintenance Manual
360398/A 14
2.8 Reverse Door Hinges and Handle
Notes
• The following instructions apply to reversing a right-hinged door to a left-hinged door. Some steps will need to be
reversed if changing from left-hinged to right-hinged.
• Door hinge and handle cannot be reversed on units equipped with Access Control.
• Unitmustbeonoororanelevatedworksurfacewithadequatespacetoplacedoorface-downinfrontofunit.
• To prevent personal injury and/or damage to the door, Helmer recommends two people for this procedure.
Remove Door and Hinges
1. Press and release door to open the access panel. Switch the AC power switch to OFF and switch the back-up battery
switch to OFF.
2. Disconnect AC power cord from power receptacle.
3. Remove six screws securing the front access panel to the unit and carefully place it in front of the refrigerator ensuring
there is no strain on the wiring.
4. Remove plug from access panel on handle-side of unit. Remove grommet from hole on hinged-side of unit and slide
braided sleeve out of the slot.
5. Remove two (2) screws securing door handle assembly to the door and set assembly aside.
6. Remove two (2) screws attaching the latch plate to the unit and set aside.
3
56
i.Series
4
1

Helmer Scientic i.Series® and Horizon Series™Refrigerator - Undercounter Service and Maintenance Manual
360398/A 15
7. With the door shut, remove the cover plate from both hinges.
8. Using a 1/16” Allen wrench, loosen the set screw inside the hex nut on top of the each hinge spring.
9. Using a 7/16" wrench, loosen the hex nut on each hinge spring. The hinge pin will drop from below allowing the spring to
be removed. Set the hinge pins and springs aside.
10. Carefullyliftthedoorando󰀨thehingeandplaceitface-downinfrontoftheunittakingcarenottodamagethedisplay
assembly and ensuring there is no strain on cables running from the cabinet to the door.
11. Remove the two (2) screws attaching the upper and lower hinges to the door using a #2 Phillips screwdriver and
set aside.
12. Using a #2 Phillips screwdriver, remove the 3 screws securing the upper and lower hinges to the unit and set aside.
Reroute Communication Cables
1. Access the electrical compartment by using a #2 Phillips head screwdriver to remove the top and bottom center screws
from the right-side panel, and loosening the remaining screws in each corner of the panel.
2. Slide the panel upward to disengage the four (4) screws from the keyhole openings and remove the panel.
3. Locate the control board and disconnect the display power and communication cables.
9b
9a
7
11 12
1 3a
3b
i.Series
8

Helmer Scientic i.Series® and Horizon Series™Refrigerator - Undercounter Service and Maintenance Manual
360398/A 16
4. Remove the remaining screws from the door assembly.
5. Using a punch or J-hook tool along the bottom edge, lift the inner door frame out of the outer door frame.
6. Remove the plug from the door on the handle-side and set aside.
7. Pull grommet out of hole in door on hinged-side and slide the braided sleeve out of the slot.
8. Thread the display power and communication cables through the front opening in the center panel which divides the
electrical compartment from the refrigeration compartment.
9. Reroute the display power and communication cables along the inside edge of the door and through the slot in the
corner opposite their initial location.
10. Tape cables to inside of door ensuring any excess cable is on the outside of the door.
11. Cut the zip ties securing the braided sleeve, and slide the sleeve and grommets along the cables toward the door.
12. Slip the braided sleeve through the slot in the door and insert the door-side grommet into the hole in the door.
13. Secure the braided sleeve around cables using zip ties at each end to prevent the sleeve from sliding.
567
8 9 9
i.Series

Helmer Scientic i.Series® and Horizon Series™Refrigerator - Undercounter Service and Maintenance Manual
360398/A 17
Reassemble Door / Reverse Hinges
1. Reinstalltheinnerdoorpanelandsecurewithscrewsintheholesoppositetheoriginalconguration.
2. Reinstall the door hinge plates onto the opposite side of the door frame by aligning holes in the hinge plates with the
holes in the door frame and hand-threading the two (2) long screws in each hinge (leave screws slightly loose).
3. Reinstall the corresponding hinge plates to the unit by hand-threading the three (3) short screws through the hinge and
into the cabinet.
4. Align the upper hinge cams on the door with the lower hinge cams on the refrigerator as you carefully reattach the door
to the unit.
5. Level the door and tighten all screws securing hinges to the unit.
6. Slide the braided sleeve through the slot in the front access panel allowing approximately 3” (76 mm) of slack between
the door and the cabinet so the door can open and close without straining cables. Install the grommet in the access panel.
7. Attach the door handle on the opposite side of the door with two (2) screws.
8. Attach the strike plate to the opposite side of the unit with two (2) screws. Test the locking mechanism to ensure
proper functionality.
9. With the door closed, reinstall the hinge pin and spring in the upper hinge. Secure with hex nut using a 7/16 wrench
(the hex nut should be ush with the top of the hinge pin). Repeat the process for the lower hinge.
10. Secure the set screw inside the hex nut using a 1/16” Allen wrench.
11. Replace the hinge cover plates.
12. Reconnect the display power and communication cables to the control board.
13. Reinstall the right-side access panel by engaging the four (4) screws in the unit base with the keyhole openings in the
panel. Insert the top and bottom center screws and tighten all screws using a #2 Phillips screwdriver.
14. Reinstall the front access panel and secure with six (6) screws.
15. Plug the power cord into the power receptacle. Switch the AC power switch ON. Switch the back-up battery switch ON.
16. Verify the door is level, hinges operate smoothly and door seals tightly.
17. Allow the temperature to stabilize at the setpoint before moving inventory back into the unit.
i.Series

Helmer Scientic i.Series® and Horizon Series™Refrigerator - Undercounter Service and Maintenance Manual
360398/A 18
3 Controls
i.Series models are equipped with the i.C3monitoring and control system. The i.C3system combines temperature control and
monitoring into a single user interface.
Note
Please refer to the i.C3User Guide for complete information regarding the i.C3User Interface.
3.1 Home Screen and Screensaver
The Home Screen is the default screen and is displayed when:
♦The Home icon is touched from any other screen.
♦There is no interaction for two minutes on any screen other than those used to enter a password.
Home Screen Screensaver
3.2 Home Screen Functions
Note
Refer to the i.C³ User Guide for options available on all i.C³ screens.
♦View current interior cabinet temperature readings
♦View the current system time and date
♦ Accessanyofthevehomescreenapplications(touchi.C³ APPS for additional applications)
♦View information about current alarm events
♦View whether the monitoring system is running on battery power
♦Mute audible alarms
♦ Turnthechamberlightonando󰀨(ifapplicable)
♦View a graph of the chamber temperature
♦View unit ID
♦Shortcut to Event Log
3.3 Alarm Reference
If an alarm condition is met, an alarm activates. Some alarms are visual only; others are visual and audible. Some alarms are sent
through the remote alarm interface. The table below indicates if an alarm is audible (A), visual (V), or sent through the remote
alarm interface (R).
Table 2. i.Series Alarm Reference
Alarm Alarm Type Alarm Alarm Type
High Temperature A, V, R Low Battery V
Low Temperature A, V, R No Battery A, V, R
Compressor Temperature A, V, R Probe Failure A, V, R
Door Open (Time) A, V, R Communication Failure A, V, R
Power Failure A, V, R
i.Series

Helmer Scientic i.Series® and Horizon Series™Refrigerator - Undercounter Service and Maintenance Manual
360398/A 19
3.4 Settings
>
Through the i.C³ monitoring and control system, current settings may be viewed and changed. To view settings, touch i.C³ APPS,
Settings. Use a touch-drag motion to scroll up or down to select the desired setting.
Settings screens
Notes
• IftheSettingsscreenispasswordprotected,entertheappropriatepassword.Ifviewingsettingsforthersttime,enterthe
factory default password of “1234”.
• Default values for general settings, alarm settings, and display settings are available in the i.C³ User Guide.
• Changingtemperaturesettingsa󰀨ectsoperationoftherefrigerator.Donotchangesettingsunlessinstructedin
product documentation or by Helmer Technical Service.
Thei.C³temperaturemonitorandcontrollerisprogrammedatthefactory.Tochangeasetting,rstentertheSettingsscreen,then
select the setting. The method for accessing the Settings mode for each setting varies.
Device Control Settings
Device control settings are programmed at the factory. Setpoints can be viewed and changed through the i.C³ monitoring and control
system. To view temperature setpoints, touch i.C³ APPS, Settings, Device Control Settings.
Device Control Settings screen.
Table 3. Setpoints
Setting Initial Factory Value
Temperature Setpoint 4.0 °C (iLR and iBR models); 5.0 °C (iPR models)
Upper Rail 0.7 °C
Lower Rail -0.7 °C
Delay on Start-Up 2 minutes
Speed During Probe Error 50%
i.Series
