Hena MID-8506CM User manual

USER'S MANUAL
MID-8506CM
MID-8506CM ROCKCHIPS 2926 说明书，封面封底70g书纸,135x102mm,钉装

1
Table of Contents
Table of Contents......................................P1
Features..................................................P2
Unit at a Glance .......................................P3
Getting Started....................................P4-P5
About Applications....................................P6
Connect to a Wi-Fi network...................P7-P8
Optional Connections...............................P9
Specifications...........................................P10

Features
Browse the Web.
Visit your favorite websites
Check your e-mail
Keep in touch with friends and family
Watch YouTube™ videos
Browse the world’s most popular
video-sharing community
Read your favorite books
Download thousands of books with the
included E-book reader *
Discover thousands of apps for Android™
Games, applications, and more with
marketplace(need for customer installed)
Connect to the Internet wirelessly
High-speed Wi-Fi 802.11 b/g/n networking
2
Enjoy your media library anywhere
Portable powerhouse plays popular music,
video,and photo formats
microSD memory card reader
Increase your storage capacity (up to 32 GB
supported)
Built-in camera
Convenient front-facing camera
Automatic orientation detection
Read any way you want; the display adjusts
automatically!
Reading books in the ePub format requires the
included E-book reader application.

Unit at a Glance
3
1. Power
Press to turn the unit on, or to turn the screen
on or off.
Press and hold to access the Power Off menu.
2.Headphone
Audio output connection for headphones.
3.USB OTG AND HOST
Connect to a USB device or a computer to
transfer data (e.g. music, videos,photos, files).
Connect to a USB device
4.DC IN
Connect to an adapter or a computer to supply
power.
5.RESET
Press this button to reset the system when the
device is halted.
6.TF-CARD
Load external TF-cards here.
7.
Return key
8.VOL+/VOLPress
VOL+ to increase the volume level.
Press VOL- to decrease the volume level.
DC IN 5 V TF CA RD
RES ET
VOL +
1
2
3
4
5
6
7 8

Getting Started
4
Turning the Tablet on or off
To turn the tablet on:
Press and hold the Power key until the LCD
screen turns on. Wait until the Home screen
appears; the tablet is now ready for use.
To turn the tablet off:
Press and hold the Power key until the Device
Options menu appears.
Turning the Screen On or off (Standby)
When the tablet is on, you can turn off the
screen to conserve battery power. Simply
press the Power key once to turn the screen
off. Press the Power key again to turn the
screen back on.
To conserve battery power, the screen can
be set to turn off automatically when the tablet
is not in use (between
1 minute and 30 minutes).
This Screen timeout option can be found in the
Display menu.
2. Touch ok the screen to turn off the tablet.

Getting Started
Unlocking the Screen
When the screen turns off, you will have to
unlock the screen when you turn it back on.
To unlock the screen, drag the lock icon across
the screen towards the lock icon.
5
Launcher screen:
About Applications
To open an application, touch the application
icon on the home screen or in the Launcher
where you can tap theicon right up on the home
screen to get in.
The screen shown above is for illustrative
purposes only. Reserves the right to modify and
improve the final list of applications available
on the tablet.

About Applications
6
Preinstalled Applications
Some applications have been installed on your
tablet for your convenience.
These applications include:
Browse the web.
Perform simple mathematical operations.
Take pictures or videos with the
frontfacing camera.
Check your e-mail.
Play music.
Access the Settings menu to adjust the
tablet’s options.
Installing Applications
You can also download an install additional
applications from the device’s applications
marketplace, the web browser, or other sources.
The tablet must be set to allow installation of
applications from non-Market sources. The
Unknown sources option can be set in the
Application settings menu.

Connect to a Wi-Fi network
7
The Notification bar displays icons that indicate
your tablet’s Wi-Fi status.
When Wi-Fi is on, the tablet will look for and
display a list of available Wi-Fi networks.
If a network that you have connected to
previously is found, the tablet will connect to it.
If you don’t see your network in the list,you can
force the tablet to re-scan.To scan for networks,
tap the Menu key, and then touch Scan.
Notification that an open Wi-Fi network is in
range.
Connected to a Wi-Fi network
(waves indicate connection strength).
There are no Wi-Fi networks in range,
or the Wi-Fi radio is off.
[no icon]
1. Turn on the Wi-Fi radio if it is not already on.
To turn on Wi-Fi:
a.Go to the Home screen: Press the Home key.
b.Open the Settings menu: tap the icon right up
on the home screen to get into the launcher,
then touch Settings icon.
c.Open the Wireless & networks menu: Slide the
icon to ON status.

8
2. Select an available Wi-Fi network to connect
to: In the same Wi-Fi settings menu above,
touch a network in the list.
If the network is open,the tablet will prompt you
to confirm connection to the network. Touch
Connect to confirm.
If the network is secured (as indicated by a
Lock icon),the tablet will prompt you to enter a
password or other credentials.Touch the
Wireless password box to show the on-screen
keyboard and then use it to enter the password.
Touch Connect to confirm.
To learn about how to add a Wi-Fi network
when it is not in range or when the router is set
to obscure the network name (SSID); or to
configure advanced Wi-Fi options, please
refer to the manual.
When you have successfully connected to a
Wi-Fi network, the Notifications bar at the the
low of the screen will show a Wi-Fi signal
indicator.
Connect to a Wi-Fi network

9
Optional Connections
Connecting to a Computer
Connect the tablet to a computer to transfer
files.
1.Connect your tablet to the computer.
With the included USB cable: Plug the small
end of the cable into the USB 2.0 high speed
connector of the tablet. Plug the large end of
the cable into an available USB 2.0 high speed
port on the computer.
2.When your tablet is connected,slide up
the USB icon right down on the screen and
then touch icon USB connected.
3.Mount the storage.
Touch button Turn on USB storage to mount
the tablet’s built-in storage. When it is
mounted, you can copy files to or from your
tablet.

10
Specifications
Processor RK 2926 1GHz(Cortex A9)
RAM 512MB DDR3
Storage 4~16GB flash built-in;
microSD card slot (max.32GB
supported)
(option)
Display 8.0”TFT LCD(800x600),
Capactive touch screen
Wi-Fi
Networking IEEE 802.11 b/g/n
Music was tested with a 128 kbps MP3 file;
video was tested with a 1920x1080 MPEG-4
/AVC file; browsing was tested with the screen
brightness set to default. Actual playback
results may vary.
Audio Output 3.5mm headphone
PC Interface USB 2.0 high speed
Additional
Features
Built-in microphone
Front facing camera(0.3MP)
1x0.7W speaker
Operating
System Android™ 4.1
Power Rechargeable Li-poly battery
power Adapter(DC 5V,2A)
Playback Time
(hours)
5 hours music,
2.5 hours video,
3.5 hours web browsing

FCC INFORMATION (ADDITIONAL)
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generate, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
RF Exposure
This device was evaluated for compliance with FCC RF Exposure requirements for
typical body-worn operations with a separation distance of 0cm to the body. The use of
accessories with metallic components in its assembly should be avoided. Accessories
that do not satisfy these requirements may not comply with FCC RF exposure
requirement.
