HEPER C-LIGHT Manual

8 1⁄ 2 "
5 1⁄ 2"
7 1 ⁄ 2"
Steel Rope
M10 Hexagon Bolt
33 lb ft
M10 Nut
33 lb ft
M8
Fixing Screw
7,37 lb ft
1 1⁄4"
F
4 x M4
Allen Screw
1,84 lb ft
4 x M5 Allen Screw
4 lb ft
Control Gear
18 1 ⁄ 2"
8 1 ⁄ 4"
3 x M5
Cross-slotted bolts
4 lb ft
2 x M5
Cross-slotted bolts 4 lb ft
C-LIGHT
1
2
3
4
5
6
1⁄4"
Designates 1-10 V DIM connection.
(1-10V) + Brown
(1-10V) - White
4.2
4.1
Installation and Maintenance Manual
Control Gear
HEPER USA LLC
W227 N546 Westmound
Drive Waukesha
WI 53186 – USA
Tel: [phone]
[email protected]
www.heperlighting.com

1. By turning the movable hanging apparatus of the luminaire you can
adjust the rope direction. After the apparatus is locked on the rope,
screw the M8 setscrew to fix.
2. Pass the rope by loosening the M10 key head bolt that provides the
connection of the hanging apparatus. Complete the assembly by
screwing M10 nut.
3. Shows the electrical connections of the luminaire.
6. After the Control gear is pulled out, unscrew the M5 Cross-slotted bolts
from the Driver sheet.
SELV (Safety Extra-Low Voltage)
Luminaire: IP66
Safety Standard: Class I
Impact strenght: IK08
220-240 V AC 50-60 Hz
HEPER USA LLC
W227 N546 Westmound
Drive Waukesha
WI 53186 – USA
Tel: [phone]
[email protected]
www.heperlighting.com
C-LIGHT
Installation and Maintenance Manual
ASSEMBLY INSTRUCTIONS
English
4.To be able to change the module; please detach the electrical
connections of the product. After unscrew the 4xM4 bolts that provides
module connection, disconnect the socket that links electrical
connection.Given in figure 4.1. By doing so, the module is removed from
the housing. Get the the module that will be replaced and make sure its
electrical connections are done.See figure 4.2. Screw the bolts that fix
the module to housing.
5.To be able to change the LED Driver, firstly the electrical connection
must be turned off.Then unscrew the 4xM5 bolts.Pull out the control
gear.
WARNINGS AND REMARKS FOR
INSTALLATION AND MAINTENANCE
Safety Instructions
•The light source contained in this luminaire shall only be
replaced by the manufacturer or his service agent or a
similar qualified person. Always switch off the power prior
to installation, maintenance or repair activities.
•The manufacturer is then discharged from liability when
damage is caused by improper use or installation.
•If any luminaire is subsequently modified, the persons
responsible for the modification shall be considered as
manufacturer.
•To reduce the risk of death, personal injury or property
damage from fire, electric shock, falling parts, cuts,
abrasions and other hazards, please read all warnings and
instructions included with the luminaire, on the luminaire’s
packaging and affixed to the luminaire itself..
Installatio n
•LEDs are high-quality electronic components!
Please avoid contacting the light output opening of
the LED directly during installation or relamping.
IMPORTANT
•To ensure secure connection, the luminaire housing
must be positioned precisely in relation to the
mounting plate.
Cleaning And Maintenance
•Clean luminaire regularly with solvent-free cleaners
from dirt. Please do not do not clean the luminaire
with using high-pressure liquids.
