HEPER DRAGO Forward Installation and operating instructions

1/3 2020-1 / 29/06/2020
Installation & Maintenance
Instructions
HEPER USA LLC
W227 N546 Westmound Drive Waukesha, 53186
Wisconsin, United States
[phone]
[email protected]
DRAGO Forward (LB6048.575-US)
6 lbs (0.8 ft), 7 lbs (2.6 ft)
https://heperlighting.com/us/lb6048.575-us/

2/3

3/3
English ( USA )
Safety
- This product must be installed in accordance with applicable
NEC standards by a qualified electrician familiar with the
installation of exterior lighting fixtures.
- This product must be operated under specified voltage at all
times.
- Do not install if parts are damaged.
- Power must be disconnected while installing or servicing to
avoid electrical shock.
- Failing to comply with warnings and installation steps in this document
might void warranty.
- Do not touch the light source.
- Make sure that temperature of the product is at a safe level before
touching.
- Do not allow cables to touch sharp edges of metal parts or other sharp
objects to avoid damage or abrasion.
- Check all of the cable connections including grounding before
powering the product.
- Check the proper grounding of the metal housing before powering the
product.
- Only use the product for its intended purposes.
- Do not use accessories not approved or recommended by HEPER.
Installation
- The surface on which the product will be mounted must be flat and
level
- Assemble the bollard base using the provided or appropriate
hardware.
- Place the bollard base of the product centered onto the concrete base
and secure the bolts as shown on the visual.
- To assemble the product, use IP 68 rated connector.
Cleaning - Maintenance
- This product was designed and manufactured to operate for a long
period of time. To ensure maximum lifespan of the product, regular (i.e.
every six months) visual inspection and cleaning with a solvent-free
cleaner using a soft cloth is recommended.
- Do not clean or service while the product is power connected.
Disposal
- In accordance with EU Directive WEEE (Waste Electrical and
Electronic Equipment), luminaires must not be disposed of with
other household waste. At the end of their life, luminaires must
be taken to the appropriate local facility available for the
disposal or recycling of electronic products.
USA Wire Colour Codes
- Ground - GREEN
- Line - BLACK
- Neutral - WHITE
- Dim(+) - RED/PURPLE
- Dim (-) - ORANGE
Disclaimer
- HEPER reserve the right to make technical and design changes.
